Swissvoice eSense User manual

Cordless analogue telephone (DECT)
WITH COLOUR DISPLAY
eSense
User manual
Photo may differ from the actual product.

Welcome to Swissvoice
The eSense is a cordless telephone designed for connection to an analog telephone
network. International DECT (GAP)-standard digital technology offers excellent voice
quality.
You can register up to 5 handsets to your base and make internal calls free of charge.
Please read these operating instructions carefully to familiarise yourself with and take
full advantage of the benefits of your new eSense.
eSense
eSense

Contents
Keys 2
Display symbols 3
Range / Location 3
Battery advice 3
Insert the battery 4
Connecting the phone 5
Set date and time 5
Agenda 6
Set language 6
Telephoning 6
Keypad lock 8
Redial 8
PBX operation 8
Paging – Locate mislaid handsets 8
Phonebook 9
Fast Call 10
Calls list 10
Text Messaging - SMS 12
Extending the eSense 14
Telephoning with several call partners 15
Set handset 16
Set base 17
Appendix 17
eSense
eSense 1

Handset
Base
eSense
2eSense
1 Earpiece
2 Color display
3 Right softkey / Open menu "Edit
Phonebook" / Delete / Back
4 Left softkey / Menu/OK / Mute
microphone
5 Talk key / Loudspeaker/Handsfree
6 Open redial list / Long press to insert a
dial pause / Increase volume / Scroll
up in lists and menus
7 Key R
8 Digit keys
9 Star key
In standby: Long press to activate the
keypad lock.
10 Key 0: Insert a space
11 Microphone
12 Hash key
Switches between lower and upper
case letters / Switches ringer on/off
13 Open phonebook / Decrease volume /
Scroll down in lists and menus
14 Internal key
15 End call key / Long press to switch
handset off
1 Paging key
Keys
12
1
2
3
4
15
5
8
11
10
9
6
7
14
13
1

Display symbols
Steady on: batterie’s charge level.
Flashing: batteries have to be charged.
Steady on : the caller’s list is open.
Flashing : new calls in the caller’s list.
Ringer off.
Handsfree active.
Alarm is set.
Steady on, when the handset is near the base. Flashes, if out of range or
not registered.
Keypad locked.
Range / Location
To obtain the best possible range, we recommend positioning the telephone in a
location central to your sphere of activity. Avoid positioning the telephone in niches,
recesses and behind steel doors.
The maximum range between base station and handset is approximately 300 meters
outdoors. Depending on the surrounding conditions as well as spatial and structural
factors, the range may be smaller. Silent zones can occur due to the digital transmis-
sion in the frequency range used – even within the range, depending on the structural
environment. In this case the transmission quality may be reduced through the
increased incidence of short breaks in transmission. Normal call quality can be
restored if you move slightly out of the silent zone. If the range is exceeded, the call
will be disconnected unless you move back into range within ten seconds.
Battery advice
Use only the original battery (Li-Ion 3.7 V / 550 mAh) as well as the original power sup-
ply (6.5 VDC, 300 mA or 7.5 VDC, 200 mA).
The handset operating times (standby 150 hours/active 10 hours) and charging times
apply only if the battery is charged to the defined minimum capacity.
eSense
eSense 3

eSense
4eSense
Charging is electronically controlled to ensure optimal charging and care of battery in
different charge states. Full capacity is achieved only after several charging cycles.
Insert the battery
The battery compartment is situated in the
handset.
Open the handset cover.
Insert the battery in the battery compartment.
Replace the handset cover.
Note:
Using other rechargeable battery or non-rechargeable battery/primary cells
can be dangerous and cause malfunctions or damage to the telephone. Do
not short-circuit the battery (danger). In particular, avoid inadvertent short-
circuits during storage and transport e.g. bunch of keys, metal panels or
similar objects, and make sure the battery do not come into contact with
greasy materials. When not in the handset, therefore, battery should be
stored only in insulating packaging. Ensure also that the contacts do not
touch greasy parts.
Rechargeable battery can become warm while recharging. This is a normal
occurrence and is not dangerous.

Connecting the phone
• Before you can start using your telephone you must plug in the telephone
connector cable and the mains cable.
• When the phone is delivered, the battery is not yet charged.
• To charge the battery, insert the handset in the base station. The battery will take
around 8 hours to fully charge (initial charge).
Set date and time
After setting up the telephone first, date and time are not set.
• Press left softkey , select Clock & Alarm with the navigation key
(up/down) and press left softkey .
• Select
Date&Time and press left softkey .
• Enter date and press left softkey .
• Enter the time and press left softkey .
• Set the time format (12 or 24 h) and press left softkey .
eSense
eSense 5
Telephone line socketMains power socket

Agenda
Your telephone also acts as an appointments reminder: You can set 5 different
appointment reminders. An alarm is played on the handset at the defined time.
• Press left softkey , select
Agenda with the navigation key (up/down)
and press left softkey .
• Select
Add Event and press left softkey .
• Enter a subject, set date and time and save every setting by pressing the left
softkey .
• Select
Silent (the appointment will appear on your display, but no alarm tone will
sound)
or
• select
Alarm and Once/Daily and save every setting by pressing the left softkey
.
In the menu Agenda you have the following options:
- Add Event
- Show Details
- Edit Event
- Send as a Text
- Send as a SMS text message
- Delete Event
- Del. All Events
Set language
• The language of the display texts can be changed in the menu:
Settings/Set Handset/Language
Telephoning
• Dial the desired number using the keypad.
• Press the Talk key .
End the call
Press the End call key .
eSense
6eSense

Accepting a call
• Incoming calls are signalled by a ring tone and the caller's number is displayed.
• Press the Talk key and conduct your conversation.
End the call
Press the End call key .
Switch ringer off
Press and hold the key for approx. 3 seconds seconds to switch the ringer off.
Set speaker/loudspeaker volume
You can adjust the speaker/loudspeaker volume during a conversation.
Set the desired volume using the navigation key (up/down) .
Switch handset off
• Press and hold the End call key (approx. 5 sec).
• Press and hold again the End call key to reactivate the handset.
Set alarm
• Press left softkey , select Clock & Alarm using the navigation key
(up/down) and press left softkey .
• Select
Alarm using the navigation key (up/down) and press left softkey
.
• Activate the alarm (On) and select the desired alarm function (e.g. On daily), enter
the alarm time and press left softkey .
The activated alarm is displayed in standby mode by . The alarm sounds for 60
seconds or can be deactivated immediately by pressing any key.
Calls cannot be made if the battery is almost discharged or the handset is
out of range of the base station.
eSense
eSense 7

Keypad lock
Activate keypad lock
• Press approx. 3 sec. All keys are locked.
Deactivate keypad lock
• Press the softkey under Unlock and then press key .
Redial
The Redial list contains up to 20 entries.
• Press the navigation key (up) and select the desired entry using the navigation
key (up/down).
• Press the Talk key.
Edit redial list
• Open the Redial list, select the desired entry and press left softkey .
You have the following options:
- Show Details
- Save Number
– Add number to the phonebook.
- Send Message – Send a SMS message.
- Delete Call
PBX operation
Your telephone is designed for use in the analogue telephone network and can be
operated on a PBX that supports DTMF dialling and flash signalling. To enter the R key
(e.g. needed to establish a connection) press the navigation key left.
You can adjust the flash/recall time for key R (see chapter "Set base").
Paging – Locate mislaid handsets
All registered handsets ring for one minute, when the Paging key on the base is
pressed. To stop the ring press the End call key on the handset or the Paging key on
the base.
eSense
8eSense

eSense
eSense 9
Phonebook
You can store up to 250 names and numbers in the phonebook on each handset.
Digits / Characters
Different characters are printed on each key. The entries in the phonebook are sorted
alphabetically.
Key #Change from upper case to lower case letters (ABC/abc).
Navigation key up Press and hold key to insert a pause inside a phone
number (“P” appears).
Key 0Insert a space.
Add new entries in the phonebook
• Press right softkey .
• Select
Add Entry and press left softkey .
• Enter the desired name, number and melody and press left softkey
after each input.
Edit entry
• Press the navigation key (down), select the desired entry and press left softkey
.
• Select
Edit Entry and press left softkey .
• Edit the entry and press left softkey .
When pressing the right softkey you can edit the phonebook and
you have the following options:
- Search - Search an entry in the phonebook.
- Add Entry
- Copy Phonebk
- Copy phonebook to another handset.
- Memory Status - Display the used and free phonebook memory.
- Del. Phonebook - Delete the entire phonebook.

When pressing the navigation key down, you open the menu "Names" and
you have the following options:
- Show Details
- Send Message
- Send a SMS message
- Edit Entry
- Copy Entry
- Copy entry to another handset
- Ringtone - Select the desired ringtone
- Delete Entry
- Fast Call
- see below
Fast Call
Phone numbers from the phonebook can be assigned to numerical keys 1 to 9.
Programming fast call keys
• Press navigation key down, select the desired entry and press left softkey
.
• Select
Fast Call and press left softkey .
• Select the desired fast call key and press left softkey .
• Select
Assign and press left softkey .
Calling a fast call number
To call a fast call number, press the corresponding key for approx. 3 seconds. The pro-
gramed number is called.
Calls list
The symbol appears when you have new calls. The calls list can contain up to
50 entries.
Open calls list
• Press left softkey , select Calls Lists and press left softkey
.
To use this function, the caller's number must be transmitted (CLIP). Contact
your network operator for further information.
eSense
10 eSense

• You can now access the following calls lists/options:
- Missed Calls
- Received Calls
- Dialled Calls
- Delete Calls
- Delete all calls in the desired list or delete all calls in all lists.
Call a number from the calls lists
• Open the calls list.
• Select the desired list and press left softkey .
• Select the desired entry using the navigation key (up/down).
• Press the Talk key to call the number.
or
• press left softkey and select a function from the list.
Options in a call list
You have the following options:
- Show Details
- Save Number
– Save number in the phonebook.
- Send Message – Send SMS message
- Delete Call
If the caller's number is suppressed, only Withheld is displayed. The call is
not entered in the call list.
eSense
eSense 11

Text Messaging - SMS
You can receive, save and send SMS messages with your eSense. Your telephone
supports SMS messages up to 612 characters in length. You can save up to 50 SMS
messages. When receiving a new SMS message the symbol is displayed.
Read new SMS messages / Inbox
• Press left softkey , select Text Messaging and press left softkey
.
• Select
Inbox and press left softkey .
• Select the desired SMS message. Press softkey Read.
• You can now read the message. Press softkey Options.
• Select a function from the list.
• Press left softkey and follow the instructions on the display.
Write and send SMS messages / Outbox
• Press left softkey , select Text Messaging and press left softkey
.
• Select
Write Message and press left softkey .
• Enter the text using the keypad.
Key 0Enter a space
Key #Commutation between upper and lower case (ABC/abc/Abc)
• Press softkey Options. Select
Send . Press left softkey .
• Enter the destination number with the exchange access number or select an entry
from the phonebook.
• Press softkey Send.
• When sending a message failed, the SMS is stored in the outbox.
To send and receive SMS messages, your telephone line must have active
Calling Line Identification Presentation (CLIP) and activated Connected Line
Presentation. Make sure these functions are activated on your line. Various
functions are available depending on the network operator/service provider.
For more information, contact your network operator/service provider.
If you receive a call while composing an SMS message, the SMS is auto-
matically saved as a draft. You can accept the call and continue composing
or sending the SMS message later by selecting " Write Message ".
eSense
12 eSense

eSense
eSense 13
Delete SMS messages
To always have enough storage capacity delete regularly messages you have already
read.
You can delete SMS messages from In-/Outbox, from Drafts or all messages at the
same time.
Drafts
When writing a SMS message, press Options/Save to save your text as draft for later
use.
Templates
You can store 3 templates to save time when sending text messages that have the
same content.
Text Settings (SMS settings)
• Press left softkey , select Text Messaging and press left softkey
.
• Select
Text Settings and press left softkey .
You have the following options:
-Service Centers - Before you can send and receive SMS messages, SMS
service centres for sending an receiving must be programmed.
-Mailbox No. - Assign the number of your personal mailbox.
-Message Size - Adjust SMS length (Long Message = 612 characters, Short
Message = 160 characters)
-Message Alert - A brief beep is heard every time a new SMS message is
received.
-Users - Your telephone is set to enable all users to access all SMS messages. To
enable each user to have his own private inbox you can set up 4 specific users
with PIN code protection.

Extending the eSense
The delivered handset is already registered on to base station. In standby the internal
number of the handset is displayed.
You can register up to 5 handsets to your base station.
If you register your eSense handset with a "third party" base station or a "third party"
handset on your eSense base station (GAP), you may not be able to use some
functions or only to a limited extent.
Register new handsets
Registering an additional handset with the main base station (the base station you
have connected to the telephone network):
1. Before registering an additional handset, you first need to unregister it from its
original base station:
• Press left softkey , select
Registration and press left softkey
.
• Select
De-register and press left softkey .
• The eSense may now ask for the PIN. If so, enter the PIN (default 0000) and press
left softkey .
• Press left softkey again to confirm.
Your handset is now no longer registered with any base station.
2. Preparing the main base station (base you have connected to the telephone
network) for registering additional handsets:
• On the base station you want to use as the main base station, press and hold down
the Paging key for around 10 seconds.
3. Registering an additional handset:
• Press left softkey , select
Registration and press left softkey
.
• Select
Register HS and press left softkey .
•
Base1234 is displayed on the handset. Select the main base station (default 1).
• After a few seconds you will be asked to enter the PIN.
• Enter the PIN (default 0000) and press left softkey .
• If registration is successful you will hear the dialling tone when you press the Talk
key , and after one minute the handset will go to standby mode.
Repeat this procedure for every additional handset.
eSense
14 eSense

If the registration is not successful:
• Interrupt power supply of base and handset (disconnect power adapter/remove
battery).
• Repeat the registration procedure.
Telephoning with several call partners
During a call you can make a second internal call (enquiry call), switch between call
partners (brokering) or simultaneously converse (3-way conference call) without the
need for two telephone lines.
Internal conversation / Internal call
• Press the navigation key (right) and enter the desired internal party. If only two
handsets are registered, pressing the navigation key (right) will automatically call
the other handset.
If you receive an external call while you are on the phone to an internal call partner,
you will hear an incoming call alert. End the internal call by pressing the End call key.
Press the Talk key. You are connected to the external party.
Call transfer to another handset
You are conducting an external call and you want to transfer it to another handset.
• Press the navigation key (right).
• Enter the desired internal number.
• When the internal party responds press the End call key to transfer the call to the
other party.
Brokering / Conference
You are conducting an external call.
• Call another internal party (see above).
• The internal party answers.
• Press the navigation key (right) to switch between the calls.
• Long press the navigation key (right) to start a conference call. If one of the hand-
sets presses the End call key, the other handset will be connected to the external
call.
eSense
eSense 15

Set handset
• Press left softkey , select Settings/Set handset and press left softkey
.
• Select a function from the list using the navigation key (up/down) and press left
softkey .
-Ringtone - Select the desired ringtone for internal and external calls
-Ringer Volume
-Receiver Vol.
-Handset Name
- To better distinguish between handsets, you can give each
handset a name.
-Language
-Wallpaper
-Menu Colour
-Screensaver
- Activate or deactivate the clock screensaver
-Light Timeout - Set the display backlight timeout
-Disp. Contrast
-Auto Talk
- Just pick up the handset from the base to answer a call (without
pressing any key).
-Key Beep - Every time a key is pressed, a brief beep is heard.
-PBX Access Code - You may need to enter an access code (e.g. 0) to allow the
public exchange to assign an external line for external calls or for calling back
numbers in the calls list. For further information, refer to your PBX operating
instructions.
eSense
16 eSense

Set base
• Press left softkey , select Settings/Set base and press left softkey
.
• Select a function from the list using the navigation key (up/down) and press left
softkey .
-Ringtone
-Ringer Volume
-Diallling Mode
– Tone : Normal dialling procedure on analog lines. Pulse : May
be required for connecting older telephone systems. Please refer to the relevant
documentation.
-Ring Priority – If you have more than one handset registered with you base
you can set that one of the handsets will ring first or that all handsets will ring at
the same time.
-Recall Mode – Set the recall time (flash time) for the analogue network. Select
Recall 1 (100ms) or Recall 2 (270 ms).
-First Ring – The first ring is suppressed.
-System PIN – You can modify the PIN code (0000 on delivery).
-Master Reset - Reset of the base station.
-ECO Mode – ECO : the handset’s power transmission is regulated and a radiation
reduction is achieved when it is near the base station.
ECO PLUS : Multi Handset
ECO Mode.
Appendix
Using Internet/cable telephone adapters on an analog port
When using an analog telephone on the analog connection of an Internet or cable
telephone adapter, not all the described features (in particular calling line display) may
function in the same way as with a standard analog telephone line. This does not
cause the eSense to malfunction.
Several factors can cause a failure of specific features to function:
• The Internet/cable telephony provider may not provide the function on its
Internet/cable telephony connection.
• The adapter used to convert Internet/cable telephony to analog telephony (usually
supplied by the provider) may not forward the functions to connected telephones or
may forward them in a non-analog format.
If this happens, please check the eSense on an analog fixed line and/or contact your
Internet/cable telephony provider.
eSense
eSense 17

Care
Your telephone is a sophisticated product in terms of design and construction, and
should therefore be handled with care.
To clean the telephone, wipe first with an antistatic cloth or a damp, soft leather cloth
and then dry using a dry cloth.
Recycling (environmental protection)
At the end of the product's life cycle, the telephone must not be disposed of in
normal domestic waste. Please take it to a collection point for processing
electrical and electronic equipment: see symbol on the product, in the user
manual and/or packaging.
Some materials used in this product can be recycled if you take it to a recycling depot.
By recycling parts or raw materials from used products you will be making an important
contribution to environmental protection. Please contact your local authority if you
require information about collection points in your neighbourhood.
Disposing of the rechargeable battery
By law, all used batteries and accumulators must be recycled and not disposed of in
domestic waste. Please dispose of them according to the official regulations. Take
them to a recycling depot. The batteries/accumulators will be recycled since they may,
for example, contain lithium (Li), nickel cadmium (Ni - Cd), lead (Pb), cadmium (Cd) or
mercury (Hg). The batteries and accumulators are labelled with symbols and
information on their contents,
e.g.:
eSense
18 eSense
