Tait TB7100 Install guide

Multitone paging Interface
Fitting Instruction
MAF-02731-01-01
Issue 1
July 2008

2Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
Contents
1.1 Personal Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Equipment Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Tools and Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Parts Required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.5 Disassembly and Reassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.6 Programming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.7 Set-up Tx Channel Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.8 Set-up Programmable Audio I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.9 Set-up Programmable Digital I/O. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.10 Program Key Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.11 Transmit Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.12 Set Fan Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.13 User Interface Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.14 Final System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.15 Final Reassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Associated Documentation
MAS-02731-01-xx Multitone Paging Transmitter Service Manual
AllavailableMultitonePagingInterface/Transmitterdocumentationis TaitWorldSupportwebsite.
Consult your nearest Tait Dealer or Customer Service Organisation for more information
Tuning and Configuration
Once the Multitone Paging Interface is fitted, you will need to tune the base station before
operating it. To do this you will need to use the Calibration and Program Application software to
configure your base station to suit the requirements of your radio system. Refer to the Calibration
Application and Program Application documentation for full details on these procedures. The
Calibration and Programming Software will be available from the TaitWorld Support web site.

Multitone PagingInterfaceFitting Instruction 3
© Tait Electronics Limited July 2008
This section describes how to fit a Multitone Paging Interface into a
TB7100 base station (DC and no duplexer fitted). It also provides some
generalinformationonsafetyprecautionsandMultitonePagingTransmitter
set-up. We recommend that you read the entire chapter before beginning
the fit out.
1.1 Personal Safety
1.1.1 Proximity to RF Transmissions
Donotoperatethetransmitterwhensomeoneisstandingwithin90cm(3ft)
of the antenna. Do not operate the transmitterunless you have checked that
all RF connectors are secure.
1.1.2 High Temperatures
Take care when handling a TB7100 base station which has been operating
recently. Under extreme operating conditions (+60°C [+140°F] ambient
airtemperature)orhighdutycyclestheexternalsurfacesoftheTB7100 base
station can reach temperatures of up to +80°C (+176°F).
1.2 Equipment Safety
1.2.1 ESD Precautions
Important This equipment contains devices which are susceptible to
damage from static charges. You must handle these devices
carefully and according to the procedures described in the
manufacturers’ data books.
We recommend you purchase an antistatic bench kit from a reputable
manufacturer and install and test it according to the manufacturer’s
instructions. Figure 1.1 shows a typical antistatic bench set-up.
Youcanobtainfurtherinformationonantistaticprecautionsandthedangers
of electrostatic discharge (ESD) from standards such as ANSI/ESD
S20.20-1999 or BS EN 100015-4 1994.

4Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
1.3 Tools and Equipment
Torque-drivers The following torque-drivers are required.
■Philips #2 bit
■PZ1 and PZ2 Pozidriv bit
■Torx T10 bit
Refer to the illustrations in “Disassembly and Reassembly” on page 5 for
the corresponding torque values.
Card Remover Tool To remove the UI board, it is recommended to use the card remover tool
(220-02034-xx) included in the TBA0ST2 tool kit.
Test Equipment The following test equipment is required:
■test PC
■calibration and test unit (CTU) (TBA0STU)
■TB7100 CTU adapter (TBB0STU-TBB, included in TBA0STU)
■TMAA20-04 cable (RJ12 socket to RJ45 plug, included in TBB0P00)
■T2000-A19 cable (included in TBB0P00, or TPA-SV-006)
■RF communications test set (audio bandwidth of at least 10kHz)
■oscilloscope
■multimeter
■function generator
■DC power supply (capable of 13.8V and 10A for 25W base stations, and
20A for 50W/40W base stations)
The standard test setup is illustrated in the service manual MAS-02731-01-
xx.
Figure 1.1 Typical antistatic bench set-up
commonpointground
(building ground or
mains ground via 1M
ohm series resistor)
conductive wrist strap dissipative rubber
bench mat

Multitone PagingInterfaceFitting Instruction 5
© Tait Electronics Limited July 2008
Programming and
Calibration
Software
InstalltheTB7100programmingandcalibrationapplicationsonthetestPC.
These applications are available from the TaitWorld support web site.
1.4 Parts Required
Before beginning the fitting procedure gather the following parts.
1.5 Disassembly and Reassembly
This section describes how to:
■remove and open and close the base station
■remove and fit the modules
General Important Before disassembling the base station, disconnect the base
station from any test equipment or power supply.
Disassemble only as much as necessary to fit the new modules.
Observe the torque settings indicated in the relevant figures.
Important To ensure adequate airflow through the base station, do not
cover thefan intake grill on the front panel.Do not operate
for more than a few minutes with the fan intake covered.
Qty IPN IPN Description Use
1 219-03186-00 CBL assy 16Way IDC to 15Way D-
Range 240mm Paging interface PL100A to transmitter module D-range
1 219-03187-00 CBL assy IDC 16Way to 16Way
190mm Paging interface PL101A to SI board J101
1 219-03188-00 CBL assy 18Way Ribbon IDC skt to m/
m Paging interface PL2 to UI board
1 219-03189-00 CBL assy 12Way m/m to m/m
130mm EMC board to paging interface SK101
1 302-00026-00 BRKT mtg PCB TB7100 Bracket for mounting paging interface
board
1 303-23055-00 CVR plt A4M955 N conn Blanking panel for rear panel Rx
connector
1 316-85159-00 PLT 9w drng TB7100 pocsag Tx Mounting plate and label for EMC board
1 365-01891-00 LBL frt pnl TB7100 multitone Front panel label
1 XA2235-02-PCB 9WayD-Range/MMatch Decoupling EMC board
1 XA2731-01-PBA PBA Multi Tone Interface TB7100 Paging interface board
3 349-02061-00 SCRW M3x6 P/H T10 BZ T/T CRL Screw for bracket
2 352-00010-28 NUT M3 Nyloc hex For blanking panel
2 354-01043-00 FSTNR scrw Lock 4-40 For mounting EMC board
5 369-00010-14 CBL tie nyl 140x2.6mm Fixing down cables

6Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
Saving the Base
Station
Configuration
Before replacing a module in the base station, you should decide whether
you need to save its configuration data. If you are unsure whether you have
a record of the configuration, use the Programming Application to read the
base station and save the configuration files before removing any modules.
Once you have replaced the module, you will be able to restore the original
configuration by programming the saved configuration back into the base
station.
1.5.1 Removing the Multitone Paging Transmitter
Important The modules in the Multitone paging transmitter are not
hot-pluggable. It is recommended the tray is removed from
the rack before any modules are removed.
1. Remove the fusee at the rearof the Multitone paging transmitterto
disconnect the Multitone paging transmitter from DC power.
2. Use a Philips #2 screwdriver to disconnect the cables from the DC
power connector f.
3. Disconnect the antenna connectors d.
4. Disconnect any other connectors.
5. Disconnect the ground cable from the ground point c.
6. Use a PZ2 Pozidriv screwdriver to remove the four M6 screws, and
remove the Multitone paging transmitter from the rack.
7. Use a Torx T10 screwdriver to remove from the cover the 15
countersunk screws. Remove the tray cover b.
Figure 1.2 Opening the tray
b
e
f
d
c

Multitone PagingInterfaceFitting Instruction 7
© Tait Electronics Limited July 2008
1.5.2 Removing the UI Board
1. Remove the volume knob by pulling slowly but firmly. The knob is
a friction fit and can leave the collet behind on the shaft. If this
happens, remove the collet from the shaft and place inside the knob.
2. Disconnect the speaker connector b.
3. Use a Torx T10 screwdriver to remove the three screws ctogether
with the spring washers and flat washers.
4. Insert the card remover tool (220-02034-xx) from the tool kit
(TBA0ST2), or a small flat-bladed screwdriver into the two small
holes at the bottom of the UI board. Lever the board completely off
the spring clips d.
5. Carefully slide the UI board towards the rear of the Multitone paging
transmitter until the volume-control shaft clears the front panel. Lift
the UI board clear of the chassis.
6. Disconnectcablerunningfromthe receivermoduletooneofthetwo
Micro-MaTch connectors e.
7. Keep the UI board disassembled until “Refitting UI board” on
page 14.
1.5.3 Removing the Receiver Module
1. Disconnect the cables to the RF b, DC power c, system interface
d, and the user interface econnectors.
2. Remove the Rx RF cable, connected to b (219-02978-00 CBL
coax 400Ntype pnl skt BNC) from the rear panel. Place the cable
aside.
3. Fit the blanking panel (303-23055-00 CVR plt A4M955 N conn) to
t h e i n s i d e o f t h e c h a s s i s c o v e r i n g t h e n e w R x h o l e i n t h e r e a r p a n e l .
Figure 1.3 Removing the UI board
e
d
c
b
Cables not shown.
Torx T10
4.5lb·in (0.5N·m)

8Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
4. Secure the panel in place using two M3 Nyloc nuts (352-00010-28
NUT M3 Nyloc hex), torque to 50cm.N (4.5in-lbs).
5. Use a Torx T10 screwdriver to remove the five screws fand g
together with the spring washers and flat washers, put to one side.
6. Lift the receiver module clear of the chassis, put to one side.
7. Remove the metal heatsink gfor the audio PA, put to one side.
8. Put all the removed items into a plastic bag and retain as spares.
Note Although the boards of the transmitter and receiver modules look
alike, the transmitter board cannot be used in the receiver module
and the receiver board cannot be used in the transmitter module.
There is no heat transfer plate on the receiver module. Similar
boards from the Tait mobile radio range cannot be used as replace-
ments either.
1.5.4 Modifying the SI Board
Removal 1. Disconnect the system interface cables eto the transmitter and the
receiver,thefancontrolcablef,thetemperaturesensor cableg, and
move them to one side.
2. Remove the DC power cables hand iand put the cable connected
to hto one side. Move the cable connected to ito one side.
Note the connection position for i.
3. Removethe cable ties securing the cables that were connected toDC
power
c,systeminterfaced,andtheuserinterfaceec on ne ct or s.
Figure 1.4 Removing the receiver module
f
g
e
bcd
f
Torx T10
4.5lb·in
Torx T10
4.5lb·in
h

Multitone PagingInterfaceFitting Instruction 9
© Tait Electronics Limited July 2008
4. Remove the cables originally connected to the receiver module, and
User interface and put them to one side.
5. Retain the receiver DC power cable and place in the bag used above.
6. Use a Torx T10 screwdriver to remove the two screws 1).
Use a PZ1 Pozidriv screwdriver to remove the screw jon the
heatsink of U406.
7. Carefully lift the front of the SI board off the spring clips 1!.
8. Carefully slide the SI board towards the front of the base station until
the connectors b, cand dclear the rear panel. Lift the SI board
clear of the chassis.
Modify 1. Remove Item J104 d(240-00010-45,SKT 9wy drng 90° PCB mtg)
and put aside.
2. For XBBS104 SI Board, PCB=220-02077-06 and later, place the
links in the following positions.
3. Park Links: W300, W301, W302, W401, W402
4. Insert Links: J400 (1-2), J401 (1-2), J507 (1-2), J500 (2-3), J503 (1-
2), J502 (2-3), J501 (1-2), J206 (1-2), J207 (2-3), J221 (1-2).
Fitting 1. Slidethe SIboardintothetray chassisbyfittingthe connectorsband
cinto the rear panel.
2. Press down firmly on the front of the SI board to engage the two
spring clips 1!.
Important Make sure that the thermal pad is fitted under and the
plastic insulating washer is fitted on U406.
Figure 1.5 Modifying the SI board
g
h
bc d
Torx T10
4.5lb·in
1) 1)
j
1!
1! ef
PZ1
4.5lb·in
Cables not shown.
i

10 Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
3. Use a torque-driver to fasten the two screws 1) (Torx T10) and the
screw j(PZ1) on the heatsink of U406 to 4.5lb·in (0.5N·m).
4. Refitthe transmitter power cable to the SI boardterminals i, the fan
control cable f, and the temperature sensor cable f.
5. Put all removed items into a plastic bag and retain for spares.
1.5.5 Fitting the EMC Board
1. Locate these items:
b316-85159-00, 9-way D-range plate.
cXA2235-02-PCB, EMC board.
d2 x 354-01043-00, screw lock 4-40 fastener.
e2 x 352-00010-28, M3 Nyloc hex nut.
2. Fit the XA2235-02-PCB cas shown below with the Micro-MaTch
connector facing up.
3. Ensure the FSK ENCODER plate bis sittinglevel and the text is on
the outside. Torque Fasteners dand Nyloc nuts eto 50cm.N
(4.5in-lbs).
Figure 1.6 Fitting the SI board
bc
Torx T10
4.5lb·in
j
1!
PZ1
4.5lb·in
Cables not shown.
1)
f
g
i

Multitone PagingInterfaceFitting Instruction 11
© Tait Electronics Limited July 2008
1.5.6 Fitting the Bracket
1. Locate these items:
b302-00026-00 Multitone paging interface bracket.
c3 x 349-02061-00 M3x6 panhead T10 screws.
2. Fit the bracket bas shown below. One corner clips under a hook in
the chassis. The three screws care fitted and torqued to 50cm.N
(4.5in-lbs).
Figure 1.7 Fitting the EMC board
b
c
Hex
4.5lb·in d
Cables not shown.
e
Figure 1.8 Fitting the bracket
bc
Torx T10
4.5lb·in
Cables not shown.
c

12 Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
1.5.7 Fitting the Paging Interface Board
1. Locate the following items:
b XA2731-01-PBA Multitone paging interface.
2. Place the board bin position on the bracket das shown below,
ensure the connectors are in the position shown below.
3. Press down firmly on the front and rear of the paging interface board
bto engage the four spring clips c.
4. Ensure the shorting links W1.1 and W2.1 are fitted to the Multitone
paging interface board b as shown below.
Figure 1.9 Fitting the Paging Interface board
Figure 1.10 Setting the Paging Interface board links
b
c
d
c
c
3V3 OUTPUT
W2
NON-INV
W1
5V OUTPUT
INVERTED
DATA POLARITY
W2.1
W1.1

Multitone PagingInterfaceFitting Instruction 13
© Tait Electronics Limited July 2008
1.5.8 Connecting the Cables
1. Locate the following items:
e219-03186-00 Cable 16Way IDC to 15Way D-Range 240mm.
f219-03187-00 Cable IDC 16Way to 16Way 190mm.
b219-03188-00 Cable 18Way Ribbon IDC skt to m/m.
h219-03189-00 Cable 12Way m/m to m/m 130mm.
2. Ensure the cable gfrom the transmitter to the user interface is still
fitted.
3. Ensure the power cable ifromthe transmitter to the SI board is still
fitted.
4. Ensure the RF cable cfrom the transmitter to the rear panel is still
fitted.
5. Ensure the fan power cable dfrom the SI board to the fan module is
still fitted.
6. Fit the cable bto the user interface Micro-MaTch connector where
the user interface to SI board cable was removed from. Fit the other
end to the Multitone paging interface board PL2 as shown below.
7. Fit the cable hfrom the EMC board to the paging interface board
SK101 as shown below.
8. Fit the cable ffrom the SI board J101 to the paging interface board
PL101A as shown below.
9. Fit the cable efrom the paging interface board PL100A to the
transmitter module’s D-range as shown below.
Figure 1.11 Fitting the cables
H
F
E
B
G
C
D
I
I
D

14 Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
Refitting UI board 1. Plug the two Micro-MaTch connectors einto the UI board.
The Micro-MaTch connector for the transmitter is closest to the
edge of the UI board.
2. Align the volume-control shaft with the hole in the front panel, also
align the programming/microphone connector and function buttons
as the board is slid into place.
3. Gently slide the UI board into position so that the spring clips dare
engaged. Press firmly around the spring clips to ensure they are
engaged fully.
4. Use a Torx T10 screwdriver to fasten the three screws cto 4.5lb·in
(0.5N·m).
5. Plug the speaker connector binto the UI board.
6. On the front panel peel off the two decals and fit the new Multitone
label (365-01891-00).
7. Fit the volume knob onto the shaft and press firmly until fully seated.
8. Using the cable ties (369-00010-14) fix down the cables.
1.6 Programming
1. Run the TB7100 programming application (PGM) version 1.14.00
or later. Select radio model as TB7100 Tx.
Figure 1.12 Removing the UI board
e
d
c
b
Cables not shown.
Torx T10
4.5lb·in (0.5N·m)

Multitone PagingInterfaceFitting Instruction 15
© Tait Electronics Limited July 2008
1.7 Set-up Tx Channel Configuration
1. Program the radio using the front panel RJ45 (PROG/MIC)
programming port and the TX/RX switched to Tx.
2. In the PGM Specifications form select the band that is being built.
3. In the Channels form set up the channels as required.
Note Note: frequency will changeaccording to the radio band,e.g.H5,
6,7 will be 460.1MHz and B1 will be 160.1MHz. (25kHz band-
width, country squelch for all)
1.8 Set-up Programmable Audio I/O
1. On the Programmable I/O form in the Audio tab set as per the fol-
lowing table.
1.9 Set-up Programmable Digital I/O
1. On the Programmable I/O form in the Digital tab set as per the fol-
lowing table.
Rx/PTT Type Tap In Tap In Type Tap In
Unmute Tap Out Tap Out Type Tap Out Unmute
Rx None A-Bypass In On PTT None D-Split On PTT
Mic PTT None A-Bypass In On PTT None C-Bypass Out On PTT
EPTT1 T12 A-Bypass In On PTT None C-Bypass Out On PTT
EPTT2 None A-Bypass In On PTT None C-Bypass Out On PTT
Pin Direction Label Action Active Debounce Signal
State Mirrored To
AUX_GPI1 Input RT_DI_1 BCD Pin 0 Low 10 None None
AUX_GPI2 Input RT_DI_2 BCD Pin 1 Low 10 None None
AUX_GPI3 Input RT_DI_3 External PTT 2 Low 10 None None
AUX_GPIO4 Output HI_VSWR F2 Key Status High None Momentary None
AUX_GPIO5 Output OOL F3 Key Status High None Momentary None
AUX_GPIO6 Output HI_TEMP F4 Key Status High None Momentary None
AUX_GPIO7 Input TXKEY External PTT 1 Low 2 None None
IOP_GPIO1 None PIN_9 No Action High None None None
IOP_GPIO2 None PIN_10 No Action High None None None
IOP_GPIO3 None PIN_11 No Action High None None None
IOP_GPIO4 None PIN_12 No Action High None None None
IOP_GPIO5 None PIN_13 No Action High None None None
IOP_GPIO6 None PIN_14 No Action High None None None
IOP_GPIO7 None PIN_15 No Action High None None None
CH_GPIO1 None C_HEAD No Action High None None None

16 Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
1.10 Program Key Settings
1. On the Key Settings form set the keys as per the following table
1.11 Transmit Tests
Note Ensure W401 and W402 jumpers on the SI board are parked
before continuing.
Note A functiongeneratorwill be requiredto generate the squarewaves
the Multitone paging interface expects to receive.
1. On a communications test set Monitor RF on the transmit channel.
2. Connect the Multitone paging transmitter system connector directly
to the CTU using the standard cable.
3. Connect a multimeter between earth and J3 onthe Multitone paging
interface board. Adjust RV1 on the Multitone paging interface for
1.5VDC.
4. Connect the function generator to to pin 3 of the FSK ENCODER
9-way D-range. Inject5V p-p square wave at 256Hz onpin 3 andkey
Key Action
Key 1 Backlighting Toggle
Key 2 Action Digital Output Line
Key 3 Action Digital Output Line
Key 4 Action Digital Output Line
Figure 1.13 Link positions on the SI board
J400J500 J502J503
J207
W40
W40
J206
J507
J501
PCB version 220-02077-06
J401

Multitone PagingInterfaceFitting Instruction 17
© Tait Electronics Limited July 2008
the transmitter using the TX key on the CTU. Adjust RV2 on the
Multitone paging interface for 4.5kHz (WB) deviation.
1.12 Set Fan Voltage
1. On the SI board connect a multimeter between earth and J222.
Adjust RV200 for 1.4V DC (see “Link positions on the SI board” on
page 16).
1.13 User Interface Check
1. Check both Chassis fans are in operation.
2. Check LED operation: Power, TX.
3. Check F1- Toggles back light.
4. Check that F2-F4 LED's on the front panel turn on when the
corresponding function button is pressed.
5. Check CTU digital input and LCD. Use switches 1 and 2 only.
Figure 1.14 Paging Interface Board Test points
3V3 OUTPUT
W2
NON-INV
W1
5V OUTPUT
INVERTED
DATA POLARITY
W2.1
W1.1
J3

18 Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
6. Check the RJ45 communications using the TB7100 programming
application to interrogate the Tx.
1.14 Final System Check
1. Set the default options on the Programmable I/O form in the Digital
tab set as per the following table.
2. Enable the following Digital Action Parameters: Alarm on Out Of
Lock, Alarm on High Temperature, Alarm on Very High
Temperature and Alarm on High Reverse Power.
3. Set all Key Settings to none.
4. On the SI board place W300 (Tx / Rx GPIO 5) Link (“Link
positions on the SI board” on page 16.
Pin Direction Label Action Active Debounce Signal
State Mirrored To
AUX_GPI1 Input RT_DI_1 BCD Pin 0 Low 10 None None
AUX_GPI2 Input RT_DI_2 BCD Pin 1 Low 10 None None
AUX_GPI3 Input RT_DI_3 BCD Pin 2 Low 10 None None
AUX_GPIO4 Output HI_VSWR Alarm Status Low None None None
AUX_GPIO5 Output OOL Alarm Status Low None None None
AUX_GPIO6 Output HI_TEMP Alarm Status Low None None None
AUX_GPIO7 Input TXKEY External PTT 1 Low 2 None None
IOP_GPIO1 None PIN_9 No Action High None None None
IOP_GPIO2 None PIN_10 No Action High None None None
IOP_GPIO3 None PIN_11 No Action High None None None
IOP_GPIO4 None PIN_12 No Action High None None None
IOP_GPIO5 None PIN_13 No Action High None None None
IOP_GPIO6 None PIN_14 No Action High None None None
IOP_GPIO7 None PIN_15 No Action High None None None
CH_GPIO1 None C_HEAD No Action High None None None

Multitone PagingInterfaceFitting Instruction 19
© Tait Electronics Limited July 2008
1.15 Final Reassembly
1. Ensure all internal cables are connected correctly as shown below.
2. Place the tray cover onto the chassis.
3. Use a Torx T10 torque-driver to fasten the tray cover with the 15
countersunk screws to 4.5lb·in (0.5N·m).
4. Fit the fuse b at the rear of the Multitone paging transmitter.
Figure 1.15 Final reassembly
Fuse

20 Multitone PagingInterface Fitting Instruction
© Tait Electronics Limited July 2008
Tait Contact Information
Tait Radio Communications
Corporate Head Office
Tait Electronics Limited
P.O. Box 1645
Christchurch
New Zealand
For the address and telephone number of regional
offices, refer to the TaitWorld website:
Website: www.taitworld.com
Technical Support
For assistance with specific technical issues, contact
Technical Support:
E-mail: [e-mail]
Website: www.taitworld.com/technical
