Symmons Allura SLC4712PP Manual

Model Numbers Feature Highlights
☐SLC4712PP Centerset Lavatory Faucet with
Push Pop Drain Assembly
• Two handle 4 inch centerset lavatory faucet with
quarter turn ceramic components
• Solid Brass Construction
• Lever handles with red & blue indicators
• 1/2 inch IPS shanks
• Aerator with standard 1.0 gpm flow rate (3.8 L/min)
• Polished chrome finish
Compliance
- ASME A112.18.1/CSA B125.1
- NSF/ANSI/CAN 61: Q<1, NSF/ANSI 372
- WaterSense 1.0 gpm
Dimensions
c
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
Warranty
Allura®
SLC4712PP
Lavatory Faucet
Operation & Maintenance Manual
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2023 Symmons Industries, Inc. ■symmons.com ■[e-mail] ■ZV-3715 REV 0 ■ 021623
Certied by
IAPMO R&T
Note: Dimensions are subject to change without notice.
WARNING: This product can expose you to chemicals
including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.
Deck thickness
1/2"-14 NPSM
Hole diameter
1" (25 mm)
1-3/4" ( 45 mm) max

2
Parts Breakdown
Replacement Parts
Part Number Item
Cartridge
LN-01452 (hot)
OFF = CW
LN-01453 (cold)
OFF = CCW
LN-01454* Handle Kit
RL324* Push Pop Drain Assembly
Hot = RED
Cold = BLUE
hot & cold
plug buttons (2)
screw (1)
handle (1)
Aerator assembly
SWA-17FR*
FLR-111-1.5*
FLR-111-1.0*
ow rates
2.2 gpm (8.3L/min)
1.5 gpm (5.7L/min)
1.0 gpm (3.8L/min)
hot plug button
* Note: When ordering replacement parts for faucets
with an optional decorative nish, append appropri-
ate three letter nish sufx code to part numbers
marked with an asterisk (*).
Push Pop
Drain Assembly
cold plug button
screw
philips (M4 .7 x 6mm)
faucet body
cartridge
cartridge retainer
fastener
gasket
standard
aerator
1.5 gpm
collar
handle
Tools Required
Adjustable Wrench
Phillips Head Screwdriver
Plumber Putty
Plumber Tape
Soft Jaw Pliers
PLUMBER
PUTTY

3
Visual Install Guide
Step 4
Flush water supply lines
Step 3
Step 2
Step 1
Attach faucet to sink
Step 1
Visual Install Guide Allura Lavatory Faucet, SLC4712PP
Connect water supply lines
(supply hoses are not included)
1
2
3
Plumbers Putty L
Q
X
N
Y
O
M
Push Pop Install: Insert drain body (L) into
drain opening. From below, Tighten locking
nut (O) with gasket (M) and washer (N) to
ange. Tighten tail nut (Y) with washer (X) to
secure tail pipe (Q).
Do Not overtighten.

4
Caution: If replacing an older faucet ensure water
supply is turned OFF before removing. en turn faucet
control valves ON to relieve water pressure.
Step 1 Attach faucet to sink
Step 2 Connect water supply lines
Step 3 Push Pop Install: Insert drain body (L)
into drain opening. From below, Tighten locking nut
(O) with gasket (M) and washer (N) to ange. Tighten
tail nut (Y) with washer (X) to secure tail pipe (Q).
DO NOT overtighten.
Supply hoses
not included
COLD
HOT
Installation Instructions
1
2
3
Plumbers Putty L
Q
X
N
Y
O
M
Step 4 Flush water supply lines
Care of faucet finish
Clean nish area by using mild soap and water or non-abrasive
cleaners and then rinse immediately. A non-abrasive wax may
be used to preserve nish area.

5
Valve cartridge replacement
Valve cartridge replacement
HOT
HOT
COLD
COLD
HOT
COLD
RED = Hot
BLUE = Cold
3
5
4
M4 .7 x 6 mm
1
2

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2023 Symmons Industries, Inc. ■symmons.com ■[e-mail] ■ZV-3715 REV 0 ■ 021623
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
Troubleshooting Chart
