tanning essentials CORDLESS Installation guide

CORDLESS - TRAINING MANUAL
www.tanningessentials.co
SIMPLE TANNING SYSTEMS built purposely for a perfect spray tan.

5
2
3
4
WELCOME
Thank you for choosing the Tanning Essentials Cordless Spray Tan System. Please read
the following to help assist you with the set up and maintenance of your spray tan unit.
QUICK SET UP GUIDE
The Tanning Essentials Cordless Spray Tan System contains:
1 x TE Cordless Applicator System 2 x 90ml Solution Cup with Lid
1 x Adjustable Drying Nozzle 1 x Adjustable Spray Nozzle
1 x Charger 1 x Vegan Leather Carry Case
1
2
3
4
5
6
www.tanningessentials.co
6
1

CORDLESS APPLICATOR
www.tanningessentials.co
STEP 1
Unscrew the solution cup and fill it with your chosen professional
spray tan solution. 50-90ml max.
STEP 2
Connect the solution cup to the Cordless system.
To securely tighten, align the unlocked symbol on the solution cup
with the dot on the applicator, and twist the cup clockwise until the
locked symbol on the cup aligns with the dot on the applicator.
STEP 3
Set the nozzle by turning it to your desired setting.
The vertical setting is used when spraying up and down, and the
horizontal setting is used when spraying left to right/right to left.
STEP 4
To control the amount of solution released from the fluid nozzle,
adjust the dial to select your spray level. Number 1 is the lowest,
and number 5 is the highest. A higher setting will result in more of
the tanning solution being dispensed. Recommended setting (3) for
the body and 1-2 for the face.
Note: How fast you move will affect the application. If the solution
looks like it is going to drip on the skin you are moving too slowly,
reduce the dial setting or increase the speed.

CORDLESS UNIT
www.tanningessentials.co
STEP 6
Once the treatment application is complete, hold the power button
down to turn the system off. Unscrew the retaining nozzle by twisting
it anti-clockwise, remove the adjustable spray nozzle and replace it
with the drying nozzle attachment. To secure the fitment of the dry
nozzle, re-attach the retaining nozzle by twisting clockwise.
STEP 7
Re-power system with airflow set to MIN, be sure not to pull the
trigger as this will release residual solution that may be present
in the system.
STEP 8
Once treatment is complete, and the system is turned off, place it
back on charge.
STEP 5
To begin your application, power on the system by holding down
the power button for 1-2 seconds. Once powered, click the power
button again to increase airflow from min to max. Recommended
setting MIN for drying and MAX for application.
Note: Pull the trigger to start the stroke and release the trigger to
finish the stroke. The system must be moving when the trigger is
pulled.

CORDLESS APPLICATOR MAINTENANCE GUIDE
STEP 1 Unscrew the solution cup and empty any excess solution.
It is recommended this is done over a sink.
STEP 2 Rinse the empty solution cup with warm water.
STEP 3 Refill the solution cup with warm water and screw it back into the
applicator, turn the solution dial to “C”, and spray until the water
runs clear.
Note: Ensure the adjustable spray nozzle is attached.
STEP 4 Once a cup of water has run through, re-rinse the cup and empty.
Re-set solution dial to the regular spray setting of your choice.
STEP 5 Wipe any excess water from the applicator with a cloth and leave
it out to dry
Note: Your Cordless system is NOT compatible with harsh cleaners such
as gun cleaners, chlorine bleach, or 100% ethanol. Using these cleaners
will cause damage to the system.
www.tanningessentials.co
Maintenance on the Applicator must be run at the end of each day the applicator is used.
Store your Cordless system in the carry case indoors in a cool, dry place below 50°c.
Do not leave excess solution in the cup.

TROUBLESHOOTING
If you are experiencing problems with this unit, in the first instance please carefully read the
relevant sections of the User Manual and the Troubleshooting section below. If you cannot
solve your problem please contact your supplier for further assistance.
www.tanningessentials.co
PROBLEM CAUSE WHAT TO DO
My solution is
bubbling from
the cup
The air flow is
cutting in and
out
Seal is not fitted correctly.
The solution cup is not screwed
in correctly.
The solution cup is cross
threaded.
Solution cup is overfilled.
Battery might be low.
Airflow setting is set to MIN.
Fit seal correctly.
Unscrew and re-attach the solution
cup. To securely tighten, align the
unlocked symbol on the solution
cup with the dot on the applicator,
and twist the cup clockwise until
the locked symbol on the cup aligns
with the dot on the applicator.
Unscrew and re-attach the solution
cup. To securely tighten, align the
unlocked symbol on the solution
cup with the dot on the applicator,
and twist the cup clockwise until
the locked symbol on the cup aligns
with the dot on the applicator.
Empty some solution from the cup
and re-attach.
Place on charge.
Increase airflow to MAX by pushing
the power button a second time.

TROUBLESHOOTING
www.tanningessentials.co
PROBLEM CAUSE WHAT TO DO
The solution is
splattering
System will
not turn on
System will
not charge
System is
leaking
The airflow setting is set to MIN.
Battery might be low.
The solution cup is too low.
The system has a flat battery.
Charging cord not attached
correctly.
Charger port is not pushed
into the wall socket.
Electricity is not turned on.
The solution cup is not screwed
in correctly.
Residual solution remains
in the system.
Increase airflow to MAX by pushing
the power button a second time.
Place on charge.
Add more solution to the cup.
Place on charge.
Remove, then re-fit charger.
Push charger plug firmly into
the socket.
Ensure power point is turned on.
Unscrew and re-attach the
solution cup.
You may need to depressurise
applicator, remove cup and hold
Cordless system over the sink and
pull trigger to drain residual
solution.

PROBLEM CAUSE WHAT TO DO
No solution
is coming
out of
Cordless
system
Solution is
beading on
skin
Nozzle may be blocked.
Solution pick-up tube not fitted
correctly.
Solution cup is filled to low.
The solution dial is set too low.
Trigger is not being pulled.
Trigger is jamming.
Too much tanning solution has
been sprayed on the skin.
Dial is set to high and releasing
too much solution.
The spray application is too slow.
Spray warm water through the
applicator.
Remove the tube and re-fit.
Add more solution to the cup.
Increase setting on the solution
dial. Number 1 is the lowest, and
number 5 is the highest.
Pull the trigger to release the
solution.
Spray warm water through the
system while the solution dial is
set to “C” and pull the trigger
repetitively until it releases.
Dab area with a clean, dry towel
and re-spray lightly over the area
to blend tan.
Reduce setting on the dial.
Speed up the application, or
reduce the setting on the dial.
1 is the lowest, and 5 is the highest
setting.
TROUBLESHOOTING
www.tanningessentials.co

PROBLEM CAUSE WHAT TO DO
Solution is
beading on
skin
The client
has tanning
solution in
areas they
do not wish
to tan
The client
appears to
be orange
The client has not prepared their
skin correctly i.e moisturiser or oil
based product residue may remain
on the skin.
The client may be excessively
hot and perspiring.
The technician has sprayed the
area incorrectly.
The client has touched a part of
their body with a spray-tanned
area.
Too much tanning solution has
been sprayed onto the skin.
The client may not have followed
rinse instructions for rapid tan.
The client may have a low
tolerance to DHA.
Dab area with a clean, dry towel
and re-spray lightly over the area
to blend tan. Client may even have
to remove product residue from
the skin before proceeding with
the tan application.
Dab area with a clean, dry towel
and re-spray lightly over the area
to blend tan.
Using a damp cloth, wipe the area
immediately, or once developed,
exfoliate the area using a tan
remover product.
Using a damp cloth, wipe the area
immediately, or once developed,
exfoliate the area using a tan
remover product.
Exfoliate the skin using a tan
remover product.
Exfoliate the skin using a tan
remover product.
Exfoliate the skin using a tan
remover product.
TROUBLESHOOTING
www.tanningessentials.co

PROBLEM CAUSE WHAT TO DO
The spray
has not
developed
as dark as
desired
The spray tan solution used may
be old or heat affected, reducing
the desired reaction on the skin.
Sometimes a green hue will appear
to indicate a product has degraded.
A different solution was sprayed,
or the spray application dial was
set lighter.
The client may have showered or
perspired before the tan could
develop.
Client may have showered too
early.
Other factors may affect the tan’s
development, including diet,
hormones and medication.
The client may have used soap or
body wash, preventing DHA from
developing on the skin.
Keep the solution in a cool, dry
place and ensure the solution
hasn’t expired.
The client can be re-sprayed if
required after their minimum 8
hours and after taking a shower.
The client can be re-sprayed if
required after their minimum 8
hours and after taking a shower.
The client can be re-sprayed if
required after their minimum 8
hours and after taking a shower.
Please refer to the client.
Ensure the client has followed the
correct preparation and post-spray
tan care recommendations.
The client can be re-sprayed if
required after their minimum 8
hours and after taking a shower.
TROUBLESHOOTING
www.tanningessentials.co

SAFETY, WARNINGS & CAUTIONS
The Tanning Essentials Cordless Spray Tanning System is designed and built
to the highest standards.
• Do NOT expose the system to excessive heat.
• Do NOT place near naked flame sources or alike.
• Do NOT make unapproved alterations to this product.
• Do NOT expose the system to excessive heat.
• Do NOT use if it has a damaged power cord or plug.
• Keep out of reach from children.
• Keep away from water.
• Avoid direct sunlight and store indoors in a cool, dry place below 50°c.
• Unplug this apparatus during electrical storms or when unused for long periods.
• If the battery leaks, avoid contact with the skin and eyes. If contact is made,
seek medical advice.
• Only use attachments/accessories specified by the manufacturer.
• Use this product only with an approved power supply per the manufacturer’s
specifications.
• Please dispose of used batteries properly, following local regulations.
Do not incinerate. This product should be delivered to an appropriate collection
facility for recycling and not disposed of in the general waste. Removal of the
rechargeable lithium-ion battery in this product should be conducted only by
a qualified professional.
The Tanning Essentials Cordless system has a one year warranty from the date
of purchase.
www.tanningessentials.co

WARRANTY INFORMATION
IMPORTANT
Please keep your proof of Purchase and User Manual in a safe place as you will
require these to make a warranty claim. Prior to making a claim you should read
through the trouble shooting section in the manual and contact your supplier.
All warranty claims should be made directly to your supplier.
If within one (1) year from the date of purchase, the product fails due to a defect in
material or workmanship, we will repair if possible or replace it free of charge with a
comparable unit which may be new or refurbished. This warranty applies only to the
original purchaser and is not transferable. The goods must be returned to the seller
with proof of purchase to be assessed at the purchasers cost.
Warranties shall not apply to any defect, failure or damage caused by improper use or
improper or inadequate maintenance and care. The manufacturer shall not be obligated
under these warranties:
a) to repair damage resulting from attempts by personnel other than authorised
representatives to install, repair or service the product;
b) to repair damage, malfunction, or degradation of performance resulting from
improper use or incompatible solution;
c) to perform maintenance or cleaning or to repair damage, malfunction, or
degradation of performance resulting from failure to perform user maintenance
and cleaning as prescribed;
d) to repair damage, malfunction, or degradation of performance resulting from
use of the product in an environment not meeting the operating specifications,
To activate your warranty, please complete the information and post to Tanning
Essentials within 14 days of purchase.
www.tanningessentials.co

TROUBLE SHOOTING
www.tanningessentials.co
WARRANTY RETURN FORM
DATE:
PRODUCT NAME:
CUSTOMER NAME:
PURCHASE DATE:
BUSINESS NAME:
SUPPLIER INVOICE No*:
CONTACT NUMBER:
E MAIL:
ADDRESS :
(PO Box Not Accepted)
Please include this form when returning warranty items.
Customer Information:
Product Information:
Reason for Return:
I give my authority for goods to be left at the postal address mentioned above: Please circle YES / NO
Please Note: If circled Yes, no liabillity will be taken
* All waranty claims must include proof or purchase. This must be a photocopy of the original invoice.

SAFETY INFORMATION
The Tanning Essentials Cordless Spray Tan System is designed and built to the highest
standards. This system must be used with professional spray tan solution, kept away
from water, be connected to the correct power supply at all times and must not be
operated by children.
Please note the details of your model here:
The Tanning Essentials Cordless Spray Tan System is made in China
WARRANTY CARD
www.tanningessentials.co
To submit your warranty online, please visit www.tanningessentials.co and select the warranty link. Please include proof of purchase.
MODEL TYPE: SERIAL NUMBER:
SUPPLIER NAME:
NAME:
ADDRESS:
EMAIL:
BEAUTYBUSINESS TYPE TANNING HAIR MOBILE HOME
DATE OF PURCHASE:
SUBURB:
COUNTRY:
PHONE:
POST CODE: STATE:
MODEL NAME:
SERIAL NUMBER:
DATE OF PURCHASE:
SUPPLIER NAME:

OUR DETAILS
ADDRESS:
15 Production Drive, Campbellfield, VIC. 3061 Australia
PHONE:
1300 877 677 (within Australia)
INTERNATIONAL PHONE:
[phone]
EMAIL:
[e-mail] www.facebook.com/tanningessentials
WEB:
www.tanningessentials.co www.youtube.com/user/TanningEssentials
www.tanningessentials.co
Tanning Essentials
15 Production Drive
Campbellfield, VIC. 3061
Australia
AFFIX
POSTAGE
STAMP
HERE
