Symmons Elm SRT-5570 Reference guide

3/32"
1/8"
1 2 3 4
Step 1
Cut copper
tubing to length HOT
Supply COLD
Supply
Step 6
Solder supply lines
and check for leaks
Step 2
Solder valve
assembly together
Step 4
Attach supply valves
to deck
Step 5
Attach handles
Step 3
Attach spout
centerbody to deck
Step 7
Remove plug and
attach spout
Step 8
Flush supply lines
Check for leaks with plug
installed in centerbody.
Remove and discard plug
before attaching spout.
centerbody
plug
Quick Install Guide Elm Roman Tub Faucet, SRT-5570
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause cancer, birth defects,
or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Roman Tub Faucet SRT-5570
Installation Brief
Elm®
Tools & Materials Need Help?
Symmons customer service:
Phone: [phone]
Email: [email protected]
Monday - Friday 7:30 am - 6:00 pm EST
www.symmons.com/service

Finish Options
-STN Satin Nickel
-SBZ Season Bronze
- Chrome (standard nish)
Model Numbers
SRT-5570 Roman Tub Faucet
Compliance
ASME A112.18.1/CSA B125.1

4"
(101 mm)
2-5/16" dia
(58 mm)
Connect using
1/2" copper tubing
Hole size
1-1/16" (27 mm) min
1-1/2" (38 mm) max
Finished deck
thickness
1-5/16" (33 mm) min
1-7/16" (36 mm) max
Dimensions Elm Roman Tub Faucet, SRT-5570
8" (203 mm) min
18-1/4" (464 mm) max
with Symmons supplied copper tubing
4-1/4"
(102 mm)
7-7/8"
(200 mm)
9-3/8"
(238 mm)
9-3/4"
(246 mm)
2-1/2" dia
(64 mm)
6-13/16"
(173 mm)
Dimensions subject to change without notice.
3"
(76 mm)
1" dia
(25 mm)
1" dia
(25 mm)
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ ZV-1094 REV B ■121018
RL-143*
includes two
handles
KN-114E (hot)
OFF = CW
KN-113E (cold)
OFF = CCW
KN-113E
identified
by groove
handle (2)
screw (2)
escutcheon (2)
Replacement Parts
Part Number Item
Handle kit Qty
valve cartridgevalve cartridge
retaining
plate
ange nut
RL-142 Mounting kit, Qty
retaining nut (2)
washer (2)
mounting nut (2)
spout
handle
escutcheon
centerbody
plug
centerbody
cartridge
retaining nut
gasket
ange nut
supply valve
8" copper
tube
copper tee
hole plug
Ordering replacement parts:
Call Symmons customer service at [phone],
[phone] M-F 7:30 am - 6:00 pm EST or
check our website at www.symmons.com for a
list of Symmons distributors.
*
Note: For faucets with an optional decorative nish,
add appropriate sufx code letters to part numbers
marked with an asterisk (*) when ordering.
1/8" Allen
wrench
(not included)
3/32" Allen
wrench (not included)
Parts Assembly Elm Roman Tub Faucet, SRT-5570
