Takstar EKT-8L User manual

欢迎使用EKT-8L卡拉OK音箱。该产品是针对小型KTV场合
和家庭K歌系统而设计、开发的一款性价比高的卡拉OK音箱。该
音箱的特点是麦克风人声歌唱语音效果突出，并且演唱轻松，在
音乐表现上也具备高品质的音效，高、中、低频衔接流畅，结合
箱体容积和导相管、吸音棉的调节，使得这款音箱在低频方面有
上佳的表现，较有扎实的低频力度和低频下潜深度。使用前请您
仔细阅读说明书，以便能正确的操作使用。
若存在有疑问或者您有宝贵的建议，可通过
拨打得胜官方服务热线 400 6828 333 或使用微信
扫描二维码关注得胜官方公众号与我们联系。
该音箱的低音扬声器所使用的纸盆阻尼特性和刚性良好，以确
保了扬声器在不同频率段工作时，不至于引起失真，海绵折环
也选用了耐腐蚀性较强的海绵压制而成，且弹性良好，以确保
扬声器能承受较大的振幅和动态。
一般来说音箱的中高频更容易触动人的听觉心理，在中频段的
调试如果把握不当，容易使人产生听觉疲劳、烦燥感。所以在
三寸高音纸盆材料选用上，选用了在中、高频频率段具有响应
特性平滑、人声和音乐在中高频表现保真度较高的纸盆，结合
耐高温音圈，使得这款三寸高音的音色细腻的同时更能承受长
时间的音乐功率。结合了人耳的生理听觉特性，在分频器元件
上对高频进行了适当修饰，音色上把握了“中音准、透，高音
细、亮而不噪”的准则，使音箱在KTV房间内大声压歌唱、播
放音乐时，有着较为满意的效果体现，且不会出现中高频的毛
刺感，避免造成人耳的听觉疲劳。
适用于小型KTV包房、家庭K歌
EKT-8L音箱*2
说明书*1
1.确保功率放大器和音箱的功率、阻抗相匹配，失衡搭配可导致
设备损坏或音质效果不佳。
2.使用时，音箱正面朝向听众区域，以确保获得较佳听感。
3.音箱的安装需由专业工程人员进行，应固定牢靠，并选择安装
在不易碰触的位置。
4.搬运音箱时，请小心轻放，保护好音箱不受损坏。
EKT-8L卡包音箱
注：以上数据由得胜实验室测试得到，并拥有最终解释权！
额定功率：80W(AES)
额定阻抗：8Ω
频率响应（±3dB）：45Hz-20kHz
灵敏度（1W/1M）：92dB
覆盖角：H100°×V 55°
最大声压级：114dB
分频模式：两分频
分频点：3200Hz
吊挂／安装：横向吊挂
接线方式：按压式接线盒
箱壳：12mm中纤板
表面处理：聚氯乙烯
单元：高频：3″×2（13芯）
低频：8″×1（35芯），100磁钢
规格（mm）：458×268×233（W×H×D）
净重：约6.7kg

Thank you for purchasing EKT-8L KTV Speaker. This cost-effective
KTV speaker is specifically developed for small KTV room and family
karaoke system. It features prominent vocal while still maintaining
smooth transition among highs, mids and lows while playing music.
Coupled with the cabinet volume, reflex port and acoustic foam,
the speaker also performs well in low frequency, offering robust
bass strength and depth. In order to correctly use the device, please
read the manual carefully.
EKT-8LKTV Speaker
If you have any questions or suggestions, please contact our local
dealer.
Features
• Good damping and rigidity of the paper cone in the woofer, ensures
no distortion across frequencies. The sponge surround is made of
compressed corrosion-resistant material, and is elastic enough to
withstand greater amplitude and dynamics.
• Generally speaking, MF/HF from speakers reacts much with human
auditory senses, and if improperly tuned, could cause hearing
fatigue and annoyance. Therefore, for the 3’’ tweeter, we opt for
paper cone that has a smooth frequency response in MF/HF and
offers higher fidelity in MF/HF vocals and music, along with a
heat-resisting voice coil to endure prolonged music power.
• The crossover is carefully tuned on the HF end to fit physiological
characteristics of the human ears. MF is clean and clear, and HF is
detailed, bright yet not noisy, offering an overall satisfactory
experience in KTV singing or music application without stressing
the ears.
Technical Specifications
• Rated Power: 80W (AES)
• Rate Impedance: 8Ω
• Frequency Response (±3dB): 45Hz-20kHz
• Sensitivity (1W/1M): 92dB
• Coverage Angle: H100° × V55°
• Max SPL: 114dB
• Crossover Mode: two-way
• Crossover Frequency: 3200Hz
• Installation: suspended horizontally
• Connection: push type terminal
• Enclosure: 12mm MDF
• Finish: PVC
• Driver: HF: 3” × 2 (13mm voice coil)
LF: 8” × 1 (35mm voice coil), 100mm magnet
• Dimensions (mm): 458×268×233 (W×H×D)
• Net Weight: approx. 6.7kg
Note: The above data is measured by Takstar laboratory, and
Takstar has the final interpretation right!
Applications
• Small KTV room, family karaoke
Standard Configuration
• 2 * EKT-8L Speaker
1 * User Manual•
Cautions
1. Make sure that the power and impedance of the power amplifier
match with those of the speaker, otherwise it may damage
equipment or lower sound quality.
2. Put the front of the speaker facing the audience to ensure a better
hearing sensation.
3. Have professional technicians install the speaker firmly in places
hard to reach by ordinary people.
4. Transport the speaker with care to prevent damage.
Safety Instructions
To avoid electric shock, overheat, fire, radiation, explosion,
mechanical risk and injury or property loss due to improper use,
please read and observe the following items before use:
1. Please check if the power of the connected equipment matches
with that of this product before operation. Adjust the volume to
proper level during operation. Do not operate at over-power or
high-volume level for extended time to avoid product malfunction
or hearing impairment.
2. If there is any abnormality during use (e.g., smoke, strange odor),
please kill the power switch and unplug from power source, then
send the product to the local dealer for repair.
3. Keep this product and its accessories in a dry and ventilated area.
Do not store in a humid or dusty area for extended time. Keep away
from fire, rain, liquid intrusion, bumping, throwing, vibrating, or
from blocking any ventilation openings, to prevent malfunction.
4. The product must, when installed on walls or ceilings, be fixed
firmly in place at adequate strength to prevent from falling.
5. Please abide by safety rules during operation. Do not use the
product in places prohibited by laws or regulations to avoid
accident.
6. Do not disassemble or repair the product by yourself to avoid
injury. If you have any questions or require any services, please
contact our local dealer.
