VABCHES D8L239BS02 User manual

1-42
D8L239BS02
D8L239HS02
D8L239BR02
As this item contains many parts, please read the installation
instruction carefully before installation . Please use tools
properly and carefully. If you have any questions about the
product and installation, please contact us.
Our professional after-sales team will serve you online all
[email protected]
day.
WhatsApp community↑

Before You Start
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware of to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw. （Assembly
speed can be increased by using electric screwdriver）
Helpful Hints
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with an R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- If there is a back panel in the package, please install it to make sure your unit is
complete and sturdy.
-Please fix all the screws provided for the back panel which can enhance product
stability. If it is difficult to fix it when tightening, it can be fixed with the help of a
hammer and then tightened.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
PEOPLE NEEDED FOR ASSEMBLY: 1-2
2-42

Board Identification
Not actual size
DRESSING MIRROR
Qty:1
A
UPPER LEFT PARTITION
Qty:1
C
UPPER LEFT SIDE PANEL
Qty:1
3-42
B
UPPER RIGHT PARTITION
Qty:1
D
FIXED SHELF
Qty:6
F
UPPER RIGHT SIDE PANEL
Qty:1
E
FRONT BAFFLE
Qty:1
G
DESK TOP
Qty:1
I
SMALL PARTITION
Qty:2
H

Board Identification
Not actual size
BACK PANEL
Qty:3
J
LOWER LEFT PARTITION
Qty:1
L
LOWER LEFT SIDE PANEL
Qty:1
4-42
K
LOWER RIGHT PARTITION
Qty:1
M
SIDE SLAT UNDER DRAWER
Qty:2
O
LOWER RIGHT SIDE PANEL
Qty:1
N
ADJUSTABLE SHELF
Qty:2
P
BOTTOM FRONT RAIL
Qty:2
R
BOTTOM
Qty:2
Q

Board Identification
Not actual size
LEFT DOOR
Qty:1
S
MIDDLE SLAT UNDER DRAWER
Qty:1
U
RIGHT DOOR
Qty:1
5-42
T
LOWER MIDDLE BACK
Qty:1
V
DRAWER LEFT SIDE
Qty:1
X
DRAWER FRONT
Qty:2
W
DRAWER RIGHT SIDE
Qty:1
Y
SMALL DRAWER BOTTOM
Qty:2
AA
SMALL DRAWER BACK
Qty:2
Z

Board Identification
BIG DRAWER FRONT
Qty:1
BB
BIG DRAWER BOTTOM
Qty:1
BIG DRAWER BACK
Qty:1
6-42
STOOL SIDE PANEL
Qty:2
STOOL BACK APRON
Qty:1
STOOL FRONT APRON
Qty:1
STOOL BOTTOM BOARD
Qty:1
SPONGE CUSHION
Qty:1
CC DD
EE FF GG
HH II
BACK PANEL
Qty:1
JJ

Board Identification
DRAWER LEFT SIDE
Qty:2
KK
DRAWER RIGHT SIDE
Qty:2
7-42
LL

Board Identification
Not actual size
8-42
C
A
F
B
F
F
J
D
E
JF
F
F
H
G
I
V
K
L
O
P
Q
R
S
M
U
N
JJ
J
P
Q
R
T
O
W
KK
LL
Y
XZ
W
KK
LL
Z
AA
AA
BB
DD
CC
EE
HH
EE
GG
II
FF

Part List
Ø15X9.5mm
1
CAM LOCK
spare:3
X45
9-42
Ø6.5X35mm
2
CAM BOLT
spare:3
X45
Ø8X30mm
3
WOODEN DOWEL
spare:3
X32
Ø6X30mm
4
WOODEN DOWEL
spare:3
X50
Ø6.3X50mm
5
SCREW
spare:2
X18
Ø4X40mm
6
SCREW
spare:3
X42
Ø3.5X14mm
7
SCREW
spare:3
X60
Ø3X14mm
8
SCREW
spare:3
X50
M4X18mm
9
SCREW
spare:1
X10
107X10X21mm
X5
Ø5X17mm
X8
HINGE
X6
HANDLE SHELF SUPPORT
spare:1
14
PERFECT STICKER
spare:3
X44 15CL
LEFT CABINET MEMBER
X3
HEXAGON WRENCH
X1
Ø25mm
4X65mm
15CR
RIGHT CABINET MEMBER
X3
350mm
10 11 12
13
14"14"
350mm
Ø21mm

10-42
Part List
Cam Lock
Fastening
System
Insert the cam bolt into the
hole first, then insert the
cam lock and lock it.
1
3
2
4
The opening must point toward the
edge of the board
350mm
15DL
LEFT DRAWER RUNNER
X3
350mm
15DR
RIGHT DRAWER RUNNER
X3 16
LIGHT BULB
X10 17
TIPPING RESTRAINT
HARDWARE KIT
X1 set
14" 14"
18
SCREW
spare:1
X2 19
PLUG BOARD
X1 20
HAIR DRYER RACK
X1 21
SCREW
spare:1
X2
Ø4X14mm Ø3X12mm

X8
STEP1
11-42
1X8 X8
Ø15X9.5mm
2 6
Proper orientation of CAM LOCK
UNLOCK
LOCK
GROOVE
6
Ø6.5X35mm Ø4X40mm
KK
LL
Z
2
KK LL
Z
W
W
KK
1
X 2
AA
AA

X4
STEP2
12-42
6
Ø4X40mm
GROOVE
6
X
Y
CC
X
DD
Z

STEP3
13-42
X4
1
Ø15X9.5mm
2
X4
2
Ø6.5X35mm
Proper orientation of CAM LOCK
UNLOCK
LOCK
BB
1
BB
DD
X

STEP4
14-42
X2
15DL
X12
7X2 15DR
Ø3.5X14mm
7
7
7
7
7
7
KK Z
W
350mm 350mm
RIGHT DRAWER RUNNER
LEFT DRAWER RUNNER
LL
15DR
15DL
X 2
AA

STEP5
15-42
7
7
7
7
7
7
DD
X
Y
CC
BB
RIGHT DRAWER RUNNER
LEFT DRAWER RUNNER
15DR
15DL
X1
15DL
X6
7X1 15DR
Ø3.5X14mm 350mm 350mm

STEP6
16-42
X12
2
Ø6.5X35mm
B C
D E
2

STEP7
17-42
X12 X24
1 4
Ø6X30mm Ø15X9.5mm
Proper orientation of CAM LOCK
UNLOCK
LOCK
1
B
C
F
F
F
D
E
F
F
F
EDGE BANDING
EDGE BANDING
4
X12
14
Ø21mm
14

STEP8
18-42
X6
2
Ø6.5X35mm
2
2
B
C
D
E

STEP9
19-42
X2
1X2 2
Ø15X9.5mm
G
1
2
Ø6.5X35mm
4
Proper orientation of CAM LOCK
UNLOCK
LOCK
X4
4
Ø6X30mm
G
X2
6
Ø4X40mm
6
A
H
X2
14
Ø21mm
14
G
H

STEP10
20-42
THIS STEP REQUIRES 2 PEOPLE
Proper orientation of CAM LOCK
UNLOCK
LOCK
X6
1X4 3
Ø15X9.5mm Ø8X30mm
X2
6
Ø4X40mm
X2
14
Ø21mm
A
E
D
B
C
6
14
1
3
