Teac DV-H500 User manual

9A07928600
DV-H500
DVD Player
OWNER’S MANUAL
MANUEL DU PROPRIETAIRE
Thanks for buying a TEAC. Read this manual carefully to get the best performance from this unit.
Nous vous remercions pour l’achat d’un appareil TEAC.
Lire ce manuel avec attention pour obtenir les meilleures performances possibles de cet appareil.

PAGE 2 INTRODUCTION
IMPORTANT SAFETY INSTRUCTIONS
CAUTION : PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS IN THIS OWNER’S MANUAL
AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire
hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation,
use and servicing.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read owner’s manual
When shipping the DVD player, always use the
original shipping carton and packing materials.
For maximum protection, repack the unit as it was
originally packed at the factory.
2. Power Sources
This product should be operated only from the type of
power source indicated on the marking label. If you
are not sure of the type of power supply in your
home, consult your product dealer or local power
company. For produces intended to operate from
battery power, or other sources, refer to the operating
instructions.
3. Grounding or Polarization
This product is equipped with a polarized alternating
current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
4. Ventilation
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from overheating. These
opening must not be blocked or covered. The
openings should never be blocked by placing the
product on a bed, sofa, rug or other similar surface.
This product should not be placed in a built-in
installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s
instructions have been adhered to.
5. Heat
The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
6. Water and Moisture
Do not use this product near water-for example, near
a bath tub, wash bowl, kitchen sink, or laundry tub; in a
wet basement; or near a swimming pool and the like.
7. Cleaning
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
8. Power-Cord Protection
Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, playing particular attention to
cords at plugs, convenience receptacles, and the
point where they exit from the product.
9. Overloading
Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in
a risk of fire or electric shock.
10.Lightning
For added protection of this product during storms, or
when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will
prevent damage to the product due to lightning and
power-line surges.
11.Object and Liquid Entry
Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any kind on
the product.
12.Attachments
Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
13.Accessories
Do not place this product on
an unstable cart, stand, tripod,
bracket, or table. The product
may fall, causing serious injury
to a child or adult, and serious
damage to the product. Use
only with a chart, stand, tripod,
bracket, or table recommended by the manufacturer,
or sold with the product. Any mounting of the product
should follow the manufacturer’s instructions, and
should use a mounting accessory recommended by
the manufacturer. A product and cart combination
should be moved with care. Quick stops, excessive
force, and uneven surfaces may cause the product
and cart combination to overturn.
14.Disc Tray
Keep your fingers well clear of the disc tray as it is
closing. It may cause serious personal injury.
PORTABLE CART WARNING

PAGE 3
INTRODUCTION
IMPORTANT SAFETY INSTRUCTIONS
15.Burden
Do not place a heavy object on or step on the
product. the object may fall, causing serious personal
injury and serious damage to the product.
16.Connecting
When you connect the product to other equipment,
turn off the power and unplug all of the equipment
from the wall outlet. Failure to do so may cause an
electric shock and serious personal injury. read the
owner’s manual of the other equipment carefully and
follow the instructions when making any connections.
17.Sound Volume
Reduce the volume to the minimum level before you
turn on the product. Otherwise, sudden high volume
sound may cause hearing or speaker damage.
18.Sound Distortion
Do not allow the product to output distorted sound for
a longtime. If may cause speaker overheating and
fire.
19.Headphones
When you use the headphones, keep the volume at a
moderate level. If you use the headphones
continuously with high volume sound, it may cause
hearing damage.
20.Laser Beam
Do not look into the opening of the disc tray or
ventilation opening of the product to see the source
of the laser beam. It may cause sight damage.
21.Disc
Do not use a cracked, deformed, or repaired disc.
These discs are easily broken and may cause
serious personal injury and product malfunction.
22.Damage Requiring Service
Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
a) When the power-supply cord or plug is
damaged.
b) If liquid has been spilled, or objects have fallen
into the product.
c) If the product has been exposed to rain or
water.
d) If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the product to its normal operation.
e) If the product has been dropped or damaged in
any way.
f) When the product exhibits a distinct change in
performance-this indicates a need for service.
23.Servicing
Do not attempt to service this product yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
24.Replacement parts
When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer or have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or
other hazards.
25.Safety Check
Upon completion of any service or repairs to this
product, ask the service technician to perform safety
checks to determine that the product is in proper
operating condition.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE
USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE”WITHIN THE PRODUCT’S ENCLOSURE THAT MAY
BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER TO THE PRESENCE
OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING
THE APPLIANCE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

PAGE 4 INTRODUCTION
Safety Precautions
For CANADA
AC POWER CORD CONNECTION
CAUTION :
TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Pour le CANADA
CORDE DE CONNEXION CA
ATTENTION :
POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA
FICHE DANS LA BORNE CORRESPONDANTE DE
LA PRISE ET POUSSER JUSQU’AU FOND.
The equipment draws nominal non-operating power from
the AC outlet with its POWER switch in the STANDBY
position.
Obs! nätströmställaren skiljer ej hela apparaten fran nätet.
DO NOT cut off the mains plug from this equipment. If
the plug fitted is not suitable for the power points in your
home or the cable is too short to reach a power point, then
obtain an appropriate safety approved extension lead or
consult your dealer.
If nonetheless the mains plug is cut off, remove the fuse
and dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the mains
supply.
If this product is not provided with a mains plug, or one has
to be fitted, then follow the instructions given below:
IMPORTANT. DO NOT make any connection to the larger
terminal which is marked with the letter E or by the safety
earth symbol |or coloured GREEN or GREEN-and-
YELLOW.
The wires in the mains lead on this product are coloured in
accordance with the following code :
BLUE - NEUTRAL
BROWN - LIVE
As these colours may not correspond with the coloured
markings identifying the terminals in your plug proceed as
follows:
The wire which is coloured BLUE must be connected to the
terminal which is marked with the letter N or coloured
BLACK.
The wire which is coloured BROWN must be connected to
the terminal which is marked with the letter L or coloured
RED.
When replacing the fuse only a correctly rated approved
type should be used and be sure to re-fit the fuse cover.
IF IN DOUBT - CONSULT A COMPETENT
ELECTRICIAN.
IMPORTANT (for U.K. Customers)
TO THE USER
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against interference in a
residential area. This device generates and uses radio
frequency energy and if not installed and used in
accordance with the instructions, it may cause
interference to radio or TV reception. If this unit does
cause interference with TV or radio reception you can
try to correct the interference by one or more of the
following measures :
a) Reorient or relocate the receiving antenna.
b) Increase the separation between the equipment and
the receiver.
c) Plug the equipment into a different outlet so that it is
not on the same circuit as the receiver. If necessary,
consult the dealer or an experienced
radio/TV technician for additional suggestions.
CAUTION
Changes or modifications to this equipment not
expressly approved by TEAC CORPORATION for
compliance could void the user’s authority to operate
this equipment.
For U.S.A

This product has been designed and manufactured according to FDA regulations “title 21, CFR, chapter 1, subchapter J,
based on the Radiation Control for Health and Safety Act of 1968”, and is classified as a class 1 laser product. There is
no hazardous invisible laser radiation during operation because invisible laser radiation emitted inside of this product is
completely confined in the protective housings.
The label required in this regulation is shown ①.
<CAUTION
- DO NOT REMOVE THE PROTECTIVE HOUSING USING SCREWDRIVER.
- USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
- IF THIS PRODUCT DEVELOPS TROUBLE, MAKE A CONTACT WITH OUR SERVICEMAN, AND DO NOT USE THE
PRODUCT IN A TROUBLED STATE.
Optical pickup :
Type : TOP51
Manufacturer : Thomson Multi Media
Laser output : <250 µW (at objective lens)
Wavelength : 640 ~ 660 nm
PAGE 5
INTRODUCTION
Safety Precautions

PAGE 6 INTRODUCTION
Table of Contents
ENGLISH
About This Owner’s Manual
Introduction
<IMPORTANT SAFETY INSTRUCTIONS ............2
<Safety Precautions ..............................................4
<Table of Contents ...............................................6
<Precautions .........................................................7
<For Proper and Long Use ...................................8
<Features ..............................................................9
<Identification of Controls
Front Panel/Display window ..........................10
Rear panel .....................................................11
Remote Control .............................................12
Preparing the Remote Control .......................13
Operating with the Remote Control ...............13
Connections
<Connecting to a TV ...........................................14
<Connecting to an Audio System .......................15
<Connecting to Optional Equipment
Enjoying Dolby Digital Sound ........................16
Enjoying Dolby Digital (5.1 CH) Sound .........17
Enjoying Dolby Pro Logic Surround Sound ...18
Enjoying 2 Channel Digital Stereo Sound .....19
Enjoying DTS Sound .....................................19
Basic Operation
<Basic Playback
Playing DVDs, CDs & Video CDs ..................20
Stopping Playing & Switching Power Off .......21
Skipping forward or back ...............................21
Viewing a still frame ......................................22
Slow Playback-Viewing a slow picture ..........22
Playing Frame by Frame ...............................22
Resuming Playback from the Same Location ..23
Advanced Operation
<Viewing Information about GUI .........................24
<Using a title menu/ DVD menu .........................25
<Changing subtitle language ..............................26
<Viewing from another angle ..............................27
<Reproducing a Tru Surround effect ..................27
<Repeat Play ......................................................28
<Storing markers in memory to be
viewed (listened to) again .................................29
<Zooming Feature/ Random Play .......................30
<Program Play ....................................................31
<Intro Play ...........................................................31
Initial SETUP Operation
<Common procedures of initial settings ..............32
<SET UP Menu CLEAR ......................................32
<Selecting Display mode ....................................33
<Selecting Audio Output .....................................34
<Selecting rating level and
Password-Parental Control ...............................35
<Selecting Disc Language ..................................36
Reference
<Disc Requirements/Copyright Information ........37
<Troubleshooting ................................................38
<Specifications ....................................................39
<This owner’s manual explains the basic
instructions of this DVD player.
<Some DVD video discs have functions that may
not be explained in this owner’s manual.
Therefore, some instructions may differ from this
owner’s manual, and there may be extra
instructions. In this case, follow the instructions
displayed on the TV screen or package.
<“”may appear on the TV screen during
operation. This icon means the function explained
in this owner’s manual is not available on that
specific DVD video disc.

PAGE 7
INTRODUCTION
Precautions
ENGLISH
Notes on handling
<When shipping the DVD player, always use the
original shipping carton and packing materials.
For maximum protection, repack the unit as it was
originally packed at the factory.
<Do not use volatile liquids, such as insect spray,
near the DVD player. Do not leave rubber or
plastic products in contact with the DVD player for
a long time. They will leave marks on the finish.
<The top and rear panels of the DVD player may
become warm after a long period of use. This is
normal and not a malfunction.
<When the DVD player is not in use, be sure to
remove the disc and turn off the power.
<If you do not use the DVD player for a long
period, the unit may not function properly in the
future. Turn on and use the DVD player occasionally.
Notes on Locating
<When you place this DVD player near a TV, radio,
or VCR, the playback picture may become poor
and the sound may be distorted. In this case,
move the DVD player away from the TV, radio, or
VCR.
To Obtain a Clear Picture
The DVD player is a high technology, precision
device. If the optical pick-up lens and disc drive parts
are dirty or worn down, the picture quality becomes
poor. To obtain a clear picture, we recommend
regular inspection and maintenance (cleaning or
parts replacement) every 1,000 hours of use
depending on the operating environment. For details,
contact your nearest dealer.
Notes on Cleaning
Use a soft, dry cloth for cleaning.
<For stubborn dirt, soak the cloth in a weak
detergent solution, wring well and wipe. Use a dry
cloth to wipe it dry. Do not use any type of
solvent, such as thinner and benzine, as they
may damage the surface of the DVD player.
<If you use a chemical saturated cloth to clean the
unit, follow that product’s instructions.
Warning : Cleaning and adjustment of lenses
and/or other components of playback mechanism
should be performed by a qualified service
technician.
Notes on Moisture Condensation
Moisture condensation damages the DVD player.
Please read the following carefully.
<Moisture condensation occurs, for example, when
you pour a cold drink into a glass on a warm day.
Drops of water form on the outside of the glass. In
the same way, moisture may condense on the
optical pick-up lens inside this unit, one of the
most crucial internal parts of the DVD player.
Moisture condensation occurs during the following
cases.
<When you bring the DVD player directly from a
cold place to a warm place.
<When you use the DVD player in a room where
you just turned on the heater, or a place where
the cold wind from the air conditioner directly hits
the unit.
<In summer, when you use the DVD player in a hot
and humid place just after you move the unit from
an air conditioned room.
<When you use the DVD player in a humid place.
Do not use the DVD player when moisture
condensation may occur.
<If you use the DVD player in such a situation, it
may damage discs and internal parts. Remove
the disc, connect the power cord of the DVD
player to the wall outlet, turn on the DVD player
and leave it “ON”for two or three hours. After two
or three hours, the DVD player will have warmed
up and evaporated any moisture. Keep the DVD
player connected to the wall outlet and moisture
condensation will seldom occur.

ENGLISH
PAGE 8 INTRODUCTION
For Proper and Long Use
HDO NOT MOVE THE UNIT DURING
PLAYBACK
During playback, the disc rotates at high speed. Do
NOT lift or move the unit during playback. Doing so
may damage the disc.
HWHEN MOVING THIS UNIT
When changing places of installation or packing the
unit for moving, be sure to remove the disc and
return the disc table to its original position in the
player. Then, press the STANDBY/ON and switch the
power standby. Check that the STANDBY indicator
on the display goes off, then disconnect the power
cord. Moving this unit with the disc loaded may result
in damage to this unit.
HINSTALLATION
<Select a stable place to the side of a TV set or
stereo system to be connected to the unit.
<When using the unit with a stereo system, install
the speakers a little bit away from the TV.
<Do NOT install the unit on top of a TV or color
monitor. Install the unit away from equipment that
may be affected by magnetism, such as a
cassette deck.
HAVOID INSTALLING IN A PLACE THAT
IS:
<Exposed to direct sunlight
<Exposed to humidity or where ventilation is poor
<Extremely hot or cold
<Exposed to vibration
<Exposed to dust
<Exposed to oily smoke, steam or heat (for
example, a kitchen)
HDO NOT PLACE AN OBJECT ON TOP
Do NOT place an object on the unit.
HDO NOT BLOCK VENTS
Do NOT use the player on top of a long-fibre carpet,
bed or sofa, and do not cover it with a cloth etc. This
will prevent heat radiation and could result in
damage.
HAVOID HEAT
Do NOT place the unit on equipment generating
heat, such as an amplifier.
When installing the unit in a rack, place it on the
lowest shelf possible (however, not where it is
exposed to dust) and separated from the amplifier to
avoid the heat generated by the amplifier of other
audio equipment.
H
CAUTION : WHEN PLACING THE UNIT
IN A STEREO RACK WITH GLASS
DOORS
Be sure there is ample space between the unit and
the glass doors when opening the disc table using
the remote control. If the disc table opens against
strong resistance, such as a closed glass door,
damage to the unit may result.
HCONDENSATION
Moisture will form in the operating section of the
player if the player is brought from cool surroundings
into a warm room or if the temperature of the room
rises suddenly. When this happens, player’s
performance will be impaired. To prevent this, let the
player stand in its new surroundings for about an
hour before switching it on, or make sure that the
room temperature rises gradually.
Condensation may also form during the summer if
the player is exposed to the breeze from an air
conditioner. In such cases, change the location of the
player.
HSWITCH POWER OFF WHEN NOT
USING THE UNIT
Depending on the strength of the TV or radio
broadcast signal, having the TV or radio ON while
power to the unit is ON may result in stripes on the
TV screen or noise. However, this is not a
malfunction of this unit or the TV or radio. In such a
case, switch the power of the unit OFF.
HPOWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out
the plug by tugging the cord and never touch the
power cord when your hands are wet as this could
cause a short circuit or electric shock. Do not place
the unit, a piece of furniture, etc., on the power cord,
or pinch the cord. Never make a knot in the cord or
tie it with other cords. The power cords should be
routed in such a way that they are not likely to be
stepped on. A damaged power cord can cause a fire
or give you an electrical shock. Check the power cord
once in a while. When you find it damaged, ask your
nearest service center or your dealer for a replacement.

ENGLISH
PAGE 9
INTRODUCTION
FeaturesFor Proper and Long Use
On Handling Discs
<Do not touch the playback side of the disc.
<Do not attach paper or tape to discs.
On Storing Discs
<Do not store discs in a place subject to direct
sunlight or near heat sources.
<Do not store discs in places subject to moisture
and dust such as a bathroom or near a humidifier.
<Store discs vertically in a case. Stacking or
placing objects on discs outside of their case may
cause warping
On Cleaning Discs
<Fingerprints and dust on the disc cause picture
and sound deterioration. Wipe the disc from the
center outward with a soft cloth. Always keep the
disc clean.
<If you cannot wipe off the dust with a soft cloth,
wipe the disc lightly with a slightly moistened soft
cloth and finish with a dry cloth.
<Do not use any type of solvents such as thinner,
benzine, commercially available cleaners or
anti-static for vinyl LPs. They may damage the
disc.
HDVD : a completely new dimension in
video entertainment
<Subtitles may be displayed in one of maximum of
32 languages.
<The audio soundtrack can be heard in up to 8
languages.
<The multi-angle function allows you to choose the
viewing angle of the scenes which were shot from
a number of different angles. (Limited to DVD
recorded with multiple camera angles.)
HHigh Quality digital audio
With the linear PCM sound of a 48 kHz/ 16 bit through
96 kHz/ 24 bit, Digital to Analog Converter (DAC)
audio quality exceeding that of CDs is possible.
HMain convenient features
<GUI (Graphic User Interface) Menu Icons show
the disc information or player information and
provide access to many major functions of this
unit.
<Reproducing stereo system is connected.
[Dolby Digital 5.1CH DVD encoded software only]
<Programming of up to 5 scenes in memory
(markers).
<Parental lock settings to prevent play of discs
unsuitable for some audiences [DVD only]
HCompatible with CD as well as DVD
HDisc formats supported by this player
This unit can play back discs bearing any of the
following marks:
DVD
[3”(8 cm) disc/ 5”(12 cm) disc]
CD
[3”(8 cm) disc/ 5”(12 cm) disc]
VIDEO CD
[3”(8 cm) disc/ 5”(12 cm) disc]
Note
If no key input until 8 minutes during stop mode
then the unit will be turned off automatically.

ENGLISH
PAGE 10 INTRODUCTION
Identification of Controls
Front Panel
Display Window

PAGE 11
ENGLISH
PAGE 11
INTRODUCTION
Identification of Controls
Rear Panel
OPTICAL DIGITAL AUDIO OUT jack
Remove the dust protection cap from the connector and connect
the optical digital cable (not supplied) firmly so that the
configurations of both the cable and the connector match. Keep
the dust protection cap and always reattach the cap when not
using the connector to project against dust.
Remote Control Selector switch
Single : To use remote control unit of
DV-H500, select Signal.
System : When connected to the
TEAC AV-H500D Amplifier with
remote control cord, select SYSTEM.

PAGE 12
ENGLISH
INTRODUCTION
Identification of Controls
REMOTE CONTROL
You will find instructions for each of the remote control functions in the appropriate sections of this instruction
manual.

PAGE 13
ENGLISH
INTRODUCTION
Identification of Controls
Open the battery cover.
Insert batteries (AAA size).
Close the cover.
1
2
3
<Make sure to march the +and _on the batteries
to the marks inside the battery compartment.
Notes on the remote control
<Direct the remote control at the remote sensor of
the DVD player.
<Do not drop or give the remote control a shock.
<Do not leave the remote control near extremely
hot or humid place.
<Do not spill water or put anything wet on the
remote control.
<Do not open the remote control.
Notes
<Improper use of batteries may cause battery
leakage and corrosion.
<To operate the remote control correctly, follow the
instructions below.
<Do not insert the batteries into the remote control
in the wrong direction.
<Do not charge, heat, open, or short-circuit the
batteries. Do not throw the batteries into fire.
<Do not leave dead or exhausted batteries in the
remote control.
<Do not use different types of batteries together, or
mix old and new batteries.
<If you do not use the remote control for a long
period of time, remove the batteries to avoid
possible damage from battery corrosion.
<If the remote control does not function correctly or
if the operating range becomes reduced, replace
all batteries with new ones.
<If battery leakage occurs, wipe the battery liquid
from the battery compartment, then insert new
batteries.
<The batteries should last about one year with
normal use.
Insert the batteries into the remote control so you can
use it to operate the DVD player.
This section shows you how to use the remote
control.
Point the remote control at the remote sensor and
press the buttons
Distance : Within about 23 ft (7 m) from the front of
the remote sensor.
Angle : Within about 30˚in each direction of the
front of the remote sensor.
<Do not expose the remote sensor of the DVD
player to a strong light source such as direct
sunlight or illumination. If you do so, you may not
be able to operate the DVD player with the
remote control.
Preparing the Remote Control Operating with the Remote Control

PAGE 14
ENGLISH
CONNECTIONS
Connecting to a TV
Connect the DVD player to your TV
If the player is connected to the TV through a video cassette recorder, the picture may not be played
back normally with some DVDs. So we strongly recommended you not to connect the DVD player to
your video cassette recorder when setting up your home entertainment system.
To view pictures from the video cassette recorder, set the player to the standby mode.
Notes
<Refer to the owner’s manual of your TV as well.
<When you connect the DVD player to your TV, be sure to turn off the power and unplug both units from the wall
outlet before making any connections.
<If your television set has one audio input, connect the DVD player to a Y cable adapter (not supplied) and then
connect to your TV.
<Connect the DVD player to your TV directly. If you connect the DVD player to a VCR, the playback picture will
be distorted because DVD video discs are copy protected.
<Change the setting of speaker output in Initial Setup, from Multichannel to Two channel. (Refer to page 34)
If the TV has an S-Video Input,
connect the DVD player with a
S-Video cable to get more
clear picture. It is not
necessary to connect Video
input jack (yellow).
If you connect the TV and the
DVD player with an AV
CONNECTOR cable, do not
connect other video and audio
jacks. (European Model only)

PAGE 15
ENGLISH
CONNECTIONS
Connecting to an Audio System
You can listen to the sound of audio CDs and DVD video discs in stereo.
Notes
<Refer to the owner’s manual of your audio system as well.
<When you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the
equipment from the wall outlet before making any connections.
<If you place the DVD player near a tuner or radio, the radio broadcast sound might be distorted. In this case,
move the DVD play away from the tuner and radio.
<The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a
moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
<Turn off the receiver before you connect or disconnect the DVD player’s power cord. If you leave the receiver
power on, the speakers may be damaged.
<Change the setting of speaker output in Initial Setup, from Multichannel to Two channel. (Refer to page 34)
Warning
Do not set the Digital Audio Output of this DVD player to “Dolby Digital”unless you are connecting the optical
digital audio jack of this DVD player to an AV decoder that has the Dolby Digital (AC-3) decoding function. High
volume sound may damage your hearing as well as the speakers.
If the TV has an S-Video Input,
connect the DVD player with a
S-Video cable to get more
clear picture. It is not
necessary to connect Video
input jack (yellow).
If you connect the TV and the
DVD player with an AV
CONNECTOR cable, do not
connect other video and audio
jacks. (European Model only)

PAGE 16
ENGLISH
CONNECTIONS
Connecting to Optional Equipment
You can enjoy the high quality dynamic sound of Dolby Digital Dolby Pro Logic, and 2 Channel Digital
Stereo.
Dolby Digital
Dolby Digital is the surround sound technology used in the theaters showing the latest movies, and is now
available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVD video
discs with this dynamic realistic sound by connecting the DVD player to a 6 channel amplifier equipped with a
Dolby Digital decoder or Dolby Digital processor.
Notes
<Refer to the owner’s manual of your audio equipment as well.
<When you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the
equipment from the wall outlet before making any connections.
<The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a
moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
<Turn off the amplifier before you connect or disconnect the DVD player’s power cord. If you leave the amplifier
power on, the speakers may be damaged.
Enjoying Dolby Digital Sound
To enjoy Dolby Digital sound from
this DVD player you need the
following:
<DVD video discs recorded in
Dolby Digital.
<6 channel amplifier equipped with
a Dolby Digital decoder, or Dolby
Digital processor and power
amplifier.
<5 speakers and 1 sub woofer.
To enjoy Dolby Digital sound:
You need to select “Stream/PCM”on
the SETUP menu.
*Manufactured under license from
Dolby Laboratories. “Dolby”and
the double-D symbol are
trademarks of Dolby Laboratories.
Confidential Unpublished Works.
©1992-1997 Dolby Laboratories,
Inc, All rights reserved.
If the TV has a S-Video Input, and
the AV Amplifer has S-Video
input/output, you can connect them
with S-Video cables to get more clear
picture.
If you connect with S-Video cables, it
is not necessary to connect Video
input jack (yellow).

PAGE 17
ENGLISH
CONNECTIONS
Connecting to Optional Equipment
or
Dolby Digital Surround (5.1 CH)
Dolby Digital (AC-3) is a six-channel digital surround sound technology developed by Dolby Laboratories for
theater-like surround sound reproduction. DVDs supporting Dolby Digital (AC-3) technology feature the
logo. You can enjoy realistic, theater-like surround sound from DVD movie or music disc featuring this logo. Two
front, one center and two rear speakers plus a subwoofer make up the “5.1-channel”audio system that Dolby
Digital (AC-3) uses.
Hook-ups
Connect an amplifier with 5.1 channel inputs to the player and to the speakers. See the figure below.
Note :
Make sure that the setting of speaker output in Initial Setup is Multichannel. (Refer to page 34)
Enjoying Dolby Digital (5.1 CH) Sound
If the TV has a S-Video Input,
and the AV Amplifer has S-
Video input/output, you can
connect them with S-Video
cables to get more clear
picture.
If you connect with S-Video
cables, it is not necessary to
connect Video input jack
(yellow).

PAGE 18
ENGLISH
CONNECTIONS
Connecting to Optional Equipment
Enjoying Dolby Pro Logic Surround Sound
or
or
Dolby Pro Logic Surround
You can still enjoy the excitement of Surround Sound even if your A/V receiver does not offer Dolby Digital (AC-3)
decoding. If you A/V receiver has a Dolby Pro Logic decoder. Refer to the following connecting diagram.
Connect one or two rear
speakers.
The output sound from the
rear speakers will be
monaural even if you connect
two rear speakers.
<With a receiver equipped
with Dolby Digital (AC-3)
Connect the equipment the
same way as described in
“Enjoying Dolby Digital (AC-3)
Sound”on the previous page.
Refer to that receiver’s
owner’s manual and set the
receiver so you can enjoy
Dolby Pro Logic Surround
sound.
If the TV has a S-Video Input,
and the AV Amplifer has S-
Video input/output, you can
connect them with S-Video
cables to get more clear
picture.
If you connect with S-Video
cables, it is not necessary to
connect Video input jack
(yellow).
Notes
<Change the setting of speaker output in Initial Setup, from Multichannel to Two channel. (Refer to page 34)
Warning
Do not set the Digital Audio Output of this DVD player to “Dolby Digital”unless you are connecting the optical
digital audio jack of this DVD player to an AV decoder that has the Dolby Digital (AC-3) decoding function. High
volume sound may damage your hearing as well as the speakers.

PAGE 19
ENGLISH
CONNECTIONS
Connecting to Optional Equipment
Enjoying 2 Channel Digital Stereo Sound
2 Channel Digital Stereo
You can enjoy the dynamic sound of 2 Channel Digital Stereo by connecting this DVD player to a receiver
equipped with a digital audio input and speaker system (right and left front speakers).
Enjoying DTS Sound
“DTS”and “DTS Digital Surround”are trademarks of Digital Theater Systems, Inc.
Introducing DTS Digital SurroundTM...the finest technology ever invented to transform existing “home
theater”system into six discrete channels of exceptionally clear, better-than-compact disc, digital audio
performance. And DTS Digital Surround is the only 5.1 surround sound format than can deliver this revolutionary 3-
dimensional experience through new music recordings on compact discs, original 5.1 soundtracks on motion
picture laserdiscs, and soon, a wide variety of products on DVD.
Notes
<Refer to the owner’s manual of your audio receiver as well.
<When you connect the DVD player to other equipment, be sure to turn off the power and unplug all of the
equipment from the wall outlet before making any connections.
<The output sound of the DVD player has a wide dynamic range. Be sure to adjust the receiver’s volume to a
moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound.
<Turn off the receiver before you connect or disconnect the DVD player’s power cord. If you leave the receiver
power on, the speakers may be damaged.

PAGE 20
ENGLISH
BASIC OPERATION
Basic Playback
Press the POWER switch.
When the STANDBY is on, you can power on with
the remote control.
Press the OPEN/CLOSE (L)button.
<Press the OPEN/CLOSE (L) button on the remote
control unit.
<The disc table comes out.
Load a disc and press the OPEN/CLOSE (L)
button.
<Load a disc with the label side facing up, using the
disc table guide to align the disc.
Depending on the disc, playback begins
automatically.
Press the PLAY (G) button.
<Press the PLAY (G) button on the remote control
unit.
<The disc table will close, and playback will begin.
<Depending on the disc, a menu is displayed. If a
menu is displayed, refer to step 5.
Select the item you want to view. (DVD only)
Select the item with the g/5/t/bbuttons, then
press the SELECT button.
1
2
3
4
<Turn the TV’s power on and set its input to a
position for DVD viewing (VIDEO etc.).
<When this unit is connected to a stereo, turn the
power of the stereo components on.
Playing DVDs, CDs and Video CDs
5
Ex: When a DVD that has menu screens is loaded
To return to the menu screen
<
Although this differs depending on the disc, pressing
the TITLE button, the MENU button or the RETURN
button during DVD playback or the RETURN button
during Video CD playback will return the screen to
the menu screen.
Note:
The Track No. that is displayed, begin with NO.1
even if Track of disc do not start with NO.1.
