Synergy H-DBRK-ALP User manual

SYNERGY
CUSTOM FITNESS
C O N G R A T U L A T I O N S
O N Y O U R N E W P U R C H A S E
W E L C O M E T O T H E S Y N E R G Y F A M I L Y !
Do you need support? we are here for you
ASSEMBLY INSTRUCTIONS Model #
scan QR code for options
on how to contact us
We are here to support you in any way we can. Scan the QR code for
options on how to best contact us or visit us at
https://www.synergycustomfitness.com
You can also email us [e-mail] or call us at
1-877-305-4057
Page 1 H-DBRK-ALP

SYNERGY
CUSTOM FITNESS
D(6) Shelf Brackets
F(12) 4.3/4" - 1" Bolt
E(1) Small wrench
G(24) 1" Nylon washer
H(12) 1" lock washer
I(12) 1" hex nut
J(16) 1" - 1/2" bolt
K(4) 1/2 specialty washer
L(4) 1/2 flat washer
O(2) Base support
Plates
N(4) 4" - 1/2" bolt
M(16) 1/2 hex nut
C(6) L Angle Shelf Support
Model #
A
B
(2) Upper tubes
(2) Leg base
INSIDE THE BOX
Page 2
*Additional 1 3/8 wrench tool needed but not included
3- Tier Horizontal Storage Alpha H-DBRK-ALP

A
BJ
M
N
O
Step 1 completed
K
STEP 1
1
Place [A] upright tube onto [B] leg
base and use hardware [J] [L] [K]
[M] and [N] to secure leg using
[O] base support plate as shown.
NOTE: there are only 2 base support plates. Place in
the inside of each leg as shown.
Repeat for second leg
DO NOT FULLY TIGHTEN YET
Model #
Page 3
WARNING: Many of these parts are heavy and could cause serious injury if not handle properly,
to help avoid injury we recommend assembling with another person and using proper tools,
use included tool
H-DBRK-ALP
L

Insert hardware [F] [G] [H] [I] as
illustrated to secure shelf bracket
[D] top upright support plate
onto [B] upright tube.
Repeat for second leg
DO NOT FULLY TIGHTEN YET
Step 2 completed
x
D
F
G
H
I
STEP 2 Model #
2
Page 4
*We recommend setting up the first tier below before installing the higher tiers brackets
H-DBRK-ALP

C
JM
D
STEP 3 Model #
3
Place both L Angle Shelf Support [C] on shelf
brackets [D] and use hardware [J] and [M] to secure.
Page 5
Center hole will give a leveled
flat surface for kettlebells
while the back hole will tilt the
shelf forward for dumbbells.
The extra holes will allow you to
shift the placement of the L Angle
Shelf Support when use for
dumbbells. They can be staggered
giving you three different positions
Forward, Center and Back
Repeat steps 2 and 3 for next tier on desire height.
use included tool
H-DBRK-ALP

ALMOST COMPLETED Model #
Page 6
IMPORTANT
I DO NOT HAVE ADDITIONAL ACCESSORIES
then now is the time to make sure all hardware is securely
fastened before adding any weights to it.
WAIT... I DO HAVE ADDITIONAL ACCESSORIES
If you have additional accessories to attach to this unit then
DO NOT FULLY TIGHTEN until all accessories are attached.
See assembly instructions for additional accessories
H-DBRK-ALP

Wasn't that easy?
You have assembled your new
horizontal dumbbell rack and
didn't even break a sweat.
Now go brag about it in social media
and get your workout done!
COMPLETED Model #
Page 7 H-DBRK-ALP
