3-AXIS IR CAMERA
USER’S MANUAL
TBK-4806E48IRV

Explanation of two Symbols
THE GRAPHIC SYMBOLS WITH SUPPLEMENTAL MARKING ARE ON
THE BOTTOM OF THE SYSTEM.
1. User Information
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,within an
equilateral triangle, is intended to alert the user to the
presence of un-insulated "dangerous voltage" within
the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance-(servicing) instructions in
the literature accompanying the appliance.

"WARNING-TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THE UNIT TO RAIN OR MOISTURE"
◈ Do not install the camera in extreme temperature conditions.
Do use the camera under conditions where temperatures are
Within -10°C to 45°C. Especially be careful for ventilation under
high temperature. (with heater : -30°C ~ 50°C)
◈ Do not install or use the camera in an environment where the
humidity is high.
It can cause the image quality to be poor.
◈ Do not install the camera under unstable lighting conditions.
Severe lighting change or flicker can cause the camera to work
improperly.
2. Precautions

◈ Never use the camera close to a gas or oil leak.
It can cause malfunctions to occur.
◈ Do not disassemble the camera.
There are no user-serviceable parts inside it.
◈ Do not drop the camera or subject them to physical shocks.
It can cause malfunctions to occur.
◈ Never keep the camera face to strong light directly.
It can damage CCD.
Note
When this camera is installed near wireless communication devices that
emits strong electromagnetic field, irregularity such as noise on the
monitor may appear.

◈Connecting to Monitor and Power
• The wire is polarized.
• Use DC 12V power source.
3. Composition
Owner’s Manual Hexagon Wrench (3mm) Sunvisor Bolt
Mounting Screw IR PIPE CAMERA
No. Function Terminal Color Remark
#1 VideoOutput Yellow 1.0Vp-p
#2 PowerInput Red RegulatedDC12V
Video
(Yellow)
Power-DC 12V
(Red)
Video Output
GND

4. Name and Function of Each Part
 Fixing Bolt for Sunvisor: You can unfasten the
bolt in order to fix mounting bracket above.
 IR LED (Infrared LED): Automatically controlled
according to light condition.
 Front Body
 Sunvisor: To reduce direct sunlight and protect
the camera unit from rain or snow outdoor.
 Rear Body
 3-Axis Bracket: Fix the camera main body
to bracket by wrench bolt.
 Cable
 3.0mm Hexagon Bolt

5. Camera Installation
Sunvisor Bolt
Bracket Fixing Bolt (3EA)

TYPE DAY&NIGHT IR POPE COLOR CAMERA
WITH ILLUMINATOR
IMAGE SENSOR 1/3"CCD [SONY NEW CCD]
EFFECTIVE PIXEL NTSC=768(H)X494(V), PAL=752(H)X582(V)
CELL SIZE NTSC:6.35uM(H)x7.4uM(V),
PAL:6.5uM(H)x6.25uM(V)
RESOLUTION COLOR:530
B/W 550 TVL
COLOR:550
B/W 580 TVL
TV TYPE NTSC, PAL
SYNC.TYPE INTERNAL
SCANNING SYSTEM 2:1 INTERFACE
SCANNING FREQUENCY
(Horizontal)
15.734 KHz(NTSC), 15.625 KHz(PAL)
SCANNING FREQUENCY
(Verticall) 59.94 Hz(NTSC), 50 Hz(PAL)
VIDEO OUTPUT 1.0 Vp-p (Sync. Negative) Termination 75 Ω
GAMMA CHARACTERISTIC γ=0.45typ.
MIN.ILLUMINATION 40M Range at 0Lux
S/N RATIO 50dB or More (AGC OFF)
GAIN CONTROL(AGC) AUTOMATIC
SHUTTER 1/60~1/100,000 sec(NTSC), 1/50~1/100,000
sec(PAL)
TEST ILLUMINANCE AREA AVERAGE TEST ILLUMINANCE BY FRONT
VIEW
SUPPLIED VOLTAGE Regulated DC 12 V ± 15%
CURRENT CONSUMPTION 550mA (at DC 12V) Max.
LENS VARIFOCAL LENS:3.5~16mm
OPERATION TEMP. -10 ~ 50°C
PRESERVATION TEMP. -20 ~ 60°C
DIMENSION 93mm ×93mm × 117mm
WEIGHT APPROX. 850g
DAY&NIGHT IR COLOR 410K CAMERA

6. Dimension
(
mm
)
104.9
Ø65
102.5
254.3
175
99.1

If you have trouble operating your camera, refer to the following table.If the
guidelines do not enable you to solve the problem, contact an authorized
technician.
Problem Solutions
Nothing appears on
the screen.
• Check that the power cord and line connection
between the camera and monitor are fixed properly.
• Check that you have properly connected VIDEO
cable to the camera VIDEO output jack.
The image on the
screen is dim.
• Is lens stained with dirt? Clean your lens with soft,
clean cloth.
• Set the monitor to proper condition.
• If the camera is exposed to too strong light, change
the camera position.
• Adjust the lens' focus properly.
The image on the
screen is dark.
• Adjust the contrast feature of the monitor.
• If you have an intermediate device, set the
75Ω/ Hi-z properly. (refer to page 12)
• Adjust DC Level, VR Level properly.
(refer to page 10)
The camera is not
Working properly,
and the surface of the
camera is hot.
• Check that you have properly connected the camera
to an appropriate power source. (refer to page 11)
The image on the
screen flickers.
• Is the camera facing to direct sunlight or fluoresent lighting?
Change the camera position.
7. Troubleshooting

INFORMATION
This equipment has been tested and found to comply with limits for a
Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct
the interference at their own expense.
WARNING
The manufacturer could void the user's authority to operate the
equipment.
CAUTION - To prevent electric shock and risk of fire hazards:
• Do NOT use power sources except for that specified.
This installation should be made by a qualified service person
and should abide to all local codes.
