Tait TB9300 User manual

TB9300 Base Station/Repeater
Specifications Manual
MBC-00009-26 · Issue 26 · August 2022

2TB9300 Specifications Manual
© Tait International Limited August 2022
Contact Information
Tait Communications
Corporate Head Office
Tait International Limited
P.O. Box 1645
Christchurch
New Zealand
Imported into the EU by:
Tait Communications GmbH
Stipcakgasse 40
1230 Vienna
Austria
Imported into the UK by:
Tait Europe Limited
Unit A, Buckingham Business Park, Anderson Road
Swavesey
Cambridge, CB24 4UQ
United Kingdom
For the address and telephone number of regional
offices, refer to our website:
www.taitcommunications.com
Copyright and Trademarks
All information contained in this document is the
property of Tait International Limited. All rights
reserved. This document may not, in whole or in part,
be copied, photocopied, reproduced, translated, stored,
or reduced to any electronic medium or machine-
readable form, without prior written permission from
Tait International Limited.
The word TAIT, TAITNET and the TAIT logo are
trademarks of Tait International Limited.
All trade names referenced are the service mark,
trademark or registered trademark of the respective
manufacturers.
By using a Tait product you are agreeing to be bound
by the terms of the Tait Software Licence Agreement.
Please read the Tait Software Licence Agreement
carefully before using this Tait product. If you do not
agree to the terms of the Tait Software Licence
Agreement, do not use the Tait Product. The full
agreement is available at
www.taitcommunications.com/our-resources/
legal#Tait_Software_Licence_Agreement.
Disclaimer
There are no warranties extended or granted by this
document. Tait International Limited accepts no
responsibility for damage arising from use of the
information contained in the document or of the
equipment and software it describes. It is the
responsibility of the user to ensure that use of such
information, equipment and software complies with the
laws, rules and regulations of the applicable
jurisdictions.
Enquiries and Comments
If you have any enquiries regarding this document, or
any comments, suggestions and notifications of errors,
please contact your regional Tait office.
Updates of Manual and Equipment
In the interests of improving the performance,
reliability or servicing of the equipment, Tait
International Limited reserves the right to update the
equipment or this document or both without
prior notice.
Intellectual Property Rights
This product may be protected by one or more patents
or designs of Tait International Limited together with
their international equivalents, pending patent or
design applications, and registered trade marks, for a
complete list please check
www.taitcommunications.com/our-resources/
legal#Intellectual_Property
Environmental Responsibilities
Tait International Limited is an
environmentally responsible company
which supports waste minimization,
material recovery and restrictions in the
use of hazardous materials.
The European Union’s Waste Electrical
and Electronic Equipment (WEEE)
Directive requires that this product be disposed of
separately from the general waste stream when its
service life is over. For more information about how to
dispose of your unwanted Tait product, visit the Tait
WEEE website at www.taitcommunications.com/our-
resources/compliance#WEEE. Please be
environmentally responsible and dispose through the
original supplier, or contact Tait International Limited.
Tait will comply with environmental requirements in
other markets as they are introduced.

TB9300 Specifications Manual Contents 3
© Tait International Limited August 2022
Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Scope of Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Associated Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Publication Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1 Base Station Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.2 Frequency Bands and Sub-bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.3 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.4 Power and Current Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.4.1 120VAC Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.4.2 230VAC Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.4.3 12VDC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
1.4.4 24VDC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1.4.5 48VDC Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
1.5 Receiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
1.6 Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
1.7 Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
1.7.1 Requirements for Delay, Jitter, Loss and Duplication . . . . . . . . . . . . . . . . . . 36
1.7.2 Channel Group Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
1.7.3 Digital Air Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
1.8 System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
1.8.1 External Frequency Reference Input (BNC). . . . . . . . . . . . . . . . . . . . . . . . . . 38
1.8.2 Ethernet Interface (RJ45) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
1.8.3 System Interface (DB-25). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
1.8.4 Balanced Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
1.8.5 Audio Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1.8.6 Rx Gate Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1.8.7 RSSI Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
1.8.8 Antenna Relay Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
1.8.9 Tx Key Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
1.8.10 1PPS Timing Reference Input (BNC). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
1.9 Miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
1.9.1 Channel Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
1.9.2 Duplexer Attenuation Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
1.9.3 Operating Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
1.9.4 Heat Load Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
1.9.5 Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

4 Contents TB9300 Specifications Manual
© Tait International Limited August 2022
1.9.6 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
2 Module Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
2.1 Reciter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
2.1.1 Identifying the Reciter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
2.1.2 Physical Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
2.2 PA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
2.2.1 Identifying the PA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
2.2.2 Physical Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
2.3 PMU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
2.3.1 Identifying the PMU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
2.3.2 Physical Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
2.3.3 Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
3 Compliance Standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Appendix A Frequency Response Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

TB9300 Specifications Manual Preface 5
© Tait International Limited August 2022
Preface
Scope of Manual
Welcome to the Specifications Manual for the TB9300 base station. This
manual provides general, performance, and physical specifications for the
TB9300 Rx only (when no PA is available), TB9300 50W and 100W base
stations.
In the following, unless mentioned specifically, this manual will use the
term “base station” to mean both base station and repeater.
Document Conventions
Within this manual, four types of alerts may be given to the reader. The
following paragraphs illustrate each type of alert and its associated symbol.
Warning This alert is used when there is a hazardous situation
which, if not avoided, could result in death or serious injury.
Caution This alert is used when there is a hazardous situation which,
if not avoided, could result in minor or moderate injury.
Notice This alert is used to highlight information that is required to
ensure procedures are performed correctly. Incorrectly performed pro-
cedures could result in equipment damage or malfunction.
This icon is used to draw your attention to information that may
improve your understanding of the equipment or procedure.

6 Preface TB9300 Specifications Manual
© Tait International Limited August 2022
Associated Documentation
The following associated documentation for this product is available on the
Tait Partner Portal website (https://partnerinfo.taitradio.com).
■TB9300 Installation and Operation Manual (MBC-00008-xx)
■TN9300 DMR Tier 2 Conventional Radio Network System Manual
(MNB-00005-xx)
■TN9300 DMR Tier 3 Trunked Radio Network System Manual
(MNB-00003-xx)
■Tait Core Networks Installation and Configuration Manual (MNB-
00012-xx)
■Safety and Compliance Information (MBA-00012-xx)
■DMR Channel Group System Manual (MNB-00010-xx)
The characters xx represent the issue number of the documentation.
Technical notes are also published from time to time to describe
applications for Tait products, to provide technical details not included in
manuals, and to offer solutions for any problems that arise. For more
information contact your regional Tait office.

TB9300 Specifications Manual Preface 7
© Tait International Limited August 2022
Publication Record
Issue Publication Date Description
26 August 2022 Updated for release 3.35 and later
■“Regulatory Information” on page 10 updated
■“Frequency Bands and Sub-bands” on page 10 updated
■“Receiver” on page 26 frequencies updated
■“Digital RF” on page 27 updated
■“Transmitter” on page 31 frequencies updated
25 April 2022 Updated for 3.30 release and later
■Minor updates
■“Requirements for Delay, Jitter, Loss and Duplication” on page 36
minimum bandwidth updated
24 November 2021 Updated for 3.25 release
■“Channel Details” on page 43 updated
23 May 2021 Changes for 3.20 release
■Simplex content added
■Receiver “Analog Audio - General” on page 29 updated
■Transmitter “Analog Audio - Modulation Characteristics” on page 34
updated
■“Antenna Relay Output” on page 41 added
22 November 2020 Changes for version 3.15 release
Minor updates throughout
Updated table in “Channel Group Size”
Major updates to compliance table
21 June 2020 Changes for version 3.10 release
Minor updates throughout
Compliance Standards table updated
Updated emission designators
20 November 2019 Changes for version 3.05 release
Minor updates throughout
Added typical digital unfaded sensitivity specs
Updated emission designators
Updated adjacent power and receive voter content
19 July 2019 Changes for version 3.00 release
Minor updates throughout
Updated System Interface (DB-25) input high threshold
18 March 2019 Changes for version 2.60 release
Analog line information added
Added Channel Group manual to associated documents
Added DMR Rx only base station to scope of manual
Added Isolation Off-state specification

8 Preface TB9300 Specifications Manual
© Tait International Limited August 2022
17 December 2018 Changes for version 2.55 release
Updated MTBF value
H4 band included
Analog line operation
Receiver disable function
16 July 2018 Changes for version 2.50 release
H5 band added.
Limiting deviation specifications updated.
General updates throughout.
15 March 2018 Changes for version 2.45 release
Publication Record has been switched so most recent changes appear at
the top
Under “Analog Audio - General”, ‘Limiting Deviation’ is now 73%
“Frequency Bands and Sub-Bands” updated for clarity
Issue Publication Date Description

TB9300 Specifications Manual Base Station Specifications 9
© Tait International Limited August 2022
1 Base Station Specifications
The performance figures given in these specifications are applicable only
to equipment operating as an integral part of a TB9300 base station. These
performance figures are minimum figures, unless otherwise indicated, for
equipment operating at standard room temperature (+22 °C to +28 °C
[+71.6 °F to +82.4 °F]) and standard test voltages as follows:
■AC power management unit (PMU) - 120 VAC and 230 VAC
■12 V DC PMU - 12 VDC
■24 V DC PMU - 24 VDC
■48 V DC PMU - 48 VDC.
The TB9300 is available in the following configurations:
■50 W single or dual base station with PMU
■100 W single base station with PMU.
■Rx only base station (when no PA is available)
Notice The software release notes list known issues or limitations of
the base station that may vary from the specifications published in this
document. Please refer to the current software release notes for any vari-
ations to the specifications in this document.

10 Base Station Specifications TB9300 Specifications Manual
© Tait International Limited August 2022
1.1 Regulatory Information
Test Methods Where applicable, the test methods used to obtain the specifications in this
document are described in the following standards:
■EN 300 086 (version 2.1.2)
■EN 300 113 (version 2.2.1)
■EN 300 219 (version 2.1.1)
■EN 301 929 Version 2.1.1)
■EN 301 489 (version 1.9.2)
■CFR Title 47 Part 15B
■CFR Title 47 Part 22, 90
■TIA/EIA-603/603-E
■AS/NZS 4295
■RSS-119
Emission
Designators
This equipment is compatible with the emissions listed in the following
table.
You can obtain further details on test methodology and conditions of
compliance testing in all countries from Tait.
1.2 Frequency Bands and Sub-bands
Many of the performance figures in this manual are applicable to all
frequency bands. In some cases the figures refer to specific bands or sub-
bands, and these are identified with the letters listed in the following table.
This table also indicates which base station configurations are currently
available in each frequency band.
Refer to “Compliance Standards” for details of which bands support which
air interfaces.
Emission Designator Common Name
Modulation
Scheme Operating Modes
7K60F2D MPT Control FFSK control channel/traffic channel data
8K00FXD or 7K60FXD 2-slot DMR 4FSK data/control channel
8K00FXD or 7K60FXW 2-slot DMR 4FSK digital voice/data/control channel

TB9300 Specifications Manual Base Station Specifications 11
© Tait International Limited August 2022
Note that the shaded areas denote frequencies that have reached end-of-life,
and whilst currently supported, are no longer available for the TB9300.
They are available for the TB9400, where B2 and B3 bands can be replaced
by the B1 band.
In Brazil, for K and L bands, the TB9300 is considered to be configured as
a base station with retransmission of receive frequencies.
Frequency
Identification Frequency Band and Sub-band 50W 100W
B band B2 = 136 MHz to 156 MHz
B3 = 148 MHz to 174 MHz
✓
✓
✓
✓
C band C1 = 174 MHz to 193 MHz
C3 = 216 MHz to 225 MHz
✓
✗
✗
✓
G band G4 = 330 MHz to 380 MHz ✓✗
H band H1 = 400 MHz to 440 MHz
H2 = 440 MHz to 480 MHz
H3 = 470 MHz to 520 MHz
H4 = 380 MHz to 420 MHz
✓
✓
✓
✓
✓
✓
✓
✓
H5 = 400 MHz to 470 MHz ✓✗
K band K4
Transmit: 762 - 776 & 850 - 870 MHz
Receive: 792 - 824 MHz
✓✓
K8
Transmit: 757 - 758 MHz
Receive: 787 - 788 MHz
✗✓
L band L2 = 896 MHz to 902 MHz (receive)
L2 = 927 MHz to 941 MHz (transmit)
✗
✗
✓
✓

12 Base Station Specifications TB9300 Specifications Manual
© Tait International Limited August 2022
1.3 Power Supply
The specifications in this section refer to the TB9300 base station fitted
with a PMU.
AC Input
Input
Voltage
Frequency
Power factor
Total harmonic distortion (THD)
Inrush current
230VAC
115VAC
Leakage current
88 VAC to 264 VAC
50 Hz to 60 Hz
> 0.95
< 8%
< 30 A @ < 4 ms
< 15 A @ < 4 ms
< 3.5 mA / 240 VAC
Protection
Fault current (input)
Transient suppression
Overvoltage inhibit (self recovering)
Undervoltage signal
10 A fuse
275 V MOV (line-to-line)
275 VAC ±10 V
83 VAC ±5 V
General
Input-to-chassis isolation
Output-to-chassis isolation
1500 VAC, 50 Hz, 1 minute
500 VAC, 50 Hz, 1 minute

TB9300 Specifications Manual Base Station Specifications 13
© Tait International Limited August 2022
DC Input
Input voltage
User-programmable alarmsa
Low battery voltage
High battery voltage
User-programmable limitsb
Startup voltage
(after shutdown)
Shutdown voltage
Battery protection (fail-safe) limitsc
Startup voltage
Undervoltage shutdown
Overvoltage shutdown
Overvoltage shutdown reset
12 V PMU
10 V to 14 V
14 V to 17.5 V
10.9 V to 15 ±0.3V
10 V to 13.5 V ±0.3V
10.8 V ±0.2 V
9.5 V ±0.3 V
18.1 V ±0.3 V
17.1 V ±0.3 V
24 V PMU
20 V to 28 V
28 V to 35 V
21.8 V to 30 V ±0.5V
20 V to 27 V ±0.5V
21.6 V ±0.5 V
19 V ±0.5 V
36.2 V ±0.5 V
34.2 V ±0.5 V
48 V PMU
40 V to 56V
56V to 70V
43.6 V to 60V ±1V
40V to 54V ±1V
43.2 V ±1 V
38 V ±1 V
72.4 V ±1 V
68.4 V ±1 V
a. User-programmable alarms can be set for low or high battery voltage, using the web interface. The alarms will be triggered
when the set voltage levels are reached. These limits are subject to the tolerances of the battery protection circuitry, as
stated in “Battery Protection (Fail-safe) Limits” above.
b. The user-programmable startup and shutdown limits allow for adjustable startup and shutdown voltages. Using the web
interface, these limits can be adjusted for different numbers of battery cells, or for the particular requirements of base station
operation. Once the limits are reached, the PMU will shutdown. These limits are subject to the tolerances of the battery
protection circuitry.
c. The battery protection limits are set in hardware at the factory and cannot be adjusted by the user. These limits will not be
reached under normal operation conditions, but are provided as “fail-safe” measures to protect the battery from deep
discharge.
Input current
0V to battery protection startup
voltaged
Battery protection startup voltage to
user-programmed startup voltagee
12 V
2 mA maximum
40 mA typical
at 10.8 V
24 V
2 mA maximum
30.1 mA typical
at 21.6 V
48 V
1.2 mA maximum
13.2 mA typical
at 43.2 V
Operating current refer to “Power and Current Consumption” on page 15
d. When the input voltage drops below the battery protection undervoltage shutdown limit, and until the voltage rises above the
battery protection startup voltage.
e. At initial power-up; or, after battery protection has occurred, when the input voltage rises above the battery protection startup
voltage (with the PMU now under control of its microcontroller), but is still below the user-programmed startup voltage
Protection
Fault current (input)
Wrong input voltage
Wrong input voltage polarity
circuit breaker or fuse in external wiringf
electronic lock-out
shunt diode
f. Provided by user.

14 Base Station Specifications TB9300 Specifications Manual
© Tait International Limited August 2022
Outputs
28 VDC output
Voltage
Current
Regulation
Ripple and noisea
Ripple and noise rms
Transient response on 28 V loadstepb
28 V
14 A maximum
±0.5%
50 mVpp
10 mVrms
2% overshoot and recover within 0.6 ms
a. 100 MHz bandwidth.
b. 10% to 100% loadstep.
Protection
Overload
Short circuit
Overvoltage
AC module
DC module
electronic current limit above 16 A
hiccup mode, self-resetting
electronic shutdown latch (33.5 V)
electronic hysteric control (33.5 V)
Auxiliary Power Supply
DC input voltage 28 V ±15%
DC output
Voltage
Current
Regulation
Ripple and noisea
Ripple and noise rms
Zero load ripple
12 V
13.65 V
3 A max
±2%
50 mVpp
10 mVrms
100 mVpp
24 V
27.3 V
1.5 A max
±2%
50 mV pp
10 mV rms
100 mVpp
48 V
54.6 V
750 mA max
±2%
50 mVpp
10 mVrms
100 mVpp
a. 100 MHz bandwidth.
Protection
Overload/short circuit
Overvoltage
12 V
electronic
current limit
16 V Zener diode
24 V
electronic
current limit
32 V Zener diode
48 V
electronic
current limit
62 V Zener diode
General
Input-to-output isolation
Output-to-chassis isolation
1000 VAC, 50 Hz, 1 minute
500 VAC, 50 Hz, 1 minute

TB9300 Specifications Manual Base Station Specifications 15
© Tait International Limited August 2022
1.4 Power and Current Consumption
The specifications in this section refer to the TB9300 base station fitted
with a PMU. Listed performance figures are typical.
The transmission measurements were taken when the base station was
transmitting at the stated RF output power, with all the front panel fans
running.
The standby measurements were taken when the base station was not
receiving or transmitting, with no front panel fans running.
All measurements were carried out with no load on the auxiliary power
supply.

16 Base Station Specifications TB9300 Specifications Manual
© Tait International Limited August 2022
1.4.1 120VAC Input
Transmit
AVAW
B Band
Single 50W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
825 mA
1.5 A
99 VA
175 VA
92 W
171 W
Dual 50 W base stationa
Minimum RF output power (5 W)
Maximum RF output power (50 W)
1.3 A
2.7 A
154 VA
321 VA
149 W
319 W
a. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
1.2 A
2.1 A
2.8 A
145 VA
247 VA
333 VA
140 W
244 W
331 W
G and H Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
860 mA
1.6 A
103 VA
191 VA
96 W
187 W
Dual 50W base stationb
Minimum RF output power (5 W)
Maximum RF output power (50 W)
1.3 A
2.9 A
156 VA
348 VA
152 W
345 W
b. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
1.3 A
2.1 A
2.8 A
151 VA
254 VA
338 VA
147 W
252 W
341 W
K Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
905 mA
1.7 A
109 VA
204 VA
101 W
201 W
Dual 50 W base stationc
Minimum RF output power (5 W)
Maximum RF output power (50 W)
1.3 A
2.9 A
156 VA
348 VA
152 W
345 W
c. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
1.3 A
2.2 A
3 A
156 VA
264 VA
360 VA
152 W
261 W
357 W

TB9300 Specifications Manual Base Station Specifications 17
© Tait International Limited August 2022
L2 Band
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
1.3 A
2.2 A
3 A
156 VA
264 VA
360 VA
152 W
261 W
357 W
Standby
AVAW
Single 50 W and 100 W base station 355 mA 43 VA 27 W
Dual 50 W base station 470 mA 56 VA 47 W
Transmit (Continued)

18 Base Station Specifications TB9300 Specifications Manual
© Tait International Limited August 2022
1.4.2 230VAC Input
Transmit
AVAW
B Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
615 mA
920 mA
141 VA
212 VA
82 W
167 W
Dual 50 W base stationa
Minimum RF output power (5 W)
Maximum RF output power (50 W)
800 mA
1.5 A
184 VA
337 VA
140 W
309 W
a. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
770 mA
1.2 A
1.5 A
177 VA
264 VA
349 VA
129 W
234 W
323 W
G and H Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
640 mA
950 mA
148 VA
220 VA
86 W
179 W
Dual 50 W base stationb
Minimum RF output power (5 W)
Maximum RF output power (50 W)
855 mA
1.6 A
197 VA
362 VA
152 W
338 W
b. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50W)
Maximum RF output power (100 W)
810 mA
1.2 A
1.6 A
186 VA
277 VA
357 VA
138 W
245 W
336 W
K Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
660 mA
1 A
152 VA
230 VA
92 W
193 W
Dual 50 W base stationc
Minimum RF output power (5 W)
Maximum RF output power (50 W)
855 mA
1.5 A
197 VA
345 VA
152 W
323 W
c. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
835 mA
1.2 A
1.6 A
192 VA
276 VA
368 VA
144 W
246 W
346 W

TB9300 Specifications Manual Base Station Specifications 19
© Tait International Limited August 2022
L2 Band
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
835 mA
1.2 A
1.6 A
192 VA
276 VA
368 VA
144 W
246 W
346 W
Standby
AVAW
Single 50 W and 100 W base station 500 mA 114 VA 28 W
Dual 50 W base station 525 mA 120 VA 46 W
Transmit (Continued)

20 Base Station Specifications TB9300 Specifications Manual
© Tait International Limited August 2022
1.4.3 12VDC Input
Transmit
AW
B Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
6.9 A
13.6 A
82 W
164 W
Dual 50 W base stationa
Minimum RF output power (5 W)
Maximum RF output power (50 W)
11.3 A
25.9 A
136 W
310 W
a. Both channels transmitting.
100W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
10.7 A
19.4 A
27.3 A
128 W
232 W
327 W
G and H Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
7.2 A
14.5 A
86 W
174 W
Dual 50 W base stationb
Minimum RF output power (5 W)
Maximum RF output power (50 W)
12.4 A
28.2 A
149 W
338 W
b. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
11.3 A
20.5 A
28.5 A
136 W
246 W
342 W
K Band
Single 50 W base station
Minimum RF output power (5 W)
Maximum RF output power (50 W)
7.7 A
16.4 A
92 W
197 W
Dual 50 W base stationc
Minimum RF output power (5 W)
Maximum RF output power (50 W)
12.2 A
28.2 A
146 W
338 W
c. Both channels transmitting.
100 W base station
Minimum RF output power (10 W)
50% RF output power (50 W)
Maximum RF output power (100 W)
12 A
22 A
31.1 A
144
264 W
373 W
