Symmons ADACHS Manual

-1.5 1.5 gpm (5.7 L/min) flow restrictor
-1.75 1.75 gpm (6.6 L/min) flow restrictor
-2.0 2.0 gpm (7.6 L/min) flow restrictor
-BBZ Brushed Bronze finish
-MB Matte Black finish
-STN Satin Nickel finish
-WHT White finish
Model Numbers
ADA Hand Shower Wand
Operation & Maintenance Manual
ADACHS
ADA hand shower wand features single mode spray, easy
to operate non-positive shut-off button, easy to clean
rubber nozzles and 2.5 gpm (9.5 L/min) ow restrictor.
Components made from metal and nonmetallic materials
plated in standard polished chrome nish.
Specification
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Compliance
Certied by
CSA Group
Dimensions
Note: Dimensions subject to change without notice.
Modifications
Note: Append appropriate -sufx to model number.
CG
ADACHS
ADA Hand Shower Wand
-ASME A112.18.1/CSA B125.1
-WaterSense 1.5 gpm (5.7 L/min)
2.0 gpm (7.6 L/min)
Measurements
A Ø 3-3/8", 85 mm
B 7-7/8", 201 mm
C G 1/2", 13 mm
BB
AA
CC
CG

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3179 REV C ■ 042518
1
2
1) Attach hose to hand shower
wand. Turn clockwise to tighten.
Installation
Operation
1) Push button on left side of hand
shower wand for full volume.
Tools Required
Plumber
tape
2) Push button on right side of hand
shower wand to reduce volume
to a trickle.
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
Troubleshooting Chart
