OPERATOR’S
MANUAL
RC² 2600 CLRC² 2600 CL
RC² 2600 LSLRC² 2600 LSL
RC² 3100 CLRC² 3100 CL

Dealer:
Owner:
Firm / Farm:
City: State:
No. of the Certificate of Guarantee:
Serial / No.:
Date: Invoice No.:
Product:
Notes:
IDENTIFICATION

1
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
Introduction
The RC² 2600 CL, RC² 2600 LSL and RC² 3100 CL models
perform mowing jobs with higher yield and superior quality.
These rotary cutters are used for citrus orchards cultivation
or similar to eliminate stubbles and also to provide services that
need a great speed to execute.
The RC² 2600 CL and RC² 3100 CL models work in a central
or lateral position related to the tractor center; the RC² 2600 LSL
model works in a lateral or super lateral position. All these models
work under the tree canopies to completely clean the orchards.
The rotary cutters are supplied with four reversible
DUROMARK blades (double cut), which are heat-treated and
offer a greater durability.
This operator's manual contains the necessary information
for the best performance of this rotary cutter. The operator must
carefully read the entire manual before working with the equipment.
Also, read and understand the safety recommendations.
For any further clarification or in the event of technical
problems that may arise during the service, consult your dealer
and the Technical Support department of the factory. They can
ensure the fully functioning of your TATU rotary cutter.

2Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
Table of contents
1. To the owner 3
2. To the operator 4 to 12
Working safely 4 to 6
Transportation over truck or trailer 7
Working safety standards 8
Lifting points 9
Safety decals 10 to 12
3. Data sheet 13 to 15
4. Components 16 to 18
5. Set-up instructions 19 to 28
Preparing the tractor 19
Hitching to the tractor 20
Coupling the cardan shaft 21
Reducing the cardan shaft length 22
Cardan shaft assembly 23
Equipment articulation 24
Assembly of the breather on the double divider 25
Assembly of the oil level marker with breather 26
Longitudinal leveling 27
Working position (RC² 2600 CL and RC² 3100 CL models) 28
6. Adjustments and operations 29 to 34
Direction of blades rotation and serial number 29
Daily working preparation 29
Cutting height of the blades 30
Drawbar extension adjustment (Third-point articulation) 30
Equipment transportation 31
Slip clutch 32
Troubleshooting guide 33
Operations - Important points 34
7. Optional 35 & 36
8. Maintenance 37 to 46
Lubrication / Lubrication points 37
Reversion or replacement of the blades 38
Removing the blade support 38 & 39
Replacement of the skid guides 39
Blades overlap 40
Procedures to overlap the blades 40
Transmission coupling set assembly 41
Slip clutch 42 & 43
Wheel lubrication / Cardan shaft 44
Gearbox / Rotary cutter storage 45
Torque table 46
9. Important 47
10. Notes 48

3
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
To the owner
General information
Important
Right and left hand side indication are made observing the equipment from the rear.
To order any parts or request technical assistance services, it is required to provide
the data contained on the nameplate, which is located on the equipment frame.
The acquisition of any Tatu product assures to the original purchaser the following
rights:
• Warranty certificate;
• Operator's manual;
• Technical assistance by the dealer on equipment delivery.
However, the owner must check the condition of the equipment on delivery, as well
as knowing the warranty terms.
Special attention should be given to the safety recommendations, operation precautions
and maintenance staff.
The instructions in this manual indicates how to get the best performance and allow
the operator to get maximum income, increasing the equipment lifetime.
This manual should be read by operators and maintenance staff.
• Only people who own a full knowledge of the tractor and equipment
must transport, operate and carry out any maintenance on them;
• Marchesan is not responsible for any damage caused by accident
on transporting, incorrect utilization or inadequate storage, either
by negligence and/or lack of experience from any person;
• Marchesan is not responsible for any damage caused by unpredictable
situations or the incorrect use of the equipment.
The warranty shall not be applied to any equipment, or any parts thereof,
which has been altered elsewhere than at the place of manufacture or which
the original purchaser thereof, at retail, has used or allowed to be used parts,
not made or supplied by Marchesan S/A.
NOTE

4Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
To the operator
Dear operator!
Respect the ecology. Do not throw trash away. This gesture
of goodwill helps to protect our environment.
Products such as oil, fuel, filters, batteries and others are
spilt over the soil and can penetrate to the underground layers,
compromising nature. Ecological and conscious disposal of them
should be done.
Working safely
These rotary cutters are simple to operate, requiring however
the basic and essential cautions to their handling.
Always keep in mind that safety requires constant attention,
observation and prudence during working, transportation,
maintenance and storage.
Read and understand the information before making any
adjustment or maintenance.
Have extreme caution when operating with the power take-off
(PTO). Do not get closer during operation.
• Security aspects must be carefully observed to avoid
accidents.
• This symbol is a warning used to prevent accidents.
• The instructions under this symbol refers to the safety of the
operator, mechanician or third parties, therefore they should
be carefully read and observed. If the safety instructions are
not being followed, a serious accident or even death may
occur.
Be careful with the environment

5
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
To the operator
Always use the safety locks to carry out maintenance operations
and to transport the equipment.
Never use your bare hands to check hydraulic leaks, the high
pressure can cause injuries.
Never attempt to change the adjustments, clean or lubricate the
equipment when the same is switched on or in movement.
Be careful while driving on slopes. Risk of overturn.
Prevent that chemical products (i.e.: fertilizers, treated seeds)
make any contact with your skin or clothes.
Keep access and work places clean and free from oil and grease.
Risk of accidents.
Never transport the equipment on highways or paved roads.
Avoid that the tractor wheels touch the drawbar in sharp turns.
The presence of any other people on the tractor or equipment
is stricly forbidden.
Have extreme caution when driving under electrical power lines.
Any contact may result in severe shocks, injuries or death.
For your protection and safety, always wear adequate clothes
and footwear while operating the equipment.

6Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
To the operator
• Only trained and qualified personnel are allowed to operate the equipment.
• While working or during transportation, only the presence of the operator is
allowed on the tractor.
• Do not allow children to play or to get over the equipment while it is operating,
during transportation or storage.
• While setting the equipment to transport position, check if there are no people
or animals close or under the equipment.
• Use personal protective equipment (PPE).
• Wear appropriate clothes and footwear. Avoid clothes that are either loose or
hanging from the body, which may become entangled in moving parts.
• Wear protective gloves to work near the cutting parts.
• Never operate the equipment without its protective devices.
• Have full knowledge of the soil before starting to work. Use the speed which is
suitable to the conditions of the ground. Provide the delineation of obstacles
or hazardous locations.
• Carefully check the transport width on narrow locations.
• Be careful while hitching the equipment to the tractor.
• Only pull the equipment using a tractor with appropriate power.
• Do not drive the equipment under the influence of alcohol or any soothing/
stimulating medicine, as it may result in a serious accident.
• In case of a fire outbreak or any possible hazard, the operator must leave the
area as fast as possible and look for a safe place. Always have emergency
numbers at hands.
• In case of emergency, know how to stop the tractor and equipment quickly.
• Always shut down the engine, remove the key and use the handbrake before
leaving the tractor seat.
• Never attempt to change the adjustments, clean or lubricate the equipment
while it is moving.
• Whenever you unhitch the equipment, either in the field or inside a building,
do it on a flat and firm surface and use the jacks. Make sure the equipment is
properly supported.
• We suggest that you carefully read the manual, as it will be a guide for
periodic verifications that need to be done and will allow that you assure the
maintenance of your equipment.
• If there is any doubt left after reading it, ask your dealer. For more complicated
operations, there will be the right person to help you there.
• Please check the general safety instructions on the back cover of this manual.

7
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
Transportation over truck or trailer
To the operator
Marchesan does not advise the equipment traffic on highways, because this
practice involves serious security risks in addition to being prohibited by the
current existing traffic law. The transportation for long distances should be
done on truck, trailer or other by following these safety guidelines:
• Use adequate ramps to load or unload the equipment. Do not make the loading
on ditch banks, it can cause a serious accident.
• When lifting with a hoist, use the appropriate points to lift.
• Fasten the moving parts that could get loose and cause accidents.
• Underpin the equipment wheels appropriately.
• Use chock blocks and safety chains to secure the equipment to the truck or
trailer during the transport.
• Stay away from the straps, cables or chains that are used on the load.
• Make sure the SMV (Slow Moving Vehicle) sign, and all the lights and reflectors
that are required by the local highway and transport autorithies are in place,
are clean and can be seen clearly by all overtaking and oncoming traffic.
• After 8 to 10 km transporting, please inspect the load condition. Repeat this
procedure every 80 to 100 km. Give more attention when transporting the
equipment on rough roads, slopes and other adverse conditions.
• Always be careful with the load height, especially when passing under electrical
power lines, bridges and others.
• Check all laws and regulations regarding the height limits and load width while
transporting the equipment to the truck or trailer. If necessary use banners,
lights and other devices in order to give adequate warning to the other drivers.

8Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
To the operator
Working safety standards
It is important to have knowledge not only about the functioning, operation of the
equipment and its technology, but also the working legal aspects when using the equipment,
such as: safety standards, operator's manual and working safety.
The equipment and tools used on the rural area must be properly handled, otherwise
health and safety of involved personnel may be compromised.
The operator must be capable and authorized to operate the tractor, meaning that
that person must comprehend the functioning instructions of the tractor and know about
the safety standards regarding the job that will be performed.
The Ministry of Labor and Employment created safety standards that aim to decrease
the risk of accidents that may occur to the rural worker. Related to the subject of agicultural
machines and equipments, we specifically cited the NR 06, NR 12 and NR 31 standards.
Regulatory Standard - NR 06:
• For purposes of applying this Regulatory Standard, Personal Protective Equipment
(PPE) is considered any device or product that is worn by an individual worker for protection
against risks that could threaten safety and health at work.
Regulatory Standard - NR 12:
• This Regulatory Standard and its annexes provide technical references, basic
principles and protective measures to ensure the health and physical integrity of workers
and establishes minimum requirements for the prevention of accidents and occupational
diseases in the design stages and use of machinery and equipment of all kinds, and also
to its manufacture, importation, trading, exhibition and cession in any way. It is understood
as using phase the construction, transportation, assembly, installation, adjustment,
operation, cleaning, maintenance, inspection, disabling and dismantling of machinery or
equipment.
Regulatory Standard - NR 31:
• This Regulatory Standard has the purpose to establish the precept to be applied on
the organization and on the working environment, in order to make compatible the planning
and development of agriculture, livestock, forestry, forest exploration and aquaculture with
safety on the working environment.

9
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
Lifting points
This rotary cutter has adequate lifting points located on the frame. When lifting with
a hoist, it is essential to hitch the cables to these points.
To the operator
• Use chains, of at least 3 meters long, to lift the equipment safely.
• Use the adequate points for lifting and be sure that the equipment is safe.
Avoid accidents.
• Always keep a safe distance from the equipment.

10 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
To the operator
Safety decals
The safety decals warn about the equipment points that require more attention and they
should be kept in good repair. If these decals become damaged or illegible, replace them.
Marchesan provide decals, upon request and indication of the respective serial number.
AATTEENNÇÇÃÃOO
AATTTTEENNTTIIOONN
AATTEENNCCIIÓÓNN
554400 RRPPMM
05.03.03.2949
E s t e e q u i p a m e n t o é f a b r i c a d o p a r a
o p e r a r a 5 4 0 R P M n a T D P. To d a s a s
c a p a s d e p r o t e ç ã o d o s c a r d a n s
d e v e m s e r m a n t i d a s n o l o c a l .
This equiment is designed to operate at
540 RPM maximum tractor PTO speed.
All drive line shields must be kept in
place.
Este equipo e s fabric ado para operar
a 5 40 RPM en la TDP. Todas las capas
de protección de los cardanes deben
ser mantenidas en el local.
05.03.03.1931
LLuubbrriiffiiccaarr ee rreeaappeerrttaarr
d
d
i
i
a
a
r
r
i
i
a
a
m
m
e
e
n
n
t
t
e
e
.
.
L
L
u
u
b
b
r
r
i
i
c
c
a
a
t
t
e
e
a
a
n
n
d
d
t
t
i
i
g
g
h
h
t
t
e
e
n
n
d
d
a
a
i
i
l
l
y
y
.
.
L
L
u
u
b
b
r
r
i
i
c
c
a
a
r
r
y
y
r
r
e
e
a
a
p
p
r
r
e
e
t
t
a
a
r
r
d
d
i
i
a
a
r
r
i
i
a
a
m
m
e
e
n
n
t
t
e
e
.
.
Ó l e o S A E 9 0 .
Giro Livre.
SAE 90 (ISO 220) Gear Oil.
Freewheeling Gearbox.
Aceite SAE 90 (ISO 220).
Multiplicador Giro Libre.

11
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
To the operator
Safety decals
AADDVVEERRTTÊÊNNCCIIAA // WWAARRNNIINNGG // AADDVVEERRTTEENNCCIIAA
– Leia o manual de instruções antes de operar e siga todas as recomendações.
– Mantenha livre os locais de correias e transmissões em geral.
– Abaixe o equipamento, pare o motor e tire a chave do trator antes de desengatar, ou trabalhar
sob o equipamento.
– Saiba como parar imediatamente o trator e o equipamento em caso de emergência.
– Pessoas não qualificadas e crianças estão proibidas de operar este equipamento.
– Cuidado com terrenos irregulares. Diminua a velocidade em curvas.
– Não opere a roçadeira na posição de transporte.
– Lea el manual de instrucciones antes de operar y siga todas las recomendaciones.
– Mantenga libre los locales de correas y transmisiones en general.
– Baje el equipo, pare el motor y retire la llave del tractor antes de desenganchar o trabajar
en el equipo.
– Sepa como detener inmediatamente el tractor y el equipo en caso de emergencia.
– Personas no calificadas y niños están prohibidas de operar este equipo.
– Cuidado con terrenos irregulares. Disminuya la velocidad en curvas.
– Nunca opere la desmalezadora en la posición de transporte.
AATTEENNÇÇÃÃOO // AATTTTEENNTTIIOONN // AATTEENNCCIIÓÓNN
As roçadeiras podem soltar fragmentos à altas velocidades, o que pode causar ferimentos
graves para pessoas próximas. Não opere a roçadeira com pessoas ao redor.
Rotary cutters can throw fragments away at high-speeds, which can cause serious injuries or
death for people near around. Don’t operate the rotary cutter with people around.
PPEERRIIGGOO // DDAANNGGEERR // PPEELLIIGGRROO
MANTENHA -SE DISTANTE - FACAS ROTATIVAS
MANTENGASE DISTANTE - CUCHILLAS ROTATIVAS
KEEP AWAY - ROTATING BLADES
Ferimentos graves ou morte podem resultar de fragmentos ou contato com as facas.
Não fique sobre ou próximo a roçadeira quando em operação.
Any contact or stone fragments thrown with action of the blades could result in serious
personal injury or death.
Never allow riders on the machine or near it while in operation.
Lesión personal grave o muerte pueden resultar de fragmentos o contacto con las cuchillas.
No permanezca cerca ni suba en la desmalezadora cuando esté en funcionamiento.
Las desmalezadoras pueden soltar fragmentos en alta velocidad, lo que puede causar heridas
graves para personas próximas. No opere la desmalezadora con personas alrededor.
– In order to prevent serious personal injury read and understand the manual.
– Keep the belts and transmissions tighten and clean.
– Lowe r the equipment, shut the engine off and remove the key from the tractor before
uncoupling or servicing under the equipment.
– Keep alert to stop the tractor and the equipment immediately in case of emergency.
– Unqualified people and children are not allowed to operate this equipment.
– Be careful with uneven terrain and reduce the speed in sharp turns.
– Never operate the machine in transport position.
05.03.03.1930
A
A
D
D
V
V
E
E
R
R
T
T
Ê
Ê
N
N
C
C
I
I
A
A
/
/
W
W
A
A
R
R
N
N
I
I
N
N
G
G
/
/
A
A
D
D
V
V
E
E
R
R
T
T
E
E
N
N
C
C
I
I
A
A
Sempre que montar novamente o cardan lateral,
posicione o rotor de modo que os roçadores não
se choquem.
05.03.03.2535
When re-installing the side drive shaft, place
the rotor in a way that the blades don’t run into
each other.
Al re-instalar el eje cardan lateral, posicione el
rotor de modo que las cuchillas no se choquen.
05.03.03.2534
No ajuste la fricción antes de leer
el manual de instrucciones.
Não ajuste a fricção sem consultar
o manual de instruções.
Do not adjust the friction before
reading the instructions manual.
AATTEENNÇÇÃÃOO
AATTTTEENNTTIIOONN
AATTEENNCCIIÓÓNN

12 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
To the operator
Decal spots
Item Quantity Model Serial number
A
01 RC² 2600 CL decal 05.03.03.4523
01 RC² 2600 LSL decal 05.03.03.4792
01 RC² 3100 CL decal 05.03.03.4749
B01 Marchesan logotype decal 05.03.03.4333
C01 Read the manual decal 05.03.03.1428
D01 Lubricate and tighten daily decal 05.03.03.1932
E01 540 RPM decal 05.03.03.2949
F01 Side drive shaft decal 05.03.03.2535
G01 PTO decal 05.03.03.1427
H01 Rotating blades decal 05.03.03.1930
I01 Final test decal 05.03.03.1087
J01 Vent decal 05.03.03.1127
K03 Lifting points decal 05.03.03.4078
L01 Lubrication points decal 05.03.03.4247
M01 Special blades decal 05.03.03.1929
N01 Friction adjustment decal 05.03.03.2534
MM
GG
FFLL
KKKK
KK
KK
JJ
JJ
EE
NN
CC
II
AA
BB
DD
HH

13
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
Data sheet
RC² 2600 CL
Model: ....................................................................................................... RC² 2600 CL
Cutting width (mm):................................................................................................. 2600
Number of blades: ......................................................................................................04
Hitching to the tractor (Three-point hitch): ...................................................... category II
(PTO): ............................................................................. 540 rpm
Blades rotation (PTO at 540 rpm):.................................................................... 1038 rpm
Tractor required power (cv):........................................................................................60
Gearbox: .....................................................................................(Oil volume) 2.85 liters
Double divider: .................................................................................(Oil volume) 2 liters
Width (mm):............................................................................................................ 2860
Length (mm): .......................................................................................................... 2150
Height (mm):........................................................................................................... 1120
Weight (kg):..............................................................................................................635
Model: ......................................................................................................RC² 2600 LSL
Cutting width (mm):................................................................................................. 2600
Number of blades: ......................................................................................................04
Hitching to the tractor (Three-point hitch): ...................................................... category II
(PTO): ............................................................................. 540 rpm
Blades rotation (PTO at 540 rpm):...................................................................... 996 rpm
Tractor required power (cv):........................................................................................60
Gearbox: .....................................................................................(Oil volume) 4.30 liters
Velocity transmission: ..................................................................(Oil volume) 3.40 liters
Width (mm):............................................................................................................ 2860
Length (mm): .......................................................................................................... 2150
Height (mm):........................................................................................................... 1120
Weight (kg):..............................................................................................................640
RC² 2600 LSL

14 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
Data sheet
ATTENTION
Model: ....................................................................................................... RC² 3100 CL
Cutting width (mm):................................................................................................. 3100
Number of blades: ......................................................................................................04
Hitching to the tractor (Three-point hitch): ..................................................... categoria II
(PTO): ............................................................................. 540 rpm
Blades rotation (PTO at 540 rpm):.................................................................... 1038 rpm
Tractor required power (cv):........................................................................................70
Gearbox: .....................................................................................(Oil volume) 2.85 liters
Double divider: .................................................................................(Oil volume) 2 liters
Width (mm):............................................................................................................ 3280
Length (mm): .......................................................................................................... 2350
Height (mm):........................................................................................................... 1120
Weight (kg):..............................................................................................................824
RC² 3100 CL
• The rotary cutter is designed for agricultural use only and it must not
be used in urban areas.
• Do not allow that people get closer during operation.

15
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
Data sheet
Equipment dimensions
• Measures in millimeters.
• * The measures may suffer variations due to different adjustments.
NOTE
AA
BB
DD
CC
Models A* BC* D
RC² 2600 CL 2150 1680
1120 2860 RC² 2600 LSL 1700
RC² 3100 CL 2350 1890 3280

16 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
Components
RC² 2600 CL
01 - Frame 06 - Double divider
02 - Drawbar 07 - Gearbox
03 - Drawbar extension 08 - Side skids
04 - Cardan shaft 09 - Protection cover
05 - Slip clutch 10 - Rear wheel
0101
0303
0404
0202
0505
0808
0909
0606
0707 1010
0707

17
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
Components
RC² 2600 LSL
01 - Frame 06 - Velocity transmission
02 - Drawbar 07 - Gearbox
03 - Drawbar extension 08 - Side skids
04 - Cardan shaft 09 - Protection cover
05 - Slip clutch 10 - Rear wheel
0101
0303
0404 0202
0505
0707
0606
0808
0808
0909
1010

18 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC² 2600 CL / RC² 2600 LSL / RC² 3100 CL
RC² 3100 CL
Components
01 - Frame 06 - Double divider
02 - Drawbar 07 - Gearbox
03 - Drawbar extension 08 - Side skids
04 - Cardan shaft 09 - Protection cover
05 - Slip clutch 10 - Rear wheel
0101
0303
0404
0202
0505
0808
0909
0606
0707 1010
0707
