Techni Mobili RTA-8404 User manual

MODEL RTA-8404
ASSEMBLY INSTRUCTIONS
Thank you for purchasing our product
REV-022021-1

•Please read carefully the assembly instructions
before the installation.
P. 1 RTA-8404 P. 1
•Do not discard this manual or any of the packaging
material until the unit has been completely assembled.
•Might require two people.

P. 2 RTA-8404 P. 2
A
x1
B
x1
C
x1
D
x1
Tabletop Back Panel Left Panel Right Panel
E
x1
F
x1
G
x1
H
x3
Middle Panel Partition Panel Bottom Panel Drawer front panel
J
x3
Leg Panel Drawer left panel K
x3
L
x3
Drawer right panel
M
x3
N
x1
Drawer back panel
Drawer bottom
panel
Back panel
I
x1

P. 3 RTA-8404 P. 3
A
C
D
E
F
B
H
H
H
I
LIST OF HARDWARE, SCREWS AND FITTINGS
MAIN PARTS LAYOUT (FOR REFERENCE):

P. 4 RTA-8404 P. 4
☛This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the
assembly using this kind of hardware.
Cam Bolt Cam Lock
1. Screw the bolt into the
corresponding panel.
2. Place the other panel over the
panel with the bolt, then insert the
cam lock to join the bolt’s head.
If the cam lock does not want to
enter, check its proper alignment.
There might be a very small gap
between the panels which is normal.
3. Turn the cam lock clockwise. This
will lock the parts together and will
close any gaps.
Alignment: The cross
points towards the panel
with the bolt.

P. 5 RTA-8404 P. 5
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING
TIPS AND WARNINGS.
❶Do a quick inventory
to make sure the
package contains all the
parts and hardware
listed in the assembly
instructions.
❷Missing, damaged and
defective parts can be
replaced at no cost to you.
Please refer to the last
pages on this manual.
❸The replacement parts
service is limited to the
continental United States. If
you reside in Hawaii, Puerto
Rico, U.S. Dependencies or
other countries, please contact
the supplier from where the
unit was purchased.
❹If during assembly you
find an issue or need
clarification, please
contact our Customer
Service for assistance.
Please refer to the last
pages on this manual.
❺On each step read
the instructions and
analyze the illustrations
thoroughly before
proceeding to do the
assembly.
❽Do not
overtighten or force
the screws as they
might break, strip,
damage the threads
of the holes or get
stuck inside the part.
❻Make sure you
understand which hardware
will be used on each step.
Using the wrong size of
screw, bolt or pin might
strip the threads or cause
damage to the part in which
it is being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until all
pieces are positioned
correctly.
❾Sometimes the laminate might cover partially or
entirely the hole on a panel. If there is no visible hole
for the screw, pass and press the tip of your finger
over the area where the hole should be located to
feel the indentation, and once found, carefully pierce
the laminate to reveal the hole underneath.
❿If the hole seems too small for the screw, first
make sure you are using the correct size of screw
and that it’s been installed in the correct hole. If the
hole still appears to be too small, carefully pierce the
laminate to reveal the hole’s actual size.

ASSEMBLY STEPS
P. 6 RTA-8404 P. 6
Attach the cam bolts 5to the corresponding holes on panels A, C, D, E
and Has shown. Please make sure to insert them in the correct hole as
some holes are intended for the wooden pins in subsequent steps.
Please note that on panel Ethe bolts are attached on both sides.
STEP 2
Hardware:
25
Pcs
STEP 1
Hardware:
28
Pcs
Insert the wooden pins 1into the corresponding holes of panels B, C, D,
E, F, G, I, Jand Kas shown. Make sure to insert in the correct holes as
some are intended for other purposes in other steps..
ATTENTION: DO NOT JOIN ANY PARTS IN THIS STEP!
!
(NOT INCLUDED)
5
1

P. 7 RTA-8404 P. 7
Grab the Metal Sliders 7and group them by their shape (Flat or L
shaped). All the Lshaped sliders will be used until step 12, so please
set them aside. With the panels Dand Epositioned as shown, assemble
the flat sliders using screws 2as shown. Please note that the wheel
goes toward the front of the panel, and there will be 2 holes above the
wheel.
STEP 3
Hardware:
12
Pcs
6
Pcs
Insert and align the cam locks 5into the corresponding holes on
panel B, and assemble to it the panels Cand Eas shown and as
explained in page 4.
STEP 4
Hardware:
❺4
Pcs
(NOT INCLUDED)
(NOT INCLUDED)
2
7
Scan QR Code to
view this step
TOP
BACK
FRONT

P. 8 RTA-8404 P. 8
Insert and align the cam locks 5into the corresponding holes on panels F
and G, and assemble them to Eas shown and as explained in page 4.
Insert back panel Nand leg panel Ias shown.
STEP 5
Hardware:
4
Pcs
STEP 6
(NOT INCLUDED)
5
TOP
FRONT

P. 9 RTA-8404 P. 9
Insert and align the cam locks 5into the corresponding holes on
panels Gand F, and assemble to them the panel Das shown and as
explained in page 4. Attach the Plastic Feet 8to the bottom of panels
C, Dand Eas shown.
Insert and align the cam locks 5into the corresponding holes on
panels B, C, Dand E, and then with the help of another person,
assemble the tabletop Aas shown and as explained in page 4.
STEP 8
Hardware/Tools:
7
Pcs
(NOT INCLUDED)
5
STEP 7
Hardware:
4
Pcs
6
Pcs
5
8

P. 1 0 RTA-8404 P. 1 0
Attach the Z bracket 9to the upper corners of the back panel Nusing
screws 3. Then Install the hole covers 6over the cam locks on the
places indicated.
STEP 9
Hardware:
4
Pcs
11
Pcs
STEP 10
Hardware:
2
Pcs
First insert and align the cam locks 5in the drawer side panels J and
K, and assemble the panels to the front panel Has shown and as
explained in page 4. Then insert the bottom panel Minto the grooves
of panels J, Kand Has shown.
2
Pcs
3
6
9
(NOT INCLUDED)
5

P. 11 RTA-8404 P. 11
Assemble the drawer back panel Lto the side panels Jand Kusing
screws 4as shown.
Assemble the Lshaped sliders 7to the bottom of the drawer using
screws 11 as shown. NOTE: An incorrect assembly will raise the
drawer 1” and will not fit in the desk.
STEP 11
Hardware/Tools:
4
Pcs
STEP 12
Hardware/Tools:
4
Pcs
4
(NOT INCLUDED)
11
J
K
Scan QR Code to
view this step

P. 1 2 RTA-8404 P. 1 2
Install the Handle 10 to the drawer front panel using its own screws,
then cover the cam lock holes on panel Jand Kwith 6as shown.
Insert the drawers into the cabinet starting with the bottom, then
middle, and finally the top one. You might have to insert them at
an angle facing down.
STEP 13
Hardware/Tools:
1 Set
2
Pcs
STEP 14
REPEAT STEPS 10-13
FOR THE OTHER
2 DRAWERS.
6
10

P. 1 3 RTA-8404 P. 1 3
ALL DONE!
Give yourself a nice pat on the back. You did a great job!

AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING
CARE AND MAINTENANCE WARNINGS:
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap
and water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as
underneath the tabletop.
•Do not sit on the unit or lean against it.
•Do not allow small children to play under or over the unit.
•Do not allow small children to reach inside the drawers without your supervision.
•Do not pull, push or drag the unit to move it for more than 1 feet. The unit must be
lifted by at least 2 persons when moving in the same or adjacent rooms.
•Before moving the unit, make sure to secure or remove any object that is heavy or
might fall off. Please note that lifting from the tabletop with too much weight on the
product might lead to part damage/separation.
•When lifting the unit, use both hands and bend your knees, not your backs.
•When transporting the unit to places far away, protect and secure the unit to avoid
damage in transit.
•Shall any part of the unit become defective during the warranty period, replacement
parts might be available to you at no charge. Please refer to the last pages on this
manual.
•The warranty does not extend to regular wear and tear, nor the manufacturer
assumes liability for damages or consequences due to accidents, incorrect assembly,
negligence, improper use, modifications, or not heeding the above warnings.
10 LBS
90 LBS
19 LBS
P. 1 4 RTA-8404 P. 1 4
MAXIMUM WEIGHT CAPACITIES

P. 1 5 RTA-8404 P. 1 5
TECHNI MOBILI WARRANTY
DESKS/LAPTOP CARTS/FILE CABINETS: LIMITED 5-YEAR WARRANTY
TV Stand/Entertainment Center: 2 YEAR WARRANTY
RTA Products, LLC warrants to the Original Purchaser who acquired anew product from
RTA Products or its authorized resellers that this product will be free from defects in its
workmanship and materials, under normal use and service conditions, as described herein.
"Defects" as used in this warranty, is defined as any imperfections that impair the use of the
furniture or product.RTAProducts LLC will replace any defective part, at its discretion, and
without charge to the original purchaser other than the freight from the end consumer to RTA
Products.Replacement parts can only be supplied if parts are available.Items out of
production may be unavailable.This warranty will be effective for the applicable time period
beginning the date of purchase on your original sales receipt.RTA product’s obligation
under this warranty is limited to repairing or replacing products or parts as provided herein.
This product has been designed for and is intended for office and home-office use only.This
warranty is Original Purchaser’s sole remedy for product defects, and this warranty does not
extend to any product, or damage to any product, caused by or attributed to abuse or
misuse, products used for commercial or rental purposes, use modifications of, or
attachments to the product, and products or parts not used, maintained, or extended
hereunder is in lieu of any and all other warranties, express or implied, including without
limitations any implied warranty or merchantability or of fitness for aparticular purpose.
Please note, all desks made with PVC Laminate surface should not be exposed to direct
sunlight, as it may damage the material.Damage of this nature is not covered under this
warranty.
RTA Products will not be responsible for indirect, special, incidental or consequential
damages.This warranty is limited to merchandise purchased in the Continental United
States.Some States do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.This warranty gives
you specific legal rights.You may also have other rights that may vary from state to state.
RTA Products will advise you of the procedure to follow in making warranty claims.The
following are the procedures for warranty claims:
a. Call us Monday –Friday, from 9am-5pm (Eastern Time) at [phone] to explain the
defect and give your name, address and phone number.Please have ready the model
number of our product, date and place of purchase.You can also write to us by e-mail to
[e-mail] and include the same information.
b. b. If we determine that replacement will remedy the situation, and in order to determine
the extent or the cause of the defect, purchaser will need to send the part in question at
purchaser’s expense.Once we receive the part, we will examine it and determine whether
the claim is valid (or not), and then proceed to send the replacement.We will ship the
replacement at our expense.

P. 1 6 RTA-8404 P. 1 6
