tams elektronik Multi-Decoder MD-2 User manual

tams elektronik
Manual
Multi-Decoder MD-2
Item no. 43-03126 | 43-03127
8- fold servo decoder
and 4-fold turnout decoder
tams elektronik
n n n
MM D

tams elektronik
English Multi-Decoder MD-2
© 12/2019 Tams Elektronik GmbH
All rights reserved. No part of this publication may be reproduced or
transmitted in any form or by any means, electronic or mechanical,
including photocopying, without prior permission in writing from Tams
Elektronik GmbH.
Subject to technical modification.
Remark: Rail om® is a German trademark registered in the name of
Lenz Elektronik for class 9 "Electronic ontrols" under the number 301
16 303 and a trademark registered in the U.S.A. under Reg. No.
2,746,080 for classes 21, 23, 26, 36 and 38 "Electronic ontrols for
Model Railways". In order to increase the readability of the text, we
have refrained from making reference to it whenever the term is used.
Page 2

tams elektronik
Multi-Decoder MD-2 English
Table of ontents
1. Getting started............................................................................4
2. Safety instructions.......................................................................5
3. Operation overview.....................................................................7
4. Technical specifications..............................................................12
5. onnecting the decoder.............................................................14
5.1. onnecting servos............................................................14
5.2. onnecting push-buttons (→ Operating mode 2)................16
5.3. onnecting accessories (→ Operating mode 1)...................17
5.4. Power supply....................................................................19
5.5. onnection examples........................................................21
6. Programming the decoder..........................................................22
6.1. Programming decoder addresses.......................................22
6.2. Possible settings and default values...................................25
6.3. Programming Vs.............................................................26
7. heck list for troubleshooting.....................................................32
8. Guarantee bond........................................................................35
9. EU declaration of conformity......................................................36
10. Declarations conforming to the WEEE directive...........................36
Page 3

tams elektronik
English Multi-Decoder MD-2
1. Getting started
How to use this manual
This manual gives step-by-step instructions for safe and correct
connecting and operation of the decoder. Before you start, we advise
you to read the whole manual, particularly the chapter on safety
instructions and the checklist for trouble shooting. You will then know
where to take care and how to prevent mistakes which take a lot of
effort to correct.
Keep this manual safely so that you can solve problems in the future. If
you pass the decoder on to another person, please pass on the manual
with it.
Intended use
The Multi-Decoder MD-2 is designed to be operated according to the
instructions in this manual in digital model railway layouts. Any other
use is inappropriate and invalidates any guarantees.
The Multi-Decoder MD-2 should not be mounted by children under the
age of 14.
Reading, understanding and following the instructions in this manual
are mandatory for the user.
Checking the package contents
Please make sure that your package contains:
one Multi-Decoder MD-2 (ready-built module) or
one Multi-Decoder MD-2 in a housing (complete unit)
a D (containing the manual and further information)
Page 4

tams elektronik
!
Multi-Decoder MD-2 English
Required materials
In order to connect the decoder, you need wire. Recommended
diameters:
> 0,05 mm² for the connections to LEDs, push buttons and
switches;
> 0,25 mm² for all other connections.
When using motor-run turnouts, you need an additional adapter AMW-2
for each turnout (item-no. 72-00086).
2. Safety instructions
Caution:
The decoder contains integrated circuits. These are very sensitive to
static electricity. Do not touch components without first discharging
yourself. Touching a radiator or other grounded metal part will
discharge you.
Mechanical hazards
ut wires can have sharp ends and can cause serious injuries. Watch
out for sharp edges when you pick up the P B.
Visibly damaged parts can cause unpredictable danger. Do not use
damaged parts: recycle and replace them with new ones.
Electrical hazards
Touching powered, live components,
touching conducting components which are live due to malfunction,
short circuits and connecting the circuit to another voltage than
specified,
impermissibly high humidity and condensation build up
Page 5

tams elektronik
English Multi-Decoder MD-2
can cause serious injury due to electrical shock. Take the following
precautions to prevent this danger:
Never perform wiring on a powered module.
Assembling and mounting the kit should only be done in closed,
clean, dry rooms. Beware of humidity.
Only use low power for this module as described in this manual and
only use certified transformers.
onnect transformers and soldering irons only in approved mains
sockets installed by an authorised electrician.
Observe cable diameter requirements.
After condensation build up, allow a minimum of 2 hours for
dispersion.
Use only original spare parts if you have to repair the kit or the
ready-built module.
Other dangers
hildren can cause any of the accidents mentioned above because they
are inattentive and not responsible enough. hildren under the age of
14 should not be allowed to mount this module.
In schools, training centres, clubs and workshops, assembly must be
supervised by qualified personnel.
In industrial institutions, health and safety regulations applying to
electronic work must be adhered to.
Page 6

tams elektronik
Multi-Decoder MD-2 English
3. Operation overview
The MD-2.BiDiB is a stationary decoder used to control a maximum of 8
servos. In addition, coil driven turnouts or semaphore signals,
decouplers or other accessories or push-buttons for manual activation
of the servos can be connected.
Operating mode 1:
8-fold servo decoder
+ turnout- and/or
switching decoder
onnecting area 1
("pin headers")
8 servos*1
(8-fold servo decoder)
onnecting area 2
("terminal strips")
4 solenoid accessories*2
(4-fold turnout decoder)
or 8 other accessories*3
(8-fold switching decoder)
or combination of turnouts and other
accessories
* see page 8
Page 7

tams elektronik
English Multi-Decoder MD-2
Operating mode :
8-fold servo decoder
with push-buttons
for manual activation
onnecting area 1
("pin headers")
8 servos*1
(8-fold servo decoder)
onnecting area 2
("terminal strips")
8 push-buttons for toggling between the
servos´ two end positions (as well
suitable for purely analogue operation)
*1 Servos: to control for example turnouts, semaphore signals or
(railroad crossing) gates.
*2 Solenoid accessories: accessories switched by short switching
impulses, for example coil driven turnouts (with or without limit stop),
coil driven semaphore signals, decouplers. Hint: In order to control
motor-run turnouts, you need an additional adapter AMW-2.
*3 Other accessories: for example light signals (to switch over between
the signals) or other lights (to switch them on and off).
The voltage supply for the connected accessories is provided by the
Multi-Decoder MD-2.
Page 8

tams elektronik
Multi-Decoder MD-2 English
Motion sequences
You can set separately for each of the 8 servos:
Starting and end position
Rotational speed
Simple linear motion curve or linear motion curve with teetering
when reaching the end position (to be adjusted separately for the
two directions of motion)
Simple linear motion curve with constant
velocity.
It is not possible to break the motion sequence
before the end position has been reached.
When reaching an end position the motion
sequence is stopped automatically.
Linear motion with teetering at the end
positions (typical motion sequence of
semaphore signals and railroad crossing gates).
The teetering motion has to be set separately
for each direction of motion.
Driving the decoder via accessory decoder commands
Turnouts, servos or other accessories are operated via accessory
decoder commands in D or Motorola format, sent from the controla
unit to the accessory decoder´s addresses:
operating mode 1: 12 addresses
operating mode 2: 8 addresses
The decoder automatically recognizes the commands´data format. It is
possible to switch the outputs via mixed D and Motorola commands
as well as to operate one output alternately in D and Motorola
format.
Page 9

tams elektronik
English Multi-Decoder MD-2
Use in analogue mode
When operating mode 2 is set (for connection of buttons in connection
area 2) the servos can be controlled either by turnout commands or by
the connected buttons. This means that the MD-2 can also be used in
pure analogue operation.
Programming
Using a D central unit, the decoder address and the decoder´s
features can be defined by programming the configuration variables
( V). It is also possible to set the address by using a push-button
switch.
When using a Motorola central unit the (accessory) decoder address
has to be set with a push-button switch. hanging the other decoder´s
features is not possible in layouts run in Motorola format only.
Feedback via RailCom (according to R N-217)
The Multi-Decoder MD-2 is Rail om compatible, i.e. the decoder is able
to pass the Rail om messages via the rails to special Rail om detectors.
After a switching or setting command to its address the decoder sends:
status message, e.g. "turnout is set right", "turnout has been
switched" or "turnout still has to be switched" and / or
time message, e.g. "another 2 seconds are required to carry out the
switching or setting command" and/or
error message, e.g. "turnout cannot be switched"
and, by this, confirms the recepton of the command.
Page 10

tams elektronik
!
Multi-Decoder MD-2 English
Overload protection
In case the maximum current at one of the outputs or the total
maximum current of one ot the two connecting areas has been
exceeded, the decoder automatically switches off. Then, you have to
switch the decoder currentless, to eliminate the overload and to switch
on the decoder again.
Caution:
When connecting an in- or output to a live wire (e.g. to the power supply),
a very high current occurs suddenly. In this case, the overload protection
is ineffective, the decoder can be damaged irreparably.
Power supply
The Multi-Decoder MD-2 can either be supplied by the central unit or a
booster. In order to release the digital electric circuit it is also possible
to supply the decoder by a transformer of its own instead.
Page 11

tams elektronik
English Multi-Decoder MD-2
4. Technical specifications
Data format D , Motorola
Adress range
Hint: The adress range to be used also
depends from the central unit.
MM: 1020 turnout addresses
D : 2040 turnout addresses
Feedback log Rail om
Supply voltage Digital voltage of the central unit
or 14 – 20 V a.c. voltage
urrent consumption (without
connected devices) approx.
approx. 40 mA
onnecting area 1
("pin headers")
8 servos
max. current / output: 1,000 mA
onnecting area 2
("terminal strips")
4 pairs of outputs, depending on
the operating mode for use as
8 switching outputs or
4 turnout outputs
max. current / output:
up to 2 seconds: 1,500 mA
continuous: 1,000 mA
Max. total current onnecting area 1: 1,000 mA
(continuous)
onnecting area 2: 1,000 mA
Protected to IP 00
Page 12

tams elektronik
Multi-Decoder MD-2 English
Ambient temperature in use 0 ... +60 °
Ambient temperature in storage -10 ... +80 °
omparative humidity allowed max. 85 %
Dimensions of the P B
Dimensions including housing
approx. 72 x 82 mm
approx. 100 x 90 x 35 mm
Weight of the assembled board /
including housing (approx.)
approx. 40 g
approx. 88 g
Page 13

tams elektronik
English Multi-Decoder MD-2
5. onnecting the decoder
Make the connections one after the other to:
servos (connecting area 1)
push-buttons (connecting area 2, operating mode 2) or
turnouts, other solenoid accessories and/or other accessories
(connecting area 2, operating mode 1)
central unit
power supply
Operating mode 1 Operating mode
onnecting
area 1
("pin
headers")
8 servos*1
(8-fold servo decoder)
8 servos *1
(8-fold servo decoder)
onnecting
area 2
("terminal
strips")
4 solenoid accessories*2
(4-fold turnout decoder)
or 8 other accessories*3
(8-fold switching decoder)
or combination of
turnouts and other
accessories
8 push-buttons for
toggling between the
servos´ two end positions
(suitable for purely
analogue operation)
* see page 8
5.1. onnecting servos
The connecting area 1 is equipped with pin headers, where you can
insert the servos´ connecting sockets directly. If yo have to extend the
servos´ connecting cables, you should use 3-pole pin and socket strips,
grid dimension 2,54 mm (e.g. item no. 85-11103-10 and 85-11203-10).
Page 14

tams elektronik
!
Multi-Decoder MD-2 English
A B C
S1 servo 1 GND (-) V (+) signal
S2 servo 2 GND (-) V (+) signal
... ... … ... ...
S8 servo 8 GND (-) V (+) signal
Caution: The maximum current for connecting area 1 as well as
the maximum current per servo connection is 1,000 mA (see section 4.
"Technical specifications"). With a too high current consumption of the
connected accessories the decoder switches off automatically.
INFO: servo connections
Connection Short term Identification
symbol
Colour of
connecting wire
(deviations possible)
Voltage supply "GND" - black or brown
"V " + red
Impulse (signal) "PW" white or orange
Page 15

tams elektronik
!
English Multi-Decoder MD-2
5.2. onnecting push-buttons (→ Operating mode 2)
The connecting area 2 is equipped with terminal strips to plug in and
screw on the connecting wires for the push-buttons.
1 | 2 Push-button for servo 5
3 | 2 Push-button for servo 6
4 | 5 Push-button for servo 7
6 | 5 Push-button for servo 8
10 | 11 Push-button for servo 1
12 | 11 Push-button for servo 2
13 | 14 Push-button for servo 3
15 | 14 Push-button for servo 4
Caution: The push-buttons should be connected to the decoder
only. A push-button connected to other components of the layout
possibly causes a short-circuit and, as a consequence, irreparable
damages at the connected items.
Page 16

tams elektronik
Multi-Decoder MD-2 English
5.3. onnecting accessories (→ Operating mode 1)
The connecting area 2 is equipped with terminal strips to plug in and
screw on the connecting wires for turnouts and other (solenoid)
accessories. You can connect to each of the four output pairs either one
solenoid accessory or two other accessories. A mixed use as turnout
and switching decoder is possible.
1 Output
pair 1
(T1)
Solenoid accessory / turnout 1
or switching contact 1
Turnout 1
"diverging" (1r)
2 Return conductor for
T(urnout)1
3 Solenoid accessory / turnout 1
or switching contact 2
Turnout 1
"straight" (1g)
4 Output
pair 3
(T3)
Solenoid accessory / turnout 3
or switching contact 5
Turnout 3
"diverging" (3r)
5 Return conductor for
T(urnout)3
6 Solenoid accessory / turnout 3
or switching contact 6
Turnout 3
"straight" (3g)
Page 17

tams elektronik
!
!
English Multi-Decoder MD-2
10 Output
pair 2
(T2)
Solenoid accessory / turnout 2
or switching contact 3
Turnout 2
"diverging" (2r)
11 Return conductor for
T(urnout)2
12 Solenoid accessory / turnout 2
or switching contact 4
Turnout 2
"straight" (2g)
13 Output
pair 4
(T4)
Solenoid accessory / turnout 4
or switching contact 7
Turnout 4
"diverging" (4r)
14 Return conductor for
T(urnout)4
15 Solenoid accessory / turnout 4
or switching contact 8
Turnout 4
"straight" (4g)
Caution: The maximum current for connecting area 2 as well as
the maximum continuous current per output is 1,000 mA (see section 4.
"Technical specifications"). With a too high current consumption of the
connected accessories the decoder switches off automatically.
Caution: Be sure not to connect the in- and outputs by accident
to a live wire. The extreme overload suddenly occurring can damage
the decoder irreparably.
Page 18

tams elektronik
Multi-Decoder MD-2 English
5.4. Power supply
You can supply the decoder either via the central unit or via a seperate
transformer according to the two following diagrams.
7 Power supply / transformer (~)
8 Input D signal
9 not in use
16 Power supply / transformer (~)
17 Input D signal / central unit
18 not in use
Caution: If a component gets too hot, disconnect the decoder
and the power supply from the mains immediately. Possible short
circuit! heck the assembly!
Power supply via central unit
Caution: Switch off the central unit before connecting the
decoder.
Page 19
!
!

tams elektronik
English Multi-Decoder MD-2
Power supply via separate transformer
Caution: When connecting several devices to the same voltage
supply, generally all connections have to be polarised identically.
Otherwise a short circuit will occur, possibly damaging connected
devices.
Page 20
!
