SYMA S52H User manual

User manual V1.0
Remote Control Helicopter
S52H
8

DE
Contents
1-17
EN ENGLISHINTRODUCTION
18-35
DEUTSCH EINFÜHRUNG

Contents
1.0 Important Notices and Safety Guidelines
2.0 Product Description
2.1 Specifications
2.2 Helicopter Diagram
3.0 Product Assembly
3.1 Propeller Installation
3.2 Helicopter Battery Charging
3.3 Remote Control Use
4.0 Flight Guide
4.1 Flight Operation
4.2 Flight Control
5.0 Troubleshooting
7.0 Product Accessories
2
4
7
10
11
4
4
5
2.3 Remote Control Diagram
5
6
7
7
8
6.0 Contact Us 11
9.0 Warranty 15
8.0 Exploded View 12
5
1
EN

1. In order to protect the legitimate rights and interests of users, please be sure to read the contents of
this manual carefully before using this product.
2. When using this product, please be sure to strictly observe and perform the requirements which
include but are not limited to the instructions and safety guidelines. For any personal injury, accident,
property loss, legal dispute, or any other adverse event causing a conflict of interest resulting from the
use of the product or any irresistible factors that are in violation of the safety instructions, the user
shall bear the related responsibilities and losses. Syma will not take any responsibility.
3. Once you start using the product. you are deemed to have read, understood, recommended, and
accepted the terms and contents of the instructions (including disclaimers, safety instructions,
warning instructions, etc) included with this product.
4. In case you are having challenges on any aspect of the product, may it be operation or
maintenance, please contact our customer service directly.
1.0 Important Notices
Safety Guidelines
Thank you for purchasing this SYMA product. To ensure that you operate the helicopter correctly and
conveniently, please read these instructions carefully before first use and store them in a safe place for
future reference.
1. Please store the smaller-sized helicopter accessories in places that are out of reach of children.
2. For all first-time flights, the left joystick must be slowly pushed up in order to prevent the helicopter
from ascending too fast to avoid unnecessary collision and possible damage and injury.
3. When the flight is ended, first turn off the power of the remote control. Then turn off the power of the
helicopter.
4. Avoid placing the batteries in places with high temperatures and exposure to heat.
5. Take extra precautions to ensure that the helicopter is at a minimum distance of 15 feet from the
pilot, other people, and animals in order to prevent bodily injury during flight operations. A minimum
separation distance of 20 cm must be maintained between the user's body and the device under
normal use conditions.
6. Children under the age of 8 must be instructed in the correct and safe operation of the helicopter by
an adult.
7. Children must be under adult supervision when using this helicopter.
8. Non-rechargeable batteries are not to be recharged; Batteries are to be inserted with the correct
polarity; Different types of batteries or new and used batteries must not be mixed.
9. The supply terminals can not be short-circuited.
10. Discharge the battery to 40%-50% (On a full charge, fly for half of the total flight time) if it will not be
used for 10 days or more, this can greatly extend the battery life.
2
EN

Repair and maintenance
1. Use a dry and soft cloth to clean the toy.
2. Do not expose the toy to extreme heat, moisture or direct sunlight.
3. Do not immerse the toy in water as this may damage the electrical components.
4. Remove the batteries of the remote control when not using the toy for an extended time.
11. Please keep a safe distance from the spinning propellers to avoid injury.
12. To ensure the electromagnetic environment requirement of the aviation radio (station), using
remote controls in the zone, which is in a radius of about 5000m zones from the circle center of the
airport runway, is forbidden. All users also should abide by the regulation of the radio set forth by
government and regulatory agencies including the duration and area.
13. Only uses the recommended transformer for the model, and the transformer is not a toy. Check the
cord, plug, enclosure, and other parts of the transformer regularly. If any damages have been
discovered, please immediately stop using it, until it was completely repaired.
14. Never look steadily at the laser beam since the laser radiation.
15. NOTE: Assemble the helicopter under adult supervision.
16. The pilot is responsible for the safe operation and safe distance from uninvolved persons and
property on the ground and from other airspace users and shall never fly the Helicopter above crowds
(> 12 persons).
17. Use a screwdriver to open the battery cover of the toy.
18. The packing has to be kept since it contains important information.
19. It is strongly recommended to fly in areas without airflow. Do not fly in areas with an air
conditioner/electric fan or table lamp, or other electrical equipment which may be easily damaged.
20. Use only the supplied charging cable.
21. Chargers used with the helicopter should be examined regularly, such as the cord, plug,
enclosures, and other parts. In case of any damages are found, please stop using it unless it is repaired
or replaced.
22. Do not touch the rotating rotor, avoid loose clothing or hair that could be caught in the rotor, and
do not fly near the face.
3
EN

2.0 Product Description
2.1 Specifications
Helicopter weight about 47g
Helicopter size 265x37x100 mm
Battery (built-in) 3.7V 150mAh
Charging time about 30 minutes
Flight time about 8 minutes
Remote control
Operating frequency 2.4 GHz
Range 30m
Battery 1.5V*AAA*4(Not included)
Package contents
Helicopter 1
Remote control 1
USB charging cable 1
Connect buckle
Screwdriver
Clockwise/anticlockwise propellers
Instructions
2
2
1
1
Helicopter
Brand Name
Model S52H
SYMA
4
EN
2.2 Helicopter Diagram
① Balance Bar
② Propeller Blade
③ Main Shaft
④ Landing Skids
①
②
②
③
③
④
①

5
EN
2.3 Remote Control Diagram
POWER
Left Joystick
(Ascend and
descend)
Right Joystick
(Forward/Backward/
Turn Left/Turn Right)
One-key take off/
landing
Right Trim
Left Trim
1. Before replacing and installing the
propeller, please remove the screws.
2. Install the labeled "A" propeller and
labeled "B" propeller in the corresponding
positions, and use a screwdriver to tighten
back the screws.
3.1 Propeller Installation
3.0 Product Assembly

CHA
6
EN
3.2 Helicopter Battery Charging
1. Switch the helicopter to "OFF".(NOTE: Before recharging the battery, wait for 10-15 mins
to let the battery cool down)
2. Connect the charging cable with the arrow icon to the helicopter correctly according to
the instructions in the picture and reverse connection is not allowed.
3. Insert the other end of the charging cable into the port of the computer and the indicator
light is off at this time.
4. The red indicator is on when fully charged.
1. Please make sure that the forward and reverse propeller blades are installed in the correct position.
If the installation is incorrect, the helicopter will not be able to fly normally.
2. Since the propeller blades are thin, please be careful when installing them to prevent accidental
scratches.
3. Please use the propeller blades provided by our manufacturer.
4. The blades are consumables, if necessary, please purchase additional accessories.
Important: battery charging information
1. Rechargeable batteries should only be charged under the supervision of adults.
2. Caution: Risk of explosion if battery is replaced with incorrect ones. Please dispose the batteries
according to the instructions.
3. Don't use or leave the battery near a heat source such as fire or heater.
4. After flying, don't charge batteries at once to avoid batteries too heat to cause to the fire, make sure
it cool down before charging.
5. Don't hit or let batteries fall down when charging to avoid inner short-circuit.
6. Only use the supplied adapter for charging. If the battery is aging, please replace it with a new
battery in time.
7. After fully charged, please remove the adapter in time, otherwise the battery will be discharged and
charged again, which will shorten the battery life.
8. The toy is only to be connected to Class II equipment bearing the symbol:
Note:
!

3.3 Remote Control Use
Remote control battery installation: Open the battery cover of the remote control, and install 4*AAA
batteries correctly according to the electrode instructions of the battery box (battery needs to be
purchased separately)
Maxmium radio-frequency power transmitted 4dbm. Frequency range:2405-2478 MHz
1. During the battery installation, it must be ensured that the polarities of the batteries are matched
with that of the battery box. No battery shall be installed with the opposite polarity.
2. Please do not use new and old batteries together.
3. Please do not use different types of batteries together.
4. Do not use rechargeable batteries.
4 x AAA Batteries Battery Cover
Note:
!
7
EN
4.0 Flight Guide
4.1 Flight Operation
1. Turn on the power switch of the
helicopter, the indicator light flashes 2. Turn on the power switch of
the remote control, the indicator
on the remote control flashes

Ascend
Descend
8
EN
3. Before the helicopter takes off, be sure to
place the helicopter on a level surface to
ensure that the helicopter flies stably after
take-off.
5. Method 1: Push the left joystick up, the
helicopter takes off slowly
4. At this time, push the remote control
throttle up then down, and reset it to the
center. When both indicator light of the
remote control and helicopter changes
from flashing to solid. It means the
helicopter enters into a ready-to-fly state.
Level surface
TailHead
Method 2: Press the one key take-off button,
and the helicopter takes off automatically
1
2
4.2 Flight Control

Forward Backward
Turn left Turn Right
If the helicopter drifts to the left or right when it is hovering in the air, press the left or right trimming
button to correct it.
9
EN
Tail
Head

10
EN
5.0 Troubleshooting
Helicopter does
not respond
1. Low battery of the helicopter
2. Low battery of the remote control
3. Failed helicopter gyroscope
detection
Unable to pair
the helicopter
Check the power of the helicopter
and remote control
Possible CauseProblem Solution
1. Charge the helicopter battery
2. Replace the remote control battery
3. Place the helicopter flat on the ground,
and then start the remote control after
the gyroscope is successfully detected
Helicopter flight is
not responsive
Too much interference from the
surrounding environment
Operate the helicopter indoors in a
windless environment
Motor does not
work
Check the motor for foreign objects
(eg: hair, sand)
With regular cleaning
Blade falling 1. Loose screws
2. Collision during transport process
Replace the blades
1. Charge the helicopter, or replace the
battery of the remote control.
2. Place the helicopter flat on the
ground, start the remote control after
the gyroscope is successfully detected,
and push the left joystick up and then
down. The indicator lights of the
helicopter and the remote control will
change from flashing to stay on,
indicating that the frequency pairing is
successful.
Unable to hover,
the declination
flying of the
helicopter
1. Too much interference from the
surrounding environment
2. The blades are too loose or too tight
3. The connect buckle is not in place or
is too tight
4. The connect buckle is missing or
multiple connect buckles result in
flight instability
1. Operate the helicopter indoors in a
windless environment
2. Adjust the tightness of the blade to
ensure the blade is stable without
shaking
3. Replace the connect buckle
4. Check for missing or more than one
connect buckle. Also check whether the
balance bar is deformed and worn, if so,
replace the balance bar
Remote controller
does not work
The remote control is low on power Replace the remote control battery and
install it with correct polarity.

6.0 Contact Us
Please do not hesitate to contact us if you need any further support.
[email protected]
[phone](US)
[phone](UK)
[phone](DE)
11
EN
7.0 Product Accessories
For online support, please scan this
code with Facebook Messenger
Main blade
USB Charging
Cable
Balance bar
BatteryMotor A Motor B
Remote control Connect buckle

8.0 Exploded View
12
EN

13
EN
Battery Warning
Please follow all instructions in the manual to avoid irreparable damage. Avoid causing the battery to
catch fire, smoke, or explode.
1. Before charging or using, please pay attention to the condition of the battery. If the charge drops,
please replace the battery to avoid odor, overheating, discoloration, deformation, or leakage.
2. Please use the appropriate lithium Charging line, we recommend that you only use the Charging
line provided.
3. Please do not charge the battery in place near the fuel, or in a vehicle. (It is best to place the battery
in a non-conductive or non-flammable container.)
4. Do not store Li-Po batteries near moisture or direct sunlight, or in the location of high temperatures
(e.g. excessive heat such as in cars parked in the sun.)
5. When charging, put the battery in a place where you can see it.
6. Do not disassemble, modify the wiring or puncture the battery.
7. Please make sure that the output voltage of the device matches the input voltage.
8. Do not overcharge the battery.
9. Do not charge the battery immediately after each use. Cool down the battery by placing it in a dry
place.
10. Batteries must not be short-circuited. keep the batteries away from children.
11. Improper use may result in battery explosion, fire, or other hazards.

Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
FCC Notice.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference,and
2. This device must accept any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.
"This device complies with FCC radiation exposure limits set forth for general population
(uncontrolled exposure). This device must not be collocated or operating in conjunction with
any other antenna or transmitter."
RF frequency band: 2405-2478MHz
Transmitter power: 4dbm
Product Name: RC Helicopter
Decoration of Conformity Inserts: Hereby, GuangDong SYMA Model Aircraft Industrial Co., Ltd.
declares that the radio equipment type helicopter is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
http://www.symatoys.com/down/declaration-of-conformity.html
14
EN

WARRANTY:
LIMITED 2-YEAR WARRANTY AND FREE LIMITED REPLACEMENT PARTS FOR 2-YEARS
Symatoys.com.cn warrants to the original buyer only that its products will be free from
defects in material and workmanship for 2 years from the date upon which the product is
shipped, either directly from symatoys.com.cn or from an Authorized Re-seller’s location, to
the buyer.
The following condition's must to be eligible for warranty coverage:
1. During the warranty period product is used as intended by the manufacturer.
2. The Product has not been disassembled or modified.
3. The labels and serial numbers show no signs of tampering or altering.
4. Buyer has a warranty code obtained by registering their product online prior to making a
claim.
EXCEPTIONS: THE LIMITED WARRANTY SHALL NOT APPLY TO:
• Damage caused by normal wear and tear
• Accident, negligence, abuse, misuse, misapplication or willful damage by buyer (or its
agents), or acts of nature
• Crash or burning caused by non-manufacturing factors
• Damage caused by authorized modification or disassembly not authorized by the instruction
manual
• Damage. caused by incorrect use or operation
• Damage caused by mismatch or misuse of battery or charger
• Failure of the operator to follow the operating instruction or use outside the products
operating parameters
• Damage caused by operating the product in or around electromagnetic interference (i.e.,
radio transmitting tower, high-voltage wire, substation, etc.)
• Damage caused by operating the product where there may be interference caused by other
wireless devices
• Operating the product with load capacity in excess of the sale weight listed in the manual
• Operating the product with aged, damaged or unauthenticated third-party components
• Operating the product with a defective battery
WARRANTY
PROCEDURE: Any claims for breach of the foregoing limited warranty shall only be valid if
buyer makes such claim in writing within 2 year of the date of shipment of the product to
which the claim. To make a warranty claim, please email at: [email protected] with
your full name. address. phone number, order number. vehicle type. part type and purchase
date and product issue.
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
2 YEAR
15
EN

LIMITED REMEDY:
Symatoys.com.cn's sole liability, and buyer's sole remedy for any breach of the foregoing
warranty shall be at Symatoys.com.cn's option to exchange the product with a new product or
a refurbished product that is functionally equivalent to the original product, or issue a credit
or refund to the purchase price the product.
Any replaced products shall be warranted as set forth herein, provided that the period within
which buyer may make further claims shall be limited to the remainder of the original period.
for the applicable product or 2 years, whichever is longer (although the warranty period shall
be suspended during any period of replacement)
DISCLAIMER:
Haftungsausschluss:
THE WARRANTY AND REMEDIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES.
AND Symatyos.com.cn DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, NON-INFRINGEMENT AND ANY WARRANTIES ARISING OUT OF COURSE
OF DEALING, COURSE OF PERFORMANCE AND TRADE USAGE.
Symatoys.com.cn IS NOT RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUEN-
TIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR CONDITION, OR UNDER ANY
OTHER LEGAL THEORY. INCLUDING BUT NOT UMITED TO COSS OF USE; LOSS OF REVENUE;
LOSS OF ACTUAL ANTICIPATED PROFITS (INCLUDING LOSS OF PROFITS ON CONTRACTS);
LOSS OF THE USE OF MONEY, LOSS OF ANTICIPATED SAVINGS; LOSS OF BUSINESS COSS OF
OPPORTUNITY; LOSS OF GOODWILL, LOSS OF EPUTATION; LOSS OF DAMAGE TO COMPRO-
MISE OR CORRUPTION OF DATA; OR ANY INDIRECT OR CONSEQUENTIAL LOSS OR DAMAGE
HOWSOEVER CAUSED INCLUDING THE REPLACEMENT OF EQUIPMENT AND PROPERTY.
ANY COSTS OF RECOVERING OR REPRODUCING ANY DATA STORED IN OR USED WITH THE
PRODUCT OR ANY FAILURE TO MAINTAIN THE CONFIDENTIALITY OF INFORMATION STORED
THE PRODUCT.
Some states do not allow the exclusion or limitation of incidental or consequential damages.
so the above limitation or exclusion may not apply to you. In addition, some states do not
allow limitations on how long an implied warranty lasts. so the above limitation may not
apply to you.
FREE REPLACEMENT PARTS FOR 2 YEARS: Symatoys.com.cn shall also make available any
spare part needed for registered vehicles free of charge for 2 years from the date of purchase,
with the exception of batteries, motors, and transmitters. Shipping charges may apply Limit
one part type request per registered vehicle (e.g., registrants are entitled to one extra set of
batteries per registered vehicle}. To request spare parts. please email at:
[email protected] with your warranty code, vehicle name/model, current shipping
address, purchase date, and part type.
GET YOUR WARRANTY CODE AT symatoys.com.cn/pages/warranty-signup
HAVE YOUR ORDER NUMBER AND PRODUCT MODEL READY
16
EN

European Representative：
CET PRODUCT SERVICE LTD.
Osterholzallee 144
71636 Ludwigsburg Germany
Phone：[phone]
E-mail：[email protected]
British Representative：
CET PRODUCT SERVICE LTD.
Beacon House Stokenchurch Business Park,
Ibstone Rd, Stokenchurch
High Wycombe HP14 3FE UK
Tel： [phone]
E-mail：[email protected]
United States Representative：
Duvin Trade Inc
5800 Wood Sorrel Dr，Littleton，Co, 80123，United States
Phone: [phone]
E-mail: [email protected]
Manufacturer: GUANGDONG SYMA MODEL AIRCRAFT INDUSTRIAL CO.,LTD
Address: NO.2 WEST XINGYE ROAD LAIMEI INDUSTRIAL AREA CHENG HAI , Shantou, China
Postal Code: 515800
The company has the right of final interpretation of this user manual.
[phone] [phone](UK) [phone](DE)
[email protected](US) [email protected](EU)
https://www.symatoys.com.cn
17
EN
Made in china
