Takstar EBS-6T User manual

EBS-6T 定阻墙壁音箱说明书
EBS-6T×2
说明书×1
欢迎使用EBS-6T 定阻墙壁音箱，使用前请您仔细阅读说明书，以便
能正确的操作使用。
若存在有疑问或者您有宝贵的建议，可通过拨打得胜官
方服务热线400 6828 333 或微信扫描二维码关注得胜官方
公众号与我们联系。
■ 标准配置
■ 产品特性
■ 适用场合
■ 技术参数
■ 产品图示
■ 产品尺寸图
■ 安全警示
■ 产品安装
• 6.5英寸专业级墙壁嵌入式安装扬声器，系统采用两分频全频段设计
• 面板支架采用防潮，防水，耐紫外线的全天候工作材料
• 低音采用6.5口径防潮防水的复合材质振膜，高音采用1英寸蚕丝振膜，
整个系统声音温暖厚实，中音饱满，高音细腻柔和
• 系统采用目前最流行的无边框及网罩吸附式设计，安装及拆卸维修非常
方便
会议中心、酒店、餐厅、建筑背景音乐、家庭定制安装影院、游轮音频
系统等多种用途
• 额定功率：60W(AES)
• 额定阻抗：8Ω
• 频率响应（±3dB）：62Hz-20kHz
• 灵敏度（1W/1M）：87dB
• 覆盖角：H110×V110°
• 最大声压级：102dB
• 分频模式：无源二分频
• 分频点：3000Hz
• 安装方式：嵌入式安装
• 安装开孔尺寸：W 193mm×H 304mm
• 安装深度：86.6mm
• 接线方式：按压式接线端子（IN：
红+，黑-）
• 箱壳：ABS工程塑料
• 表面处理：黑色
• 高频：1寸蚕丝膜钕磁单元
• 低频：6.5″×1（28芯），90磁钢
（聚丙烯)复合盆胴体+NBR
丁腈橡胶悬边单元
• 规格（ W×H×D）： 230mm×
340mm×86.6mm
• 净重：1.73Kg
① 此方形纸板用来安装音响开孔使用，尺寸193mm*304mm
② 螺丝刀顺时针方向对4颗脚架螺丝转动为紧固音响；
螺丝刀逆时针方向对4颗脚架螺丝转动为拆卸音响
③ 扬声器紧固后将金属网罩吸附在面板
为避免电击、高温、着火、辐射、爆炸、机械危险以及使用不当等可能
造成的人身伤害或财产损失，使用本产品，请仔细阅读并遵守以下事项:
1. 使用产品时请确认所连接设备与本产品功率是否匹配以及合理调整音量
大小，不要在超过产品功率及大音量下长时间使用，以免造成产品异常
和听力损伤；
2. 使用中若发现有异常（如冒烟、异味等），请立即关闭电源开关并拔掉
电源插头，然后将产品送经销商检修；
3. 本产品及附件都应放置在室内干燥通风处，勿长期存放在潮湿、灰尘多
的环境，使用中避免靠近火源、雨淋、进水、过度碰撞、抛掷、振动本
机及覆盖通风孔，以免损坏其功能；
4. 若产品需要固定于墙壁或天花板上时，请确保固定到位，防止因固定强
度不足导致产品发生跌落危险；
5. 使用该产品时需遵守相关安全规定，法律法规明确禁止使用场合请勿使
用本机，以免导致意外事故。
安装脚架，安装
及拆卸组件
红色按键端子，
正极输入
黑色按键端子，
负极输入
金属防尘
网罩
230mm
340mm
86.6mm
193mm (开孔尺寸)
304mm
(开孔尺寸)
紧固螺丝，安装
及拆卸扬声器
高音
强力磁铁，
吸附金属网罩
①
②
③

EBS-6T Fixed-Impedance In-Wall Speaker
EBS-6T×2
User Manual×1
Thank you for purchasing EBS-6T Fixed-Impedance In-Wall Speaker.
In order to correctly use the device, please read the manual carefully.
If you have any questions or suggestions, please contact our local dealer.
■ Standard Configuration
■ Applications
■ Technical Specifications
■ Illustration
■ Dimensions
■ Installation
■ Features
• Professional, two-way, full-range, 6.5’’ in-wall speaker.
• Utilizes all-weather-proof material for panel frame, against moisture, water,
and UV.
• 6.5’’ woofer with moisture/water-proof composite diaphragm, and 1’’ tweeter
with silk dome, producing rich mids, delicate highs and an overall warm sound.
• Popular borderless design and magnetic grille, extremely easy for installation
and removal.
BGM in hotel/restaurant/building/conference center, home theater,
yacht audio system.
• Rated Power: 60W (AES)
• Rated Impedance: 8Ω
• Frequency Response
(±3dB): 62Hz-20kHz
• Sensitivity (1W/1M): 87dB
• Coverage Angle: H110*V110°
• Max SPL: 102dB
• Crossover: two-way, passive
• Crossover Frequency: 3000Hz
• Installation Method: flush in-built
• Cut-out Size: W 193mm * H 304mm
• Installation Depth: 86.6mm
① Use the rectangular cardboard to cut an opening, sized at 193mm*304mm.
② Turn clockwise to tighten the 4 screws around the speaker frame;
Turn counterclockwise to loosen them for speaker removal.
③ Attach the metal grille on top of the installed speaker.
Mounting arm,
for installation/
removal
Red push release
terminal, positive
input
Black push release
terminal, negative
input
Dust-proof
metal grille
230mm
340mm
86.6mm
193mm (Cut-out size)
304mm
(Cut-out size)
Screw, for
installation/
removal
Tweeter
Strong magnet,
attracts metal
grille
①
②
③
■ Safety Instructions
To avoid electric shock, overheat, fire, radiation, explosion,
mechanical risk and injury or property loss due to improper use,
please read and observe the following items before use:
1. Please check if the power of the connected equipment matches
with that of this product before operation. Adjust the volume to
proper level during operation. Do not operate at over-power or
high-volume level for extended time to avoid product malfunction
or hearing impairment.
2. If there is any abnormality during use (e.g., smoke, strange odor),
please kill the power switch and unplug from power source, then
send the product to the local dealer for repair.
3. Keep this product and its accessories in a dry and ventilated area.
Do not store in a humid or dusty area for extended time. Keep away
from fire, rain, liquid intrusion, bumping, throwing, vibrating, or
from blocking any ventilation openings, to prevent malfunction.
4. The product must, when installed on walls or ceilings, be fixed
firmly in place at adequate strength to prevent from falling.
5. Please abide by safety rules during operation. Do not use the
product in places prohibited by laws or regulations to avoid
accident.
• Connection: push release terminal
(IN: red+, black−)
• Enclosure: ABS plastic
• Finish: black
• HF: 1’’ driver, silk dome, Nd magnet
• LF: 6.5’’driver * 1, 28mm voicecoil,
90mm magnet, PP composite cone
+ NBR surround
• Dimensions (W*H*D): 230mm*
• Net Weight: 1.73Kg
340mm*86.6mm
