tanning essentials SPRAY STATION Installation guide

www.tanningessentials.co
SIMPLE TANNING SYSTEMS built purposely for the perfect spray tan

www.tanningessentials.co
WELCOME
QUICK SET UP GUIDE
Thank you for choosing the Tanning Essentials Turbo Twister Spray Station.
Please read the following to help assist you with the set up and maintenance of
your spray station.
The Tanning Essentials Turbo Twister Spray Station contains:
3 Fan units 2 Additional rapid spray applicator cups with lids
1 Base unit 2 Connector cords
2 Side panels 1 Power cord
1 Floor 1 Foot pedal with 3 connected cords
2 Steel support bars 14 Screws
1 Hose 1 Cup holder
2 Rapid spray applicators Set of base seals
Watch the full set up video now on youtube/tanningessentials
OUR DETAILS
Contact Us International [phone]
United Kingdom [phone]
Email [e-mail]
/tanningessentials

www.tanningessentials.co
FRONT OF SPRAY STATION
Anti-slip Comfort
Floor Mat
Bottom Fan Unit
Middle Fan Unit
Top Fan Unit
Inbuilt Spray
Tan System
Aluminium Side
Panels
Filter
Opening
Cup
Holder
ON / OFF
Switch

www.tanningessentials.co
BACK OF SPRAY STATION
Fan Unit
ON / OFF
Unit Switch
Base Unit Handle
and Filter Access
Screws
Metal Bar
Fan Unit Handle
Foot Pedal / Power
Connection Point
Hose Connection
(Side of Base Unit)
Female Socket
Male Socket
Cup
Holder

www.tanningessentials.co
SPRAY STATION BASE
SPRAY APPLICATOR
Foot Pedal / Power
Connection Point
Fan Unit
Placement Guide
Metal Bar and Base Seal
Placement Guide
ON / OFF
Switch
Adjustable
Spray Nozzle
Solution Dial
(On Side)
Spray Trigger
Handle
Hose Connector
(Underneath)
Solution Cup
Hose Connector Base Unit Handle
and Filter Access

www.tanningessentials.co
TOWER ASSEMBLY
STEP 1
Lay the floor into position, the wide straight edge is the front.
STEP 2
Using the handle, place the base unit on the back of the floor
with the hollow side facing down.
STEP 3
Locate your three fan units, picking them up with the handles
located on the back, place the first fan unit onto the base,
lining it up with the grooves – make sure it is securely in place
with no movement.
Stack the next fan unit on top of the first one. And the third fan
unit on top of the second one so you have a total of three fan
units on top of the base. Ensure the red filter release buttons
are on the right hand side when looking at the front of the station.
STEP 4
Locate the metal bars and base seals to align them with the
holes on the top of the base station, ensuring the seals with
washers are positioned between the base and bars with the
washers on top. Loosely screw the metal bars to the base
unit and the fans using the screws provided, allowing room to
insert the sides and only tighten after the sides are in place.

www.tanningessentials.co
TOWER ASSEMBLY
STEP 7
Locate the foot pedal and power cord. Connect the
power cord to the shorter cord coming out of the foot
pedal. Connect one of the longer cords from the foot
pedal into the base of the station, this is your spray
machine. Connect the other longer cord from the foot
pedal into the bottom fan unit of the tower. Find one of
the connector cords and insert the metal male end into
the bottom fan unit, and the female end into the middle
fan unit. Find the second connector cord and insert the
metal male end into the middle fan unit, and the female
end into the top fan unit. Plug the power cord coming out
of the foot pedal into the wall socket.
STEP 5
Locate the aluminium sides and peel off the protective
film. Insert the aluminium sides in between the fan units
and the loosely screwed-on metal support bars. Once
the side panels are inserted, starting from the top, tighten
the screws to clamp the side panels tightly into position.
(Note: these are reversible for two colour options)
STEP 6
Attach the spray applicator holder. Gently slide the inner
rubber out, ensuring it stays attached to the plastic at all
times. Turn the cup upside down, with the opening of the
rubber facing towards the edge. Fit the rubber onto the
edge of the side panel, as far as it can go. While holding
the rubber in place, swing the cup upwards on its hinge
and slide over the rubber.

www.tanningessentials.co
TOWER ASSEMBLY
STEP 8
Attach the hose to the Rapid spray unit by pulling the
connection back exposing the prongs and ensuring the
“U” groove is facing up. Line up the prongs to meet the
unit, push the connection in to cover the fitting and screw
in clockwise until firmly in place and sitting straight.
STEP 9
Connect the hose to the applicator by aligning the “D”
fitting with the flat edge towards the back. Push the fitting
into the applicator and screw clockwise until firm without
over tightening.
STEP 10
Place the applicator in the cup holder.
Turn each fan unit ON and tyrn the spray unit/base ON.

www.tanningessentials.co
RAPID APPLICATOR FUNCTIONS
Horizonatal Vertical
The most common setting is 2 or 3. The “C” setting is designed for
cleaning your applicator.
The Rapid applicator has adaptable spray patterns:
C

www.tanningessentials.co
SECONDARY SPRAY APPLICATOR MAINTENANCE
O-RING SEAL
FLUID
NOZZLE
ADJUSTABLE
NOZZLE
RETAINING
RING
TROUBLESHOOTING - BLOCKED NOZZLE OR CONTINUOUS SPRAY WITHOUT PRESSING THE TRIGGER
STEP 1 - Locate and unscrew retaining ring. To release; turn retaining ring in an anti-clockwise motion.
STEP 2 - Gently pull on the adjustable nozzle to remove.
STEP 3 - Fit an 8mm spanner to the flat edges of the fluid nozzle and turn anti-clockwise to unscrew.
STEP 5 - Ensure you do not misplace the o-ring seal, which is located behind the fluid nozzle.
STEP 6 - Once removed, visually inspect the fluid nozzle for small particles or blockages -
rinse thoroughly with hot water.
STEP 7 - Gently wipe the fluid needle to clean and remove any debris. (the fluid needle should not be
removed from the applicator at any time)
STEP 8 - Once visually clear of any debris, re-attach fluid nozzle, ensuring the O-ring is in position, then
use the spanner (8mm) to gently tighten back into place.
STEP 9 - Replace adjustable nozzle and rotate back into position.
STEP 10 - Repeat previous step, this time with the retaining ring.
FLUID
NEEDLE
Secondary maintenance must be run on the applicator every 2-4 weeks or when required.
Secondary maintenance will deliver a more thorough clean to prevent or clear any blockages
and uphold the applicators performance.

SPRAY STATION TROUBLESHOOTING AND MAINTENANCE
If you are experiencing problems with this unit, in the first instance please carefully read the
relevant sections of the User Manual and the Troubleshooting section below. If you cannot
solve your problem please contact your supplier for further assistance.
www.tanningessentials.co
PROBLEM CAUSE WHAT TO DO
Your unit isn’t
extracting at
full capacity.
Unit isn’t working correctly.
The unit is not turned on.
The filter needs to be changed.
Feel for air from the back of each
unit.
Check each fan unit switch is on
and illuminated blue and make
sure all cords are inserted correctly.
Replace the filter.
The blue light
on the power
switch does
not turn on.
The foot pedal
does not work.
There is a build
up of solution
around the fan
units.
Electricity not turned on.
The fuse needs to be replaced.
Electricity is not turned on.
The fan units need to be
cleaned.
The filter needs to be changed.
Check the power cord is plugged
in correctly.
Change the fuse. This is located on
the side of each fan unit where the
power switch is, above the metal
pronged male plug.
Check each tan unit switch is on
and illuminated blue, and make
sure all cords are inserted
correctly.
Check the power is turned on
at the power outlet.
Clean the unit using warm soapy
water. Approximately once a month
unstack the fan units and clean in
between with warm soapy water.
Replace the filter.

www.tanningessentials.co
CHANGING THE EXTRACTION FILTERS
STEP 1
Press the red button on the side of the system and swing
open the front of the unit.
STEP 2
Remove the filter, discard and replace with a new filter
with the metal grid facing forward.
STEP 3
Close the unit back up by pressing the red button and
pushing the front of the unit in place until it locks.
The filters are disposable and replacement filters are ordered in a 2 pack (so you will require
2 packs for this unit). It is recommended that filters be changed after 100+ sprays.
CHANGING THE FUSE
STEP 1
Use a flat edge screwdriver to open the fuse
compartment.
STEP 2
Remove the old fuse and replace with a new one.

RAPID TROUBLESHOOTING
If you are experiencing problems with this unit, in the first instance please carefully read the
relevant sections of the User Manual and the Troubleshooting section below. If you cannot
solve your problem please contact your supplier for further assistance.
www.tanningessentials.co
PROBLEM CAUSE WHAT TO DO
My solution is
bubbling from
the cup
Seal is not in properly
Solution Cup is not screwed in
correctly
The cup is cross-threaded
Solution cup is overfilled
Fit the gun seal correctly.
Unscrew and reattach the cup.
Unscrew and reattach the cup.
Empty some solution from the
cup so it is half to 3/4 full.
The air flow is
cutting in an out
The filter is dirty
The power setting need
adjusting
Remove the filter from the base of
the unit and rinse in warm water.
Wait until filter is completely dry
before refitting.
Increase the power on your system.
Power cord not attached
Electricity not turned on
Ensure that the power cord is
pushed in firmly to the base of the
unit and wall socket
Ensure that the power point is on
The Spray Unit
will not turn on
Spray Cup is not tight enough
Too much solution
Nozzle may be blocked
Tighten the solution cup
Empty some solution from the
cup so it is half to 3/4 full
Perform secondary maintenance
The spray
applicator is
leaking
Prongs & groove are not
aligning properly
Pull connection back exposing
the prongs. Ensuring the groove
is facing the top, line up the prongs
to meet the unit. Release the
connection & screw in clockwise.
My hose won’t
screw into the
unit.

RAPID TROUBLESHOOTING
www.tanningessentials.co
PROBLEM CAUSE WHAT TO DO
There is a ‘E’
showing in
place of the
number setting
on the display
face.
Overheated or electrical
malfunction
This will go down once the
machine has cooled down
This will not disappear if the
machine is no longer able to
function.
The spray is
spluttering
Solution in cup low
Control dial is set too low
Nozzle may be blocked
Air pressure is low
Add solution to the cup
Increase power
Perform secondary maintenance
Increase air pressure
Clean filter in machine
There is a ‘C’
showing in
place of the
number setting
on the display
face.
Your filter needs to be cleaned Remove the filter from the base of
the unit and rinse in warm water.
Wait until filter is completely dry
before re-fitting. To clear the setting
hold down the heat button and the
display will return to normal.
No solution is
coming out of
the spray
applicator
Nozzle may be blocked
Solution in cup too low
Trigger is jamming
Solution Dial on applicator set
too low
Spray warm water through the
applicator
Add solution to the cup
Spray warm water through the
applicator while the Solution Dial
is set at C and pull the trigger
repeatedly until it frees
Increase solution dial on applicator,
number 1 being the lowest and
Number 6 being the highest setting

PROBLEM CAUSE WHAT TO DO
The solution
is sitting on
the skin or
beading on
the client
The client
has tanning
solution in
areas they
don’t wish
to tan
The client
appears
orange
Too much tanning solution has been
sprayed onto the skin
Client has not prepared their skin
correctly i.e. moisturiser or perfume
on the skin
Client maybe excessively hot and
perspiring
If machine air pressure is set to low
it will not atomise the solution
Client may have used a body wash
or scrub high in oil.
The technician has sprayed the area
incorrectly
Client has touched part of their body
with a spray tanned area
Too much tanning solution has been
sprayed onto the skin
The client may have left a rapid
tanning solution on too long
The client may have low tolerance to DHA
Dab area gently with a clean dry
towel and re-spray lightly, blending
the tan in
Increase the air speed.
The client needs to remove the
product from the skin.
Exfoliate the area using tan removing
product for best results or a cloth
and soap
Exfoliate the skin before re-spraying
and ensure the spray application is
lighter
RAPID TIPS & TRICKS
www.tanningessentials.co

RAPID TIPS & TRICKS
www.tanningessentials.co
PROBLEM CAUSE WHAT TO DO
The spray
tan has not
developed
as dark as
desired
The spray tan solution used may be
old or heat affected reducing the
reaction in the skin. Sometimes a
green hue will appear to indicate this
A different solution was sprayed or the
spray application dial was set lighter
The client may have showered or
perspired before the tan could develop
Client may have showered too early
Other factors may affect the tan’s
development, including diet,
hormones and medication. Please
refer to the client
Client may have used soap or body
wash preventing DHA from developing
on the skin.
Be sure to keep the solution in a cool dry
place and ensure the solution is fresh
Ensure the client has followed the
correct recommendations for
preparation and post spray tan care
The client can be resprayed if
required after their minimum 8 hours
and after a shower has been taken

www.tanningessentials.co
WARRANTY INFORMATION

www.tanningessentials.co
WARRANTY RETURN FORM
DATE:
PRODUCT NAME:
CUSTOMER NAME:
PURCHASE DATE:
BUSINESS NAME:
SUPPLIER INVOICE No*:
CONTACT NUMBER:
E MAIL:
ADDRESS :
(PO Box Not Accepted)
Please include this form when returning warranty items.
Customer Information:
Product Information:
Reason for Return:
I give my authority for goods to be left at the postal address mentioned above: Please circle YES / NO
Please Note: If circled Yes, no liabillity will be taken
* All waranty claims must include proof or purchase. This must be a photocopy of the original invoice.

www.tanningessentials.co
SAFETY INFORMATION

OUR DETAILS
ADDRESS:
10 Apex Court, Thomastown, VIC. 3074 Australia
PHONE:
1300 877 677 (within Australia)
INTERNATIONAL PHONE:
[phone]
EMAIL:
[e-mail] www.facebook.com/tanningessentials
WEB:
www.tanningessentials.co www.youtube.com/user/TanningEssentials
www.tanningessentials.co
Tanning Essentials
10 Apex Court,
Thomastown, VIC. 3074
Australia
AFFIX
POSTAGE
STAMP
HERE
....................................................................................................................................................................... ..................
