Teac LX Series User manual

TEAC Corporation May 2006 D00634900D
RECORDING UNIT
LX Series
Instruction Manual
Please read this manual before using the product, and
keep the manual handy.

SAFETY INSTRUCTIONS
i
CAUTION:
Read all of these Instructions.
Save these Instructions for later use.
Follow all Warnings and Instructions marked on the product.
1) Read instructions -- All the safety and operating instructions should be read before the product is operated.
2) Retain instructions -- The safety and operating instructions should be retained for future reference.
3) Heed Warnings -- All warnings on the product and in the operating instructions should be adhered to.
4) Follow instructions -- All operating and use instructions should be followed.
5) Cleaning -- Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
6) Attachments -- Do not use attachments not recommended by the product manufacturer as they may cause hazards.
7) Water and Moisture -- Do not use this product near water -- for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool; and the like.
8) Accessories -- Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to the product. Any mounting of the product should follow the
manufacturer ﾕs instructions, and should use a mounting accessory recommended by the manufacturer.
9) Ventilation -- Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product
and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer ﾕs instructions have been
adhered to.
10) Power Sources -- This product should be operated only from the type of power source indicated on the marking label. If
you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products
intended to operate from battery power, or other sources, refer to the operating instructions.
11) Grounding or Polarization -- This product may be equipped with a polarized alternating-current line plug (a plug having
one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician
to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
12) Power-Cord Protection -- Power-supply cords should be routed so that they are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point
where they exit from the product.
13) Lightning -- For added protection for this product during a lightning storm, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet. This will prevent damage to the product due to lightning and power-line
surges.
14) Overloading -- Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in risk
of fire or electric shock.
15) Object and Liquid Entry -- Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the
product.
16) Servicing -- Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.

SAFETY INSTRUCTIONS
ii
17) Damage Requiring Service -- Unplug this product from the wall outlet and refer servicing to qualified service personnel
under the following conditions:
a) when the power-supply cord or plug is damaged.
b) if liquid has been spilled, or objects have fallen into the product.
c) if the product has been exposed to rain or water.
d) if the product does not operate normally by following the operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to its normal operation.
e) if the product has been dropped or damaged in any way.
f) when the product exhibits a distinct change in performance -- this indicates a need for service.
18) Replacement Parts -- When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result
in fire, electric shock, or other hazards.
19) Safety Check -- Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition.
20) Heat -- The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.

SAFETY INSTRUCTIONS
iii
FCC Part 15
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Caution
Changes or modifications to this equipment not expressly approved by TEAC CORPORATION for compliance
could void the user's authority to operate this equipment.
For the customers in Europe
WARNING
This is a Class A product. In a domestic environment, this product may cause radio interference in which case
the user may be required to take adequate measures.
Pour les utilisateurs en Europe
AVERTISSEMENT
Il s'agit d'un produit de Classe A. Dans un environnement domestique, cet appareil peut provoquer des
interférences radio, dans ce cas l'utilisateur peut être amené à prendre des mesures appropriées.
Für Kunden in Europa
Warnung
Dies ist eine Einrichtung, welche die Funk-Entstörung nach Klasse A besitzt. Diese Einrichtung kann im
Wohnbereich Funkstörungen versursachen ; in diesem Fall kann vom Betrieber verlang werden,
angemessene Maßnahmen durchzuführen und dafür aufzukommen.
DISCLAIMER
TEAC disclaims all warranty, either expressed or implied, with respect to this product and the accompanying
written materials. In no event shall TEAC be liable for any damages whatsoever (including, without
limitation, damages for loss of business profits, business interruption, loss of business information or other
loss) arising out of the use of or inability to use this product.
This product is not an approved medical device.
The names of products that appear in this document are registered trademarks of the respective
holders.
Specifications are subject to change without notice.

LICENSE AGREEMENT AND LIMITED WARRANTY
iv
IMPORTANT:
PLEASE CAREFULLY READ THE LICENSE AGREEMENT HEREIN BEFORE USING THE SOFTWARE. THE RIGHT TO USE
THE SOFTWARE IS GRANTED ONLY ON THE CONDITION THAT YOU AGREE TO THE LICENSE AGREEMENT. IN CASE
YOU DO NOT AGREE TO THE LICENSE AGREEMENT, DO NOT INSTALL THE SOFTWARE. IF YOU HAVE ALREADY
INSTALLED THE SOFTWARE, STOP THE USE AND UNINSTALL THE SOFTWARE. IF YOU DO NOT AGREE TO THE
LICENSE AGREEMENT, YOU MAY RETURN THE PACKAGE FOR A REFUND. UNAUTHORIZED REPRODUCTION OR
DISTRIBUTION OF THE SOFTWARE, OR ANY PORTION OF IT, MAY RESULT IN SEVERE CIVIL AND CRIMINAL
PENALTIES, AND WILL BE PROSECUTED TO THE MAXIMUM EXTENT POSSIBLE UNDER LAW.
This License Agreement with limited warranty is a legal agreement between you (either an individual or a single entity) and
TEAC Corporation ("TEAC") for the SOFTWARE, which include computer software and electronic documentation.
1. GRANT OF LICENSE
TEAC grants to you the right to use the SOFTWARE only in combination with the TEAC recording unit LX Series.
2. COPYRIGHT
All title and copyrights in and to the SOFTWARE and any copies thereof are owned by TEAC or a supplier to TEAC. The
SOFTWARE is protected by Japanese copyright laws, international treaty provisions, and all other applicable national laws.
3. RESTRICTIONS
You may not distribute copies of the SOFTWARE to third parties.
You may not reverse engineer, decompile, or disassemble the SOFTWARE, except and only to the extent that applicable law
notwithstanding this limitation expressly permits such activity.
You may not rent or lease the SOFTWARE.
You may not reproduce the SOFTWARE except for archival purpose.
4. TERMINATION
Your rights under this Agreement terminate upon the disposal of all copies of the SOFTWARE, or without prejudice to any
other rights, TEAC may terminate this Agreement if you fail to comply with the terms and conditions of this Agreement. In
such event, you must destroy all copies of the SOFTWARE.
5. LIMITED WARRANTY
TEAC warrants that the SOFTWARE will be usable for the purpose expressed on TEAC's document when properly installed
on a computer. TEAC does not warrant that the operation of the SOFTWARE will be uninterrupted or error free, and that the
SOFTWARE is fit for any particular purpose.
6. NO LIABILITY FOR CONSEQUENTIAL DAMAGES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL TEAC BE LIABLE FOR ANY SPECIAL
INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES
FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER
PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE THE SOFTWARE, EVEN IF TEAC HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES AND JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION
MAY NOT APPLY TO YOU.
7. MISCELLANEOUS
This agreement is governed by the laws of Japan.
Should you have any questions concerning this Agreement, or if you desire to contact TEAC for any reason, please write to
the address set forth below:
TEAC CORPORATION
3-7-3 Naka-Cho,Musashino-Shi,Tokyo
180-8550, Japan
E-mail: [email protected]
Phone: + 81-422-52-5014
Fax: [phone]

Contents
v
Section 1 Preface
Overview 1-2
Features 1-3
AboutTAFFmat 1-5
Notes on Usage 1-6
NamesandParts 1-8
Front 1-8
Rear 1-10
RecordingTimes 1-12
Sampling Frequency and Number of Channels 1-13
Section 2 Installation
Connections 2-2
NotesonConnections 2-3
PC System Requirements 2-3
Installing LX-10/20 IEEE 1394 Version 2-4
Installing Interface Card 2-4
Installing OHCI Driver 2-5
Installing LX Series Device Driver 2-8
Installing LX Navi 2-15
Installing LX-10L/20L LAN Version 2-16
Installing LX Navi 2-16
About IP Address Settings 2-21
StartingProgram 2-22
Starting Navi directly without the LX
Network dialog box displayed 2-21
Inserting and Ejecting Media 2-23
InsertingMedia 2-23
EjectingMedia 2-24
About Data on Media 2-24
AboutExpansionUnit 2-25
AboutSlotSettings 2-25
About Maximum Sampling Frequency
When Using Expansion Unit 2-25
About Power Supply Connection 2-26
Section 3 Introduction to LX Navi
Outline of Main Window 3-2
Overview of Steps in Recording and Reproduction 3-4
Section 4 Settings
SystemSettings 4-2
InputAmpSettings 4-5
DC Amp AR-LXDC/DC2 4-5
PA Amp AR-LXPA/PA2 4-6
STAmpAR-LXST1 4-9
Sensitivity Settings Using TEDS Functions 4-11
AutoOffset 4-13
Calibration By Using Calibrator 4-14
ZeroBalance 4-15
Setting Tachometer Pulse Inputs 4-16
OutputAmpSettings 4-18
Outline of Trigger Recording 4-19
RepeatMode 4-19
IntervalMode 4-20
Repeat Mode Settings 4-21
LevelTriggerSettings 4-23
Interval Mode Settings 4-24
Saving and Loading Settings 4-25

Contents
vi
SavingSettings 4-25
Loading Settings 4-26
Section 5 Operations
Specifying Recording Devices and File Names 5-2
RecordingtoMemory 5-4
Recording to Media (MO/PC Card) 5-6
RecordingtoPC 5-8
RecordingOperations 5-9
ExchangingMedia 5-10
Copying 5-11
Reproducing 5-12
ReproducingOperations 5-13
Moving Reproducing Point (Skip) 5-13
Searches 5-14
ConvenientFeatures 5-15
DisplayingWaveform 5-15
ChannelProperty 5-16
DisplayingBarMeter 5-17
DisplayingDigitalValues 5-17
Viewing Header Information 5-17
Changing Modes 5-18
StoppingFan 5-19
Listening to Data by Sound 5-19
LX Stand-alone Operations 5-20
RecordingtoMedia 5-21
RecordingtoMemory 5-22
Reproducing 5-23
Recording Synchronization 5-24
Settings and Recording Operations 5-24
Connecting Recording Synchronization Cables
andTurningonPower 5-25
Operations 5-26
Section 6 Specifications
Main Unit Specifications 6-2
ExternalDimensions 6-3
BlockDiagram 6-4
Tachometer Pulse Input Specifications 6-5
Generator Output Specifications 6-6
Expansion Unit Specifications 6-7
ExternalDimensions 6-8
DC Input Amp Specifications 6-9
ClockDiagram 6-10
PAAmpSpecifications 6-11
STAmpSpecifications 6-13
Output Amp Specifications 6-15
BlockDiagram 6-16
FileFormat 6-17
TypesofFiles 6-17
FileName 6-17
Directory Structure on Media 6-18
DataFile 6-19
Data File When Turning on Tachometer Pulse Inputs 6-20
Converting Data to Physical Quantities 6-22
HeaderFile 6-23
ConnectorSpecifications 6-26
DIGITAL CONTROL Connector 6-26
Recording Synchronization Specifications 6-27

Contents
vii
Section 7 Appendixes
Troubleshooting 7-2
Supplied Accessories and Options 7-3
SuppliedAccessories 7-3
Options 7-3

Contents
viii

1-1
Section 1 Preface
Overview ............................................................. 1-2
Features .............................................................. 1-3
About TAFFmat .................................................... 1-5
Notes on Usage .................................................. 1-6
Names and Parts ................................................. 1-8
Front .............................................................. 1-8
Rear ............................................................... 1-10
Recording Times .................................................. 1-12
Sampling Frequency and Number of Channels .... 1-13

Overview
1-2
Overview The LX series instrumentation data recorders can record and reproduce signals of a maximum 48 kHz
sampling frequency via 8 channels onto MO (Magneto Optical Disk) or PC card media. Recorded data on
the media is stored as PC files. The maximum input channels are 32 channels by using the selectable
types of the 8 channels input cards and the optional channel expansion unit.
You can choose the recording media among the followings: Recording to the internal memory, 3.5 inch
MO, PC card, and a PC.
The file format is TEAC's proprietary TAFFmat format. TAFFmat files can be loaded into commercially
available analysis software.
From a PC you can use the supplied LX Navi software to set recording conditions such as the input range
or sampling frequency. The interface with a PC is hot-pluggable and compatible with IEEE 1394, so after
setup you can disconnect the LX while the power is still on, and start or stop recording by using control
buttons on the main unit. You can also use LX Navi to record or reproduce while connected to a PC.
You can chose the 100BASE-TX Ethernet interface as alternative.
An optional color LCD remote control unit is available to set recording conditions, to record and reproduce,
and to monitor by using bar meters.
LX-10 or LX-20
Remote Control Unit
In
p
ut Am
p
Out
p
ut Am
p
Record
Reproduce
Direct
Memory
MO or
PC Card External
Drive
IEEE1394
or Ethernet
Test0001.dat

Features
1-3
Features
zInput/Output Amps
The LX main unit equips 2 slots and the optional expansion unit provides additional 2 slots for installing the
input amps and/or the output amps. The input/output amp provides 8 channels inputs/outputs from the
below selections.
DC input amp card: Use to connect voltages and/or to connect signals of external amplifiers.
AnotherDCinputampcardformeeting lower sampling frequencies is available.
PA amp input card: Addition to voltage inputs, use to connect IEPE (Integrated Electronics
Piezoelectric)type accelerometers. Another PA amp card for providing A/C
weighting filter is available.
ST amp input card: Use to connect strain gauges and/or gage-type sensors, also voltages.
Analog output amp card: Use to reproduce analog signals.
zRecording Modes
You can select either MO drive or PC card drive for data recording on to a removable media.
Memory recording: Recording to 64MB (add up to 512 MB as option) internal memory.
Stored data can be transferred to the removable media or the PC.
MO recording: Recording to 1.3GB MO.
Stored data on the MO can be loaded into the PC by using an MO drive mounted.
PC card recording: Stored data on the PC card can be loaded into the PC by using the PC card slot.
PC recording: ecording directly into the PC.
You can also transfer data to a PC while recording to memory or the media, or automatically save to the
media after recording to memory.
zSampling Frequency Series
Addition to the LX-10/10L providing with 96 kHz sampling frequency series, the LX-20/20L provide with the
selections of the sampling frequency series of 102.4 kHz, 100 kHz, 96 kHz, or 65.536 kHz and the tachometer
pulse inputs.
zInterface to PC
You can select either IEEE1394 (LX-10/20) for higher speed data transfer or 100BASE-TX (LX-10L/20L) for
LAN configuration on an interface to communicate with a PC.
zReal Time Monitor
You can monitor the data as formats of wave forms, bar graphs, and digital displays on the PC display while
recording. You can reproduce the recorded data on the internal memory or the media.

Features
1-4
A Variety of Recording Triggers
Manual: Starts recording manually.
Level Trigger: Starts recording by detecting level changes in a specified channel.
External Trigger: Starts recording by using an external signal as the trigger.
Pre-trigger: A pre-trigger can record the data that was read into a
buffer before a recording-startcondition (based on a level trigger or
external trigger) was satisfied.
Post-trigger: Continues to record for a set period even after a recording-stop condition
(based on a level trigger or external trigger) was satisfied.
Interval operation: Repeatedly starts and stops recording for a specified number of times, during a
specified period.
zEvent Marks
You can mark data during recording, and search for such event marks when you want to reproduce
some recorded data.
zRecording and Reproducing Voice Memos
A microphone amp and a speaker are built in, so you can record and reproduce (listen to) voice
memos.

About TAFFmat
1-5
ch 1
ch 2
ch 3
ch 4
ch 5
ch 6
ch 7
ch 8
1/6000 sec
Order of recorded data
About TAFFmat
TAFFmat (an acronym for Teac Data Acquisition File Format) is a file format composed of the following:
za data file containing A/D (analog to digital) converted data. The file is in binary format with the
extension dat.
za header file containing information such as recording conditions. The file is in text format with the
extension hdr.
This document uses the term ID to refer to a collection of data collected from the start of recording on the LX
series until the recording is stopped or paused. For each ID, one data file and one header file is recorded.
A voice memo is recorded as a WAV file with the extension wav.
The above files share a common file name, to which is appended an ID number. When a new file name is
specified, this ID number becomes 1. Each time recording starts, this number is incremented by 1.
A/D-converted data is recorded as 2-byte integers from -32768 to +32767. Negative numbers are
expressed as complements of 2. The byte order is from the lower bytes to the higher bytes. The data order
is as follows: first sampling channel order -> second sampling channel order ->...-> last sampling channel
order. At the LX series, ADC value +/- 25000 represents +/- 100 % of the input range.
This document uses the term scan to refer to a collection of data resulting from one sampling. A data file is
a collection of scan repetitions.
Example:
Data of 1 scan when the sampling frequency is 6 kHz:
Standby
REC Start FWD Pause PAUSE Resume FWD Stop STOP
Aaaaa001.dat
Aaaaa001.hdr Aaaaa002.dat
Aaaaa002.hdr

Notes on Usage
1-6
Notes on Usage
zUse of a UPS is Recommended
We recommend that you use a UPS (Uninterruptible Power Supply) whenever you use an AC adapter.
This can protect important data during a power stoppage. If power is turned off while a media is in
a drive, data recorded on that media might become unreadable. Use an optional battery unit to
back up the operation at the power stoppage.
zUse Specified Media Only
Use 1.3 GB, 3.5 inch MO disks from Fujitsu Ltd.
Use PC cards checked by TEAC in advance (contact us for information).
Other media might be unable to record or reproduce correctly.
PC Cards Checked by TEAC for Correct Operations (As of August 2005)
Sun Disk
Compact Flash Buffalo Compact Flash Micro Drive
128MB SDCFB-128-801 64MB RCF-X64MY 340MB DMDM-10340
256MB SDCFH-256-903 256MB RCF-G256M 1GB DSCM-11000
SDCFB-512-801 1GB RCF-G1G
512MB SDCFH-512-801 2GB RCF-G2G
SDCFB-1000-801
SDCFB-1024-J60
Lexar Media
Compact Flash Rnesas PCMCIA TYPEⅡ Flash memory card
1GB
SDCFH-1024-903 1GB CF1GB-80-380 128MB HB288128A5
SDCFB-2000-801 2GB CF2GB-40-380 512MB HB28B512A6
2GB SDCFH-2048-J60 1GB HB28B1000A6I･O Data
Compact Flash 2GB HB28B2000A8HHagiwara sys-com
Compact Flash 256MB CFX-256M
1GB HPC-CF1GZP 1GB CF40-1G
zRemove Media Before Powering Off the LX
Remove the media before you power off the LX. If you power off the LX while data is being written,
data recorded on that media might become unreadable. Also, remove the media before moving the
LX main unit. Moving the unit while the media is inserted might result in damage, in particular on a
MO disk.
zRemove Media
Remove the media only at the STOP state of the REC mode.
zNever Remove Recorded File, Never Rename File/Folder Name of Recorded File By Windows
Operation
If you manipulate the recorded files on the media by Windows operation, such as partially removing
the file, or renaming the file/folder name, the link between the data file and the header file will be
lost or the writing speed to the media to support the specifications cannot be assured, and then the
data will become unreadable on the PC when such media is re-inserted in the LX.
Write-protect an MO disk before inserting it into a PC drive.

Notes on Usage
1-7
zClean Disk and Lens
Dust might collect on an MO disk or lens after they have been used for a long time. This dust might cause
errors. To prevent this problem, clean the MO disk and lens using a cleaning kit (separate purchase). The
period after which cleaning is required depends on the environment but, as a general rule, clean once every
three months.
9To clean an MO disk, use the cleaning kit TZ-381 (separate purchase). To clean a lens, use the lens
cleaner 0240470 (separate purchase).
9For details on how to clean, see the explanation supplied with the cleaning kit.
zHandling PC Card
To discharge static electricity from your body, touch a metallic surface near you before handling the unit.
Never touch the media being inserted to the PC card slot while recording and playing back.
zMake Sure to Select FAT16 When Formatting Media by Windows Operation
The LX file format does not support FAT32, use FAT16 format before using.
zAbout No MO/PC Card Drive
The drive is not installed. Naturally, the functions concerning the recording to the media are disabled.
zAbout No Output Amp Model
The output amplifier is not installed. Naturally, the functions concerning the output amp are disabled.
However, you can view the reproduced data on a PC.
zPower OFF While Amp Calibration State
When turning on the power of the LX unit, the unit goes into the calibration of the installed amps
automatically (Input level LED on each amp are flashing in red), and then goes to the ready state for
operations (Input level LED turns on green). Turning the power OFF while the amp calibration state
initializes the setting parameters.

Names and Parts
1-8
Names and Parts
Front
1 Drive
Opening the cover reveals the disk slot.
2 Input level LED
When the input signal for some channel is larger than +/- 10 % of a set input range, the LED glows
green.
When the signal exceeds +/- 115 % of the range, the LED glows red.
3 Input connector
Inputs the signal to be measured.
4 Power switch
Pushing the switch up turns on the power. Pushing the switch down turns off the power.
5 Volume knob
Adjust the volume for reproducing voice memos.
6 EARPHONE jack
Connects to an earphone when you are using the earphone to listen to voice memos.
When an earphone is inserted, sound does not come from the speaker.
7 MEMO IN jack
Connects to a microphone used for voice memos.
8 USAGE LEDs
Indicates the usage rate of the recording device. During recording to memory, these LEDs indicate
what percentage of the total memory is being used. During recording to a media, these LEDs
indicate what percentage of the total media capacity is being used. During recording to a PC, these
LEDs indicate what percentage of memory is being used as the buffer for transmitting data. From
the left, the LEDs indicate the percentages of 5, 10, 20, 35, 50, 70, 90, and 100%.
These LEDs also function as a low-voltage alarm, and blink when the power voltage falls to 11 V or
less. In such a situation, recording or reproduction stops.
1 2 3
5
4
9 8 7 6
1012 11

Names and Parts
1-9
9 Output connector (When the analog playback amp card is installed into the slot.)
Outputs the reproduced signal. Outputs the input signal during recording-standby status or during
recording. You can set the output range in 0.1 V steps, from 1 V to 5 V.
10 Output level LED (When the analog playback amp card is installed into the slot.)
When the output signal for some channel is larger than +/-10% of a set output range, the LED glows green.
When the signal exceeds +/-115% of the range, the LED glows red.
11 P LOCK button
Pressing this button for 3 seconds causes the lamp to glow and disables the five buttons on the left: STOP,
REC, FWD, PAUSE, and EVENT. To release the lock, again press the button for 3 seconds.
12 Recording/reproduction control buttons
Buttons used for recording or reproduction. Details are given later.

Names and Parts
1-10
SERIAL NO.
MADE IN JAPAN
Rear
LX-10 IEEE 1394 Version
The LX-10L LAN version has an interface (at 7) shown below.
LX-20L LAN Version
The LX-20 IEEE 1394 version has an interface (at 7) shown above.
1 2 3 4 4 5 6
8 7
9
ＲＸ
ＬＡＮ
SERIAL NO.
MADE IN JAPAN
