Symmons Degas 542TS-ORB Manual

542TS, 542TSD
Degas®Tub Spout Series
Operation & Maintenance Manual
Model Numbers Specifications
542TS Degas Non-Diverter Tub Spout
542TSD Degas Diverter Tub Spout
8" diverter tub spout (542TS) and 8 1/8" non-diverter
tub spout (542TSD) made from brass materials plated in
standard polished chrome nish.
Modifications Warranty
-ORB Oil rubbed bronze
-STN Satin nickel finish
Note: Append appropriate -sufx to model number.
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Dimensions
Measurements
A Ø 2 1/2”, 64 mm
B 1/2”, 13 mm
C 8 1/8”, 206 mm
D 1/2”-14 NPT
E 8”, 203 mm
Required for Installation
Teon Tape
Note: Dimensions are subject to change without notice.
DD
C
C
B
B
AA
AA
EE D
D
B
B
542TSD
542TS

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3044 REV A ■ 080118
1) Install tub spout to stub out pipe. Turn clockwise to
secure.
Note: 542TSD only.
1) Diverter lever in down position for tub spout operation.
2) Diverter lever in up position for shower operation.
542TS, 542TSD
Degas®Tub Spout Series
Operation & Maintenance Manual
Installation Diverter Control
1
2
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
