System air Humidity Sensor Wireless User manual

HumiditySensor
Wireless
UserManual
-en_GB
Documentinoriginal
language2017-03-20A004

Contents
1DeclarationofConformity...............................1
2Productdescription......................................2
2.1Humiditymeasurement..........................3
3Guidelinesforinstallation...............................3
4Interfacedescription.....................................4
4.1Power-up..........................................4
4.2Active/User/Faultmode..........................5
4.3Bindingmode.....................................6
5Changebatteries.........................................7
6Troubleshooting..........................................8

1DeclarationofConformity
Manufacturer
SystemairAB
Industrivägen3
SE-73930SkinnskattebergSWEDEN
Ofce:[phone]Fax:[phone]
www.systemair.com
herebyconrmsthatSmartDial,CO2sensor,Humidity
sensor,InputmoduleandRS485Gatewaycomplywithall
applicablerequirementsintheDirective2014/53/EU.
TheunitswillmeettherequirementsoftheWEEEandROHS
directives.
HumiditySensorUserManual
1SystemairAB

Thecompletetechnicaldocumentationisavailable.
Skinnskatteberg,20-03-2017
MatsSándor
TechnicalDirector
2Productdescription
TheHumiditysensorrequiresanRS485Gatewaytofunction.
TheHumiditysensorisawirelesssensorthatmeasuresthe
relativehumidity(RH)level.Ifthehumiditysensordetects
humidityaboveapresetlevel,theairhandlingunitwillstart
forcedventilation.
TheHumiditysensorisintendedforwallmountingeitheron
thewalloronawall-box.Thehumiditysensorshouldbe
placedwhereyouwantinstantaneoushumiditymeasuring.
HumiditySensorUserManual
2SystemairAB

TheHumiditysensorispoweredby2AlkalineAA-Batteries,
included.Expectedbatterylifetimeis2years.
2.1Humiditymeasurement
•Measurementrangeis0-100%RH.
•Measurementaccuracyis3%RHfrom11-89%RH.
•Measurementaccuracyis7%RH0-10%and90-100%.
•Measurementresolutionis1%RH.
•Measurementstabilityis1,5%RHover5years.
Note:
ThefunctionoftheHumiditysensorisconguredinthe
Systemairairhandlingunitcontroller.SeetheManualforthe
specicairhandlingunit.
3Guidelinesforinstallation
SeetheRS485GatewayUserManualformoreinformation.
HumiditySensorUserManual
3SystemairAB

4Interfacedescription
TheManMachineInterface(MMI)forthisproducthasone
capacitivebuttonandonecombined(redandgreen)LED
indicatorthatindicatesthestatusofthedevice.
1.GreenandRedcombinedLED
2.Capacitivebutton
4.1Power-up
Afterthedevicehasbeenturnedon,thegreenLEDlightsup.
After2seconds,thedevicewillgotoidlemode.
IntheidlemodethestatusLED’sareturnedoff.
WhenthebuttonispushedtheActive/User/Faultmodeis
entered.
HumiditySensorUserManual
4SystemairAB

4.2Active/User/Faultmode
IntheActive/User/FaultmodetheLED’scanshowfollowing
status:
•Flashingred(fault).Thisstatusisrepeatedeveryfew
seconds.
•BothredandgreenLEDcontinuouslylit.Batterylow.
•Whenthebuttonispushedandheldforlessthan1second,
aPartyActivemessageissenttothegateway.
Note:ItisnotpossibletodeactivatethePartyActivemode
fromthismodule.Itmustbedeactivatedontheairhandling
unitcontrolpanelorthewirelesscontrolpanelifoneis
used.
Note:Thereisno(visible)feedbackwhenthebuttonis
touched.
•Whenthebuttonispressedandheldfor10seconds,the
greenLEDstartsashingfor3seconds.
•Ifthebuttonisreleasedwithinthese3seconds,the
bindingmodeisentered.
•Ifthebuttonisnotreleasedwithinthese3seconds,the
LEDgoesoffandthegatewaywillgotoidlemode.
HumiditySensorUserManual
5SystemairAB

•Ifthebuttonisnotpressedforatleast10seconds,the
modulewillgotoidlemode.
4.3Bindingmode
IntheBindingmode,themodulecontactsthegatewayand
requestsconnection.
Bindingisonlypossiblewithin2minutesafterpower-up.
Note:
Bindingmodemustrstbeactivatedonthegateway.See
RS485GatewayUserManualformoreinformation.
IntheBindingmodetheredandgreenLED’sarealternately
litfor2seconds.
•Whenthebindingprocedureisdoneoratimeouthas
occurred,theresultofthebindingisindicatedfor2seconds
•Next,theActive/User/Faultmodeisentered.
GreenLEDlit—bindsuccessful
RedLEDlit—bindfailed
HumiditySensorUserManual
6SystemairAB

Whenthebuttonispressedagain,theActive/User/Faultmode
isentered.
5Changebatteries
1.Useascrewdriverorsimilarto
pushupthelock(1)andipout
theunit(2).
2.Changethebatteries.
3.Remountinoppositeorder.
HumiditySensorUserManual
7SystemairAB

6Troubleshooting
IndicationProbablecauseandaction
HumiditySensorisnotworkingCheckifbatteriesaredepleted
orinsertedincorrectly
RFbindingand/or
communicationproblems
Checkifremotemodulestoo
close(<1m)ortoofaraway(>
30m)fromthegateway
HumiditySensorUserManual
8SystemairAB

HumiditySensorUserManual
9SystemairAB

lastpage
SystemairABreservestherighttomakechangesandimprovements
tothecontentsofthismanualwithoutpriornotice.
