Symmons Allura 4700-TRM Installation instructions

Allura®
Model Numbers
Allura Trim Series
Allura Trim Series with TA-10 Flow Control Spindle & T-12A Cap Assembly
Installation & Operation Instructions
TRIM ONLY
4700-TRM
Shower Valve Trim
4701-TRM
Shower Trim
4702-TRM
Tub/Shower Trim
4703-TRM
Hand Shower Trim
4705-TRM
Shower/Hand Shower Trim
4706-TRM
Tub/Shower/Hand Shower Trim
Compliance
• ASME A112.18.1/CSA B125.1
Limited Lifetime - to the original end purchaser in consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete warranty information.
Go to www.symmons.com/register to register your Symmons product.
TRIM, TA-10, T-12A
4700TRMTC
Shower Valve Trim
4701TRMTC
Shower Trim
4702TRMTC
Tub/Shower Trim
4703TRMTC
Hand Shower Trim
4705TRMTC
Shower/Hand Shower Trim
4706TRMTC
Tub/Shower/Hand Shower Trim
Warranty
4700-TRM
4700TRMTC
4701-TRM
4701TRMTC
4702-TRM
4702TRMTC
4705-TRM
4705TRMTC
4703-TRM
4703TRMTC
4706-TRM
4706TRMTC
TA-10T-12A

2
1. Recommended Tools
MM
CC
OOGG
KK
HH
FF
AA PP
RR
LL
NN
BB
JJ
QQ
SS
TT
UU
FLOORFLOOR
DD
FIGURE 2
II
EE
Notes:
1) Valve body and piping not included and shown as reference only.
2) Plaster shield (p/n T-176) for dry wall, plaster or other type walls 1/2" or greater.
3) All dimensions measured from nominal rough-in (see I as reference).
4) Dimensions subject to change without notice.
Phillips Screwdriver
Adjustable Wrench Safety Glasses Thread Seal TapeDrill Allen Wrench (3mm)
FIGURE 1
2. Dimensions
Measurements
A 6-3/4", 171 mm
B 5-1/2", 140 mm
C
Male 1/2" NPT fitting must be
recessed 1/4" (6 mm)
from finished wall
D
Diverter Valve Hole Size
Min. Ø 3", 76 mm
Max. Ø 3-1/4", 83 mm
E 3-1/2", 89 mm
F 4-1/8", 105 mm
G Ref. 10", 254 mm
H
Shower Valve Hole Size
Min. Ø 3", 76 mm
Max. Ø 4", 102 mm
IRough-in
2-3/8" ± 1/2", 60 mm ± 13 mm
J 3-1/8", 79 mm
K Ref. 12", 305 mm
L
Male 1/2-14 NPT fitting
must protrude 4" (102 mm)
from finished wall
M Ref. 32", 813 mm
N 5-1/4", 133 mm
O Ref. 77", 1956 mm
P Ø 2-1/2", 64 mm
Q 6", 152 mm
R 2-1/8", 54 mm
S Ø 5", 127 mm
T Ø 7", 178 mm
U Ø 2-1/2", 64 mm

3
5. Installation - Adjust Packing Nut (Model Numbers Ending in TRMTC)
1) Turn hot and cold supplies on. Valve will not operate unless both hot and cold water supply pressures are on.
2) Place handle over flow control spindle.
3) Tighten packing nut for positive frictional resistance as handle is rotated from shut-o position across adjustment range.
6. Installation - Setting Limit Stop Screw (Model Numbers Ending in TRMTC)
1) Turn hot and cold supplies on. Valve will not operate unless both hot and cold water supply pressures are on.
2) Place handle on flow control spindle and open valve to maximum desired temperature.
3) Turn limit stop screw clockwise until it seats.
WARNING: Failure to adjust limit stop screw properly may result in serious scalding.
The temperature limit stop screw limits valve handle from being turned to maximum position resulting in excessive hot
water discharge temperatures.
3. Parts Breakdown (Model Numbers Ending in TRMTC)
4. Installation - Remove Test Cap (Model Numbers Ending in TRMTC)
1) Check for leaks around the valve assembly and all pipe
fittings.
Flow control spindle (TA-10) and cap assembly (T-12A) will
come factory assembled for all model numbers ending in
TRMTC. When ready to remove Test Cap and install trim,
follow the instructions below:
2) Remove test cap from valve (FIGURE 4.1).
3) If system is dirty, flush valve.
4) Thread flow control spindle and cap assembly into valve
body. Turn clockwise to secure to valve (FIGURE 4.2).
FIGURE 4.1 FIGURE 4.2
LIMIT STOP
SCREW
2
1
PACKING
NUT
FIGURE 3
Replacement Parts
Item Description Part Number
1 Cap Assy. T-12A
2 Flow Control Spindle TA-10
IMPORTANT: Model numbers ending in TRMTC
coordinate with Temptrol pressure balancing valves
ordered with Test Cap. The Test Cap is used to
allow pressurization of system. Do not remove
test cap from valve during wall construction,
installation of valve or pressurization of system.
WARNINGS:
1. Do not expose valve with test cap to heat
for longer than 2 minutes when soldering
copper tubing. Doing so may damage the
internal components of the valve and will
void the product warranty.
2. Ensure test cap is tightened securely after
soldering valve body.

4
Replacement Parts
Item Description Part Number
A Showerhead 4-143
B
C
Shower Arm
Flange 300S
D
E
F
G
Plug Button
Screw
Star Washer
Handle
RTS-026
H
I
Lock Nut
Dome Cover T-19/20
J
K
L
Diverter Escutcheon
Screws
Mounting Plate
T-416A
M Dome Cover T-19
N
O
P
Dial
Screws
Mounting Plate
T-133C
Q Hand Shower EF-101
R
S
T
Wall Cradle
Screws
Mounting Plate
EF-106
U Wall Elbow EF-105
V 60" Hose RTS-045
W
W1
Tub Spout
Diverter Tub Spout
060
054
Notes:
1) Append appropriate sux for premium finish.
2) Append appropriate flow rate to showerhead
or hand shower for low flow.
3) Apply a bead of silicone around the perimeter
of all shower trim installed flush to the
finished wall. Leave opening on bottom of
escutcheons for weep hole.
4) Apply plumber tape to all threaded
connections.
FIGURE 7
Q
RS
T
V
U
A
B
C
K
K
L
DE
G
F
H
I
J
WW1
O
O
P
DE
G
F
N
M
EF-109*
*Order in-line vacuum breaker (EF-109) for
hand shower systems without dual checks.
7. Parts Breakdown

5
8. Installation - Shower Valve Trim
FIGURE 8.1
1
2
FIGURE 8.2
FIGURE 8.3
9. Installation - Diverter Valve Trim
1) Attach arm and flange to shower pipe. Turn clockwise
to tighten (FIGURE 10.1).
2) Install showerhead to shower arm. Turn clockwise to
tighten (FIGURE 10.2).
3) Install tub spout to stub out pipe. Turn clockwise to
tighten (FIGURE 10.3).
FIGURE 10.1 FIGURE 10.2
FIGURE 10.3
10. Installation - Showerhead & Tub Spout
1) Secure large shower escutcheon to Temptrol
pressure balancing valve using mounting screws.
Snap dial into shower escutcheon (FIGURE 8.1).
Note: Dial should be in the 6 o'clock position.
2) Install dome cover by turning clockwise (FIGURE 8.2).
3) Install handle to shower valve. Secure handle with
star washer and screw. Attach plug button to handle
(FIGURE 8.3).
FIGURE 9.1 FIGURE 9.2
FIGURE 9.4
FIGURE 9.3
2) Secure small diverter escutcheon to mounting plate.
Tabs should snap in place (FIGURE 9.2).
1) Secure small mounting plate to Symmons diverter valve
using mounting screws (FIGURE 9.1).
3) Install lock nut and dome cover by turning clockwise
(FIGURE 9.3).
4) Install handle to diverter valve. Secure handle with
star washer and screw. Attach plug button to handle
(FIGURE 9.4).

6
3) Install wall elbow to stub out pipe. Tighten set screw to
secure (FIGURE 11.3).
4) Attach small end of hand shower hose to wall elbow.
Turn clockwise to tighten (FIGURE 11.4).
1
3
FIGURE 11.1
2
4
TILE ANCHOR
DRY WALL ANCHOR
ANCHOR TOOL
11. Installation - Slide Bar Assembly
5) Attach large end of hand shower hose to hand shower
wand. Turn clockwise to tighten (FIGURE 11.5).
FIGURE 11.3 FIGURE 11.4
FIGURE 11.5
1) Place mounting plate in position. Mark and drill 3/16"
holes for tile anchors, 5/16" holes for drywall anchors.
Install anchors (FIGURE 11.1).
Note: For dry wall 1/2" thick or less, insert anchor tool
into drywall anchor to secure behind wall prior to
installing wall cradle.
2) Remove cover of hand shower cradle. Install cradle
and mounting plate. Secure with three screws. Replace
cover on hand shower cradle (FIGURE 11.2).
3
1
2
4
FIGURE 11.2

7
12. Operation (Temperature Control)
1) Turn shower handle counter-clockwise
approximately 1/4 turn to put valve in
cold position (FIGURE 12.1).
2) Turn shower handle counter- clockwise
approximately 1/2 turn to put valve in
warm position (FIGURE 12.2).
3) Turn shower handle counter- clockwise
approximately 3/4 turn to put valve in
hot position (FIGURE 12.3).
FIGURE 12.1 FIGURE 12.2 FIGURE 12.3
13. Operation (Dual Outlet Diverter Control)
1) Cartridge is factory set to divert to
function 1 (FIGURE 13.1).
2) Turn handle to position 2 to divert to
function 2 (FIGURE 13.2).
3) Turn handle to position 3 to share
functions 1 and 2 (FIGURE 13.3).
FIGURE 13.1 FIGURE 13.2 FIGURE 13.3
14. Operation (Triple Outlet Diverter Control)
1) Cartridge is factory set to divert to
function 1 (FIGURE 14.1).
2) Turn handle to position 2 to divert to
function 2 (FIGURE 14.2).
3) Turn handle to position 3 to divert to
function 3 (FIGURE 14.3).
FIGURE 14.1 FIGURE 14.2 FIGURE 14.3
4) Turn handle to position 4 to share
functions 2 and 3 (FIGURE 14.4).
5) Turn handle to position 5 to share
functions 1 and 3 (FIGURE 14.5).
6) Turn handle to position 6 to share
functions 1 and 2 (FIGURE 14.6).
FIGURE 14.4 FIGURE 14.5 FIGURE 14.6
Note: Additional handle positions for
same output are illustrated.

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2019 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3276 REV A ■ 062419
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause cancer, birth
defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
15. Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
