System Sensor RTS151KEY User manual

1 I56-0758-016
06-10
SPECIFICATIONS
Dimensions: 4.6˝ H × 2.75˝ W × 1.8˝ D
Weight: 0.24 Lbs.
Power Requirements
Power LED (Green): 14 – 35 VDC, 12 mA maximum
Alarm LED (Red): 2.8 – 32 VDC, 12 mA maximum
Alarm Response Time: 40 seconds maximum
Temperature: –10°C to 60°C (14°F to 140°F)
Humidity: 95% relative humidity, noncondensing Max
Listing: UL, FM, CE
RTS151KEY(A)
Remote Test Station
INSTALLATION AND MAINTENANCE INSTRUCTIONS
I56-0758-016
3825 Ohio Avenue, St. Charles, Illinois 60174
1.800.SENSOR2; Fax: [phone]
www.systemsensor.com
NOTE: RTS151KEY(A) replaces RTS451KEY.
NOTICE: This manual shall be left with the owner/user of this equipment.
NOTE: A test coil is required only for use with D2/DNR/DH400/DH500 mod-
els.
For D2 models order part # DCOIL. For DH400/500 models order part #Coil.
GENERAL INFORMATION
The System Sensor RTS151KEY(A) is an automatic fire detector accessory de-
signed to test remotely located duct and beam detectors. For 4-wire detec-
tors, the RTS151KEY(A) features a multi-colored LED that alternates between
steady green and red. Green indicates power and that the detector board is
in place. Red indicates alarm. For 2-wire detectors, the LED will show red for
alarm. Consult the detector installation instructions for additional informa-
tion.
The National Fire Protection Association has published codes, standards, and
recommended practices for the installation and use of this product. It is rec-
ommended that the installer be familiar with these requirements, with local
codes, and any special requirements of the local authority having jurisdiction.
RTS151 CONTENTS
1 RTS151KEY(A) remote test station
1 screw pack (2 mounting screws)
2 Keys
OPERATION
Test Function
Insert the key and turn clockwise to the “TEST” position.
Alarm Indication
With the key in the “TEST” position, some time will elapse (40 seconds maxi-
mum) depending on the detector type, before the alarm indicating LED will
turn red.
Reset Function
Turn the key counterclockwise to the “RESET” position and hold. The LED
should turn off. Then, turn the key back to the “NORMAL” position and re-
move. The RTS151KEY(A) is capable of resetting only certain models of detec-
tors. Refer to the detector installation instructions for additional information.
Wiring Instructions
Consult the appropriate detector installation instructions for the applicable
wiring diagram. The RTS151KEY(A) mounts to a single gang box (2 1/2˝ mini-
mum depth), or directly to the wall or ceiling.
In Canadian applications, the RTS151KEY(A) is intended to be located in the
same room as the smoke detector and within 60 feet of the unit.
H0195-01
H0582-21
FIGURE 1. RTS151KEY(A)
FIGURE 2: WIRING DIAGRAM FOR RTS151KEY(A) TO D4120 4-WIRE
DUCT SMOKE DETECTOR:
19
20
15
2
6
1
5
4
3
D4120
RTS451KEY(A)
(GREEN LED)
POWER
(RED LED)
ALARM
FIELD
INSTALLED
JUMPER
11
2
AUX OUT +
AUX OUT –
ALARM
R TEST
R RESET
14
3
SUP, NO
SUP, C
* Sup. contacts cannot be used if they are wired to control panel.
*
FIGURE 3: WIRING DIAGRAM FOR RTS151KEY(A) TO DNR 2-WIRE DUCT
SMOKE DETECTOR WITH REMOTE TEST CAPABLE HEAD:
H0633-00
RTS451/RTS451KEY
RTS151/RTS151KEY
JUMPER
4
5
3
2
1
TEST COIL +
TEST COIL –
COMM +
OUT
(CONV ONLY) +
COMM –
RA/RTS –
RA +
RTS +

2 I56-0758-016
©2016 System Sensor. 06-10
FIGURE 4: WIRING DIAGRAM FOR RTS151KEY(A) TO D2 2-WIRE DUCT SMOKE DETECTOR:
H0612-12
24 VAC (+10%, –15%)
FULL WAVE RECTIFIED,
UNFILTERED POWER
MAY BE USED
RTS151KEY(A)
(OPTIONAL) REMOTE
TEST STATION
MAGNET
TEST
SWITCH
ALARM
LED (RED)
4
5
2
1(+)
(–)
+ RA
+ RTS
– RA
+ TEST COIL
– TEST COIL
+ IN
+ OUT
–
(–)
(+)
D2
24 VDC
AUX POWER
SUPPLIED
BY USER
(100mA
SUPPLY)
RTS151KEY(A)
(OPTIONAL) REMOTE
TEST STATION
24 VAC (+10%, –15%)
FULL WAVE RECTIFIED,
UNFILTERED POWER
MAY BE USED
MAGNET
TEST
SWITCH
ALARM
LED (RED)
4
5
2
1(+)
(–)
+ RA
+ RTS
– RA
+ TEST COIL
– TEST COIL
+ IN
+ OUT
–
24 VDC
AUX POWER
SUPPLIED
BY USER
(100mA
SUPPLY)
D2
NOTE: THE USE OF THE RTS151KEY(A) REQUIRES THE INSTALLATION OF
AN ACCESSORY COIL, DCOIL, SOLD SEPARATELY.
METHOD #1 - AUX POWER LOCATED
AT DUCT DETECTOR
METHOD #2 - AUX POWER LOCATED
AT TEST STATION
FIGURE 5. WIRING DIAGRAM FOR RTS151KEY(A) TO DH100ACDC
4-WIRE DUCT SMOKE DETECTOR:
FIGURE 6. WIRING DIAGRAM FOR RTS151KEY(A) TO DH100 2-WIRE
DUCT SMOKE DETECTOR:
NOTE: Terminal 6 of the RTS151KEY(A) is not used when wired to a 2-wire detector.
15
19
14
3
20
2
11
2
6
1
Alarm Signal
Aux. Power +
Sup. N. O.
Sup. COM
Aux. Power “
Reset
Test
(Red LED) Alarm
(Green LED)
Power
DH100ACDCLP RTS151KEY(A)
5
4
3
*
* Sup. contacts cannot
be used if they are
wired to control panel.
1
2
3
4
5
6
3
4
5
Test +
Test / Reset –
Reset +
Test
Reset
RA +
RA –
V Out +
DH100 RTS151KEY(A)
6
2
1Alarm
LED
No Connection
H0193-05
H0156-08
THREE-YEAR LIMITED WARRANTY
System Sensor warrants its enclosed product to be free from defects in materials and
workmanship under normal use and service for a period of three years from date of
manufacture. System Sensor makes no other express warranty for the enclosed product.
No agent, representative, dealer, or employee of the Company has the authority to in-
crease or alter the obligations or limitations of this Warranty. The Company’s obligation
of this Warranty shall be limited to the replacement of any part of the product which is
found to be defective in materials or workmanship under normal use and service during
the three year period commencing with the date of manufacture. After phoning System
Sensor’s toll free number 800-SENSOR2 (736-7672) for a Return Authorization number,
send defective units postage prepaid to: Honeywell, 12220 Rojas Drive, Suite 700, El Paso
TX 79936, USA. Please include a note describing the malfunction and suspected cause
of failure. The Company shall not be obligated to replace units which are found to be
defective because of damage, unreasonable use, modifications, or alterations occurring
after the date of manufacture. In no case shall the Company be liable for any consequen-
tial or incidental damages for breach of this or any other Warranty, expressed or implied
whatsoever, even if the loss or damage is caused by the Company’s negligence or fault.
Some states do not allow the exclusion or limitation of incidental or consequential dam-
ages, so the above limitation or exclusion may not apply to you. This Warranty gives you
specific legal rights, and you may also have other rights which vary from state to state.
FIGURE 7. WIRING DIAGRAM FOR RTS151KEY(A) TO DH400ACDC DUCT
SMOKE DETECTOR:
5
7
11
10
6
3
4
2
6
1
Alarm Signal
Aux. Power +
Sup. N. O.
Sup. COM
Aux. Power –
Reset
Test
(Red LED) Alarm
(Green LED)
Power
DH400ACDC RTS151KEY(A)
5
4
3
*
* Sup. contacts
cannot be used if
they are wired to
control panel.
H0156-09
FIGURE 8. WIRING DIAGRAM FOR RTS151KEY(A) TO BEAM1224/
BEAM1224T SMOKE DETECTOR:
H0585-04
1
2
3
4
5
3
2
1
5
4
RTS151KEY(A)BEAM1224/BEAM1224T
REMOTE ALARM OUT
AUX (–)
TEST INPUT
REMOTE TROUBLE OUTPUT
RESET INPUT
TEST
RESET
T2-3
T3-3
T2-4
T2-2
T2-1
OPTIONAL YELLOW LED
NOTE: R
TS151KEY(A) CAN BE USED WITH INTELLIGENT BEAM DETECTOR PRODUCTS.
CONSUL
T INTELLIGENT BEAM DETECTOR MANUAL FOR ADDITIONAL INSTRUCTIONS
(RED LED) ALARM
