Teac TU-NR-C-G User manual

D01396001A
Z
Strain gauge load cell Instructions for Use
TU-NR-C-G
Tension/Compression Load Cell
Introduction
Thank you for purchasing the TU-NR-C-G load cell.
Please read this document completely before using this
load cell to achieve its best performance and ensure safe
and proper operation.
oCompany names and product names in this document are the
trademarks or registered trademarks of their respective owners.
Included accessories
If anything is missing or damaged, contact the retailer
where you purchased the product.
Test report × 1
Instructions for Use (this document) × 1
IMPORTANT SAFETY INSTRUCTIONS
VWARNING
If something abnormal occurs
Request repair from the retailer where you purchased
the product.
Do not open the cover.
Never remove the cover from this unit. Doing so could
cause malfunction. Request inspection and repair from the
retailer where you purchased the product. Do not alter this
unit. Doing so could cause malfunction.
Do not put foreign objects or water, for example,
into the unit.
Do not place a container that holds water, for example, on
top of this unit. If liquid is spilled, for example, and enters
the unit, this could cause malfunction.
Do not use the unit with any power supply voltage
other than that specified.
Do not use the unit with any power supply voltage other
than that specified. Doing so could cause malfunction.
VCAUTION
Unsuitable installation locations
Do not place the unit in the following types of locations.
Doing so could cause malfunction.
oLocations where it might be exposed to smoke or steam,
such as near a kitchen table or humidifier
oUnstable locations, including unsteady stands and
tilted places
oLocations that are very humid or dusty
oLocations that are exposed to direct sunlight
When not using the unit for a long time
For safety, cut the power supply when not using this unit
for a long time.
Do not operate a damaged unit.
Precautions for use
oThis unit is not built to be water or splash resistant,
and it cannot be used in conditions when the relative
humidity is high. Moreover, use in atmospheres with
corrosive gases should be avoided.
oBe careful to prevent water, oil and other substances
from getting on the unit.
oAvoid use in conditions where condensation could occur.
oConnect cores to the load cell after discharging (elim-
inating) static electricity from your body.
oIf the surrounding temperature changes suddenly, the
values output by this device could become unstable,
making accurate measurement impossible.
(This could occur, for example, in a location blown by
warm or cold air.)
oConduct load calibrations periodically.
Installation procedures
oInstall this unit in a place where the structure is level
and can sufficiently bear the load being used. Output
precision could be affected if the attachment surface
does not meet parallelism and flatness requirements.
oRefer to Figure 1 for use with only compression loads.
Refer to Figure 2 for use with tension/compression loads.
oAttach a load button when using with compression.
When using with tension, attach a load rod, for example.
Load button Load
direction
Load
direction
Load rod
Always ensure a gap
Figure 1. Compression Figure 2. Compression/
tension
oInsert screws (steel hexagon socket head cap
screws) into the screw holes near the edge of the
load cell, and fix it to the flat attachment surface.
(Output precision could be affected if the attachment
surface is not flat.) The size of the screws used and their
number depends on the rated capacity (model name)
of the load cell as shown below.
Screw types and tightening torques
Rated
capacity
Center screw section Flange bolt section
Tightening
torque
Dimension
of load cell
screw hole
Tightening
torque
Dimension
of load cell
screw hole
1kN 96N·m M12 × 1 10N·m M6
2kN 96N·m M12 × 1 10N·m M6
5kN 96N·m M12 × 1 10N·m M6
10kN 96N·m M12 × 1 10N·m M6
20kN 96N·m M12 × 1 10N·m M6
50kN 400N·m M20 × 1.5 25N·m M8
100kN 1.3kN·m M32 × 2 43N·m M10
200kN 3.2kN·m M40 × 2 190N·m M16
Use screws with a strength grade of 12.9.
In addition, the length of thread engagement for the screw
and the mounting part (internal threads) should be about
twice the nominal diameter of the screw.
Please consult with us if you are uncertain about screw
selection, for example.
oTighten with the torque shown in the“Screw types and
tightening torques” table to prevent the load button
or load rod from becoming loose. Be sure not to apply
torque that exceeds the tightening torque shown
in the table even when removing an attached load
button or load rod.
A thread-locking fluid can be used on the screw, but
be aware that this could prevent removal of the load
button or load rod.
oWhen connecting a load button or load rod to this unit
(or disconnecting one), check the values in the Values
Table of the Specifications.
oWhen using with tension, consider the detent of all the
screws, and consider implementing inspections before
starting work, for example.
In addition, also consider examinations to prevent
accidents caused by falling objects due to damaged
load cells resulting from overloads and unbalanced
loads, for example.
Precautions when placing loads on the unit
oMake sure the load is perpendicular to the surface to
which this unit is attached.
oApply the load so that it is centered on the center of
the unit. If the load is not centered (eccentric load),
twisting, for example, and measurement errors could
occur. This could even result in damage.
F1 F2F
F is the correct load orientation
F1 is an eccentric inclined load
F2 is an eccentric load
oIf the load receiving area is contacted by something that
is at a different temperature and the load is increased,
the values output by this device could become unstable,
making accurate measurement impossible. In such a
case, wait until the temperature difference ceases to
exist before measuring.
oDo not apply any load to the area shown by shading
with diagonal lines in the illustration below. Applying a
load to the shaded area will break the load cell.
Electrical connection of load cell
Connect as shown in the illustration below. Incorrect con-
nections could result in inability to balance and in errors
occurring in the output voltage when loads are applied.
Receptacle in device
A
B
C
D
E
NDIS-compliant receptacle
oThis unit does not support remote sense.
See the operation manuals of indicators and strain
amps that support remote sense for how to connect
sensors with those units.
oThe shield is connected to the main body of this prod-
uct. For this reason, if grounding is necessary because
of external noise or another issue, arrange to ground
the shield to a part other than the body of this unit,
for example.
oUse a specialized cable when replacing the cable or to
increase the length. (Please consult with us.)

Warranty explanation
oThe warranty period for this device is one year from the date of purchase.
oBe aware that repairs will require payment in the following cases even during the
warranty period.
1) Malfunction or damage due to misuse
2) Malfunction or damage caused by modifications or repairs conducted by any party
other than our company or a service person designated by our company
3) Malfunction or damage caused by dropping, transportation or similar handling
after product delivery
4) Malfunction or damage caused by fire, earthquake, water, lightning or other
natural disaster
5) Malfunction or damage caused by external factors, including power supplies and
equipment environmental conditions, that deviate from the operation require-
ments of this product
6) Malfunction or damage if the product was not purchased from our company or
an agent designated by our company
oWe offer paid service after the conclusion of the warranty period. For details, please
contact the retailer where you purchased the unit.
oBe aware that our company will bear no responsibility for any secondary damages
resulting from the operation of this device or related to data.
oInformation is given about products in this manual only for the purpose of example
and does not indicate any guarantees against infringements of third-party intellectual
property rights and other rights related to them. TEAC Corporation will bear no respon-
sibility for infringements on third-party intellectual property rights or their occurrence
because of the use of these products.
When included cable connected
Red Input (+)
Black Output (−)
Blue Input (−)
White Output (+)
Yellow Shield
A
B
C
D
E
Handling after use
oWhen moving this unit while it is attached, take protective
measures to prevent it from being shaken or subjected
to excessive external forces.
oWhen storing it, keep it in a dry place where it will not
be exposed to water or oil, for example.
Rated capacity A ØB C ØD ØE ØF ØG
(H7) H J K L M N ØP ØQ
1kN 102kgf 25 65 22 70 41 18 14 0.5 2 55 22 50 M12 × 1 52 6.5
2kN 204kgf 25 65 22 70 41 18 14 0.5 2 55 22 50 M12 × 1 52 6.5
5kN 510kgf 25 65 22 70 41 18 14 0.5 2 55 22 50 M12 × 1 52 6.5
10kN 1.02tf 25 65 22 70 41 18 14 0.5 2 55 22 50 M12 × 1 52 6.5
20kN 2.04tf 30 65 22 70 41 18 14 0.5 2 55 22 50 M12 × 1 52 6.5
50kN 5.1tf 30 88 27 92 60 30 22 1 2 67 22 50 M20 × 1.5 74 9
100kN 10.2tf 34 117 31 121 82 46 34 1 2 81 22 50 M32 × 2 100 11
200kN 20.4tf 50 − − 166 116 60 44 1 2 117 40 70 M40 × 2 142 17
Values Table
Model
Allowable bending moment Allowable lateral load Allowable
torque
Natural
frequency
(kHz)
Weight
(kg)
Extent of precision
compensation
Extent that will not cause
mechanical damage
Extent of precision
compensation
Extent that will not cause
mechanical damage
TU-NR-C 1KN-G 0.6N·m 8.4N·m 58.8N·m 2.7kN·m 2.1N·m 6.5 0.6
TU-NR-C 2KN-G 1.1N·m 16.3N·m 98.0N·m 4.1kN·m 3.9N·m 8 0.6
TU-NR-C 5KN-G 1.7N·m 25.3N·m 166.7N·m 6.8kN·m 11.4N·m 11 0.6
TU-NR-C 10KN-G 3.7N·m 53.8N·m 323.6N·m 14.4kN·m 51.5N·m 16 0.6
TU-NR-C 20KN-G 10.4N·m 148.9N·m 657.0N·m 29.9kN·m 164.6N·m 21 0.7
TU-NR-C 50KN-G 13.6N·m 195.2N·m 1.6kN·m 30.1kN·m 392.0N·m 18 1.1
TU-NR-C 100KN-G 48.1N·m 687.6N·m 3.2kN·m 63.9kN·m 1.9kN·m 16 2.2
TU-NR-C 200KN-G 190.7kN·m 2.7kN·m 6.5kN·m 175.2kN·m 7.9kN·m 12 6.0
Contact information
TEAC CORPORATION (Manufacturer)
147 Ochiai, Tama-shi, Tokyo 206-8530 Japan
Phone: [phone]
TEAC AMERICA, INC.
10410 Pioneer Blvd. Unit #1, Santa Fe Springs, California90670,
U.S.A.
Phone: [phone]
TEAC EUROPE GmbH. (EU Importer)
Bahnstrasse 12, 65205 Wiesbaden-Erbenheim, Germany
Phone: [phone]
TEAC UK Limited (UK Importer)
Luminous House, 300 South Row, Milton Keynes,
Buckinghamshire, MK9 2FR, UK
Phone: [phone]
1222 MA-3591A
Specifications
TU-NR-C 1KN-G to TU-NR-C 200KN-G
Rated capacity: 1 kN, 2kN, 5kN, 10kN, 20 kN, 50 kN,
100kN, 200kN
Safe overload rating: 150% R.C.
Rated output: 0.75mV/V ±1% (1kN)
1.0mV/V ±1% (2kN)
1.5mV/V ±1% (5kN to 200kN)
Linearity: 0.15% R.O.
Hysteresis: 0.15% R.O.
Repeatability: 0.1% R.O.
Zero balance: 5% R.O.
Safe excitation voltage: 20V (12V recommended)
Input terminal resistance: 350Ω ±1%
Output terminal resistance: 350Ω ±1%
Insulation resistance: 1000MΩ or more (DC50V)
Compensated temperature range: −10 to 60°C
Permissible temperature range: −30 to 80°C
Temperature effect on zero balance:
0.1% R.O./10°C (1kN to 2kN)
0.05% R.O./10°C (5kN to 200kN)
Temperature effect on output: 0.1% R.C./10°C
Connector: PRC03-21A10-7F
Cable: Ø8, 4-core shielded, 5m, bare lead wires for one end,
PRC03-12A10-7M for other end
Body material: alloy tool steel
Environmental compliance: RoHS (10 substances)
TEDS: not supported
Dimensional drawings
(K)
P.C.D. P
8-Q
M
N
H
J
ØG
ØF
ØE
ØB
ØD
ØE
ØF
ØG
H
N
（−）
（＋）
J
C
A
L
A section detail
Load direction
A section
A
B
B
A
A
B
A
Boss parallelism
Boss parallelism
Concentricity
Concentricity
Flange parallelism
Geometric tolerances
Rated capacity Flange
parallelism
Boss
parallelism Concentricity
1kN 102kgf
0.01 0.02 0.07
2kN 204kgf
5kN 510kgf
10kN 1.02tf
20kN 2.04tf
50kN 5.1tf
100kN 10.2tf
200kN 20.4tf
