switel M550 User manual

Mobile Phone
Operating Instructions
M550

2
2
Operating Instructions 3. . . . . . . . . . . .
Declaration of Conformity 95. . . . . . . . .
HAC Hearing Aid Compatible
to M3 / T3 Rating
The M550 Phone has a built in Induction Coil and is
hearing aid compatible.
To ensure optimum benefit, users with hearing aids
may wish to select the T setting on their hearing aids.

1
Contents
3
1 Quick Start Guide 4. . . . . . . . . . . . . .
2 At a Glance 16. . . . . . . . . . . . . . . . . .
3 How does it work 20. . . . . . . . . . . . . . .
4 Getting Started 24. . . . . . . . . . . . . . . .
5 Phone Book Set Up 29. . . . . . . . . . . . .
6 Making and Receiving Calls 35. . . . . . .
7 Calls List 39. . . . . . . . . . . . . . . . . . . .
8 SMS − Text Messages 40. . . . . . . . . . .
9 Voice Mail 45. . . . . . . . . . . . . . . . . . .
10 Other Useful Features 47. . . . . . . . . . .
11 SIM Tool Kit 67. . . . . . . . . . . . . . . . . .
12 Menu Structure 68. . . . . . . . . . . . . . . .
13 Trouble Shooting 77. . . . . . . . . . . . . . .
14 Technical Properties 80. . . . . . . . . . . .
15 Safety Information 84. . . . . . . . . . . . . .
16 Maintenance / Guarantee 89. . . . . . . . .
17 Index 91. . . . . . . . . . . . . . . . . . . . . . .

Quick Start Guide
4
1 Quick Start Guide
Important: Before you start, please read the
safety information on page 84.
Quick Glance
1 LED
2 Earpiece
3 Display
4 Navigation keys (scroll up/down)
5 Softkey, left
6 Call key
7 One−touch dialling keys
8 Star key / Ringer On/Off − Silent Mode
9 Softkey, right
10 On/Off key / End call key
11 Keypad
12 Hash key
13 Microphone
14 Charge contacts
15 Mini USB socket
16 Headset socket (Headset not supplied)

Quick Start Guide
5
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
13
14

2
Quick Start Guide
6
What is in the box
The package contains:
1 mobile phone 1 desktop charging unit
1 li−ion battery 1 operating manual
1 AC adaptor
Installing the SIM card
Risk of swallowing small objects!
The SIM card can be removed.
Small children can swallow them.
Switch the phone off.
Pay attention that the SIM card is not bent or
scratched. Prevent any contact with water, dirt
or electrical charges.
Slide the mobile phone’s
battery compartment cover
towards the bottom using a
little force. Lift the battery
compartment cover off the
phone completely.
If there is already a battery
inside, remove it.

Quick Start Guide
7
Your telephone number is carried by the SIM
card, not the phone. Therefore if you use a
SIM card you had in a previous phone, you will
keep the same phone number.
Slide the SIM card with the
golden contacts facing
down in the SIM card
holder provided for it at the
top right. The SIM card
must be located under the
metal retaining bar to be in
the correct position.
Insert the battery. The
golden contacts on the bat-
tery must face towards the
top left. Press lightly on the
bottom end of the battery
until it snaps into place.

3
Quick Start Guide
8
Replace the battery com-
partment cover back on
the phone. Slide the bat-
tery compartment cover
upwards until it snaps in to
place.
Charging the battery
Before starting to charge the battery, check
that it has been installed properly.
Do not remove the battery while it is being
charged. This could damage the phone.
When charging the battery for the first time, it
should be charged for at least 4 hours. Some
batteries only reach their full capacity after se-
veral complete charge/discharge cycles.
Charging via the mini USB socket
Plug the power adapter in the
mini USB port.

4
5
Quick Start Guide
9
Connect the power adapter
plug as illustrated in the dia-
gram. For safety reasons,
only use the power adapter
plug supplied.
Charging via the desktop charging unit
Plug the power adapter in the
mini USB socket on the charg-
ing unit. Insert the phone in
the charging unit to charge it.
The display will go blank but even so the bat-
tery is still being charged. This is correct ope-
ration.
It may take a few seconds before the phone in-
dicates the charging process.
You can use the phone during the charging
process.
Battery status warning
The current battery charge status is indicated in the
display as follows:
Full Half empty Low Empty
Mains power
outlet

Quick Start Guide
10
When the battery charge is low, a corresponding
warning message appears in the display.
Charge the battery.
In cases where the battery charge is extremely low, it
is possible that the back−lighting no longer works and
certain functions are no longer available.
When the battery charge drops below the minimum
status, the phone switches off automatically.
Switching the mobile phone on and off
3 sec. Switch the mobile phone on
3 sec. Switch the mobile phone off
Some SIM cards will require you to enter a PIN
code. Follow the prompts on the screen or
read more details about PIN & PIN2 on
Page 58.
Make sure you are in range of your Network
Some networks offer better coverage than others in
different areas. The icon indicates you have a
signal and are connected to the network. The net-
work will also appear in the display.
