Techni Mobili RTA-8404 User manual

Thank you for purchasing our product.
MODEL RTA-8404
ASSEMBLY INSTRUCTIONS
REV.FP-1121-2

•Please read carefully the assembly instructions
before the installation.
•Do not discard this manual or any of the packaging
material until the unit has been completely
assembled.
•Might require two people.
P. 1 RTA-8404 P. 1

P. 2 RTA-8404 P. 2
A
x1
B
x1
Tabletop Left back panel
MAIN PARTS LIST
C
x1
D
x1
E
x1
F
x1
Left panel Right panel Middle panel Right shelf panel
G
x1
H
x3
Bottom panel Drawer front panel I
x1
J
x3
Bottom skirt panel Drawer left panel
K
x3
L
x3
Drawer right panel Drawer back panel M
x3
N
x1
Drawer bottom panel Right back panel

MAIN PARTS LAYOUT (FOR REFERENCE):
P. 3 RTA-8404 P. 3
LIST OF HARDWARE, SCREWS AND FITTINGS
PART QTY ITEM
128 Wooden
dowel
212 ST5x8
Euro screw
34ST3x16
412 ST4x38
525
sets
Cam bolt
and lock
617 Hole cover
PART QTY ITEM
73
sets
Sliders, set
of 4 pcs
2 “flat” per set:
2 “L” per set:
86Plastic glide
92Z Bracket
10 3
sets
“L” handle
84mm plus 2
screws
M3.6x22
11 12 ST3.5x15
NOTE: You will need for the assembly a Phillips screwdriver and mallet/hammer (not
included).
A
B
C
D
E
F
H
H
H
I
” per set:

P. 4 RTA-8404 P. 4
☛This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the
assembly using this kind of hardware.
Cam Bolt
Cam Lock
1. Screw the bolt into the corresponding hole
on panel “A”.
3. Insert the cam lock on panel “B” making
sure it goes aligned to receive the bolt’s head.
4. Turn the cam lock clockwise. This will lock the
parts together and will close any gaps.
Alignment: The cross points
towards the panel “A” with the bolt.
2. Join panel “B” to panel “A”. If panel “B” comes
with the cam lock pre-installed, make sure it is
aligned to receive the bolt’s head (refer to point
3). There might be a very small gap between the
panels which is normal.
Panel “B”
Panel “B”
Panel “B”
Panel “B”

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
❶Do aquick inventory
to make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged
and defective parts can
be replaced at no cost
to you. Please refer to
the last pages on this
manual.
❹If during assembly
you find an issue or
need clarification, please
contact our Customer
Service for assistance.
Please refer to the last
pages on this manual.
❺On each step read the
instructions and analyze
the illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you
understand which
hardware will be used on
each step.Using the
wrong size of screw, bolt
or pin might strip the
threads or cause damage
to the part in which it is
being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until
all pieces are
positioned correctly.
❾Sometimes the laminate might cover
partially or entirely the hole on apanel.If there
is no visible hole for the screw, pass and press
the tip of your finger over the area where the
hole should be located to feel the indentation,
and once found, carefully pierce the laminate to
reveal the hole underneath.
❿If the hole seems too small for the screw,
first make sure you are using the correct size of
screw and that it’s been installed in the correct
hole.If the hole still appears to be too small,
carefully pierce the laminate to reveal the
hole’s actual size.
P. 5 RTA-8404 P. 5
❸The replacement parts
service is limited to the
48 contiguous United States.
If you reside in Alaska,
Hawaii, Puerto Rico,
U.S. territories or other
countries, please contact the
supplier from where the unit
was purchased.

ASSEMBLY STEPS
ATTENTION: DO NOT JOIN ANY PANELS IN THIS STEP!
Insert the wooden pins 1into the indicated holes of panels B, C, D, E, F,
G, I, J and Kas shown. Make sure to insert in the correct holes as
others are intended for other hardware in other steps.
STEP 1
Hardware:
1
Dowels
28
Pcs
(NOT INCLUDED)
P. 6 RTA-8404 P. 6
Attach the cam bolts 5to the indicated holes on panels A, C, D, E and H
as shown. Please make sure to insert them in the correct holes as others
are intended for the wooden pins in subsequent steps. Please note that
on panel Ethe bolts attach on both sides.
STEP 2
Hardware:
5
Bolts
25
Pcs
(NOT INCLUDED)
other steps
.
C
ED
J
J
J
K
K
K
B
G
F
I
A
C
D
E
(Left side of panel)
E
(Right side of panel)
H
H
H

P. 7 RTA-8404 P. 7
Grab the “flat” metal sliders 7 (the “L” shaped will be used until step 12,
please set them aside). With the panels Dand Epositioned as shown,
assemble the flat sliders using screws 2as shown.
NOTES:
•The wheels go towards the front of the panels.
•There will be 2 free holes above the wheels.
With the help of another person, join the panels Cand Eto panel B,
insert and align the cam locks 5into the corresponding holes on panel B,
and turn them to lock the pieces as shown and as explained in page 4.
STEP 3
Hardware:
2
M6x20
12
Pcs
7Flat
sliders
6
Pcs
(NOT INCLUDED)
Scan QR Code
to view this step
STEP 4
Hardware:
5Cam
locks
4
Pcs
(NOT INCLUDED)
(Front)
(Left side of panel)
E
ED
7
(Front)
(Front)
C
(Top)
(Top)
B
Cam locks
alignment
(Flat)
(Left side of panel)
E
(Right side of panel)

P. 8 RTA-8404 P. 8
With the help of another person, flip over the pieces assembled in step
4, and assemble the panels Fand Gto panel Ewith cam locks 5as
shown and as explained in page 4.
•Slide the back panel Nthrough the grooves of panels Fand G and
into the groove of panel E.
•Attach the skirt panel Ito panel Eas shown.
STEP 5
Hardware:
5Cam
locks
4
Pcs
(NOT INCLUDED)
STEP 6
E
E
E
C
F
F
G
I
N
(Top)
E
Cam locks
alignment
E
F
G

P. 9 RTA-8404 P. 9
•Assemble the panel Dto panels Fand Gwith cam locks 5as shown
and as explained in page 4.
•Attach the plastic glides 8to the bottom of panels C, Dand E.
With the help of another person, bring the unit built in step 7to the
upright position, and attach the tabletop Ato panels B, C, Dand Ewith
cam locks 5as shown and explained in page 4.
STEP 7
Hardware:
5Cam
locks
4
Pcs
8
Glides
6
Pcs
(NOT INCLUDED)
STEP 8
Hardware:
5Cam
locks
7
Pcs
(NOT INCLUDED)
(Top)
C
G
F
ED
C
D
E
A
B
Cam locks
alignment
Cam locks
alignment

P. 1 0 RTA-8404 P. 1 0
•Attach the Z brackets 9to the upper corners of the back panel Nwith
screws 3.
• Install the hole covers 6over the cam locks on the indicated places.
•For each of the 3 drawers, assemble the side panels Jand Kto the
front panel Hwith cam locks 5as shown and as explained in page 4.
• Slide the bottom panel Mthrough the grooves of panels Jand Kand
into the groove of panel Has shown.
STEP 9
Hardware:
3
ST3x16
4
Pcs
6
Covers
11
Pcs
9
Z Bracket
2
Pcs
(NOT INCLUDED)
STEP 10
Hardware:
5
Cam lock
6
Pcs
6
(Back)
9
(4 covers go
inside this space)
Cam locks
alignment
J
K
H
M
N

P. 11 RTA-8404 P. 11
For each of the 3 drawers, assemble the back panel Lto the side panels
Jand Kwith screws 4as shown.
For each of the drawers, assemble the L shaped sliders 7to the bottom
of the drawer with screws 11 as shown.
NOTES
•The wheels go towards the back of the drawer.
•If assembled incorrectly, the drawers will raise 1” and won’t fit.
(L Shaped)
STEP 11
Hardware:
4
ST4x38
12
Pcs
(NOT INCLUDED)
STEP 12
Hardware:
7
L Sliders
6
Pcs
11
ST3.5x15
12
Pcs
(NOT INCLUDED)
Scan QR Code
to view this step
L
J
K
7
J
K

P. 1 2 RTA-8404 P. 1 2
For each of the 3 drawers, install the handle 10 to the front panel H
using its own screws, then cover the cam lock holes on panels J and K
with 6as shown.
Insert the drawers into the unit starting with the bottom, then middle, and
finally the top one. You might have to insert them at an angle facing
down.
STEP 13
Hardware:
6
Covers
6
Pcs
10
Handle +
2 screws
3
Sets
(NOT INCLUDED)
STEP 14
K
K
10
6
H
J

WEIGHT LIMITS
P. 1 3 RTA-8404 P. 1 3
90 Lbs.
(40.5 Kg)
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and
water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as
underneath the tabletop.
•Do not sit on the unit or lean against it.
•Do not allow small children to play under or over the unit.
•Do not allow small children to reach inside the drawers or compartments without your
supervision.
•Do not pull, push or drag the unit to move it for more than 1 feet. The unit must be lifted by
at least 2 persons when moving in the same or adjacent rooms.
•Before moving the unit, make sure to secure or remove any object that is heavy or might
fall off. Please note that lifting from the tabletop with too much weight on the product might
lead to part damage/separation.
•When lifting the unit, use both hands and bend your knees, not your backs.
•When transporting the unit to places far away, protect and secure the unit to avoid damage
in transit.
•Shall any part of the unit become defective during the warranty period, replacement parts
might be available to you at no charge. Please refer to the last pages on this manual.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes
liability for damages or consequences due to accidents, incorrect assembly, negligence,
improper use, modifications, or not heeding the above warnings.
CARE, MAINTENANCE AND SAFETY WARNINGS:
WEIGHT LIMITS
19 Lbs.
(8.55 Kg)
10 Lbs.
(4.5 Kg)

RTA Products, LLC warrants to the Original Purchaser who acquired anew product from
RTA Products or its authorized resellers that this product will be free from defects in its
workmanship and materials, under normal use and service conditions, as described
herein."Defects" as used in this warranty, is defined as any imperfections that impair the
use of the furniture or product.RTA Products LLC will replace any defective part, at its
discretion, and without charge to the original purchaser other than the freight from the end
consumer to RTA Products.
Replacement parts can only be supplied if parts are available.Items out of production
may be unavailable.This warranty will be effective for the applicable time period
beginning the date of purchase on your original sales receipt.RTA product’s obligation
under this warranty is limited to repairing or replacing products or parts as provided
herein.This product has been designed for and is intended for office and home-office use
only.This warranty is Original Purchaser’s sole remedy for product defects, and this
warranty does not extend to any product, or damage to any product, caused by or
attributed to abuse or misuse, products used for commercial or rental purposes, use
modifications of, or attachments to the product, and products or parts not used,
maintained, or extended hereunder is in lieu of any and all other warranties, express or
implied, including without limitations any implied warranty or merchantability or of fitness
for aparticular purpose.Please note, all desks made with PVC Laminate surface should
not be exposed to direct sunlight, as it may damage the material.Damage of this nature
is not covered under this warranty.
RTA Products will not be responsible for indirect, special, incidental or consequential
damages.This warranty is limited to merchandise purchased in the Continental United
States.Some States do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.This warranty
gives you specific legal rights.You may also have other rights that may vary from state to
state.
RTA Products will advise you of the procedure to follow in making warranty claims.The
following are the procedures for warranty claims:
a. Call us Monday –Friday, from 9am-5pm (Eastern Time) at [phone] to explain
the defect and give your name, address and phone number.Please have ready the
model number of our product, date and place of purchase.You can also write to us by
e-mail to [e-mail] and include the same information.
b. If we determine that replacement will remedy the situation, and in order to determine
the extent or the cause of the defect, purchaser will need to send the part in question
at purchaser’s expense.Once we receive the part, we will examine it and determine
whether the claim is valid (or not), and then proceed to send the replacement.We will
ship the replacement at our expense.
P. 1 4 RTA-8404 P. 1 4
TECHNI MOBILI WARRANTY
DESKS/LAPTOP CARTS/FILE CABINETS: LIMITED 5-YEAR WARRANTY
TV Stand/Entertainment Center: 2 YEAR WARRANTY

FOR SEVERAL HELP OPTIONS
INCLUDING REPLACEMENT PARTS ORDERS
_________________________________________________________________
VISIT: WWW.TECHNIMOBILI.COM
CLICK ON SUPPORT TAB
Scan QR Code to order replacement parts
OR EMAIL US: [e-mail]
P. 1 5 RTA-8404 P. 1 5
