System air CWR-86E Operating instructions

INSTALLATION & OWNER’S
MANUAL
CWR-86E Wired Controller
Thank you for purchasing the wired controller.
This manual describes the safety precaution requirement of using this controller.

● Read this manual carefully and be sure you understand
the information before attempting to use the controller.
● Keep this manual where it is readily accessible after
reading it through.
● If another user operates the controller in the future, be
sure to hand over this manual to the new user.

Contents
Installation .........................................................................................................1
1. Safety Precautions .......................................................................................... 1
2. Accessories ..................................................................................................... 3
3. Installation Procedure...................................................................................... 4
Operation ........................................................................................................... 9
1. Safety Precautions .......................................................................................... 9
2. Parts of the Wired Controller......................................................................... 11
3. Icons in the Display ....................................................................................... 13
4. Operation Guide ............................................................................................ 13
Field Setting..................................................................................................... 24
1. Restore Factory Default ................................................................................ 24
2. Query and Set the Indoor Unit Address......................................................... 25
3. Commissioning Parameter Settings .............................................................. 26
4. Query Operations .......................................................................................... 33
5. Error Display.................................................................................................. 37
Troubleshooting .............................................................................................. 40

Installation
1. Safety Precautions
Please read these Safety Precautions carefully before installing the wired controller.
This manual classifies the precautions into WARNING and CAUTION. They both contain
important information regarding safety. Be sure to follow all the precautions below.
After completing the installation, conduct a trial operation to check for faults and explain to
the customer how to operate the controller with the aid of the operation manual. Ask the
customer to store the installation manual along with the operation manual for future
reference.
Ask your dealer or qualified personnel to carry out installation work.
Do not attempt to install the wired controller yourself. Improper installation may result in
leakage, electric shocks or fire.
Consult your local dealer regarding relocation and reinstallation of the wired controller.
Improper installation work may result in leakage, electric shocks or fire hazards.
Install the wired controller in accordance with the instructions in this manual.
Improper installation may result in water leakage, electric shocks or fire.
Failure to follow these instructions properly may result in personal
injury or loss of life.
Failure to observe these instructions properly may result in property
damage or personal injury, which may be serious depending on the
circumstances.
Identifier Meaning
Warning
Caution
Warning
●
●
●
1
Important Indicates a useful hint or additional information.

Be sure to use only the specified accessories and parts for installation work.
Failure to use the specified parts may result in the unit falling down, water leakage, electric
shocks or fire.
Install the wired controller on a foundation strong enough to withstand the weight of the
wired controller.
Insufficient strength may result in the wired controller falling down and causing injury.
Electrical work must be performed in accordance with the relevant local and national
regulations and with the instructions in this manual.
Be sure to use a dedicated power supply circuit only. Insufficient power circuit capacity and
improper workmanship may result in electric shocks or fire.
Always perform installation work with the power turned off.
pressing electric parts may result in electric shock.
Do not disassemble, reconstruct or repair.
This may result in electric shock and/or fire.
Make sure that all wiring is secured, the specified wires are used and that there is no strain
on the terminal connections or wires.
Improper connections or securing of wires may result in abnormal heat build-up or fire.
The choice of materials and installations must comply with the available national and
international standards.
●
●
To avoid leakage and electric shock due to entry of water or insects, fill the wiring through
hole with putty.
To avoid electric shocks, do not operate with wet hands.
Do not wash the wired controller with water, as this may result in electric shocks or fire.
When the follow me function of the wired controller is used, select the installation location
while considering it should be a place:
●
1).Where the average temperature in the room can be detected.
2).Which is not exposed to direct sunlight.
3).Which is not near a heat source.
4).Which is not affected by the outside air or air draught due to, for example,
opening/closing of doors, the air outlet of the indoor unit or the like.
●
●
●
●
Caution
2
●
●
●
●

2. Accessories
Please check that you have all the following parts.
Please prepare the following parts on site.
12
2
No. Name Schematic Qty. Remarks
No. Name Qty. Remarks
Philips head screw,
M4X25mm
2
3
1
2
3
4
5
Plastic support bar
φ5X16mm
Operation and Installation
Manual
86 electrical box
2-core shielded copper wires
Wiring tubes (insulation suite)
Big Phillips screwdriver
Small slotted screwdriver
General specification for electrical box,
which is embedded into the wall.
2*AWG16-AWG20, pre-embedded
into wall.
Longest wiring length is 200 metres.
Pre-embedded into wall.
To install the Philips screws.
To dismantle the bottom lid of the wired
controller.
Used to install the wired
controller on the electrical
box
Used to install the wired
controller on the electrical
box
1
1
1
1
1
1
3
/
Table 2.2
Table 2.1



Make sure to refer to "1. Safety Precautions" to determine the location.
3-2 Structural Dimensions
3-3-1 Insert a small slotted-head screwdriver into the bottom slot of the wired controller and
rotate in the direction indicated to remove the rear cover of the wired controller. Pay attention
to the direction of rotation to prevent any damage to the rear cover of the wired controller. (see
Figure 3.3)
3-3 Rear Cover Installation
3. Installation Procedure
3-1 Determine Where to Install the Wired Controller
Figure 3.1 Figure 3.2
Screwdriver rotation direction
Slotted screwdriver
Figure 3.3
RT1
FOLLOW ME
4
86mm 20mm
86mm
60mm
41.7mm

3-3-2 Use a cutting tool to adjust the height of the two plastic support bars (accessory 2) to
match the standard length of the screw pillars of the electrical box to the wall surface. Make
sure that the support bars are level on the wall when the screw pillars of the electrical box are
mounted. (see Figure 3.4)
3-3-3 Once the heights of the plastic support bars are adjusted, fix the bars on the rear cover.
(see Figure 3.5)
Screw post of electrical box
Fix the support bars in the
direction of the arrow
Use a cutting tool to adjust the lengths of
the two plastic support bars
Figure 3.4
Figure 3.5
Warning
•When using the small slotted screwdriver to open the rear cover of the wired
controller, be careful not to damage the PCB inside.
• Do not touch the PCB of the wired controller.
5
h
h

Figure 3.6
To X1/X2 of indoor unit
Cross recessed
head screw Electrical box
Rear cover of
wired controller
3-3-4 Take the shielded wiring that has been pre-embedded in the wall, and thread it through
the wire hole of the rear cover. Use the Philips head screws (accessory 1) to fix the rear cover
of the wired controller to the electrical box via the support bars. Make sure that the rear cover
is not deformed after being installed (see Figure 3.6).
3-4-1 Wiring specification
• The rear cover may be deformed if the screw is too tight.
• Prepare the electrical box and the 2-core shielded copper wire on site.
• Do not touch the PCB of the wired controller.
Important
Caution
△
!
3-4 Wiring
6
Type 2-core shielded copper wire
AWG 16-20
Maximum 200m
Diameter
Length
Table 3.1

Figure 3.7
1-to-1 1-to-1 1-to-1
One controller to one indoor unit connection method
One controller to one indoor unit connection method
Two controllers to one indoor unit connection method
3-4-2 Communication wiring
• The communication between the indoor unit and wired controller is bi-directional
communication. The parameters displayed on the wired controller are refreshed in real time
according to changes in the parameters of the indoor unit.
• X1 and X2 are terminals to connect the indoor unit and wired controller. There is no polarity
between X1 and X2.
• The longest wiring length between the wired controller and indoor unit is 200 meters.
P/Q/EP/Q/EP/Q/E
P/Q/E
X1/X2
○○○
X1/X2 X1/X2
7



Figure 3.8
• For the two controllers to one indoor unit connection method, two wired controllers control
the same indoor unit, where one controller will be the "Main", and the other be the
"Secondary". Refer to "Field setting". The default setting of the wired controller is set to
main controller.
• This method is only available for two CWR-86E wired controllers.
Two controllers to one indoor unit connection method
Not allowed
2-to-1
1-to-1
2-to-1
3.5 Install Main Body of Wired Controller
Take the shielded wiring that has been pre-embedded in the wall and pass it through the wiring
hole of the rear cover of the wired controller. Once connected, connect the wiring to the
terminal X1/X2 (CN2) of the wired controller, and fix the wired controller to the rear cover. (see
Figure 3.9)
Fix the wired controller correctly and firmly to the rear cover so that the wired controller will not
drop. (see Figure 3.10)
P/Q/EP/Q/EP/Q/E
P/Q/E
X1/X2
○○○
X1/X2 X1/X2
X1/X2 X1/X2
8

Figure 3.9
• During installation, reserve a certain length for the connecting shielded wiring to
make it easier to remove the wired controller for maintenance.
The Safety Precautions classifies the precautions into WARNING and CAUTION.
They both contain important information regarding safety. Be sure to follow all the
precautions below.
This controller is not intended to be used by persons, including children, with reduced physical,
sensory or mental capabilities or lack of experience and knowledge, unless they are
supervised or have been given instructions on how to use the controller by a person
responsible for their safety.
Childen should be supervised to ensure that they do not play with the controller.
Figure 3.10
Caution△
!
Operation
1. Safety Precautions
Please read the Safety Precautions carefully before operating the wired controller.
9
CN2
X1 X2


Failure to follow these instructions properly may result in personal
injury or loss of life.
Failure to observe these instructions properly may result in property
damage or personal injury, which may be serious depending on the
circumstances.
Identifier Meaning
Warning
Caution
Do not install the wired controller by yourself.
Improper installation may result in electric shocks or fire.
Consult your dealer.
Do not modify or repair the wired controller.
This may result in electric shocks or fire.
Consult your dealer.
Do not relocate or reinstall the wired controller by yourself.
Improper installation may result in electric shocks or fire.
Consult your dealer.
Do not use flammable materials (e.g., hairspray or insecticide) near the controller.
Do not clean the controller with organic solvents such as paint thinner.
The use of organic solvents may cause crack damage to the controller, electric shocks or fire.
Warning
●
●
●
●
10

Figure 4.1
Do not play with the wired controller.
Accidental operation by a child may result in impairment of bodily functions and harm health.
Never disassemble the wired controller.
Pressing the interior parts may result in electric shocks or fire.
Consult your dealer or authorized contractor for internal inspections and adjustments.
To avoid electric shocks, do not operate with wet hands.
Do not wash the wired controller.
Doing so may cause electric leakage and result in electric shocks or fire.
Do not leave the wired controller wherever there is a risk of wetting.
If water gets into the wired controller there is a risk of electrical leakage and damage to
electronic components.
Caution
●
●
●
●
●
2. Parts of the Wired Controller
⑤ Adjust ▲
⑥ Adjust ▼
⑦ ON/OFF button
⑧ Operating indicator
⑨ Cancel
⑩ Confirm
Infrared signal
receiving window
Display area of
wired controller
① Mode
②Fan speed
③Swing
④ Function
11

Table 4.1
Note 1: Auxiliary heater function is reserved.
To turn on/off the unit
To set the operating mode: Auto → Cool→ Heat→ Dry→ Fan
To adjust temperature setting and timing (for timer) upwards.
To adjust temperature setting and timing (for timer)
downwards.
To switch to functions that can be set in the current mode.
To set the fan speed.
To set the swing function.
To turn off the timer/IDU LED display/silent/ECO/auxiliary
heater function1; to cancel the timer.
To turn on the timer/IDU LED display/silent/ECO/auxiliary
heater function1; to confirm the timer.
To indicate the ON/OFF state of the indoor unit.
Button Functions
12
10. Confirm
8. Operating indicator
7. ON/OFF
1. Mode
5. Adjust upwards
6. Adjust downwards
4. Function
2. Fan speed
3. Swing
9. Cancel

Figure 5.1
3. Icons in the Display
4. Operation Guide
Clean filter reminder indicator
Indoor unit ON/OFF1
Operating mode
Lock indicator
Timer ON/OFF
Fan speed
Swing
Function
Signal transmission indicator
Temperature
① ②
③ ④
⑤
⑨
⑧
③
①
②
⑤ ⑥
⑦
⑦
⑧
⑩
④
⑨
⑥
⑩
13
4-1 ON/OFF Setting
Note1: When the indoor unit is on, the icon " " spins; when the indoor unit is off, the icon " "
does not spin.

Figure 6.1
Figure 6.2
1) Press (ON/OFF) button, and the Operating Indicator " " on the wired controller will
light up, while the ON/OFF icon " " of the indoor unit on the display will spin to indicate
that the indoor unit has started running. (see Figure 6.1)
2) Press (ON/OFF) button again, and the Operating Indicator " " on the wired controller will
turn off, and the display icon " " will stop spinning as the indoor unit stops running.
4-2 Mode Setting
Press (Mode) button. Each time press this button, the operating mode will change in turn
as shown in Figure 6.3.
14

4-3 Fan Speed Setting
Figure 6.3
• The "Auto" mode is not available for all air conditioner models.
• Temperature setting is not available in the "Fan" mode.
• "Dry" mode and "Auto" mode is not available for FAPU .
Figure 6.4
Figure 6.5
15
In the "Auto","Cool","Dry", or "Heat" mode, press ▲ and ▼ buttons to adjust to the setting
temperature. (see Figure 6.4)
Note:
Auto →Cool→Heat→Dry→Fan

4-4 Swing Setting
In the "Cool", "Heat" or "Fan" mode, press (Fan speed) button to set the operating fan
speed (see Figure 6.5).
If the wired controller is configured with seven fan speeds, press (Fan speed) button to set
the fan speed in turn as shown in Figure 6.6.
If the wired controller is configured with three fan speeds, press (Fan speed) button to set
the fan speed in turn as shown in Figure 6.7.
• In the "Auto" and "Dry" modes, the fan speed is set to "Auto", and will not change even
press (Fan speed) button.
• The default fan speed is 7 fan speeds, please refer to "Field Setting" to adjust the default
fan speed.
Auto Speed 1 Speed 2 Speed 3 Speed 4 Speed 5 Speed 6 Speed 7
Figure 6.6
Figure 6.7
Figure 6.8
→ → → → → → →
16
Auto Low Mid High
→ → →
Note:

• The swing function is only available for indoor units configured with vertical louver.
• When the unit is off, the (Swing) button is invalid, and the wired controller automatically
turns off the swing function, and the display icon will no longer show the swing angle.
•This wired controller is unable to control horizontal swing in indoor unit.
Press (Swing) button to control the swing of the vertical louver of indoor unit (see Figure 6.8).
When the unit is on, the display icon shows the swing angle of the current louver.
Press (Swing) button, and the louver switches from the current angle to the angles in turn
as shown in Figure 6.9.
When the louver is in "Auto" state, Press (Swing) button again, and the louver will stop at
the current operating angle, and the display icon will show the current angle of the louver after
10 seconds.
Angle 1 Angle 2 Angle 3 Angle 4 Angle 5 Auto Stop
Figure 6.9
Figure 6.10
4-5 Function Setting
17
Note:
