SERVICE MANUAL
LCD32V8SY
1
ǃ
Caution
ĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂ
2
2
ǃ
Specification
ĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂ
6
3
ǃ
BOM list
ĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂ
9
4
ǃ
Alignment Procedure
ĂĂĂĂĂĂĂ Ă ĂĂĂĂĂĂĂĂĂĂĂĂ
16
5
ǃ
Schematic Diagram
ĂĂĂĂĂĂĂĂĂ ĂĂĂĂĂĂĂĂĂĂĂĂ
19
6
ǃ
Explode View Diagram
ĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂĂ
33
This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product
CA UTION: TO RE DUCE THE RIS K OF
ELECTR ICA L SHOCK, DO NOT RE MOVE
COVER (OR BACK). NO USER SERVICEABLE
PAR TS INS IDE . RE FER SER VIC ING TO
QUALIFIE D SERVICE PERSONNEL.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CA U T ION
RISK
RISK
OF
ELECTRI
ELECTRI
C
SHOCK
SHOCK
DO
NOT
NOT
OPEN.
OPEN.
2
dangerous
WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
SCHNEIDER ELECTRONICS GMBH-GERMANY
1. CAUTION
1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
CAUTION:
Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and
Instructions marked on the audio equipment.
1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
3
SCHNEIDER ELECTRONICS GMBH-GERMANY
IMPORTANT SAFETY INSTRUCTIONS
FOR YOUR PERSONAL SAFETY
11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system attention to Ar ticle 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
ANTENNA
LEAD- IN WIRE
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NEC SECTION810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMP
NEC-NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
a built-in
installer s
4
SCHNEIDER ELECTRONICS GMBH-GERMANY
PROTECTION AND LOCATION OF YOUR SET
PROTECTION AND LOCATION OF YOUR SET
18.
This television set should be operated only from the type of power source indicated on the marking label.If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.
21. If you are unable to restore normal operationby followingthe detailedprocedurein your operating instructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
24. Do not use attachments not recommendedby the television set manufacturer as they may cause hazards.
25. When replacementparts are required, be sure the service technicianhas used replacementparts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.
off
5
SCHNEIDER ELECTRONICS GMBH-GERMANY
OPERATION OF YOUR SET
IF THE SET DOES NOT OPERATE PROPERLY
FOR SERVICE AND MODIFICATION
LCD 32V8SY
32' LCD Widescreen
HDTV Monitor
Features
Widescreen High Definition TV Monitor with 1366*768 High
Resolution Panel and Lightening Fast 16ms Response Time
Comprehensive Connectivity Package: DVI, PC D-Sub(VGA) In,
Component Video In, S-Video In, AV In (x3), Audio In for DVI
(1), Component Video (1) & PC D-Sub (3.5mm)
Exceptional Contrast and Brightness Performance
High Performance Video Processing with Advanced De-
Interlacing
5-Line Digital Comb Filter(Y/C Separation with Adjustable
Vertical Peaking)
SRS WOW
Standard Definition NTSC M & PAL M/N Integrated Tuner Built-in analog TV tuner receives standard over-the-air television
broadcasts and cable TV programming.
Progressively converts incoming signals and up-converts to 768
progressive lines for improved resolution&clarity.Reverse 3:2 Pull
down keeps DVD images jitter-free.
Precision Y/C separation reduces interference generated by the
interlacing process of analog signals,resulting in clear,accurate
images with improved contrast.
Improves the audio experience by providing a 3-D audio image
that extend sound in both vertical and horizontal directions.
2. SPECIFICATION RELEASE
Benefits
Capable of viewing digital TV signals(480p,720p,1080i)in
720progressive lines,Lightening fast response time yields
crisp,clear,detailed images.
High contrast ratio and high brightness brings images to life with
bright,vivid color and outstanding detail.
Connect a wide array of sources for greater utility, from VCR to
Progressive Scan DVD Player, Digital TV Tuner,Digital Cable
Box, Satellite, Game, or Personal Computer.
PICTURE SIGNAL FORMAT CAPABILIT
Y
Panel Size(inch) 32 Component Video Format Y,Pb/Cb,Pr/Cr: 480i,480p,720p,1080i@50Hz/60Hz
Category LCD TV DVI Video Format (720p,1080i)@50Hz/60Hz
Aspect Ratio 16:9 HDMI Video Format ˉ
Color Temperature Adjustable(Normal/Cool/Warm) PC Compatibility VGA: Up to 1280*1024 @75Hz
Backlight Adjustabl
e
Yes TERMINALS
Scaler Mode 4:3, 14:9 Zoom, 16:9 Zoom, Cinerama, 16:9 Subtitles,
and 16:9 Widescreen. Audio/CVBS Inputs(Composite) 3 (R/L) Audio,
3 Video:AV1,AV2,AV3
(
rear
)
Picture Effect 4 (Soft,Natural, Bright, Personal) S-Video Input 1
Film Mode(3:2 pull down) Yes Audio Input for S-Video Share with AV1
Picture Enhancement YPbPr Input 1
Comb Filter Digital 5-Line Audio Input for YPbPr 1 (R/L)
Gamma Correction Yes YCbCr Input Share with "YPbPr"
CCS Yes Audio Input for YCbCr Share with Audio Input for "YPbPr"
DCDI Yes VGA Input(RGB) 1 (D-Sub,15-Pin)
Blue Stretch ˉAudio Input for RGB 1
(
3.5mm
)
Black Stretch Yes DVI 1(DVI-D, HDCP)
Motion Compensation Yes Audio Input for DVI 1 (R/L)
DLTI Yes HDMI ˉ
DCTI Yes Audio/CVBS Outputs(Composite) 1 (R/L+CVBS) (RCA)
Dynamic Skin Correction Yes Headphone Jack Output 1
DNR Yes RF Input(Antenna) 1 (F Type)
Panel Specification Scart ˉ
Panel Supplie
r
CMO Basic Info.
Viewing Technology MVA TV System NTSC M,PAL M/N
Display Resolution WXGA(1366*768) AV System NTSC/PAL
Brightness (cd/m2) 550 Channels 181
Contrast Ratio 800:1 Chassis Name PW118
Response Time 16ms Market EM2
Viewing Angle(H/V) 170°/170° Certification CB
Life Time 60,000hrs Power Supply AC 100V-240V 50/60Hz
Color 16.7M Power Consumption-TV ON 180W
SOUND Power Consumption-Standb
y
Less than 3 W
Speakers 2 - Side Integrated Default Color
Audio Power Output 2*8 W Front Cabinet Silver gray
Sound Processing MTS stereo Rear Cabinet Gray
DVSS (Dolby Virtual Surround) ˉBase Stand Silver gray
AVC (Auto Volume Control) Yes Keyboard Position Lower right on the front panel
BBE ˉUnpackaged Dimension for Main Body (L*H*D)
SRS SRS-WOW With Base Stand (mm) 980x638x300
Without Base Stand (mm)
Packaged Dimension (L*H*D)
Main Body (mm) 1155x780x370
Sound Features Mono/Stereo Speaker Box (mm) Integrated
Function Base Stand (mm) Packaged with main body together
V-Chip Yes - USA & Canada Net Weight (Kg) 26 (main body with speaker,base stand)
CCD(Closed Caption) Yes Gross Weight (Kg) 31.5 (main body with speaker,base stand)
Teletext ˉContainer Loading
PIP/POP ˉ20 feet 90
Macro Vision Yes 40 feet 191
Calendar Yes 40 feet high
Clock/Timer
s
Timer(Sleep/Wake up/Turn off
)
ACCESSORIES
Lock Front Panel Block Operation Manual English
OSD Language English/Spanish/Portuguese/French Base Stand Included-Detachable
OSD Features Semi-transparent,Size & position adjustable Wall Mount WMB300(optional)
Card Reader ˉRemote Control 06-015W33-A003X
DVD Combo ˉOthers Power cordˈBatteries
USB Connection ˉ
Game ˉ
Screen Saver Yes
Demo Function ˉ
5-Band Graphic Equalizer, 6 effects
(Stereo,Cinema,News,Surround,Custom,Concert)
LCD32V8SY
Technical Specifications
Sound Control
2. SPECIFICATION RELEASE
PART NO. SEPC QTY LOCATION
V8-L32PS1-01D01 SOFTWARE CODE 1 U018
V8-L32PS1-01D02 SOFTWARE CODE 1 U001
V8-L32PS1-01M01 SOFTWARE CODE 1 U503
V8-L32PS1-07F01 ASS'Y - SOFTWARE 1 U020
09-0BAV70-ATX SMD DIODE BAV70 1 D514
09-55C5V1-DTX SMD.DIODE BZV55-C5V1 1 D506
09-FM5817-STX SMD.DIODE FM5817 4 D513;D510;D512;D511
09-LL4148-ATX SMD. SWITCHING DIODE LL4148 8 D505;D516;D507;D508;D509;D501;D504;D503
10-HS18VC-DBX DIODE 500MW 18HSC 1 D502
12-BT3904-0BX SMD. TRANSISTOR MMBT3904LT1(NPN) 8Q514;Q503;Q504;Q517;Q516;Q515;Q518;Q501
12-BT3904-0BX SMD. TRANSISTOR MMBT3904LT1(NPN) 4 Q513;Q512;Q511;Q505
12-BT3906-0BX SMD. TRANSISTOR MMBT3906LT1(PNP) 1 Q508
12-C144ET-0BX SMD. TRANSISTOR PDTC144ET 2 Q509;Q510
12-D40N03-0BX MOSFSET NTD40 NO3RG 2 Q507;Q506
13-12F675-00B IC PIC12F675 1 U503
13-CS5211-G0B IC CS5211G 1 U502
13-L7809C-D2B IC L7809CD2T-TR (DDPAK) 1 U506
13-LD1117-50B 5.0V IC LD1117S50TR 1 U507
13-MSP345-0GB12 IC MSP34506-C12 1 U501
13-S35380-A0B IC S-35380A 1 U508
13-TA2024-00B IC TA2024 1 U505
13-TDA282-2DB IC E-TDA2822D013TR 1 U511
13-TV6415-DDB IC STV6415D 1 U504
19-BB0000-JTX SMD. RES 0 OHM 1/10W +/-5% 4 R503;L501;R650;R649
19-BB0000-JTX SMD. RES 0 OHM 1/10W +/-5% 8 R580;R622;R648;R618;R637;R594;R643;R579
19-BB0100-JTX RES. SMD 10 OHM 1/10W +/-5% 2 R575;R576
19-BB0101-JTX SMD. RES 100 OHM 1/10W +/-5% 7 R522;R599;R600;R641;R519;R508;R507
19-BB0102-JTX SMD. RES 1K OHM 1/10W +/-5% 2 R562;R559
19-BB0102-JTX SMD. RES 1K OHM 1/10W +/-5% 8 R558;R663;R664;R517;R516;R515;R509;R568
19-BB0102-JTX SMD. RES 1K OHM 1/10W +/-5% 8 R527;R644;R630;R631;R521;R518;R520;R645
19-BB0102-JTX SMD. RES 1K OHM 1/10W +/-5% 8 R554;R551;R550;R546;R539;R538;R535;R533
19-BB0103-JTX SMD. RES 10K OHM 1/10W +/-5% 8 R615;R598;R597;R574;R570;R544;R541;R532
19-BB0103-JTX SMD. RES 10K OHM 1/10W +/-5% 8 R510;R506;R569;R549;R632;R633;R616;R567
19-BB0103-JTX SMD. RES 10K OHM 1/10W +/-5% 1 R557
19-BB0123-FTX RES.SMD 12K 1/10W +/-1% 0805 1 R525
19-BB0151-JTX RES. SMD 150 OHM 1/10W +/-5% 2 R502;R504
19-BB0153-JTX SMD. RES 15K OHM 1/10W +/-5% 3 R584;R587;R590
19-BB0203-JTX SMD. RES 20K OHM 1/10W +/-5% 2 R571;R566
19-BB0221-JTX SMD. RES 220 OHM 1/10W +/-5% 0805 2 R501;R595
19-BB0222-JTX SMD. RES 2.2K OHM 1/10W +/-5% 2 R573;R572
19-BB0223-JTX SMD. RES 22K OHM 1/10W +/-5% 8 R540;R545;R531;R548;R555;R528;R591;R529
19-BB0223-JTX SMD. RES 22K OHM 1/10W +/-5% 2 R588;R585
19-BB0302-FTX RES.SMD 3K0HM 1/10W +/-1% 1 R526
19-BB0470-JTX SMD. RES 47 OHM 1/10W +/-5% 1 R513
19-BB0473-JTX SMD. RES 47K OHM 1/10W +/-5% 0805 6 R536;R537;R552;R553;R560;R561
19-BB0479-FTX SMD. RES 4.7 OHM 1/10W +/-1% 2 R636;R635
19-BB0513-JTX SMD. RES 51K OHM 1/10W +/-5% 1 R514
19-BB0680-JTX SMD. RES 68 OHM 1/10W +/-5% 0805 1 R512
19-BB0681-JTX SMD. RES 680 OHM 1/10W +/-5% 3 R586;R589;R592
19-BB0750-JTX SMD. RES 75 OHM 1/10W +/-5% 5 R583;R578;R577;R581;R582
19-BB0820-JTX RES. SMD 82 OHM 1/10W +/-5% 5 R534;R542;R543;R547;R556
19-BB0822-FTX RES.SMD 1/10W 8.2KOHM +/-1% 1 R565
19-CC0680-JTX RES. SMD 68 OHM 1/8W +/-5% 1 R617
3. BOM LIST
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 3 C617;C606;C634
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 8 C527;C642;C530;C532;C533;C534;C531;C555
25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 8 C577;C565;C558;C562;C506;C516;C529;C528
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 6 C632;C633;C547;C549;C636;C637
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 8 C560;C563;C566;C569;C571;C556;C603;C600
25-BCB220-M1X CAP. ELEC 22 UF 16V +/-20% 3 C605;C608;C602
25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 6 C553;C598;C552;C522;C514;C505
25-BDA471-M1X CAP. ELEC 470 UF 25V +/-20% 6 C545;C546;C544;C537;C536;C535
25-BDB221-M1X CAP. ELEC 220UF 25V +/-20% 3 C580;C589;C583
25-BFB339-M1X CAP. ELEC 3.3 UF 50V +/-20% 1 C526
25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% 2 C519;C520
28-AB0102-KBX SMD. CAP 1000 PF 50V +/-10% B 2 C630;C631
28-BB0100-JCX SMD. CAP. 10PF 50V +/-5% 2 C609;C616
28-BB0102-KBX SMD CAP. 0.001UF 50V B 0805 4 C517;C644;C643;C518
28-BB0103-ZFX SMD CAP. 0.01 UF 50V F 0805 5 C559;C515;C513;C509;C504
28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 8 C581;C579;C550;C551;C554;C604;C607;C610
28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 8 C614;C618;C541;C635;C639;C638;C557;C561
28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 8 C564;C662;C661;C582;C507;C525;C538;C539
28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 8 C540;C542;C548;C568;C570;C572;C573;C574
28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 7 C575;C601;C597;C595;C593;C588;C587
28-BB0105-ZFX SMD. CAP 1UF 50V +80%-20% 1 C594
28-BB0152-KBX SMD CAP. 0.0015UF 50V B 0805 1 C523
28-BB0224-ZFX SMD. CAP 0.22UF 50V +80%/-20% 0805 8 C503;C501;C500;C502;C584;C585;C590;C591
28-BB0224-ZFX SMD. CAP 0.22UF 50V +80%/-20% 0805 3 C596;C599;C625
28-BB0339-CCX SMD. CAP 3.3PF 50V +/-0.25PF 2 C511;C512
28-BB0471-JCX SMD. CAP 470PF 50V +/-5% 1 C521
28-BB0474-ZFX SMD. CAP 0.47UF 50V +80% -20%2 C586;C592
28-BB0560-JCX SMD. CAP 56PF 50V +/-5% 2 C508;C510
28-BB0820-JCX SMD. CAP. 82PF 50V +/-5% 4 C615;C613;C612;C611
28-BC0225-ZFX SMD. CAP 2.2UF 16VDC +/-20% 2 C640;C641
28-BD0683-KBX CAP.SMD 683 25V +/-10 0805 X7R 2 C578;C576
33-ELN201-NTX CHIP BEAD 200 OHM +/-25% 4 L530;L529;L528;L527
33-ELN201-NTX CHIP BEAD 200 OHM +/-25% 8 L523;L524;L525;L526;L520;L521;L522;L531
33-GLL100-KTX SMD. COIL 10 UH +/-10% CMI3216 1 L502
33-GLL100-KTX SMD. COIL 10 UH +/-10% CMI3216 8 L503;L506;L507;L508;L513;L514;L515;L519
33-GLL220-KTX SMD.COLL 22UH +/-10% 1 L504
33-PLL100-MTX SMD COIL SPI127QR-100 1 L505
34-R100K2-10X COIL CHOKE SG9006 10UH +/-20% 4 L510;L509;L511;L512
36-371620-00X NETWORK FILTER NF0801 1 U509
40-D32V6N-MAF2X P.C.B MAIN BD 1
43-SFSS11-2DM RELAY SF-SS-112DM 1 RELA1
45-OSC18M-4Y0 CRYSTAL 18.432M 1 X501
45-OSC32K-7Y0 CRYSTAL 32.768KHZ 1 X502
46-33079W-04X PIN BASE *4 TJC3-4A 1 J507
46-33079W-09X PIN BASE *9 TJC3-9A 1 J504
46-33333W-03X PIN BASE 1 J501
46-35199W-05X CONN.PH-5A 5PIN PITCH=2.0MM 1 J502
46-35199W-06X .PH-6A 6PIN PITCH-2.0MM 1 J508
46-35199W-07X CONN.PH-7A PITCH=2.0MM 7PIN 1 J503
46-39686H-04X 4P UL2468#22 1000/800MM 1 FOR J507
46-39690W-64X CONNECTOR 64PIN 32X2 2.0X2.0 1 J505
46-CC005T-09Q HS 9P UL4007#24 50MM 1 FOR J504
46-FF010F-05001 HS 5P UL1185#26 100MM 1 FOR J502
46-FF042T-07X HS 7PIN Y0509074.3 1 FOR J503
47-RCA009-XX4 RCA SOCKET AV-3.2-3W-052 3 P501;P504;P506
47-SVI008-XX1 SOCKET DSW-506WT-L 1 P503
49-382630-BAT BATT. CR2025 1 BT1
67-387200-3A0 HEAT SINK 1 FOR U505
71-268390-0A0AF LABEL (QC) GREEN 1
71-BAR005-XX0 LABEL BAR CODE 1
55-718510-0HA5C BASE 1
57-702250-0HD HOST FOOT PAD 6
63-B40100-AB4 S/T SCREW B 4 X 10 AB 12 base armor plate to base cover
64-B40100-102 M/C SCREW B 4 X 10 8 base armor plate to base support
64-F40200-102 MACHINE SCREW F4X20 4 base support to support linker
67-C71746-0A05C BASE SUPPORT 2
67-C71756-0A05C BASE SUPPORT COVER 2
67-M71720-0E0 SOLEPLATE 1
09-0BAV70-ATX SMD DIODE BAV70 2 D012;D004
09-0BAV99-ATX HIGH SPEED DOUBLE DIODE BAV99 4 D009;D003;D007;D006
09-0BAV99-ATX HIGH SPEED DOUBLE DIODE BAV99 8 D010;D008;D013;D011;D002;D014;D015;D016
09-0BAV99-ATX HIGH SPEED DOUBLE DIODE BAV99 8 D019;D018;D017;D020;D021;D022;D023;D024
12-BT3906-0BX SMD. TRANSISTOR MMBT3906LT1(PNP) 3 Q008;Q005;Q006
12-C144ET-0BX SMD. TRANSISTOR PDTC144ET 3 Q003;Q007;Q002
13-0024LC-21B IC 24LC21-SOIC8(WRITE) 2 U001;U018
13-128168-A6B DDR SDRAM M13S128168A 2 U013;U012
13-63LVDM-83B IC THC63LVDM83R 1 U003
13-74AHCT-08B AND GATE 74AHCT08PW 1 U019
13-AIC108-4PB IC AIC1084PM 1 U015
13-AL008D-70BT2 FLASH 8M S29AL008D70TFI02 1 U020
13-EF4052-BTB IC HEF4052BT(D) 1 U005
13-IC1084-25B IC 2.5V 5A AIC1084-25CM 1 U016
13-IC1084-CMB IC AIC1084-33CM 3.3V (TO-263) 1 U014
13-IRF731-40B IC IRF7314 1 U004
13-LD1117-18B 1.8V REGULATOR IC LD1117S18TR 1 U006
13-LD1117-33B IC LD1117 3.3V 1 U007
13-M24C32-MNB IC SM M24C32-WMN6P(ST00) R 1 U021
13-PT7809-STB IC PT7M7809ST 1 U09
13-PW1181-0LB DEINTERLACER AND SCALER PW118-10 1 U002
13-PW3300-10B IC PW3300-10 1 U008
13-SRV054-CTB IC SRV05-4 TCT 2 D001;D005
19-AA0152-JTX 1206 SMD.RES.1.5K OHM 1/16W 5% 2 R069;R071
19-AA0221-JTX RES. SMD 220 OHM 1/16W +/-5% 1 R216
19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 5 R091;R127;R128;R129;R088
19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 8 R067;R229;R227;R038;R209;R198;R196;R193
19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 8 R068;R070;R086;R107;R114;R125;R149;R066
19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 8 R228;R030;R028;R213;R148;R024;R063;R065
19-AB0100-JTX RES SMD 10 OHM 1/10W +/-5% 1 R221
19-AB0101-JTX RES SMD 100 OHM 1/10W 0603 1 R174
19-AB0102-JTX RES SMD 1K OHM 1/10W 0603 7 R215;R160;R102;R103;R175;R176;R092
19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 8 R077;R076;R034;R027;R078;R084;R089;R130
19-AB0103-JTX RES SMD 10K OHM 1/10W 0603 6 R167;R132;R152;R153;R165;R166
19-AB0105-JTX RES SMD 1M OHM 1/10W 0603 2 R073;R218
19-AB0155-JTX SMD. RES 1.5M OHM 1/10W +/-5% 0603 1 R116
19-AB0201-JTX SMD. RES 200 OHM 1/10W +/-5% 0603 1 R018
19-AB0202-JTX SMD. RES 2K OHM 1/10W +/-5% 0603 2 R163;R164
19-AB0220-JTX SMD RES 22 OHM 1/10W 0603 8 R101;R100;R015;R013;R012;R010;R009;R004
19-AB0220-JTX SMD RES 22 OHM 1/10W 0603 2 R003;R001
19-AB0222-JTX RES SMD 2.2K OHM 1/10W 0603 2 R147;R146
19-AB0223-JTX SMD. RES 22K OHM 1/10W +/-5% 0603 5 R059;R058;R057;R056;R055
19-AB0223-JTX SMD. RES 22K OHM 1/10W +/-5% 0603 8 R060;R061;R046;R222;R223;R225;R226;R031
19-AB0223-JTX SMD. RES 22K OHM 1/10W +/-5% 0603 8 R047;R048;R049;R050;R051;R052;R053;R054
19-AB0243-JTX SMD. RES 24K OHM 1/10W +/-5% 0603 1 R137
19-AB0271-JTX SMD. RES 270 OHM 1/10W +/-5% 0603 1 R217
19-AB0332-JTX SMD RES 3.3K OHM 1/10W 0603 6 R140;R171;R168;R150;R131;R122
19-AB0391-FTX SMD. RES 390 OHM 1/10W +/-1% 0603 1 R112
19-AB0392-JTX SMD. RES 3.9K OHM 1/10W +/-5% 4 R135;R136;R220;R219
19-AB0470-JTX RES SMD 47 OHM 1/10W +/-5%0603 8 R138;R139;R117;R099;R087;R085;R083;R081
19-AB0470-JTX RES SMD 47 OHM 1/10W +/-5%0603 8 R075;R134;R123;R124;R121;R120;R119;R118
19-AB0470-JTX RES SMD 47 OHM 1/10W +/-5%0603 4 R151;R154;R126;R133
19-AB0472-JTX RES SMD 4.7K OHM 1/10W 0603 8 R029;R033;R093;R145;R115;R144;R007;R006
19-AB0472-JTX RES SMD 4.7K OHM 1/10W 0603 2 R008;R224
19-AB0473-JTX SMD. RES 47K OHM 1/10W 0603 7 R041;R040;R042;R043;R044;R045;R026
19-AB0682-JTX RES SMD 6.8K OHM 1/10W 0603 1 R025
19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 8 R002;R005;R011;R173;R187;C195;R190;R170
19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 5 R014;R155;R156;R157;R169
19-AB0751-FTX SMD. RES 750 OHM 1/10W +/-1% 1 R111
19-CD0000-JTX RES.SMD 0 OHM 1206 4 L027;L029;L025;R021
23-A08220-JBX NETWORK RES. 22 OHM +/-5% 4 RP025;RP026;RP027;RP028
23-A08220-JBX NETWORK RES. 22 OHM +/-5% 6 RP032;RP031;RP030;RP022;RP023;RP024
23-A08220-JBX NETWORK RES. 22 OHM +/-5% 6 RP021;RP018;RP017;RP019;RP020;RP029
23-A08470-JBX CHIP ARRAY RES. 47 OHM +/-5% 0603*4 6 RP039;RP038;RP037;RP036;RP035;RP003
23-A08470-JBX CHIP ARRAY RES. 47 OHM +/-5% 0603*4 6 RP002;RP040;RP041;RP042;RP043;RP044
23-A08470-JBX CHIP ARRAY RES. 47 OHM +/-5% 0603*4 6 RP045;RP046;RP047;RP009;RP007;RP001
23-A08470-JBX CHIP ARRAY RES. 47 OHM +/-5% 0603*4 6 RP004;RP034;RP033;RP011;RP006;RP005
28-AB0102-JCX SMD. CAP 1000PF 50V +/-5% 0603 5 C176;C184;C191;C164;C215
28-AB0103-ZFX CAP.SMD 10NF 50V +80-20% 0603 2 C018;C019
28-AB0104-ZFX CAP. SMD 0.1UF 50V +80%~-20% F 1 C216
28-AB0120-JCX SMD. CAP 12 PF 50VDC 0603 +/-5% 3 C180;C179;C178
28-AB0180-JCX SMD. CAP 18 PF 50V +/-5% 0603 8 C202;C085;C157;C158;C200;C201;C084;C083
28-AB0224-ZFX CAP.SMD 0.22UF 50V +80-20%0603 6 C196;C192;C187;C177;C174;C173
28-AB0392-KBX SMD. CAP 3900 PF 50VDC +/-10% 0603 1 C159
28-AB0393-ZFX SMD. CAP 0.039 UF 50V +80%-20% 1 C160
28-AB0471-JCX CAP.SMD 470PF 50V +/-5% 0603 1 C214
28-AC0105-ZFX SMD. CAP 1 UF 16VDC +80%/-20% 2 C213;C217
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C095;C124;C123;C122;C121;C120;C119;C118
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C063;C064;C065;C066;C067;C032;C072;C071
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C099;C098;C097;C046;C048;C050;C096;C094
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C114;C109;C105;C104;C103;C102;C101;C100
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C022;C125;C008;C007;C006;C005;C002;C001
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C069;C070;C051;C013;C014;C015;C016;C021
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C026;C027;C028;C029;C030;C060;C061;C062
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C031;C068;C055;C056;C057;C058;C059;C025
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C140;C139;C138;C137;C136;C134;C133;C023
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C182;C181;C024;C141;C144;C145;C146;C147
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C163;C165;C171;C172;C175;C186;C185;C183
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C167;C169;C154;C155;C053;C082;C077;C156
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C078;C151;C150;C149;C052;C168;C166;C170
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C090;C089;C088;C087;C086;C081;C080;C079
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C131;C132;C054;C073;C076;C093;C092;C091
28-AD0104-ZFX SMD CAP 0.1UF 25V +80-20% 0603 8 C148;C074;C075;C126;C127;C128;C129;C130
28-RA0107-MAX SMD. CAP 100 UF 10V +/-20% 6 C152;C135;C116;C115;C111;C110
28-RC0106-MAX SMD. CAP 10 UF 16V +/-20% 8 C045;C044;C043;C042;C017;C020;C035;C036
28-RC0106-MAX SMD. CAP 10 UF 16V +/-20% 5 C037;C038;C041;C040;C039
28-RC0226-MAX SMD. CAP 22 UF 16V +/-20% 2 C033;C034
28-RC0476-MAH SMD. CAP 47 UF 16V +/-20% 2 C047;C049
28-RD0477-MAX ALUMINIUM CAP. 470 UF 25V +/-20% 2 C108;C107
33-ELN221-NTX CHIP BEAD 220 OHM +/-25% 1 L004
33-ELN301-NTX BEAD CHIP HB-1T2012-301 2012 2 R201;R202
33-GLN121-NTX CHIP BEAD 120 OHM +/-25% 5 L013;L009;L003;L002;L024
33-GLN121-NTX CHIP BEAD 120 OHM +/-25% 8 L005;L006;L007;L008;L015;L017;F001;L016
33-GLN121-NTX CHIP BEAD 120 OHM +/-25% 7 L020A;L014A;L013A;L001A;L017A;L019;L026
33-GLN121-NTX CHIP BEAD 120 OHM +/-25% 7 L028;L001;L020;L018;L014;L016A;L018A
33-KLN121-NTX CHIP BEAD 120 OHM +/-25% 6 L023;L022;L021;L012;L011;L010
33-KLN181-NTX SMD BEAD CHIPHB 180 OHM 2 R141;R142
33-KLN601-NTX CHIP BEAD 600 OHM +/-25% 3 L032;L031;L030
40-D32V6N-DIC4X P.C.B.DIGIBOARD 1
45-OSC14M-3Y2 CRYSTAL 14.31818MHZ 1 Y001
45-OSC27M-0Y3 CRYSTAL 27MHZ 1 Y002
46-33079W-09X PIN BASE *9 TJC3-9A 1 J008
46-35199W-04X CONN.PH-4A 4PIN PITCH=2.0MM 2 J011;J009
46-35199W-07X CONN.PH-7A PITCH=2.0MM 7PIN 1 P003
46-38612W-30X PIN BASE DF14-30P(WF) 1.25PITCH 1 P002
46-39689W-64X CONNECTOR 1 J005
46-FF025F-04001 HS 4P UL1185#26 250MM 1 FOR J009
47-DVI001-XX0 DVI SOCKET DVFR283-PC0-NP 1 P001
47-EAR005-XX0 EARPHONE SOCKET CK3-3.5-3WK-E 1 J002
47-RCA009-XX4 RCA SOCKET AV-3.2-3W-052 1 J006
47-RCA123-XX0 RCA SOCKET AV-3.2-2W-G6 2 J003;J004
47-RCA125-XX1 RCA SOCKET AV-3.2-3W-051 1 J007
47-VGA004-XX0 VGA SOCKET D-SUB-15S(BLACK) 1 P004
67-387190-0A0 HEAT SINK 1 FOR U002
67-387190-1A0 HEAT SINK 2 FOR U013;FOR U012
67-H42094-0A0 HEAT SINK 1 FOR U008
71-268390-0A0AF LABEL (QC) GREEN 1
71-BAR005-XX0 LABEL BAR CODE 1
26-EBP104-ZFX CAP. CER 0.1UF 50V +80%/-20% 1 C21
40-D32V6N-EAB1X P.C.B EA BD 1
46-35199W-06X .PH-6A 6PIN PITCH-2.0MM 1 J1
47-EAR002-XX0 EARPHONE SOCKET CK3-3.5-9WK-B 1 J2
02-IRR001-XX5 IR RECEIVER MODULE AT156A 1 IR1
12-BC857C-0BX SMD.TRANSISTOR BC857C 1 Q2
14-LED05R-XX1 LED RED FB205 1 LED1
19-BB0000-JTX SMD. RES 0 OHM 1/10W +/-5% 1 R3
19-BB0102-JTX SMD. RES 1K OHM 1/10W +/-5% 2 R10;R11
19-BB0152-JTX SMD. RES 1.5K OHM 1/10W +/-5% 2 R6;R9
19-BB0221-JTX SMD. RES 220 OHM 1/10W +/-5% 0805 2 R1;R2
19-BB0222-JTX SMD. RES 2.2K OHM 1/10W +/-5% 2 R5;R8
19-BB0512-JTX SMD. RES 5.1K OHM 1/10W +/-5% 2 R4;R7
28-BB0101-JCX SMD CAP. 100 PF 50V C 0805 4 C2;C1;C8;C7
28-BB0104-JCX SMD.CAP 0.1UF 50V +/-5% 2 C4;C6
28-BB0105-ZFX SMD. CAP 1UF 50V +80%-20% 1 C3
28-XC0106-MTX TANTALUM CAP.10 UF 16V +/-20% 1 C5
33-GLN222-NTX CHIP BEAD MGGB3216 M222HT 1206 2.2K 1L1
40-LD32V8-IRB1X P.C.B RECEIVE BD 1
46-35135W-07X PIN BASE PH-07AW 1 P6
46-FF055F-07001 HS 7P UL1007#24 550MM 1 FROM P6 TO AN J503
48-TAC001-XX0 TACT SWITCH 6 SW1;SW5;SW4;SW6;SW2;SW3
46-39674F-30X01 HS 30#/WL1253H-30 TV1217HN0-30 220MM 1
46-39687H-32X 32P UL1617#18 640/600/400MM 1 power PCB to digital PCB/to analog PCB/inverter line
46-AK076T-02F01 HS 2PIN Y0509074.1 1 VZLWFK3&%WRSRZHU3&%OLQH
47-PWS014-XX4 FILTER SOCKET 03GEEW3E8-1(04) 1
4A-LCD32T-CM0 LCD V320B1-L01 1
54-715620-0U0 SPONGE 960X8X4 MM 0.5
54-805890-0U0 SPONGE 2 for front cabinet
54-805890-1U0 SPONGE 2 for front cabinet
55-718490-1HN9D FRONT CABINET 1
56-718160-0HA1A REAR AV BRACKET 1
56-718290-0HA5C PUSH BUTTON 1
56-718330-0HC5Z LENS 1
56-718570-0HA5C POWER KNOB 1
63-B30100-AB4 S/T SCREW B 3 X 10 AB 12 FOR RCA
63-B30100-AB4 S/T SCREW B 3 X 10 AB 3 MTG FRONT CTL BD & FRONT CABINET
63-B40150-AB3 S/T SCREW B 4 X 15 AB (BLACK) 12 MTG BRACKET& FRONT CABINET
63-S30100-AB4 S/T SCREW S 3 X 10 AB 2 MTG POWER PCB& FRONT CABINET
63-S30100-AB4 S/T SCREW S 3 X 10 AB 4 MTG SPK(RIGHT)& FRONT CABINET
63-S30100-AB4 S/T SCREW S 3 X 10 AB 4 MTG SPK(LEFT)& FRONT CABINET
63-W30080-AB4 S/T SCREW W 3 X 8 AB 1 MTG LENS & FRONT CABINET
64-B30060-104 M/C SCREW B 3 X 6 2 power switch stator & hard switch
64-B30060-104 M/C SCREW B 3 X 6 2 for back AV bracket & small iron breacket(right)
64-B30080-104 M/C SCREW B 3 X 8 5 FOR SHIDLDING COVER
64-B30080-104 M/C SCREW B 3 X 8 4 MTG TUNER BOARD& BIG BRACKET
64-B30080-104 M/C SCREW B 3 X 8 4 MTG SIGHAL BOARD& BIG BRACKET
64-B30080-104 M/C SCREW B 3 X 8 1 MTG POWER BRACKET& CROSSING BRIDGE
64-B30080-104 M/C SCREW B 3 X 8 4 MTG AV BOARD& BIG BRACKET
64-B30100-303 M/C SCREW TRIANGLE B 3 X 10 4 FOR POWER SUPPLY
64-B40080-104 M/C SCREW B 4 X 8 1 MTG RIGHT SMALL BRACKET& CROSSING
64-B40080-104 M/C SCREW B 4 X 8 2 MTG BIG BRACKET& CROSSING BRIDGE
64-B40080-104 M/C SCREW B 4 X 8 2 MTG LEFT SMALL BRACKET& ALUMINUM BAR
64-B40080-104 M/C SCREW B 4 X 8 4 MTG BIG BRACKET& ALUMINUM BAR
64-B40080-104 M/C SCREW B 4 X 8 2 MTG RIGHT SMALL BRACKET& ALUMINUM BAR
64-B40080-104 M/C SCREW B 4 X 8 1 MTG LEFT SMALL BRACKET& CROSSING BRIDGE
64-B40080-104 M/C SCREW B 4 X 8 8 MTG CROSSING BRIDGE& ALUMINUM BAR
64-B40080-104 M/C SCREW B 4 X 8 10 MTG BRACKET& LCD PANEL
64-B40120-103 M/C SCREW M 4 X 12 4 MTG BRACKET& LCD PANEL
64-F30080-104 M/C SCREW F 3X8 2 MTG AV BRACKET& BIG BRACKET
64-F30080-104 M/C SCREW F 3X8 2 MTG TUNER BOARD& BIG BRACKET
64-F30080-104 M/C SCREW F 3X8 2 MTG POWER BRACKET& POWER SOCKET
64-F40080-104 M/C SCREW M 4 X 8 8 MTG SUPPORT CONNECTOR & CROSSING BRIDGE
64-Z30060-1040A MACHINE SCREW 1 for grounding screw
66-702620-0E2 SCREW POST 4 FOR DVI;FOR VGA
67-C71722-0A0 BRACKET CONNECTOR 2
67-H71718-0A0 ALUMINUM BAR 2
67-L71622-2N09A LOGO 1
67-M71719-0E0 BRACKET 1
67-M71729-0E01A TUNER BRACKET 1
67-M71730-1E0 BRACKET 1
67-M71867-1E0 BRACKET 1
67-M71868-3E0 BOARD 1
67-M71869-1E0 BRACKET(RIGHT) 1
67-M71870-0E0 TRANSOM 2
67-M80454-0E0 POWER SWICTH NIP 1
67-S71731-4E0 SCREEN COVER 1
67-X22898-0E0 SPRING - KNOB 1
81-LC32A7-PW1 32"SMPS JSK3220-007A 1
57-10654X-00F TWIST TIE NY66 6
57-29635X-00F CABLE TIES (4.8MMX160MM) 5
57-KYWCC1-0UG0
1
WIRE MOUNT 6
67-V330Y1-0M4 METAL TIE 3
06-011W33-A202X REMOTE CONTROLLER RC1113326/00 1
49-267710-BAT BATT. R6P AA SUM3 5# 2
51-PC0220-0WU08 POWER CORD 1
54-LCPVC6-000 INLAY 1
70-271510-00A SERVICE CARD 1
71-270870-0A9 LABEL 2
72-32V8SY-S139A OPERATION MANUAL 1
74-026035-6WE9B POLYBAG 1
74-110085-50G9B PALSTIC BAG 1
75-813420-CC0 POLYFOAM"UL" 1
75-813430-CC0 POLYFOAM"UR" 1
75-813440-CC0 POLYFOAM"LL" 1
75-813450-CC0 POLYFOAM"LR" 1
75-813460-CC0 POLYFOAM"LL" 1
75-813470-CC0 POLYFOAM"LR" 1
76-813480-0AT9C CARTON BOX 1
55-718080-0HA1A FRONTPANEL 2
55-718500-0HN1C REAR CABINET 1
58-32V8MP-0UI9A INLAY MODEL NO. 1
58-718040-0UI1F INLAY 1
58-718040-0UI1G INLAY 1
63-B40150-AB3 S/T SCREW B 4 X 15 AB (BLACK) 14
25-DFB229-M1X CAP. ELEC 2.2 UF 50V +/-20% BP 1
42-07808G-XX2 SPEAKER YDF78-8R2 8 OHM 10W 1 "-"to mediant speaker PIN3,"+"to mediant speaker"-"
42-G3508F-XX0 SPEAKER 8 OHM 8W 1
54-700770-000 SPEAKER AIRPROOF STRIP 6MMX1MMX2000MM 0.5
59-718520-000 SOUND BOX BAR 4 althorn to front cover
62-717900-0HA5K FRONT COVER (LEFT) 1
62-717910-0HA5K REAR CABINET(RIGHT) 1
62-717950-0HA5K ECHO CANISTER 1
62-717960-0HA5K ECHO CANISTER 1
63-B30100-AB4 S/T SCREW B 3 X 10 AB 8 aftersound canister to front cover
63-B30100-AB4 S/T SCREW B 3 X 10 AB 6 sackbut to fornt cover;sound box front cover to rear cover
63-W30100-AB4 S/T SCREW W 3 X 10 AB 2
25-DFB229-M1X CAP. ELEC 2.2 UF 50V +/-20% BP 1
42-G3508F-XX0 SPEAKER 8 OHM 8W 1
54-700770-000 SPEAKER AIRPROOF STRIP 6MMX1MMX2000MM 0.5
59-718520-000 SOUND BOX BAR 4 sound box front cover to sound box rear cover
63-W30100-AB4 S/T SCREW W 3 X 10 AB 2
40-LD32V8-SWB1X P.C.B. SWITCH BD 1
46-35184W-02X PIN BASE *2 TJC1-2A 2 P2;P1
48-POW007-XX1 POWER SWITCH 1 SW001
54-806060-0U0 ⬉⑤ᓔ݇㒱㓬⠛ 1 FOR PCB
07-457FF5-TB1G TUNER TMQH6-019A 1 TUN1
09-LL4148-ATX SMD. SWITCHING DIODE LL4148 1 D701
11-SC1815-YBX TRANSISTOR 2SC1815-Y (NPN) 1 Q36
12-BT3904-0BX SMD. TRANSISTOR MMBT3904LT1(NPN) 3 Q701;Q702;Q703
13-LD1117-50B 5.0V IC LD1117S50TR 1 U702
13-MC3406-3AB IC MC34063AD (SO-8) 1 U8
19-BB0000-JTX SMD. RES 0 OHM 1/10W +/-5% 4 R720;R726;R711;R712
19-BB0101-JTX SMD. RES 100 OHM 1/10W +/-5% 1 R718
19-BB0103-JTX SMD. RES 10K OHM 1/10W +/-5% 1 R707
19-BB0104-JTX SMD. RES 100K OHM 1/10W +/-5% 0805 2 R710;R723
19-BB0109-JTX SMD. RES 1 OHM 1/10W +/-5% 0805 2 R709;R714
19-BB0122-FTX SMD. RES 1.2K OHM 1/10W +/-1% 0805 1 R715
19-BB0181-JTX SMD. RES 180 OHM 1/10W +/-5% 1 R704
19-BB0221-JTX SMD. RES 220 OHM 1/10W +/-5% 0805 2 R705;R713
19-BB0223-JTX SMD. RES 22K OHM 1/10W +/-5% 3 R706;R702;R701
19-BB0303-FTX RES.SMD 30K 0HM 1/10W +/-1% 1 R716
19-BB0331-JTX SMD. RES 330 OHM 1/10W +/-5% 0805 1 R708
19-BB0471-JTX SMD. RES 470 OHM 1/10W +/-5% 1 R703
25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% 4 C702;C710;C716;C718
25-BDB100-M1X CAP. ELEC 10 UF 25V +/-20% 1 C703
25-BFB220-M1X CAP. ELEC 22 UF 50V +/-20% 1 C713
25-BFB470-M1X CAP. ELEC 47 UF 50V +/-20% 1 C714
28-BB0103-ZFX SMD CAP. 0.01 UF 50V F 0805 1 C707
28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 7 C701;C709;C711;C712;C715;C717;C719
28-BB0334-ZFX SMD. CAP 0.33UF 50V +80%/-20% 1 C724
28-BB0470-JCX SMD CAP. 47 PF 50V C 0805 3 C722;C705;C706
28-DC0107-MTX TANTALUM CAP. 100 UF 16VDC +/-20% 1 C708
33-ELM100-KTX SMD. COIL 10UH +/-10% 0805 1 L702
33-GLL100-KTX SMD. COIL 10 UH +/-10% CMI3216 1 L705
34-R101K2-1BX COIL CHOKE 100 UH +/-10% 2 L703;L704
34-R120J2-0EX COIL PL - 12 UH +/-5% 1 L701
34-R221J2-0EX COIL PL - 220 UH +/-5% 1 LN9
40-D32V6N-TUC2X P.C.B TUNER BD 1
46-35199W-04X CONN.PH-4A 4PIN PITCH=2.0MM 1 J702
46-35199W-05X CONN.PH-5A 5PIN PITCH=2.0MM 1 J701
71-268390-0A0AF LABEL (QC) GREEN 1
71-270870-0A9 LABEL 2
4. ALLIGNMENT PROCEDURE
1 Scopeġ
AFC031A chassis is developed for America market which supports 1 analog RF input,1 VGA input,
1 DVI input,1 compenent input,1 Video input,1 S-Video input.
2 Alignment content and methodġ
2.1 How to enter the Factory Menu
2.1.1 press “vol-” button on the remote control to decrease volume to zero
2.1.2 press “mute” buttonēmake mute icon displays on the right screen
2.1.3 input the password “9735” in 5S,then factory appears on the left up screen
2.2 How to enter Service Menu:
2.2.1 press “vol-” button on the remote to decrease volume to zero
2.2.2 press “mute” buttonēmake mute icon displays on the right screen
2.2.3 input the password “3175” in 5S,then Service Menu appears on the center screen
3 check picture geometry in VGA source
3.1 preparation and connection
3.1.1 connnect VGA cable from Chroma2327 port to set VGA input port
3.1.2 choose the “Crosshatch” pattern and the specified timing
Remark:following timing is specified
640*480@60Hz,640*480@75Hz,800*600@60Hz,800*600@72Hz,800*600@75Hz,1024*768
@60Hz,1024*768@75Hz
3.1.3 enter the “Geometry” sub-menu,make “Auto Ajust”,the picture should display in the center of the
screen,should not have distortioncnoise,etc.
4 manual white balance alignment
4.4 VGA source
4.4.1 press “input” button to choose the VGA source
4.4.2 connect VGA cable from Chroma2327
4.4.3 in “picture” sub-menu,set “warmth” item “normal”,set “Picture Preset” item “Natural”
4.4.4 enter factory menu
4.4.5 enter “Balance” sub-menu
4.4.6 input 1024*768@75 format,11Grays pattern
4.4.7 in “Balance” sub-menu,choose “VGAcalbr”,press “ok” button to selection RGB ADC calibration
4.4.8 input white pattern
4.4.9 select R\G\B Offset & Gain calibration.Target is:(x,y)=(299,315)
4.5 TV source
4.5.1 connect video signal to the video P501 connector and Fluke5418 video connector
4.5.2 choose VID1 source
4.5.3 input white pattern
4.5.4 select R\G\B Offset & Gain calibration.Target is:(x,y)=(285,294Đ
4.6 YPbPr source
4.6.1 connect YPbPr signal to J007 connector
4.6.2 choose CMPT source
4.6.3 input the SMPTE Color Bar pattern,720p60Hz format,like the attached figure1
4.6.4 select YUVcalbr and press ok on RC
4.6.5 input the special pattern(attached figure2),select Y/G Offset in ADCBal sub-menu calibration to j-
ust see 6 level grays
6grays
Figure2grayspattern
4.6.6 select Y/G Gain calibration to just see 6grays,figure3.
Figure3grayspattern 6grays
4.6.7 input Chroma2327 30IRE gray pattern,format 720p60Hz;
4.6.8 select R/G/B Offset calibration,target is (x,y)=(285,294)
4.6.9 input 100 IRE gray pattern,selection R/G/B Gain calibration,target is (x,y,Y)=(285,294,260~280
nit)
5 in case reloading the system software,it is necessary to enter factory menu to Reset data
DO NOT STUFF
DATA2m
D5V
GVCK
DATA0p
CLKp
DATA0m
DATA2p
DATA1m
DATA1p
AV33
CLKm
AV33
VCCSW
VCCD
VCCD
VCCDVCCD
VCCD
VCCD
AV33
VCCD
V33SW
AV33
AV33
R007
4.75K
D002 BAV99L
1
3
2
TP027
R001 26.7
R011
75
R004 26.7
TP028
U001
24LC21A
1
2
3
4
5
6
7
8
NC1
NC2
NC3
GND
SDA
SCL
VCLK
VCC
D001 srv05-4
1
3
2
4
5
6
R014
75
R003 26.7
R006
4.75K
D003 BAV99L
1
3
2
C007
0.1uF
L001
FB_1K_OHM_200MA
R010 26.7
R009 26.7
C002
0.1uF
C001
0.1uF
C006
0.1uF
R013 26.7
R008
4.75K
R012 26.7
C008
0.1uF
D005 srv05-4
1
3
2
4
5
6
P001
DVI_V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
33
34
25
26
27
28
29
30
31
32
DATA2-
DATA2+
DATA2/4_SHLD
DATA4-
DATA4+
DDC_CLK
DDC_DATA
A_VSYNC
DATA1-
DATA1+
DATA1/3_SHLD
DATA3-
DATA3+
+5V
GND
H_PLUG_DET
DATA0-
DATA0+
DATA0/5_SHLD
DATA5-
DATA5+
CLK_SHLD
CLK+
CLK-
SHELL1
SHELL2
A_RED
A_GREEN
A_BLUE
A_HSYNC
A_GND1
A_GND2
NC1
NC2
D004BAV70L
1
2
3
R015 26.7
C005
0.1uF
R002
75
R005
75
GSDA
RX1m
RX0p
RX2p
RXCp
RX0m
RX2m
GSCL
RX1p
RXCm
6FKHPHIRUGLJLWDOERDUGSDJHV
5 Schematic Diagram
5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
900-0254-00 Trinity Production Reference Design A
Audio Processor and Amplifiers
A
415Monday, October 25, 2004
<Variant Name>
Title
Size Document Number Rev
Date: Sheet of
Confidential
DVIL PCL
HDL1
HDR1
HDL1DVIL
PCR
DVIL
AU-5V
DVIR
DPF_L
HDL1
PCR
PCL
DVIR
DVIR HDR1
HDR1
VCCSW
AU-5V
AU-5V
AU-5V
AU-5V
AU-5V AU-5V
AU-5V
AU-5VAU-5VAU-5V AU-5V
AU-5V
AU-5V AU-5V
AU-5V
AU-5V
R041
47k
J002
PHONEJACK STEREO
1
2
3
R042
47k
C036
10uf
12
R046
22k
R043
47k
C041 10uf
12
R045
47k
R055
22k
R044
47k
D011BAV99L
1
3
2
L009 25uH
D009BAV99L
1
3
2
R040
47k
D010BAV99L
1
3
2
D008BAV99L
1
3
2
D006BAV99L
1
3
2
R048
22k
D023BAV99L
1
3
2
C045 10uf
12
D007BAV99L
1
3
2
R054
22k
J003
CONNECTOR COAX-J
1
2
3
4
R052
22k
D024BAV99L
1
3
2
R053
22k
R049
22k
C038
10uf
12
R051
22k
C039 10uf
12
U005
4052
12
14
15
11
1
5
2
4
6
10
9
13
3
X0
X1
X2
X3
Y0
Y1
Y2
Y3
INH
A
B
X
Y
R050
22k
C042 10uf
12
R047
22k
C035
10uf
12
J004
CONNECTOR COAX-J
1
2
3
4
R060
22k
C043 10uf
12
R059
22k
C044 10uf
12
R058
22k
C03710uf
1 2
R061
22k
C04010uf
1 2
R056
22k
R057
22k
D-L
DPF_R
D-R
DPF_L
SW1
SW2
Other TCL TV manuals
