SWIT ProHD DT-X71H User manual

7" Portable On-camera LCD Monitor
User Manual
Model:
DT-X71F HDSDI&HDMI, Waveform, Audio me er, Focus assis
DT-X71H 3GSDI&HDMI
DT-X71C HDMI
Please read this User Manual
throughout before using.

Preface
Congratulations on your purchase of this product. Please read this user manual carefully.
． All internal technologies of this product are protected, including device, software and trademark.
Reproduction in whole or in part without written permission is prohibited.
2 ． All brands and trademarks are protected and other relative trademarks in this user manual are the
properties of their respective owners.
3 ． Due to constant effort of product development, SWIT Electronics reserves the right to make changes and
improvements to the product described in this manual without prior notice.
4 ． The warranty period of this product is 2 years, and does not cover the following:
( ) Physical damage to the surface of the products, including scratches, cracks or other damage to the
LCD screen or other externally exposed parts;
(2) Misuse, abuse or negligent operation to the product;
(3) The product is disassembled by anyone other than an authorized service center.
It is considered normal that the LCD bright dot defects are not to exceed three.
5 ． For any suggestions and requirements on this product, please contact us through phone, fax, Email, etc.
SWIT Elec ronics Co., L d. / SWIT Elec ronics USA, LLC.
Address: 4300 Stevens Creek Blvd. Suite 230
San Jose, CA 95 29
Toll free: 866 986-SWIT(7948)
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.swit.us

Main enance
 Moni or
. Please keep the signal terminals and the cooling vent away from knife-edge, metal or liquid in order to
avoid short-circuit and damage.
2. Please don't try to disassemble any parts of the monitor by yourself, which would probably damage the
monitor and do harm to human body, and it will cause the invalidation of product warranty.
3. Please don't touch the screen with your fingers, which would probably deface the screen.
4. Please don't press the screen; the LCD is extremely exquisite and flimsy.
 The power
Please use the provided power adapter or the battery recommended by the manufacturer in order to
avoid damage. For a third party power adapter, please make sure the voltage range, supplied power, and
polarity of power lead are fit.
Please disconnect the power cable or take off the battery under the following situations:
. If you do not operate this monitor for a period of time;
2. If the power cable or power adaptor is damaged;
3. If the monitor housing is broken.
 Working Environmen
. Please don't lay this product on the unstable place.
2. Please don't lay this product in hot, cold or wet location.
 Cleaning
. Please clean the screen with dry and downy cloth or special LCD cleanser.
2. Please do not press hard when cleaning the screen.
3. Please do not use water or other chemical cleanser to clean the screen. The chemical may damage
the LCD.
4. For first time use, please tear off the factory LCD film. To protect the LCD screen, please post the LCD
protection film offered in the package.

1. Fea ures
DT-X71F
◆
◆◆
◆ New high resolu ion 7” LCD Panel
6:9, 024×600, 6.77 million colors, 900:
contrast, and H 60 ° / V 60 ° viewing angle.
◆
◆◆
◆ Mul iple inpu s
2 HD/SD-SDI, HDMI and Composite input.
◆
◆◆
◆ Loop hrough ou pu s
Each of the 2 input HD/SD-SDI has loop through
output.
◆
◆◆
◆ HDMI conver ed o SDI ou pu
Supported HDMI formats: 480i / 576i / 720p (50,
59.94, 60) / 080i (50, 59.94, 60) / 080P (23.98
24, 25, 29.97, 30), and the output SDI will embed
the audio (48KHz) from HDMI.
◆
◆◆
◆ Waveform (Y, Cb, Cr, R, G, B) and full scale
There are totally 6 kinds of waveform display,
available under both SDI and HDMI, to check the
Luminance (Y), Blue-difference (Cb),
Red-difference (Cr), Red (R), Green (G), Blue (B),
and the Y, Cb, Cr can be simultaneously displayed,
R, G, B can be simultaneously displayed, and
each of the waveforms can be set to full scale
display.
◆
◆◆
◆ Vec or scope
The displayed vector scope pattern is available
under both SDI and HDMI, represents saturation
as distance from the center of the circle, and hue
as the angle, in standard position, around it.
◆
◆◆
◆ His ogram (R, G, B)
The histogram is a bar graph that shows the
distribution of luminance values in the picture.
There’re R, G, B histograms that individually
displayed simultaneously, available under both
SDI and HDMI.
◆
◆◆
◆ 16-ch audio me er
Under HDSDI, it displays 6 channels audio bars,
with mark, and under SDSDI or HDMI, it displays
2 channels audio bars with mark. The audio bar is
green, and will turn yellow when audio exceeds
-20dB, and turn red when exceeds - 0dB.
◆
◆◆
◆ SDI imecode
Under SDI input, it can display the SMPTE
timecode, which is used extensively for
synchronization, and for logging and identifying
material in recorded media.
◆
◆◆
◆ Peaking focus assis (red/blue swi ch)
The Peaking focus assist function is to mark the
sharpest edges of the image with red or blue color,
for users to check if the subjects are focused.
◆
◆◆
◆ Zebra s ripes
Zebra Stripes are used to check if the image is
over exposed or not by showing black and white
lines on the monitor. It is considered over exposed
when luminance value exceeds 90%.
◆
◆◆
◆ False color
The false color is used to aid in the setting of
camera exposure. Under false color mode, there’s
a false color key on the bottom of screen for
reference. The over exposed subjects (above 0
IRE) on the monitor will display as RED, and the
underexposed subjects will display as BLUE. For
correct exposed subjects, it will display as green
and pink.
◆
◆◆
◆ Blue Only
Under the Blue Only Mode, only the blue pixels
are used to generate the image, because hue and
saturation can be adjusted quicker and more
accurately.
◆
◆◆
◆ DSLR scale zoom in
The Canon DSLR outputs the CMOS sensor ratio
HDMI and this zoom in mode can make the
effective image scale full screen on the monitor.
◆
◆◆
◆ User definable func ion keys
There are 3 function keys on the monitor front
panel, that permit users to define shortcuts for the
various functions.
◆
◆◆
◆ User edi able video i le
User can edit a video title for the current camera,
and the title will display on the top of screen.
◆
◆◆
◆ Fron and Rear 3-color TALLY ligh
2 TALLY lights design, to give “live” signals to
people in front of the camera, as well as the
camera operator behind.
◆
◆◆
◆ Image Flip
Set image to rotate by 80 ° .

DT-X71H
◆
◆◆
◆ High resolu ion 7” LCD Panel
6:9, 024×600, 6.77 million colors, 900:
contrast, and H 60 ° / V 60 ° viewing angle.
◆
◆◆
◆ 3Gbps SDI suppor
Accepts 3G/HD/SD-SDI input.
◆
◆◆
◆ Mul iple inpu s
3G/HD/SD-SDI, HDMI, Composite input
and L/R stereo audio.
◆
◆◆
◆ Loop hrough ou pu s
3G/HD/SD-SDI, HDMI and Composite video
loop through output.
◆
◆◆
◆ SDI embedded audio ou pu
The SDI embedded audio can be output through
3.5mm earphone on the front panel.
◆
◆◆
◆ Image Flip.
Set image to rotate by 80 °
◆
◆◆
◆ DSLR scale zoom in
The Canon DSLR outputs the CMOS sensor ratio
HDMI and this zoom in mode can make the
effective image scale full screen on the monitor.
◆
◆◆
◆ User definable func ion keys
There are 2 function keys on the monitor front
panel, that permit users to define shortcuts for the
various functions.
◆
◆◆
◆ User edi able video i le
User can edit a video title for the current camera,
and the title will display on the top of screen.
◆
◆◆
◆ Fron and Rear 3-color TALLY ligh
2 TALLY lights design, to give “live” signals to
people in front of the camera, as well as the
camera operator behind.
DT-X71C
◆
◆◆
◆ New high resolu ion 7” LCD Panel
6:9, 024×600, 6.77 million colors, 900:
contrast, and H 60 ° / V 60 ° viewing angle.
◆
◆◆
◆ Mul iple inpu s
HDMI, Composite input
and L/R stereo audio input.
◆
◆◆
◆ Loop hrough ou pu s
HDMI and Composite loop through output.
◆
◆◆
◆ DSLR scale zoom in
The Canon DSLR outputs the CMOS sensor ratio
HDMI and this zoom in mode can make the
effective image scale full screen on the monitor.
◆
◆◆
◆ Image Flip
Set image to rotate by 80 ° .
◆
◆◆
◆ User definable func ion keys
There are 2 function keys on the monitor front
panel, that permit users to define shortcuts for the
various functions.
◆
◆◆
◆ User edi able video i le
User can edit a video title for the current camera,
and the title will display on the top of screen.
◆
◆◆
◆ Fron and Rear 3-color TALLY ligh
2 TALLY lights design, to give “live” signals to
people in front of the camera, as well as the
camera operator behind.

2. Panel Ins ruc ion
DT-X71F
Fron view
⑴ PHONE: Earphone jack
⑵ POWER: Power on/off
Connect with power cable or mount battery, press the “POWER” and the power indicator is turned on
and after 0 seconds, the monitor will be switched on and get into normal working status. Press the
“POWER” again, the indicator is turned off and monitor is switched off.
Disconnect with power cable or take off the battery if the monitor will not be used for a period of time.
⑶ IN: Input signal selection
Press “IN” and revolve the “OK” to select the input video signal.
⑷ F1: User definable function key
⑸ FOCUS: Peaking Focus Assist
Press “FOCUS” once, it will display the current peaking on/off status. Press “FOCUS” again to switch
on RED line focus assist, switch on BLUE line focus assist, and switch off in turn.
⑹ F.COLOR: False color
Press “F.COLOR” once, it will display the current false color on/off status. Press “F.COLOR” again to
switch on/off the false color mode.
⑺ DISPLAY: Display current settings
Press “Display” to display safety mark, title and the current input signal information
⑻ F2: User definable function key 2
⑼ F3: User definable function key 3
⑽ WAVEFORM: Display waveform
Press “WAVEFORM” once, it will display the waveform menu as:
Revolve “OK” to select a waveform display mode and turn it on.
The selected waveform will display on the screen.
⑾ VECTOR: Display vector scope
Press “VECTOR” to switched on/off the Vector scope
⑿ MENU: Press to enter Menu
⒀ OK: Select and Apply
Under menu system, revolve “OK” to adjust settings and press to apply; and out of menu system,
directly revolve “OK” to adjust volume.
⒁ TALLY Ligh : Red, Green and Yellow 3-color TALLY indicator

Rear view
⑴ DC 12V IN: Connect with DC 2V 4-pin XLR power adapter.
⑵ TALLY Ligh : Red, Green and Yellow 3-color TALLY indicator
⑶ Ba ery moun :
Connect with JVC battery BN-VF823 or SWIT battery BN-S8823 to power the monitor.
⑷ HDSDI IN1/2: HD/SD-SDI input (BNC connector)
⑸ HDSDI OUT: HDMI converted to SDI output (BNC connector)
⑹ HDSDI LOOP1/2: HD/SD-SDI loop through output (BNC connector)
⑺ VIDEO IN: Composite video input (BNC connector)
⑻ TALLY con rolling por (RJ45): terminal description is as follows:
The RED light is on when connecting the terminal “R” with “GND”, and goes out when disconnecting.
The GREEN light is on when connecting the terminal “G” with “GND”, and goes out when disconnecting.
The YELLOW light is on when connecting the terminal “Y” with “GND”, and goes out when disconnecting
⑼ HDMI: HDMI input
Inpu forma s
Terminal 1 2 3 4 5 6 7 8
Descrip ion
Y G GND
R
Input Supported formats
CVBS PAL / NTSC
480I / 576I / 480P / 576P
080i (60 / 59.94 / 50)
720p (60 / 59.94 / 50)
HDMI
080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)
080i (60 / 59.94 / 50)
SMPTE-274M 080p (30 / 29.97 / 25 / 24 / 23.98)
SMPTE-296M 720p (60 / 59.94 / 50)
SMPTE- 25M 480i (59.94)
SDI
ITU-R BT.656 576i (50)

DT-X71H
Fron view
⑴ PHONE: Earphone jack, for SDI embedded audio, HDMI audio and analog audio
⑵ POWER: Power on/off
Connect with power cable or mount battery, press the “POWER” and the power indicator is turned on and
after 0 seconds, the monitor will be switched on and get into normal working status. Press the “POWER”
again, the indicator is turned off and monitor is switched off.
Remark: Disconnect with power cable or take off the battery if the monitor will not be used for a period of
time.
⑶ CVBS: Press to switch the input signal to Composite video
⑷ HDMI: Press to switch the input signal to HDMI
⑸ SDI: Press to switch the input signal to SDI
⑹ OVERSCAN: Overscan / Underscan switch
⑺ MENU: Press to enter Menu
⑻ F1: User definable function key
⑼ F2: User definable function key 2
⑽ RATIO: 6:9 and 4:3 switch
⑾ ZOOM: Picture Zoom-in
Press “ZOOM” to switch ZOOM : Canon DSLR scale zoom-in, and ZOOM2: pixel to pixel zoom-in.
⑿ DISPLAY: Display current settings
Press “Display” to display safety mark, title and the current input signal information
⒀ OK: Select and Apply
Under menu system, revolve “OK” to adjust settings and press to apply; and out of menu system,
directly revolve “OK” to adjust volume.
⒁ TALLY Ligh : Red, Green and Yellow 3-color TALLY indicator

Rear view
⑴ DC 12V IN: Connect with DC 2V 4-pin XLR power adapter.
⑵ TALLY Ligh : Red, Green and Yellow 3-color TALLY indicator
⑶ Ba ery moun :
Connect with JVC battery BN-VF823 or SWIT battery BN-S8823 to power the monitor.
⑷ CVBS IN: Composite video input (BNC connector)
⑸ SDI-LOOP: 3G/HD/SD-SDI loop through output (BNC connector)
⑹ SDI-IN: 3G/HD/SD-SDI input (BNC connector)
⑺ HDMI-LOOP: HDMI loop through output
⑻ HDMI-IN: HDMI input
⑼ TALLY con rolling por (RS-232): terminal description is as follows:
The RED light is on when connecting the terminal “R” with “GND”, and goes out when disconnecting.
The GREEN light is on when connecting the terminal “G” with “GND”, and goes out when disconnecting.
The YELLOW light is on when connecting the terminal “Y” with “GND”, and goes out when disconnecting.
⑽ AUDIO L: Stereo audio left channel input (RCA connector)
⑾ AUDIO R: Stereo audio right channel input (RCA connector)
⑿ CVBS-LOOP: Composite video loop through output (BNC connector)
Inpu forma s
Terminal 1 2 3 4 5 6 7 8 9
Descrip ion
Y G R GND
GND
GND
Input Supported formats
CVBS PAL / NTSC
480I / 576I / 480P / 576P
080i (60 / 59.94 / 50)
720p (60 / 59.94 / 50)
HDMI
080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)
SMPTE-425M 080p (60 / 59.94 / 50)
080i (60 / 59.94 / 50)
SMPTE-274M 080p (30 / 29.97 / 25 / 24 / 23.98)
SMPTE-296M 720p (60 / 59.94 / 50)
SMPTE- 25M 480i (59.94)
SDI
ITU-R BT.656 576i (50)

DT-X71C
Fron view
⑴ PHONE: Earphone jack
⑵ POWER: Power on/off
Connect with power cable or mount battery, press the “POWER” and the power indicator is turned on
and after 0 seconds, the monitor will be switched on and get into normal working status. Press the
“POWER” again, the indicator is turned off and monitor is switched off.
Remark: Disconnect with power cable or take off the battery if the monitor will not be used for a period of
time.
⑶ VIDEO: Press to switch the input signal to Composite video
⑷ HDMI: Press to switch the input signal to HDMI
⑸ B/W: Black and White mode
⑹ OVERSCAN: Overscan / Underscan switch
⑺ MENU: Press to enter Menu
⑻ F1: User definable function key
⑼ F2: User definable function key 2
⑽ RATIO: 6:9 and 4:3 switch
⑾ ZOOM: Picture Zoom-in
Press “ZOOM” to switch ZOOM : Canon DSLR scale zoom-in, and ZOOM2: pixel to pixel zoom-in.
⑿ DISPLAY: Display current settings
Press “Display” to display safety mark, title and the current input signal information
⒀ OK: Select and Apply
Under menu system, revolve “OK” to adjust settings and press to apply; and out of menu system, directly
revolve “OK” to adjust volume.
⒁ TALLY Ligh : Red, Green and Yellow 3-color TALLY indicator

Rear view
⑴ DC 12V IN: Connect with DC 2V 4-pin XLR power adapter.
⑵ TALLY Ligh : Red, Green and Yellow 3-color TALLY indicator
⑶ Ba ery moun :
Connect with JVC battery BN-VF823 or SWIT battery BN-S8823 to power the monitor.
⑷ CVBS IN: Composite video input (BNC connector)
⑸ HDMI-LOOP: HDMI loop through output
⑹ HDMI: HDMI input
⑺ TALLY con rolling por (RS-232): terminal description is as follows:
The RED light is on when connecting the terminal “R” with “GND”, and goes out when disconnecting.
The GREEN light is on when connecting the terminal “G” with “GND”, and goes out when disconnecting.
The YELLOW light is on when connecting the terminal “Y” with “GND”, and goes out when disconnecting
⑻ AUDIO L: Stereo audio L input (RCA connector)
⑼ AUDIO R: Stereo audio R input (RCA connector)
⑽ CVBS-LOOP: Composite video loop through output (BNC connector)
Inpu forma s
Terminal 1 2 3 4 5 6 7 8 9
Descrip ion
Y G R GND
GND
GND
Input Supported formats
CVBS PAL / NTSC
480I / 576I / 480P / 576P
080i (60 / 59.94 / 50)
720p (60 / 59.94 / 50)
HDMI
080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)

3. Menu Opera ion
Press “MENU” and it will display menu system
 Revolve “OK” to select an item. The selected item will be highlighted display.
 Press “OK” to enter the selected item.
 Under menu system, press “MENU” to back to previous menu.
 The menu will automatically save and quit if it remains idle.
4. Pic ure Se ings Submenu
The Picture Settings Submenu includes:
⑴ CONTRAST: 0- 00 value adjustment
⑵ BRIGHTNESS: 0- 00 value adjustment
⑶ HUE: 0- 00 value adjustment
(Only available under Composite input)
⑷ SATURATION: 0- 00 value adjustment
⑸ SHARPNESS: 0- 00 value adjustment
⑹ PIC.MODE: User defined and preset picture
modes: standard, soft and vivid selection
5. Sys em Configura ion Submenu
The System Configuration Submenu includes:
⑴ RATIO: Select “ 6:9” or “4:3” to adjust the aspect ratio.
⑵ SCAN: “UNDERSCAN” / “OVERSCAN” selection
⑶ ZOOM: “OFF”, “ZOOM ” and “ZOOM2” selection
ZOOM : Canon DSLR scale zoom-in
ZOOM2: Pixel to Pixel zoom-in
⑷ MARKER: Select and set the safety mark
scale from 80%, 85%, 90% and 95%.
⑸ FLIP: Select “YES” to flip the image by 80 ° .
⑹ RESET: Revolve “OK” to RESET and press to
recover all to factory setting.

6. OSD Se ings Submenu
The OSD Settings Submenu includes:
⑴ LANGUAGE: Menu language English / Chinese selection
⑵ H-POSITION: Menu horizontal position (0- 00) adjustment, real-time preview, default value: 50, center.
⑶ V-POSITION: Menu vertical position (0- 00) adjustment, real-time preview, default value: 50, center.
⑷ DURATION: Menu timeout setting
Set a time (in seconds) in which the menu
will automatically quit if remains idle.
Default: 0 seconds; Range: 5 seconds to
60 seconds.
7. Ti le Se ings Submenu
Revolve "OK" button to select the letters, and press "OK" to input. Select SPACE to input space and DEL to
delete the left letter. Max 0 letters are supported.
After setting, press "MENU", the system will
save data to current user and quit menu. The
menu will automatically save and quit if it
remains idle.
8. Display Se ings Submenu
The DISPLAY settings submenu is to select the
items to be displayed on screen when
‘DISPLAY” button is pressed. Revolve "OK" to
turn on/off the items:
( ) INFO: Including Input format, aspect ratio,
underscan/overscan, zoom status
(2) MARKER: Safety mark
(3) TITLE: User edited title

9. FUNCTION KEY Se ings Submenu
The F KEY Settings Submenu is to define
Function Keys on the front keyboard.
The DT-X7 F has 3 function keys:
F , F2 and F3;
The DT-X7 H and DT-X7 C has 2 function
keys:
F and F2.
The available function items of each model are:
-------------------DT-X71F------------------- -------------------DT-X71H-------------------
01-RATIO: Aspect ratio switch 01-RATIO: Aspect ratio switch
02-SCAN: Underscan / Overscan switch 02-SCAN: Underscan / Overscan switch
03-ZOOM: Picture Zoom-in 03-ZOOM: Picture Zoom-in
04-PIC. MODE: Preset picture mode switch 04-B/W: Color / Black & white switch
05-B/W: Color / Black & white switch 05-FLIP: Image flip
06-BLUE ONLY: Blue only mode switch on/off
07-ZEBRA: Zebra over exposure switch on/off
08-VECTOR: Vector scope switch on/off
09-PATTERN: Internal colorbar switch on/off
-------------------DT-X71C-------------------
10-RGB HIST: R, G, B Histogram switch on/off 01-RATIO: Aspect ratio switch
11-TIMECODE: SDI timecode display switch on/off 02-SCAN: Underscan / Overscan switch
12-F.COLOR: False color mode switch on/off 03-ZOOM: Picture Zoom-in
13-AUDIO BAR: Audio meter display switch on/off 04-B/W: Color / Black & white switch
14-FOCUS: Peaking focus assist switch on/off, and 05-FLIP: Image flip
red/blue selection
15-FLIP: Image flip

10. Specifica ions
LCD Performance
Size 7.0 inches
Resolution 024
× RGB × 600
Aspect ratio 6:9/4:3
Color system NTSC/PAL
Brightness 400cd/m
2
Contrast 900:
Color 6.77 million colors
Viewing angle H/V: 60/ 60
Video Forma
SMPTE-425M ** 080p (60 / 59.94 / 50)
080i (60 / 59.94 / 50)
SMPTE-274M 080p (30 / 29.97 / 25 / 24 / 23.98)
SMPTE-296M 720p (60 / 59.94 / 50)
SMPTE- 25M 480i (59.94)
SDI *
ITU-R BT.656 576i (50)
480I / 576I / 480P / 576P
080i (60 / 59.94 / 50)
720p (60 / 59.94 / 50)
HDMI
080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)
General
Working voltage DC 2V, or Battery 6.5V- 7V
DT-X7 F
≤ 5W
DT-X7 H
≤ 8W
Power consumption
DT-X7 C
≤ 7W
Working temperature 0
℃～ +40 ℃
Working humidity 0%
～ 90%
Storage temperature - 5
℃～ +60 ℃
Storage humidity 0%
～ 90%
Dimensions
92 × 39 × 47mm
Net weight 550g
* DT-X7 C doesn’t support SDI input;
** Only DT-X7 H support SMPTE-425M format.
11. Packing Lis
. Monitor
×
2. User Manual
×
3. Power adaptor
×
4. Power cable
×
5. Sun hood
×
6. Screw ball head
×
7. LCD protection film
×

This model is manufactured, warranted and supported by SWIT Elec ronics Co., L d. / SWIT Elec ronics USA, LLC,
and distributed in North America by JVC Professional Video Produc s.
To obtain service or for further information, please contact:
SWIT Elec ronics USA, LLC.
Address: 4300 Stevens Creek Blvd., Suite 230, San Jose, CA 95 29
Toll free: 866 986-SWIT (7948) • Tel: [phone]
· Fax: [phone]
Email: [email protected] • Website: www.swit.us
Version: 20807
