System Q HandyQUAD QUAD050 Installation and user guide

System Q Ltd. McGregor’s Way, Turnoaks Business Park, Hasland, Chesterfield, S40 2WB
Telephone: [phone] Website: www.systemq.com Email: [email protected]
Compatible with analogue as well as HD cameras (HD-TVI & AHD)
the HandyQUAD is a great device to configure different display
options on a screen. With 7 display modes, it’s easy to use up to
4 video loopthroughs from a DVR or distributor to configure the
ideal display option for a Reception area or to have on display to
customers in a retail outlet.
Product Code: QUAD050
7 Display Options
Easy channel selection
Full Screen
Quad
Horizontal Split
Main Monitor & Split Screen
Vertical Split
Switching
Picture In Picture
How to
FIT CCTV 391
Tip No:
This CCTV installation tip is aimed at helping you to install CCTV equipment. If you are looking for answers on “how to fit CCTV” or perhaps “how to network a DVR or
NVR” or even “how to get CCTV on your mobile phone” why not check out our full range of CCTV installation tips at: www.systemq.com
How to guides aim to answer commonly asked questions in a concise and informative manner. They are for advice & guidance only and do not replace any of the manuals or other literature supplied with our products.
Copyright © System Q ltd Last revised: January 2017 | Page 1
Question: How can I view my CCTV cameras on a screen as a
Picture in Picture display?
Answer: Use a HandyQUAD device to view one picture inset into another or choose from any of its 7 display
modes including Vertical and horizontal split screen

System Q Ltd. McGregor’s Way, Turnoaks Business Park, Hasland, Chesterfield, S40 2WB
Telephone: [phone] Website: www.systemq.com Email: [email protected]
Multiple display modes to customise your installation!
How to set up…
1. Simply plug in up to 4 compatible CCTV cameras or other video inputs to the BNC sockets marked
CAM1/2/3/4.
2. Power up with a 12VDC 500mA PSU.
3. Connect your chosen screen(s) using a choice of one or more of the BNC out, VGA or HDMI out and
switch a connected screen on to set up your display.
4. Use the Remote Control supplied or panel to set up the camera type in the Input Settings menu
and save.
5. Next scroll down and choose your preferred display option, eg, PIP Settings for Picture-In-Picture.
6. For picture in picture select the camera number you wish to appear as the main screen image as
“Main Channel”and the inset camera as“Sub Channel”and save.
7. For further setting including brightness and contrast, please refer to the online instruction manual
at www.handyquad.com
4 Monitor Outputs
x2 BNC, x1 HDMI, x1 VGA
4 Camera Inputs
All HD-TVI, AHD & Analogue compatible
