Task Force Tips Ball Intake Valve Programming manual

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
MANUAL: Ball Intake Valve
Ball Intake Valve RC
Jumbo Ball Intake Valve
Jumbo Ball Intake Valve RC
INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE
WARNING Read instruction manual before use. Operation of this device without understanding the manual
and receiving proper training can be dangerous and is a misuse of this equipment. Call 800-348-
2686 with any questions.
This instruction manual is intended to familiarize firefighters and maintenance personnel with the operation, servicing and
safety procedures associated with the Ball Intake Valve Series.
This manual should be kept available to all operating and maintenance personnel.
TASK FORCE TIPS, INC.
MADE IN USA • www.tft.com 3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219- 462-6161 • Fax [phone]
Jumbo Short Ball Intake Valve
AP & AQ Series Ball Intake Valve Jumbo Ball Intake Valve
Jumbo Short Ball Intake Valve
AP & AQ Series
With Parallel Shaft
Ball Intake Valve
With Parallel Shaft Jumbo Ball Intake Valve With Parallel Shaft
OPERATING RANGE:
For Ball Intake Valves
Pressure Max 300 PSI (20 bar)
For Jumbo Ball Intake Valves
Pressure Max 250 PSI (17 bar)
Pressure Min Full Vac.
Hydrostatic Proof Test:
900 PSI (62 bar)
Six seconds from open to close
meets NFPA 1901
slow close requirement.
Ball Intake Valve RC Jumbo Ball Intake Valve RC

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
2
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Firefighting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Firefighting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufacturers and Service Association
P.O. Box 147, Lynnfield, MA 01940 • www.FEMSA.org
Table Of Contents
1.0 MEANING OF SIGNALWORDS
2.0 SAFETY
3.0 GENERALINFORMATION
3.1 SPECIFICATIONS
3.2 CORROSION
3.3 USE WITH SALT WATER
4.0 INSTALLATION
4.1 MOUNTING ON TRUCK
4.2 ENCLOSURE MOUNTING
4.3 ELECTRICALINSTALLATION AND WIRING
4.4 ELECTRICALTESTING
4.5 CHANGING HANDWHEELTO LEFT SIDE (NON RC MODELS)
4.6 CHANGING HANDWHEELTO LEFT SIDE (RC MODELS)
4.7 BALLINTAKE VALVE RC MANUALOVERRIDE
4.8 CHANGING OFFSET OF CRANK HANDLE
4.9 CHANGING COUPLING LOCKOUT
5.0 USE
5.1 INTAKE ELBOW
5.2 VALVE POSITION INDICATOR
5.3 STORZ “SUCTION GASKET” REQUEST
5.4 BALLINTAKE VALVE RC OPERATION
5.5 SUCTION SCREEN
6.0 AIR VENTAND WATER DRAIN
7.0 PRESSURE RELIEF VALVE
7.1 RELIEF VALVE SETTING PRESSURE
7.2 RELIEF VALVE FLOW vs. PRESSURE CURVE
8.0 DRAWINGSAND PARTS LISTS
9.0 TROUBLE SHOOTING
10.0 MAINTENANCE
11.0 BALL INTAKE VALVE PRESSURE LOSS
12.0 TEMPLATES
13.0 WARRANTY
14.0 ANSWERS TO YOUR QUESTIONS

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
3
1.0 MEANING OF SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a
particular hazard. Per ANSI standard Z535.6-2006, the definitions of the four signal words are as follows:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or
serious injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.
2.0 SAFETY
DANGER Do not use AC current to operate the Ball Intake Valve RC or the Jumbo Ball Intake Valve
RC. The Ball Intake Valve RC and the Jumbo Ball Intake Valve RC are 12 or 24VDC systems
ONLY! Using the wrong power source could cause electrocution, resulting in death or serious
injury.
WARNING Injury or death can result from burst hoses and fittings. Be sure the pressure relief valve is set
at the proper pressure for the type of hose and equipment you are using. See NFPA 1961 and
NFPA 1962.
WARNING Injury or death may occur by attempting to use a damaged Ball Intake Valve. Before using the
valve inspect it for damage resulting from:
• Failure to drain valve followed by exposure to freezing conditions
• Exposure to temperatures in excess of 160 degrees F
• Missing parts, physical abuse
WARNING This equipment is intended for use by trained personnel for firefighting. Its use for other
purposes may involve hazards not addressed by this manual. See appropriate guidance and
training to reduce risk of injury.
WARNING Kinks in supply hose may reduce water flow and cause injury or death to persons dependant
on water flow. When this valve is used on a hydrant or fire truck it is recommended that it be
used with an elbow to minimize risk of hoseline kinks.
CAUTION The electric Ball Intake Valve RC and the Jumbo Ball Intake Valve RC may be remotely operated.
The electric drives are current limited but may still produce enough force to cause injury. Keep
hands and fingers away from pinch points on the valve.
CAUTION Do not use the manual override hand wheel while the electric controls are in operation. The
electric drives produce enough torque to cause injury.
CAUTION The Ball Intake Valve RC and the Jumbo Ball Intake Valve RC have current limiting capabilities
which stops the motor if an obstruction is encountered. The Ball Intake Valve RC and the
Jumbo Ball Intake Valve RC must be installed as instructed using the correct controls and
electrical boxes. Failure to do so will result in damage to the electric motor and loss of current
limiting controls. This may result in injury.
CAUTION Maximum operating pressure for the Ball Intake Valve models 300 PSI (20 bar). Do not exceed
300 PSI on either side of the Ball Intake Valve. Maximum operating pressure for Jumbo Ball
Intake Valve models 250 PSI (17 bar). Do not exceed 250 PSI on either side of the Jumbo Ball
Intake Valve.
CAUTION Valve must be properly connected. Mismatched or damaged connectors may cause leaking or
uncoupling under pressure and could cause injury.
CAUTION The Ball Intake Valve may become damaged if it is allowed to freeze while containing water.
Always drain after use to avoid damage and possible loss of use.

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
4
3.0 GENERAL INFORMATION
The Ball Intake Valve and the Jumbo Ball Intake Valve are intended for use on the intake manifold of a fire engine. The valve is
kept closed while the water supply from a hydrant or another pumper to the engine is being established. This prevents the pump
from sucking air through the intake manifold and losing its prime. Once the supply hose is filled and under pressure, and the air has
been vented from the hose, the valve may be opened to connect the pump to the water supply. An adjustable pressure relief valve
mounted on the bottom of the valve opens to relieve any excess pressure that may damage the hose or the pump.An electric remote
controlled (RC) model allows the valve to be operated from a remote location. A typical installation will consist of the BIV RC and a
remote display operator station. Motor controls are designed to auto sense 12 VDC or 24 VDC operation. The motor control circuit
utilizes a position encoder and current limiting to protect the drive train at the ends of travel. Unit is supplied with 2’ of cable with a
plug on BIV RC and 10’ of cable with a receptacle so installation effort is minimized. Cable has only four conductors (two for power
and two for communications) further easing installation effort. To complete the installation, the installer will need to mount and wire
the remote display operator station. The power supply for the BIV RC will need to be connected to a protected circuit from the trucks
power distribution center. Refer to the specifications section 3.1 for nominal current draw.
Intake
Elbow
Swivel
Side B
Coupling
Air Vent & Drain
Pressure Relief Valve
Outlet
Side A
Coupling
Handwheel
Shot Pin
Knob
Valve Position Indicator
Air Vent
& Drain
Handwheel
Intake
Elbow
Swivel
Side B
Coupling
Shot Pin
Knob
Valve Position Indicator
Outlet
Side A
Coupling
AB1ST-NX
Ball Intake Valve w/Pressure Relief Valve AC1ST-NX Ball Intake Valve
Valve Pointer
Location Crank Manual Override
Hand Wheel
Electric Motor
PLUG
AB1ST-NX-PS
Ball Intake Valve With Parallel Shaft AB1ST-NX-RC Ball Intake Valve RC

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
5
3.1 SPECIFICATIONS
MODEL BALL INTAKE
VALVE JUMBO INTAKE VALVE BALL INTAKE VALVE RC JUMBO INTAKE VALVE RC
Waterway Size 3.65” (93mm) 5.25” (133mm) 3.65” (93mm) 5.25” (133mm)
Max Pressure 300 psi (20 bar) 250 psi (17 bar) 300 psi (20 bar) 250 psi (17 bar)
Min Pressure Full Vacuum Full Vacuum Full Vacuum Full Vacuum
Opening/Closing Speed 6 sec 6 sec
Voltage -Auto Sense 12 or 24volt DC 12 or 24volt DC
Motor Current
(RC Only) Nominal Limit
@ 12 VDC @ 24 VDC @ 12 VDC @ 24 VDC
3 amp 1.5 amp 12 amp 6 amp
Recommended Fuse or Circuit Breaker Size 15 amp@12 Volt
7.5 amp @ 24 Volt
Temperature Rating* -25°F to 135°F (-32°C to 57°C)
*For temperatures below 32°F(0°C), valves must be drained after use to avoid damage. See section 2.0 SAFETY.
Environmental Rating All components designed to meet minimum rating of NEMA 4 (IP65)
3.2 CORROSION
Hose couplings are attached using polymer bearing rings which provides electrical insulation to help prevent galvanic corrosion. The
parts are then hard anodized, and finally powder coated, inside and out, to help prevent corrosion. The effects of corrosion can be
minimized by good maintenance practice. See section 10.0 for maintenance.
3.3 USE WITH SALT WATER
Use with salt water is permissible provided valve is thoroughly cleaned with fresh water after each use. The service life of the valve
may be shortened due to the effects of corrosion and is not covered under warranty.
4.0 INSTALLATION
4.1 MOUNTING ON TRUCK
Screw the large coupling to the pump inlet manifold. The valve position indicator should be clearly visible, but need not be level.
4.2 ENCLOSURE MOUNTING
Select proper location for display. A full size template is shown in section 12.0.
4.3 ELECTRIC INSTALLATION AND WIRING
Red (+) and black (-) wires must be connected to a 12 or 24 VDC protected circuit from the truck’s power distribution center. Figure
4.3 shows the control connections.
MULTIPLE OPERATOR STATIONS MAY BE INSTALLED. ALL
COMMUNICATION PAIRS (BLUE & WHITE)AND POWER
PAIRS (RED & BLACK) MUST BE CONNECTED IN TERMINAL
BOX OR ANOTHER INTERFACE BOX.
INSTALLER
SUPPLIED
POWER CABLE
INTERFACE BOX
(OPTIONAL)
NOTE:
CABLE IS GEL FILLED TO PREVENT MOISTURE WICKING INTO
ENCLOSURE. GEL IS NON-HAZARDOUS AND SHOULD BE
WIPED OFF CONDUCTORS WITH RAG.
RED RED
BLACK BLACK
BLUE BLUE
WHITE WHITE
RED
BLACK
TYPICAL TERMINAL BOX
CONNECTIONS
BLUE
WHITE
BIV OPERATOR
STATION
30 FT (9M) MAXIMUM
AB1ST-NX-RC
BALL INTAKE VALVE RC
BALL INTAKE VALVE
DUST CAP
PLUG
NOTE:
TOAVOID EXCESSIVE VOLTAGE DROP AT VALVE MOTOR, DO NOT
LENGTHEN FACTORY SUPPLIED RECEPTACLE CABLE. POWER CABLE
SELECTION IS CRITICAL. VOLTAGE SUPPLIED TO VALVE MOTOR BOARD
SHOULD NOT FALL BELOW 10 VOLTS WHEN VALVE IS IN OPERATION.
INSTALLER SUPPLIED
TERMINAL BOX OR OPTIONAL
INTERFACE BOX CAN BE USED
ELECTRIC MOTOR
MANUAL OVERRIDE
HANDWHEEL
RECEPTACLE
Figure 4.3
WARNING The electric motor and other components are ignition sources. The electric BIV should be operated only
in areas where there is adequate ventilation and no hazard of flammable vapor buildup.

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
6
4.4 ELECTRICAL TESTING
VERIFY PROPER VOLTAGE
The TFT Ball Intake Valve RC has built in circuit protection to guard against a circumstance where the unit’s movement is blocked
before reaching its full travel limits. Without this circuitry the motor would stall, overheat, and could be permanently damaged.
IMPORTANT - When mechanical installation and electrical connections are complete, perform the following test to verify voltage
supply is adequate and the current limiting feature is functioning.
Apply power to Valve Control.1. Press OPEN or CLOSE button and hold until valve reaches stop position. Continue to hold button down.2. Once movement is stopped, manually turn override knob in opposite direction while continuing to hold button3. down. If knob can be turned, then voltage supply is adequate. If knob can’t be turned and motor continues
to operate, then the current limit was not reached because the voltage supply or wiring is not adequate.
NOTE: Override knob will only turn in one direction.
To ensure proper voltage to the Ball Intake Valve RC, the wiring needs to be checked for proper gauge for the installed length of
wire, and for proper termination. Also, ensure that the power source supplying the BIV RC and the grounding are adequate (other
electrical loads on a shared circuit with the BIV RC may cause a low-voltage situation).
In addition to motor damage, a further consequence of low voltage could be that the valve will not open or close properly or fully.
SET TRAVEL STOPS
When proper voltage is verified, perform the following to set the full travel limits.
Apply power to Valve Control.1. Press CLOSE button and continue to hold until valve is fully closed. Motor must stop by current limit method. If motor continues2. to operate see proper voltage section above.
Press OPEN button and continue to hold until valve is fully open. Motor must stop by current limit method. If motor continues3. to operate see proper voltage section above.
Position indicator lights will now track valve movement.4.
4.5 CHANGING HANDWHEEL TO LEFT SIDE (NON RC MODELS)
RETAINING
RING
SMALL
BUSHING LARGE
BUSHING
KEY
SHAFT
ASSEMBLY
The handwheel is shipped from the factory on the right hand side of the valve. The hand wheel can be switched to the left hand side
for convenience or if it interferes with other equipment on the pump panel.
To move the handwheel to the opposite side, remove the retaining ring on the end of the shaft. Pull the shaft out of the gear box. As
the shaft is withdrawn, grasp the small key on the shaft so it does not get lost. Remove and switch the two plastic bushings that come
out of the sides of the gearbox. The bushing with the large hole is installed on the same side as the handwheel.
Look through the gear box and note approximate position of the keyway in the worm inside the gear box. Slide the shaft into the
gearbox on the opposite side of the gear box with the key oriented the same as the keyway. A small dab of grease will keep the key
place. Rotate the shaft until the key finds the keyway and push the shaft in until it stops. Reinstall the retaining ring. Do not over
expand the retaining ring.

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
7
4.6 CHANGING HANDWHEEL TO LEFT SIDE (RC MODELS)
STEP 1: Remove screws and end cover
STEP 2: Slide off both sprockets and chain as one unit.
STEP 3: Remove button head screws and lock washer to remove motor unit.
STEP 4: Remove 4 screws and reposition motor so electric wire points in desired direction.
STEP 5: Change hand wheel to other side as in Section 4.3.
STEP 6: Reverse steps 1, 2 and 3 to reinstall motor on other side.
STEP 7: Reverse polarity (direction) of motor by holding OPEN and CLOSE buttons together for 15 seconds.
NOTE: Remove set screw that is in hole for the button head screw and reinstall the set screw on the other side. The set
screw plugs the hole to keep dirt from entering the gearbox.
STEP 5
STEP 2
STEP 1
STEP 4
STEP 3
4.7 BALL INTAKE VALVE RC MANUAL OVERRIDE
The Ball Intake Valve RC is motor driven but also has an
override handwheel for operating the valve manually. The
override handwheel may also be used in the event of power
failure. If electrical power is supplied to the control panel then
the LED valve position display will track the valve’s position as
the handwheel is moved. If the handwheel is moved while there
is no power to the electric controls than the LED valve position
display will be in error when the electric power is reconnected.
The LED valve position indicator will self correct the first time the
valve is cycled under electric control.
If more compactness is desired the override handwheel may be
removed. The drive shaft has a hex so a wrench or socket may
be used for manual override. If the manual override handwheel
is removed assure that the correct size wrench of socket is
available in the event of power failure.
11/16” (18mm) Hex

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
8
4.8 CHANGING OFFSET OF CRANK HANDLE
Whenequippedwithacrankhandle,twooffsetpositionsareavailabletoadjust
the swing radius of the crank and knob as shown in figure 4.10. The longer
offset position offers reduced effort to operate the valve. The shorter offset
is available to avoid interference with other equipment on the apparatus. To
change the offset, remove two 3/8”-16 x 1-1/2 button head cap screws from
crank. Place crank in desired position and replace screws.
LONGER OFFSET POSITION
2.6" [67mm]
SWING RADIUS
SHORTER OFFSET POSITION
1.6" [41mm]
SWING RADIUS
4.9 CHANGING COUPLING LOCK-OUT
PULL PIN
LOCK-OUT SCREW
To change a coupling from rigid to full time swivel, use a 7/32” Allen driver to
back out the lockout screw until the coupling moves freely.
To change a coupling from full time swivel to rigid, first align the pull pin in
the elbow to vertical. Rotate the coupling until the lockout screw is aligned
with the pull pin. Use a 7/32”Allen driver to tighten the lockout screw into the
lockout divot in the elbow.
5.0 USE
5.1 INTAKE ELBOW
The intake elbow swivels 360 degrees to help prevent hose kinks, and make connection of suction lines easier. The intake can be
turned forward or backward to help make connections in tight places if the water supply is in front of or behind the truck. To turn the
elbow, pull the shot pin knob on top of the elbow. The elbow will lock into a detent every 45 degrees. There is a hole on the side of
the elbow that can be used to attach the lanyard or chain of a cap by use of a key ring . The elbow may be swivelled to any of eight
positions by pulling the shot pin knob.
5.2 VALVE POSITION INDICATOR
CLOSED
OPENOPEN
3
4
1
2
1
4
1
4
1
2
3
4
CLOSED
3
4
3
4
1
2
1
2
1
4
1
4
To open the valve turn the handwheel until the valve position says “OPEN”. To close the valve
turn the hand wheel the opposite way until the valve position indicator says “CLOSED”.
5.3 STORZ ‘SUCTION GASKET’ REQUEST
If your application of this product requires drafting, you may need a suction gasket, please call
1-800-348-2686 to receive a free suction gasket by mail.
Part Numbers: 4” STORZ - item # A4216, 5” STORZ - item #A4221
5.4 BALL INTAKE VALVE RC OPERATION
POWER
LED
POSITION
INDICATOR
CONTROL BUTTONS
Figure 5.4
Power LED:
LED will be solid green when power is present
Position Indicator:
5 LEDs indicate valve position. One for full close (red at far right), one for full open (green
at far left), three yellow for 25%, 50 %, and 75% open. Two LEDs will light when position is
between two percentages.
Note: The position indicator will lose position if the manual override is used while the power
is off. Position location is restored after the first cycle of electric operation.
All 5 position LED’s blinking indicates a fault with the motors encoder.
Control Buttons:
Manual Mode
When OPEN or CLOSE button is pressed, valve opens or closes until button is released.
Automatic Mode
When OPEN or CLOSE button is momentarily pressed, valve opens or closes fully.
During valve movement if STOP or the other direction is momentarily pressed the motor
will stop.
Changing Modes (Unit is shipped from factory in the Auto Mode)
Press CLOSE and STOP buttons together and hold for 3 seconds to change to Automatic
Mode.
Press OPEN and STOP buttons together and hold for 3 seconds to change to manual
mode.

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
9
5.5 SUCTION SCREEN
This device may be equipped with a suction
screen to catch debris larger than 3/8” diameter
in the waterway. See chart to determine
additional loss caused by the screen. To add
or replace a suction screen, order TFT part
#A1410-KIT for the 4.5” waterway, and TFTpart
#A1411-KIT for the 5.0” waterway.
SUCTION SCREEN PRESSURE LOSS
0
5
10
15
20
25
30
35
0 200 400 600 800 1000 1200 1400 1600 1800 2000
FLOW (GPM)
LOSS (PSI)
0
0.5
1
1.5
2
0 1000 2000 3000 4000 5000 6000 7000
(LPM)
(BAR)
4.5" Waterway
5.0" Waterway
6.0 AIR VENT AND WATER DRAIN
The BIV and Jumbo BIV come with anAir Vent/Drain situated on the side of the PRV pad. The BIV has a second plugged port on the
opposite side of the pad. An additional port on both the BIV and Jumbo BIV is located along side of the gearbox. To use a different
port position, relocate the factory supplied drain valve or install an additional drain valve. If the Air Vent/Drain is being relocated,
use a ¾”NPT plug to seal the empty port.The barb fitting must be removed from theAir Vent/Drain body to install and replaced once
the Air Vent/Drain body is tightened.
7.0 PRESSURE RELIEF VALVE
CAUTION Loss of prime can interrupt water flow and cause injury or death. Always bleed out air with air
valve to prevent possible loss of prime.
If there is a pressure relief valve on the bottom side of the valve. It may be set to any pressure between 50 and 200 psi. Its function
is to protect the pump and the supply hose from excess pressure. The relief valve may be mounted with its opening facing the front,
back, right or left. A piece of hose or tubing may be mounted on the round spout to direct the water coming out of the relief valve
away from the pump panel. To change the orientation of the relief valve, remove the four 7/16 bolts on the corners of the relief valve
flange, orient the valve the way you want it, and replace the bolts. Use a drop of thread locking compound on the threads of the bolt
to prevent them from coming loose.
7.1 RELIEF VALVE SETTING PRESSURE
To set the relief valve pressure turn the adjusting screw on the relief valve housing until the surface of the screw is even with
the desired pressure. A 9/16” (14mm) socket or a 1/4” Allen wrench may be used to turn the adjusting screw. Do not cap or plug
discharge opening.
7.2 RELIEF VALVE FLOW vs. PRESSURE CURVE
0
25
50
75
100
125
150
175
200
225
250
275
300
0 25 50 75 100 125 150 175 200
FLOW (GPM)
PRESSURE (PSI)
0
5
10
15
20
0 100 200 300 400 500 600 700 FLOW (LPM)
125 PSI SETTING
200 PSI SETTING
50 PSI SETTING
PRESSURE RELIEF VALVE PERFORMANCE
PRESSURE (BAR)
Adjusting
Screw
Relief Valve
Discharge Opening

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
10
8.0 DRAWINGS AND PARTS LISTS Ball Intake Valve - AB & AC Series
Optional
Parallel
Shaft Drive
AC Series
AB Series
10 11
13
14
15 17
18 59 20
22
23
25
24
58
27
21
14 60
28
30
32
29
33
69
68
36 37 38
61 62 63
42
43 45 46
47
44
54
62 64
65
66
67 31
50
49
48
51
1
2
3
4
5
6
7
8
9
11
12
13
56
57
9
5352
14
15
2
3
4
9
= Relief Valve
Parts List
= Ball Intake Valve
Parts List
71
70
5
6
7
8
57
2
16
1
72
16
RELIEF VALVE PARTS LIST
Index Description QTY Part #
1 1/2-13 X 1.0 BUTTON HEAD CAP SCREW 1 VT50-13BH1.0
2 O-RING-236 3-1/4 ID 1/8 C/S 1 VO-236
3 DEBRIS WASHER 1 A1169
4 HOUSING W/OUT THDS 1 A1150
5 5/16-18 X 3/8 SOCKET SET SCREW CUP POINT 1 VT31-18SS375
6 VALVE SEAT 1 A1168
7 PISTON -HARDCOAT 1 A1160
8 O-RING-231 2-5/8 ID 1/8 C/S 1 VO-231
9 QUAD RING 422 1.5 ID X 1/8 C/S 2 VOQ-4222
11 SPRING SEAT 1 A1166
12 RELIEF SPRING 1 A1170
13 SMALLEY RING 1 V4210
14 ADJUSTING SCREW 1 A1167
15 SPRING HOUSING 1 A1164
16 COVER PLATE/CAP 1 X631

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
11
8.0 DRAWINGS AND PARTS LISTS Ball Intake Valve Parts List - AB & AC Series
Index Description QTY Part # Index Description QTY Part #
1 BIV BODY - POWDER COAT 1 A1015
50
COUPLING HEAD STORZ 5" X 5.25PSF
INSERT RING STORZ 5”
O-RING 250, 5” ID X 1/8 C/S
1 A4115
2 O-RING-236 3-1/4 ID 1/8 C/S 1 VO-236 1 A4165
3 BACK RING STAINLESS STEEL 1 A1201S 1 VO-250
4 VALVE SEAT 1 A1520 COUPLING HEAD STORZ 6" X 5.25PSF
INSERT 6.0"BSPM X PSF5.25 1 *X696SX-LOCK
5 PLASTIC STRIP 7.00" 1 A1290 1 A4765
6 SEAL RETAINER 1 A1521S COUPLING HNDL 4.0"NHF X PSF5.25 1 A4560N
7COUPLING 5.0"NHF X PSF7.0-NFS 1 A1261NT COUPLING HNDL 4.5”NHF X PSF5.25 1 A4565N
COUPLING 6.0"NHF X PSF7.0-NFS 1 A1266NX COUPLING SH 5.0"NHF X PSF7.0 NFS
MATE PSF5.25 X PSM7.0-NFS
PLASTIC STRIP 5.25"
CUP SEAL 5.25 X 4.750 X ¼
LABEL; PORT COVER
BALL 7/16" STAINLESS
1 A1261NT
8GASKET - 5.0" HOSE COUPLING 1 V3220 1 A4745
GASKET - 6.0" HOSE COUPLING 1 V3240 1 A1291
9 PORT PLUG 1 A1299 1 A1596
10 RETAINING RING 1 VR4275 1 A1298
11 SMALLBUSHING 1 A1525 1 VB.437
13 GEAR BOX 1 A1505 COUPLING SH 6.0"NHF X PSF7.0-NFS 1 A1266NX
14 3/8-16 X 1 1/4 SOCKET HEAD CAPSCREW 4 VT37-16SH1.2 MATE PSF5.25 X PSM7.0-NFS 1 A4745
15 5/32 X 7/8 HDP SPIROLPIN #12437 1 V1900 PLASTIC STRIP 5.25” 1 A1291
16 POSITION INDICATOR 1 A1517 CUP SEAL5.25 X 4.750 X ¼ 1 A1596
17 LABEL; BGIV GEARBOX 1 AL010 LABEL; PORT COVER 1 A1298
18 BUTTON HEAD SCREW 2 VT25-20BH500 BALL7/16" STAINLESS 1 VB.437
20 KNOB 1 A1512
51
GASKET 4” PRESSURE (4” STORZ ONLY) 1 A4215
21 WASHER .812 OD X .406 ID X .065 THICK 2 VW812X406-65 GASKET 4” PRESSURE (4” STORZ ONLY)/VACUUM 1 A4216
22 CRANK BUSHING 1 A1513 GASKET 5” PRESSURE (5” STORZ ONLY) 1 A4220
23 3/8-16 X 1.5 BUTTON HEAD CAPSCREW 1 VT37-16BH1.5 GASKET 5” PRESSURE (5” STORZ ONLY)/VACUUM 1 A4221
24 CRANK SHAFT 1 A1510 GASKET 6” PRESSURE (6” STORZ ONLY)/VACUUM 1 A4226
25 KEY, 1/8" X 1.00" 1 X225 GASKET 4.0” HOSE COUPLING 1 V3198
27 THIN WASHER 2 A1530 GASKET 4.5” HOSE COUPLING 1 V3210
28 12 DP WORM 1 X220 GASKET 5.0” HOSE COUPLING 1 V3220
29 INTERNALWORM GEAR TRUNNION 1 A1501 GASKET 6.0” HOSE COUPLING 1 V3240
30 GEAR THRUST WASHER 1 A1502 52 PLASTIC STRIP 4.25" (4” STORZ ONLY) 1 A1292
31 GEAR SPACER 1 A1511 PLASTIC STRIP 5.25" 1 A1291
32 3/8-16 X 5/16 SOCKET SETSCREW CUP POINT 2 VT37-16SS312 53 CUPSEAL 4.25X3.750 X 1/4 (4” STORZ ONLY) 1 A1597
33 1/4" BALL - 302 STAINLESS STEEL 72 V2125 CUP SEAL 5.25 X 4.750 X 1/4 1 A1596
36 CUP SEAL6.0” ID X 3/16 C/S 1 A1545 54 LOCK-OUT SCREW 1 A1294
37 HALF BALLSTAINLESS STEEL 1 A1043S 56 HOLLOW TRUNNION 1 A1514
38 ELBOW 4" (4” STORZ ONLY) 1 A1071 57 7/16-14 X 1 HEX HEAD BOLT 4 VT43-14HX1.0
ELBOW 5" 1 A1054 58 LONG BUSHING 1 A1526
42 ½ BARB X ¼ NPT FITTING 1 XX329 59 HANDWHEEL 1 X281
43 DETENT PIN 1 A1560 60 NAMEPLATE 1 A1306
44 SPRING 1 X345 61 DRAIN BODY 1 A1543
45 DETENT PIN HOUSING 1 A1570 62 O-RING-115 2 VO-115
46 DETENT PIN KNOB 1 A1575 63 DRAIN SLEEVE 1 A1541
47 SPIROLPIN 1 VP125X750H 64 DRAIN LEVER 1 A1542
48 LOCKING LEVER - MOLDED 1 A4171 65 DOG POINT SCREW 1 H515
49 SPRING TORSION 1 A4230 66 O-RING-110 1 VO-110
50
SPOUT 4”NHM X PSF5.25 1 A4620N 67 O-RING-128 1 VO-128
SPOUT 4.5”NHM X PSF5.25 1 A4625N 68 O-RING-214 1 VO-214
SPOUT 5”NHM X PSF5.25 1 A4630N 69 SET SCREW 1 VT31-18SS375
COUPLING 4.0”NH X PSF5.25 1 A4660N 70 3/4"NPTM HEX SOCKET PLUG 1 XG410
COUPLING 4.5”NH X PSF5.25 1 A4665N 71 PARALLEL DRIVE GEARBOX SUBASSEMBLY 1 A1633-KIT
COUPLING 5.0”NH X PSF5.25 1 A4670N 72 POSITION INDICATOR LABEL 1 A1524
COUPLING 6.0”NH X PSF7.0
MATE PSF5.25 X PSM7.0
PLASTIC STRIP 5.25"
CUP SEAL 5.25 X 4.750 X ¼
LABEL; PORT COVER
BALL 7/16" STAINLESS
1 A1266NX
1 A4745
1 A1291
1 A1596
1 A1298
1 VB.437
COUPLING HEAD STORZ 4" X 4.25PSF
INSERT RING STORZ 4”
O-RING 155 4” ID X 3/32 C/S
1 A4114
1 A4164
1 VO-155

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
12
8.0 DRAWINGS AND PARTS LISTS Jumbo Ball Intake Valve - AX & AZ Series
Optional
Parallel
Shaft Drive
AZ Series
63
64
X631 Blank Cap
AX Series
89
90

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
13
8.0 DRAWINGS AND PARTS LISTS Jumbo Ball Intake Valve Parts List - AX & AZ Series
INDEX DESCRIPTION QTY PART # INDEX DESCRIPTION QTY PART #
1 6" BALL INTAKE BODY 1 A1086 46 DETENT PIN 1 A1560
2 HALF BALL STAINLESS STEEL 8" DIA 1 A1088S 47 PULL PIN SPRING 1 X345
3 O-RING-262 7.0 ID 1/8 C/S 1 VO-262 50 DETENT PIN HOUSING 1 A1570
4 6" BACK RING STAINLESS STEEL 1 A1084S 51 DETENT KNOB 1 A1575
5 6" VALVE SEAT 1 A1082 52 1/8 X 3/4 HDP SPIROLPIN 12310 1 VP125X750H
6 6" SEAL RETAINER STAINLESS STEEL 1 A1080S 53 LOCK-OUT SCREW 1 A1294
7 PLASTIC STRIP 7.00" 1 A1290 54 PLASTIC STRIP (for 6" StorzAnd 5" Threaded) 1A1293
10 COUPLING SHORT HANDLED 6.0"NH FEMALE 1A1266NX PLASTIC STRIP (for 6" Female Coupling) A1290
COUPLING SHORT HANDLED 6.0"NPSH FEMALE A1266IX 55 CUP SEALLOADED (6" StorzAnd 5" Male Only) 1 A1594
11 GASKET - 6.0" HOSE COUPLING 70 +/-5SHORE 1 V3240 56 INSERT 6.0"BSPM (6" Storz Only) 1 A1094
12 5/16-18 X 3/8 SOCKET SS CONE POINT 1 VT31-18CP375
60
6" STORZ WITH LOCK
1
X696-LOCK
13 O-RING-128 1-1/2 ID 3/32 C/S 1 VO-128 COUPLING SHORT HANDLED 6.0"NH FEMALE A1266NX
14 GEAR SPACER 1 A1511 COUPLING SHORT HANDLED 6.0"NH FEMALE A1266IX
15 O-RING-214 1 ID 1/8 C/S 1 VO-214 SPOUT 6.0" NH MALE A4640N
16 INTEGRAL WORM GEAR &TRUNNION 1 A1501 COUPLING SHORT HANDLED 5"NH FEMALE A1261NT
17 GEAR THRUST WASHER 1 A1502 COUPLING SHORT HANDLED 5"NPSH FEMALE A1261IT
18 GEAR BOX 1 A1506 61 GASKET 6" STORZ PRESSURE 1A4225
20 3/8-16 X 1 1/4 SOCKET HEAD CAP SCREW 4 VT37-16SH1.2 GASKET 6" STORZ SUCTIONAND PRESSURE A4226
21 LABEL BALLINTAKE GEARBOX 1 A1301 62 MIV TRUNNION STAINLESS STEEL 1 A1087
22 5/32 X 7/8 HDP SPIROLPIN #12437 1 V1900 63 O-RING-236 3-1/4 ID 1/8 C/S 1 VO-236
23 POSITION INDICATOR 1 A1517 64 7/16-14 X 1 HEX HEAD BOLT 4 VT43-14HX1.0
24 3/8-16 X 1-1/2 BUTTON HEAD CAP SCREW 1 VT37-16BH1.5 65 RELIEF VALVE HOUSING 1 A1150
25 CRANK BUSHING 1 A1513 66 1/2-13 X 1.0 BUTTON HEAD CAP SCREW 1 VT50-13BH1.0
26 KEY; 1/8" X 1.00" 1 X225 67 O-RING-232 2-3/4 ID 1/8 C/S 1 VO-232
27 1/4-20 X 1/2 BUTTON HEAD CAP SCREW 2 VT25-20BH500 70 DEBRIS WASHER 1 A1169
30 WASHER .812"OD .406"ID .065"THICK 1 VW812X406-65 71 VALVE SEAT PRV 1 A1168
31 KNOB - SOFT TOUCH 1 A1512 72 PISTON 1 A1160
32 HANDWHEEL LABEL; BIV 1 A1306 73 QUAD-RING-222 1-1/2 ID 1/8 C/S 2 VOQ-222
33 HANDWHEEL 1 X281 74 SPRING SEAT 1 A1166
34 CRANK SHAFT 1 A1510 75 RELIEF SPRING DACROMET COATED 1 A1170
35 LARGE BUSHING 1 A1526 76 WH-150-F-S02 SMALLEY RING 1.567/1.582"OD 1 V4210
36 THIN WASHER 2 A1530 77 ADJUSTING SCREW 1 A1167
37 12 DP WORM 1 X220 78 SPRING HOUSING 200 MAX 1 A1164
40 SMALL BUSHING 1 A1525 79 5/16-18 X 3/8 SOCKET SET SCREW CUPPOINT 1 VT31-18SS375
41 RETAINING RING 15 MM EXTERNALSTAINLESS 1 VR4275 80 3/8-24 X 3/8 DOG POINT 1 H515
42 3/8-16 X 1/2 SOCKET SET SCREW CUPPOINT 1 VT37-16SS500 81 FOLLOWER 1 U251
43 1/4" BALL - 302 STAINLESS STEEL 72 V2125 82 DRAIN HOUSING 1 A1543
44 CUP SEAL6 ID 6 3/8 OD X 3/16 HGT 1 A1545 83 O-RING-115 11/16 ID 3/32 C/S 2 VO-115
45
ELBOW (for 6" Female Couplings)
1
A1090 84 DRAIN SLEEVE 1 A1541
ELBOW (for 6" Male Or 6" Storz) A1091 85 O-RING-110 3/8 ID 3/32 C/S 1 VO-110
ELBOW (for 5" Female Couplings) A1092 86 DRAIN LEVER 1 A1542
ELBOW (for 5" Male Or 5" Storz) A1054 87 1/2" BARB X 1/4"NPTM NIPPLE 1 Xx329
88 3/4"NPTM HEX SOCKET PLUG 1 XG410
89 PARALLELDRIVE GEARBOX SUBASSEMBLY 1 A1633-KIT
90 POSITION INDICATOR LABEL 1 A1524

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
14
8.0 DRAWINGS AND PARTS LISTS Jumbo Ball Intake Valve - AP & AQ Series
93
Optional
Parallel
Shaft Drive
AQ Series
61
60
53
55
54
45
89
56
91
90
92

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
15
8.0 DRAWINGS AND PARTS LISTS Jumbo Ball Intake Valve Parts List - AP & AQ Series
Index Description Qty Part #
60
STORZ W/LOCK 4" COUPLING SUBASSEMBLY 1 A4124
1 6" BALL INTAKE BODY 1 A1086 STORZ W/LOCK 5" COUPLING SUBASSEMBLY 1 A4125
2 HALF BALL STAINLESS STEEL 8" DIA 1 A1088S STORZ W/LOCK 6" COUPLING SUBASSEMBLY 1 A4326
3 O-RING-262 7.0 ID 1/8 C/S 1 VO-262 PLASTIC STRIP 6.00" 1 A1293
4 6" BACK RING STAINLESS STEEL 1 A1084S LABEL; PORT COVER 1 A1298
5 6" VALVE SEAT 1 A1082 CUP SEALLOADED 1 A1594
6 6" SEAL RETAINER STAINLESS STEEL 1 A1080S 61 GASKET 6" STORZ PRESSURE 1A4225
7 PLASTIC STRIP 7.00" 1 A1290 GASKET 6" STORZ SUCTIONAND PRESSURE A4226
10 COUPLING SHORT HANDLED 6.0"NH FEMALE 1A1266NX 62 MIV TRUNNION STAINLESS STEEL 1 A1087
COUPLING SHORT HANDLED 6.0"NPSH FEMALE A1266IX 63 O-RING-236 3-1/4 ID 1/8 C/S 1 VO-236
11 GASKET - 6.0" HOSE COUPLING 70+/-5SHORE 1 V3240 64 7/16-14 X 1 HEX HEAD BOLT 4 VT43-14HX1.0
12 5/16-18 X 3/8 SOCKET SS CONE POINT 1 VT31-18CP375 65 RELIEF VALVE HOUSING 1 A1150
13 O-RING-128 1-1/2 ID 3/32 C/S 1 VO-128 66 1/2-13 X 1.0 BUTTON HEAD CAP SCREW 1 VT50-13BH1.0
14 GEAR SPACER 1 A1511 67 O-RING-232 2-3/4 ID 1/8 C/S 1 VO-232
15 O-RING-214 1 ID 3/32 C/S 1 VO-214 68 LDH BLANK CAP 1 X631
16 INTERNAL WORM GEAR & TRUNNION 1 A1501 70 DEBRIS WASHER 1 A1169
17 GEAR THRUST WASHER 1 A1502 71 VALVE SEAT PRV 1 A1168
18 GEAR BOX 1 A1056 72 PISTON 1 A1160
20 3/8-16 X 1-1/4 SOCKET HEAD CAP SCREW 4 VT37-16SH1.2 73 QUAD-RING-222 1-1/2 ID 1/8 C/S 2 VOQ-222
21 LABEL BALL INTAKE GEARBOX 1 A1301 74 SPRING SEAT 1 A1166
22 5/32 X 7/8 HDP SPIROL PIN #12437 1 V1900 75 RELIEF SPRING DACROMET COATED 1 A1170
23 POSITION INDICATOR 1 A1517 76 WH-150-F-S02 SMALLEY RING 1.567/1.582"OD 1 V4210
24 3/8-16 X 1-1/2 BUTTON HEAD CAP SCREW 1 VT37-16BH1.5 77 ADJUSTING SCREW 1 A1167
25 CRANK BUSHING 1 A1513 78 SPRING HOUSING 200 MAX 1 A1164
26 KEY; 1/8" X 1.00" 1 X225 79 5/16-18 X 3/8 SOCKET SET SCREW CUP POINT 1 VT31-18SS375
27 1/4-20 X 1/2 BUTTON HEAD CAP SCREW 2 VT25-20BH500 80 3/8-24 X 3/8 DOG POINT 1 H515
30 WASHER .812"OD .406"ID .065"THICK 1 VW812X406-65 81 FOLLOWER 1 U251
31 KNOB - SOFT TOUCH 1 A1512 82 DRAIN HOUSING 1 A1543
32 HANDWHEEL LABEL; BIV 1 A1306 83 O-RING-115 11/16 ID 3/32 C/S 2 VO-115
33 HANDWHEEL 1 X281 84 DRAIN SLEEVE 1 A1541
34 CRANK SHAFT 1 A1510 85 O-RING-110 3/8 ID 3/32 C/S 1 VO-110
35 LARGE BUSHING 1 A1526 86 DRAIN LEVER 1 A1542
36 THIN WASHER 2 A1530 87 1/2" BARB X 1/4"NPTM NIPPLE 1 XX329
37 12 DP WORM 1 X220 88 3/4"NPTM HEX SOCKET PLUG 1 XG410
40 SMALLBUSHING 1 A1525 89 SPOUT 5.0"NHM X HSBGM60 1A4631N
41 RETAINING RING 15 MM EXTERNALSTAINLESS 1 VR4275 SPOUT 6.0"NHM X HSBGM60 A4641N
42 3/8-16 X 1/2 SOCKET SET SCREW CUP POINT 1 VT37-16SS500
90
COUPLING RL 4.0"NHF X PSF5.25 1 A4662N
43 1/4" BALL - 302 STAINLESS STEEL 72 V2125 NFS RING 4.0 1 A4561
44 CUP SEAL 6 ID 6-3/8 OD X 3/16 HGT 1 A1545 COUPLING RL 4.5"NHF X PSF5.25 1 A4667N
45 MATE HSBGM60 X PSM6.0 1A1093 NFS RING 4.5 1 A4566
MATE HSBGM60 X PSM5.25 A1055 COUPLING RL 5"NHF X PSF5.25 1 A4670N
53 LOCK-OUT SCREW 1 A1294 SPOUT 4.0"NHM X PSF5.25 1 A4620N
54 PLASTIC STRIP (for 6" Storz and 5" Threaded) 1 A1293 SPOUT 4.5"NHM X PSF5.25 1 A4625N
PLASTIC STRIP (for 6" Female Coupling) 1 A1290 91 GASKET 4.0" HOSE COUPLING 1V3198
55 CUP SEAL LOADED (6" Storz and 5" Male Only) 1 A1594 GASKET 4.5" HOSE COUPLING V3210
56 INSERT 6.0"BSPM (6" Storz Only) 1 A1094 GASKET 5.0" HOSE COUPLING V3220
92 POSITION INDICATOR LABEL 1 A1524
93 PARALLELDRIVE GEARBOX SUBASSEMBLY 1 A1633-KIT

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
16
8.0 DRAWINGS AND PARTS LISTS Motor Assembly BIV RC & Jumbo BIV RC
24 16 25 26
23
10
12
11
13
15
14
116
18
17
21
22
9
7
8
7
123456
20
19
INDEX DESCRIPTION QTY PART #
1 1/4-28 X 5/8 SOCKET HEAD CAP SCREW 6 VT25-28SH625
2 REDUCER COVER 1 A1097
3 BUSHING NYLON 1 X252
4 38LINK ROLLER CHAIN 1 AX1685
5 DRIVE SPROCKET 12 TEETH 1 X253
6 BUSHING MOTOR 1 X256
7 THIN WASHER 2 A1530
8 BIV SPROCKET 25 TEETH 1 A1098
9 3/8-16 X 3/4 BUTTON HEAD CAP SCREW 1 VT37-16BH750
10 LOCK WASHER 3/8" 1 VW375SSLOCK
11 REDUCER HOUSING 1 A1096
12 CUP SEAL 1.0625 X .5625 X 1/4 1 Y4620
13 STRAIN RELIEF PG11 .39 HOLE 1 Y5205
14 6-32 X 5/16 LONG SHCS WITH HEAD SEAL 4 VT06S32SH312
15 MOTOR SOCKET 1 Y4615
16 O-RING-038 2-5/8 ID 1/16 C/S 2 VO-038
17 GEAR MOTOR W/CRIMPED TERMINALS 1 Y4600
18 MOTOR BOARD SUPPORT 1 Y4643
19 KNOB 1 Z245
20 OVERRIDE KNOB LABEL 1 Y4176
21 1/4-20 X ½ BUTTON HEAD CAP SCREW 2 VT25-20BH500
22 MOTOR ENCLOSURE TUBE 1 Y4641
23 CIRCUIT BOARD STANDOFF 3 Y5538
24 VALVE MOTOR BOARD 1 A5825
25 MOTOR ENCLOSURE CAP 1 Y4642
26 SMALLEY RING 1 V4295

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
17
8.0 DRAWINGS AND PARTS LISTS Parallel Shaft Gearbox
120
121
122
123
124
125
126
127
128
129
131
130
133
134
135
136
137
138
139
132
146
145
144
143
141
149
142
148
147
ITEM DESCRIPTION QTY PART # ITEM DESCRIPTION QTY PART #
120 KNOB 1 A1512 135 DOWELPIN 2 VP312X.50
121 1/4-20 X 1/2 BUTTON HEAD SCREW 2 VT25-20BH500 136 O-RING-154 1 VO-154
122 CRANK 1 A1559 137 SUBPLATE 1 A1551
123 CRANK BUSHING 1 A1547 138 O-RING-028 1 VO-028
124 WASHER 1 VW812X406-65 139 INNER BUSHING 1 A1552
125 3/8-16 X 1-1/2 BUTTON HEAD SCREW 1 VT37-16BH1.5 141 10-24 X 3/8 BUTTON HEAD SCREW 1 VT10-24BH500
126 GEAR BOX 1 A1550 142 WASHER 1 VW500X203-60
127 O-RING-116 1 VO-116 143 POSITION INDICATOR 1 A1558
128 SPACER 1 A1556 144 BIV NAME LABEL 1 A1550L
129 DRIVE SHAFT 1 A1555 145 O-RING-206 1 VO-206
130 NYLON BUSHING 1 AY307 146 INDICATOR GEAR 1 A1557
131 GEAR BUSHING 1 A1548 147 O-RING-214 1 VO-214
132 DOUBLE GEAR 1 A1554 148 1/4-20 X 3/4 SOCKET HEAD SCREW 1 VT25-20SH750
133 BUSHING 1 A1549 149 3/8-16 X 1 1/2 SOCKET HEAD SCREW 4 VT37-16SH1.7
134 INNER TRUNNION 1 A1553

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
18
9.0 TROUBLE SHOOTING
SYMPTOM POSSIBLE CAUSE REMEDY
Leaks Debris or damage in seal area Clean out debris or replace damaged
parts
Binding, Erratic operation Low Voltage (see below) See Below
Power LED on but no operation Low voltage due to:
-wire gage too small
-wire length too long
-poor connection
-inadequate apparatus electrical system
Checkconnections andwiring persection
4.3
LED D6 on motor board blinks
rapidly when button is pressed Loose encoder connection Replace Motor Sub Assembly
Bad motor encoder Replace Motor Sub Assembly
No Power LED Polarity reversed or poor connection Check wiring and correct polarity
OPEN & CLOSE LED blink every
4 seconds No communication with Valve Motor Check Blue & White communication wiring
10.0 MAINTENANCE
This valve should be disconnected, cleaned and visually inspected inside and out at least twice annually, or as water quality and
use may require. Moving parts such as hand wheels, valve ball and couplings should be checked for smooth and free operation.
Seals shall be greased as needed with a Silicone based grease such as Dow Corning 112.Any scrapes that expose bare aluminum
should be cleaned and touched up with enamel paint such as Rust-Oleum. Replace any missing or damaged parts before returning
valve to service.
CAUTION Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability
to unscrew the threads of complete loss of thread engagement over time. Per NFPA 1962
(1998 edition), if dissimilar metals are left coupled together an anti-corrosive lubricant should
be applied to the threads. Also the coupling should be disconnected and inspected at least
quarterly.
CAUTION Any alterations to the Ball Intake Valve and its markings could diminish safety and constitutes
a misuse of this product.
11.0 BALL INTAKE VALVE PRESSURE LOSS
FLOW (GPM)
INTAKE VALVE PRESSURE LOSS
0
5
10
15
20
25
30
35
40
0 500 1000 1500 2000 2500
PRESSURE LOSS (PSI)
TFT BIV with
5" COUPLING
11 PSI AT 2000 GPM
TFT BIV with
4" COUPLING
33 PSI AT 2000 GPM
TFT JUMBO BIV
With 5” Coupling
5 PSI AT 2000 GPM
TFT JUMBO BIV
With 6” Coupling
3 PSI AT 2000 GPM

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
19
12.0 TEMPLATES
HOLE LOCATIONS FOR BIV RC POSITION DISPLAY
TEMPLATE 4.2A
HOLE LOCATIONS FOR QUICK CONNECT PLUG
TEMPLATE 4.2B
7/32”(5.5mm) DIA
(4) PLACES
OR TAP FOR
10-32 UNC THREAD
3 1/2”
(89mm)
3 1/2”
(89mm)
Ø1.00" (25mm)
1/8" (3mm) DIA
(4) PLACES
0.919" (23mm)
OPTIONAL FLAT
INSTALLER CAN USE FLAT OR #4
SCREWS TO STOP ROTATION
0.964" (24.5mm)
SQUARE
MOUNT ENCLOSURE WITH
(4) #10 FASTENERS.
TIGHTEN SECURELY.

©Copyright Task Force Tips, Inc. 2002 - 2011 LIA-200 July 30, 2011 Rev13
TASK FORCE TIPS, INC.
MADE IN USA • www.tft.com 3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219- 462-6161 • Fax [phone]
13.0 WARRANTY
Task Force Tips, Inc., 3701 Industrial Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its
Ball Intake Valve and Ball Intake Valve RC (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free
from defects in material and workmanship during the five (5) year period from the date of purchase.
TFT’s obligation under this warranty is specifically limited to replacing or repairing the equipment (or its parts) which are shown by
TFT’s examination to be in a defective condition attributable to TFT. To qualify for this limited warranty, the claimant must return
the equipment to TFT, at 3701 Industrial Way, Valparaiso, Indiana 46383-9327 USA, within a reasonable time after discovery of
the defect. TFT will examine the equipment. If TFT determines that there is a defect attributable to it, TFT will correct the problem
within a reasonable time. If the equipment is covered by this limited warranty, TFT will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is
an intended or unintended beneficiary of the equipment, shall not be entitled to recover from TFT any consequential or incidental
damages for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT. It is
agreed and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone
else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT
ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR
PURPOSE. THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
14.0 ANSWERS TO YOUR QUESTIONS
We appreciate the opportunity of serving you and making your job easier. If you have any problems or questions, our toll-free
“Hydraulics Hotline”, 800-348-2686, is normally available to you 24 hours a day, 7 days a week.
