Installation and Service Instructions
Tools & Materials
Allura®
Step 7
Connect lift rod
and adjust linkage
Step 9
Flush water supply lines
Step 6
Step 8
Attach drain body to drain trap
Step 4
Attach drain body and tail piece to ange
Step 3
Seat ange into sink drain opening
Step 5
Install stopper and
set eye position
Step 2
Step 1
Attach faucet to sink
Step 1
Non-
Removable Removable
stopper stopper
Visual Install Guide Allura Lavatory Faucet, SLC-4712-1.5
Part No. LN-01302
Attach pivot rod to drain body
Connect water supply lines
(supply hoses are not included)
Lavatory Faucet SLC-4712-1.5
PLUMBERS
PUTTY
Need Help?
Symmons customer service:
Phone: (800) 796-6667
[email protected]
Mon - Fri 7:30 am - 6:00 pm EST
www.symmons.com/service
• Technical help
• Product information
• Warranty policy.
Model Numbers
SLC-4712-1.5 (LN-01302)
Lavatory faucet with pop-up drain
Alternate Finish Code
append to part numbers when applicable
-STN Satin Nickel
-- Chrome (standard)
WARNING: is product can expose you to chemicals including lead, which is known to the state of California to cause cancer,
birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Installation Instructions
Page 2
* Note: Attach tail piece to drain body using teon tape.
tape or plumber’s putty.
Caution: If replacing an older faucet ensure water
supply is turned OFF before removing. en turn faucet
control valves ON to relieve water pressure.
Step 1 Attach faucet to sink
Step 2 Connect water supply lines
Step 3 Seat flange into sink drain opening
* Note: Washer included with faucet should only be
used when plumbers putty is not available.
Step 4 Attach drain body to flange
Step 5 Install stopper and set eye position
Step 6 Attach pivot rod to drain body
beveled
washer
friction
washer
ange
nut drain
body
back
of sink
ange
tail
piece
Supply hoses
not included
COLD
HOT
PLUMBERS
PUTTY
ange
washer *
(optional)
* use included washer only for when
plumbers putty is not available
pivot rod
retaining nut
outer seat
pivot ball
inner seat
pivot cavity
stopper eye
stopper
ange
non
removable removable
pivot rod
Page 3
Valve cartridge replacement
Step 7 Connect lift rod and adjust linkage
Step 8 Attach drain body to drain trap
Step 9 Flush water supply lines
Care of faucet finish
Clean nish area by using mild soap and water or non-abrasive
cleaners and then rinse immediately. A non-abrasive wax may
be used to preserve nish area.
Valve cartridge replacement
clevis strap
lift rod
pivot rod
drain body
drain trap
spring clip
thumb screw
location hole
HOT
HOT
COLD
COLD
HOT
COLD
RED = Hot
BLUE = Cold
3
5
4
M4 .7 x 6 mm
1
2
Replacement Parts
Part Number Item
Cartridge
LN-01452 (hot)
OFF = CW
LN-01453 (cold)
OFF = CCW
LN-01454 Handle Kit
Hot = RED
Cold = BLUE
Part No. LN-01302
hot & cold
plug buttons (2)
screw (1)
handle (1)
Aerator assembly
SWA-17FR
FLR-111-1.5
FLR-111-1.0
ow rates
2.2 gpm (8.3L/min)
1.5 gpm (5.7L/min)
1.0 gpm (3.8L/min)
hot plug button
RL-235 Lift Rod
stopper
P-100N
pop-up drain
assembly
includes lift rod
and stopper
RL-154LR*
cold plug button
screw
philips (M4 .7 x 6mm)
faucet body
Ordering replacement parts:
Call Symmons customer service at (800) 796-6667,
(781) 848-2250 M-F 7:30 am - 6:00 pm EST or
check our website at www.symmons.com for a
list of Symmons distributors.
cartridge
cartridge retainer
fastener
gasket
standard
aerator
1.5 gpm
lift rod
collar
handle
Parts Assembly Allura Lavatory Faucet, SLC-4712-1.5
4" (102 mm)
6" (152 mm)
Deck thickness
1/2"-14 NPSM
Hole diameter
1" (25 mm)
3-3/4"
95 mm
9-1/4"
236 mm
2" ( 51 mm)
Part No. LN-01302
7/8" ( 22 mm) max
1-15/16"
49 mm
4-1/4"
108 mm
Dimensions
Allura Lavatory Faucet, SLC-4712-1.5
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: (800) 796-6667 ■ Fax: (800) 961-9621
Copyright © 2018 Symmons Industries, Inc. ■ symmons.com ■[email protected] ■ ZV-1030 REV E ■110718
