Tanita WB-100ST Instruction Manual

ELECTRONIC SCALE
MODEL WB-100ST/WB-110ST
SEPARATE
Operating Instructions Manual
Please keep this manual in a safe place,
and make sure it is readily available when-
ever necessary. Please use this product
only after carefully reading this manual and fully
understanding its contents.
1
THIS FINE INSTRUMENTIS PRECISIONCRAFTED BY
TANITA CORPORATIONTOKYO, JAPAN

Table of Contents .....................................................................................
2
1. Standard specification ...........................................................................
2
2. Precautions .................................................................................................
3
3. Parts List ......................................................................................................
3
4. Name of key Operations .......................................................................
4
5. Set up ............................................................................................................
4
6. Operation
1. Standard Weighing Procedures ................................................... 5
2. Tare Weighing ....................................................................................
5
3. Cancellation of Tare Weighing Function................................. 6
4. Auto OFF Mode .................................................................................
6
7. RS-232C Communication Specifications ........................................ 7
ODEL
Measur,
um Capaci
.l 1OST
ement System Strain Gauge Load Cell
Weight Measurement ty1Minmum Graduation 200kg/O.lkg (31st 6lb/0.21b) 270kglO.lkg
I
Display Weight 200kg10.lkg 270kglu.
I ~g
Output Items (31st61b10.21b) (42st 121b/0.21b)
Size
*The battery life is approximately 100hours ofcontinuous use.
Power Consumption
Temperature Range of usage
Weight of Equipment
1
Display
Platform
Cord Length
0.3W
0"-35°C (32"-95")
4.6kg (10.21b) (excluding batteries).
I
159~209~56mm(6 114x8114~2 114in)
30Ix336x80mm(11 718x13 114x7 718in)
2m(6ft)
Display
Output Data Interface
Power Source
Rated Power
Upper 5Digits and Lower 4Digits LCD
Heightof numerals25mm (lin)
RS-232C (D-sub Spins MaleConnector)
AC Adapter (included) Negative centre
DC9V 300mA ("LR6.15A"AIkal i Batterv~6not included)

f \
Warnings
Various symbols are used inthis instruction manual as well as on the product in order to prevent injuryto personnel and damage to property. It is
advisable tofamiliarise yourself with these terms prior to readingthe rest ofthis booklet.
1 WARNING Death or seriousinjurycouldoccurif these precautionsare not followed or the product is misused.
a
WARNING Death or serious injury due to electric shock could occur if these precautions are not followed or the product is
misused.
t
CAUTION
Injury or damage to property could occur if these precautions are not followed or the product is misused.mis-
A used.
a
Thistype of warning alerts the user to generalsafetyinstructions.
1 WARNING .Make sure that all parts are securely fastened to prevent the user from falling.
a
WARNING .when using an AC adaptor, do not insert or remove the power plug from an electric outlet with wet hands as this may
result inelectric shock.
1 CAUTION
.Do notjump onto the productto avoid falling off it, thereby causing injury.
a
.Place and use this product on a level floor to prevent itfalling over.
.If used close to radio or TVsets, this product may cause interference. To avoid abnormal operation ofelectronic equipment inhospitals or sim-
ilar facilities which are sensitive to electromagnetic waves, make sure inadvancethat such equipment is not affected by the emission from this
product.
.As this product is heavy, please hold it by its base with both handswhen moving it.
.Please unplug the AC adaptor fromthis product when moving it.
.Unplug the ACadaptor fromthejack holder.
I
This product is a delicately-adjusted precision instrument. Please observe the following instructions when using it:
a .Do not disassemble it.
.Do not subject this productto excessiveshock or vibration.
.Avoid using the product ina place exposed to direct sunlight or near a heat source.
.Avoid using the product ina place subject to wide temperature variations.
.Do notclean or wipe the product with benzene or thinner. (When the product needs cleaning, use a neutral type of detergent.)
.Do not store the product inan area with excessivehumidity, dust or vibration.
.If the productwill not be used for a long period, removethe batteries before storage.
.If the product is moved to a place with atemperature difference of 20°C or more, leave itfor at least 2 hours before use.
.When transporting the product, pack it in its original carton.
\ J
I \
<Contents of the package>
Please confirm that the package contains
the following items:
(1) Measuring platformand Display box
(2) Stand
(3) Instruction booklet
(4) Mountingscrews
(5) AC adaptor
\ J
I \
<Names of parts>
(A) Display box
(B) Jack holder
(C) Battery box
(D) Stand
(E) Measuring platform
\ 2

@ NET
: Anarrow appears nextto th~sIconwhen the tare weigh~ngfunctlon IS on.
@ STABILIZED When the measurement becomes stable, an arrow wlll appear to the rlght of STABILIZED.
0 WEIGHT LOCK When the measurement becomes stable, an arrow w~llappear to the rlght of
WEIGHT LOCK When the "WEIGHT LOCK OFF"
IS pressed, the arrow will
d~sappear
r
<Function of switches>
a ONIZERO key
@ NETmark
@ OFF key
@ STABILIZEDmark
@ TAREkey
0 WEIGHT LOCK mark
@ TIMER key
a UPkey
@ DOWNkey
a WEIGHT LOCKOFF key
\ #
When using the stand When installing the display box on the wall
Please pull out the stand at the back of the
display box.
When putting the display box away, please
insert the stand inthe slot on the back of the
display box.
a Screw the wall-hanging screws into the wall
(leave the screws protruding from the wall by
about
5 mm).
@ Insert the screw heads into the holes on the
back ofthe display box.
@Pull the display box down lightly with your
hands.
If the unit is not installed properly,
there is a riskthat the display box will
fall down.
Please avoid installing the display
box ina place where the cord will end
up being trodden on or caught on
something.
S Please do not swing the display box
around bythe cord.
<Before using>
1. Power source
Please use an AC adaptor or 6 alkali batteries (LR6).
1) In case of usingbatteries (not included)
Loosen the battery box fixing screw on the side of the display box and pull the battery box
out. Place the batteries inthe direction as illustrated and insert the battery box back into its
original position and tighten the battery box fixing screw. When the
i is displayed and
b is turned on in the battery replacement warning mark b L0 BATTERY, replace all 6
batteries.
1 A
Becareful when replacing the batteries notto let the batteriesfall out.
2) When AC adaptor (optional)
Insert the AC adaptorjack into thejack holder on the side of the display box and plug the
ACadaptor intothe ACwall outlet. (Genuine optional ACadaptor.)
<Trouble Shooting>
(1) Nothingis displayed when switchis pressed
.If ACadaptor is used :
Check the connection ofthe ACadaptorjack to thejack holder, and the connection ofthe ACadaptor plugtothe wall socket.
.If batteries are used :
The batteries may be weak. Tryan ACadaptor or new batteries.
(2) Measurementis not accurate
.Check that all feet ofthe scale are steady.
.Accurate measurement may be impossible
if the product is used where there is excessive vibration. Try using the product ina different place.
I

1. Standard Weighing Procedures
1. Turn on the poweron by pressing the key.
STABILIZED 4
l E.Lf -.f.Ll
3. The person to beweighed should stand still inthe middleof the scale.
7 17 17 kg
The weight of the person being weighed will be displayed.
*
4. Measurementis completed.
When the person being weighed steps off the scale, the display will return to "0.0".
Turn off the power by pressing the key.
2.Tare Weighing
1. Turn on the power bypressing the key.
2. After allthe segments flash, L01 is displayed.
st-lb
3. Carefully place the tare items (clothes, etc.) inthe center of the platform.
kg
The weight of the items will be displayed.
WEIGHT
LOCK
4. Press the key.
An arrowwill appear next to the 4 [NET]mark and [0.0]will be displayed.
STABILIZED 4
7 r r 7 r-
-.m -.-
5. When weighing an object including tare items, the weight of the obiect minus that of the tare
SI-~b
items, which is the netweight, will be displayed.
To change the tare weight, cancel the tare weighingfunctionandrepeat from step 3.
kg
When using the tare weighing function, the measurement range is reduced by the tare weight.
WEIGHT
LOCK
Measurement Range = Maximum Measurable Weight - Tare Weight

3.Cancellation of Tare Weighing Function
nnm- 1
STABILIZED 4 - , , , , ,- ,-,
-.- a.-
1. Remove the tare items (plates, bags, etc.) from the platform.
st-b
The weight will be displayedas anegative value.
kg
WEIGHT
LOCK
I 2, Press the key.
The arrownext to the 4 [NET] will disappearand [0.0] will be displayed.
4. Auto OFF Mode
1. When you press the key the scale will enter the Auto OFF switching mode.
2. The displaywill switch betweenCONT (continuous), 10 (rnin)and 20 (rnin)with the key.
" The defaultsettingis set to in 20 (rnin).
3. Please set time by pressing [TIMER] Thenit returns weighing mode after all segmentsflash.

Communicationstandard Conformsto EIA RS-232C
Communicationmethod Asynchronous method
Signal speed 2,400 baud
Data bit length
7 bit
Parity
EVEN
Stopbit 1 bit
.Names and connection methods for signal lines
A
An RS-232C connector (D sub 9 pin male) is attached to the side of the displaybox.
When connecting the displaybox with a personal computer, etc., please use an RS-232C cross cable.
.Weighing Mode
When receiving 4 bytesof data as indicatedin 1-1 while using the scale in weighing mode, weight datawill be output in 26 bytes, as indicatedin 1-2.
* While the scaleis used with lb (pound)measurement units, the weight data will be output in lbs (pounds).
1-1 Reception data
1234
1-2 Transmission data
1 Details of weighing mode transmission data I
SD: Unstable S-: Stable
CJ: Overload,etc,
Byte nos. 1-2 Header
fixed

c
