FUFU & GAGA Hall Tree User manual

Version:12/02/2022 1/16
Hall Tree

please read the entire manual before starting to assemble
and/or using this product.follow the manual thoroughly and
keep it for further reference.
IMPORTANT INFORMATION!
It is important that any product which is assembled using any kind of screw is re-tightened
2 weeks after assembly,and once every 3 months - in order to assure stability through-out
the lifespan of the product.
For regular maintenance and cleaning of the product, for the frame, please use a rag dipped
in neutral detergent to fully wipe it, and then dry it with a clean rag.For glass materials, wipe
with a rag dampened with water glass cleaner, and then dry with a dry rag.
Do not use an electric screwdriver, and do not use too much force when installing, because
the board is easy to break.
IMPORTANT !
Overturned furniture can cause serious or fatal crush injuries. To prevent tipping over, be sure
to use the wall attachment, if not included with this product. Please purchase the wall
attachment that fit your wall. If unsure, seek professional advice. Please read and follow each
step of the instructions carefully.
ANTI-TOPPLE WARNING !
Try to find a partner to install
with you, which can speed up
the installation efficiency and
shorten the time.
IMPROVE EFFICIENCY !
In order to avoid scratching this
furnuture should be assembled
on a soft layer-could be a rug.
AVOID SCRATCHES!
2/16

When installing, please carefully confirm whether
each screw corresponds to the manual, accessories
with similar shapes can be distinguished by size
Please prepare the following tools
3/16
Ax15 B x 15
15 x 9 mm
Cx33 D x 22
F x 8 G x4
4 x 35 mm6 x 35 mm 3
x 12 mm(BLACK)
Mx 1 N x 2
E x 2
4 x 12 mm 6 x 30 mm
6 x 30 mm
Hx 1
3 x 14 mm (BLACK)
I x
2
Jx 12
4 x 14 mm
Kx 8
Lx
1
LEFT RIGHT
O x 2 (WHITE)
3 x 16 mm
P x 4Q x 4 (WHITE)

4/16
6
4
2
3
5
1
10
12
11
13
7
9
8
14
15
16
17

1
5/16
1
F x 8
3 x 14 mm(BLACK)
F
C
4
4
G x 4
D
D
D
C
3
22
2
C x 2 D x 4
G
F
F
F
F
FF
F
FF
G
G
G
G
4
4
D
D
D
C
6 x 30 mm 4 x 35 mm
Fix hook(G) to plate 4 using screw(F) as shown.
Connect plate 2 and 3 with plate 4 using
wooden dowel(C) and fix using screw(D)
as shown.

6/16
3
4
J x 4
I x 2
C x 4 D x 7
6 x 30 mm 4 x 35 mm
C
D
C
C
C
C
D
D
D
D
D
D
D
D
3
3
2
11
14
LEFT RIGHT
4 x 12 mm
4 x 14 mm
L x 1
K x 4 M x 1
L
L
J
K
M
K
K
K
K
K
J
J
J
I
I
I
J
J
Cover plate 1 to plate 2,4 and 3
with wooden dowel(C), then fix
using screw(D) as shown.
Fix hinge(I) to plate 14 using screw(J)
as shown.
Fix support part(L&M) to right and left
of plate 14 using screw(K) as shown.

7/16
A
5
6 x 35 mm
A x 15
10
8
12
13
A
A
A
A
A
A
A
AA
AA
A
16
A
A
A
Insert quickfit screw(A) ino corresponding
holes in plate 8,10,12,13 and 16 with a
screwdriver as shown.

6
8/16
6 x 30 mm
C x 2
7
6 x 30 mm 4 x 35 mm
C x 6D x 7
6
5
7
C
C
C
5
6
7
8
8
CC
C
C
C
C
C
D
D
D
D
D
D
D
D
Connect plate 6 and 7 with plate 5
using wooden dowel(C) as shown.
Cover plate 8 to plate 6,5 and 7
with wooden dowel(C), then fix
using screw(D) as shown.
5
7
7

9/16
8
9
C x 4
15 x 9 mm 6 x 30 mm
B x 4
180°
6 x 30 mm 4 x 35 mm
C x 2D x 2
13
13
11
11
12
10
D
D
C
C
C
D
B
B
BB
C
C
C
C
B
C
13
Attach plate 11 to plate 13 with
wooden dowel(C), then fix using
screw(D) as shown.
Connect plate 10 and 12 with plate 13 using wooden dowel(C),
insert cam lock(B) into plate 13 and turn clockwise to tighten
as shown.

10
10/16
11
13
15
B
C
B
B
C
C
B
B
B
B
C
C
C
C
C
6 x 30 mm
C x 2
15 x 9 mm
B x 2
6 x 30 mm
C x 5
15 x 9 mm
B x 3
C
13 15
16
180°
180°
15
12
10
12
10
Attach plate 15 to plate 13 with
wooden dowel(C), insert cam
lock(B) into plate 15 and turn
clockwise to tighten as shown.
Attach plate 16 to plate 10,13 and
12 with wooden dowel(C), insert
cam lock(B) into plate 10,15,12
and turn clockwise to tighten as
shown.

12
11/16
13
9
6 x 30 mm
C x 6
15 x 9 mm
B x 6
B
B
B
B
B
B
B
C
C
C
C
C
C
C
180°
8
12
10
12
10
11
Slide plate 9 along grooves
in plate 10 and 12.
Cover plate 8 to plate 10,11 and 12
with wooden dowel(C), insert cam
lock(B) into plate 10,11,12 and turn
clockwise to tighten as shown.

14
J x 8
4 x 14 mm
12
10
14
I
I
I
J
J
J
J
J
J
12/16
J
J
J
J
JJ
13
Attach plate 14 to plate 13 by fixing
hinge with screw(J) as shown.

15
13/16
If there is misalignment after you install,
adjust the screw to the best condition

16
14/16
17
H x 1
E x 2
4 x 12 mm
K x 4
12
10
14
L
M
M
K
K
K
K
K
K
14
3
x
12 mm(BLACK)
H
E
E
E
E
H
13
Fix support part(L&M) to plate 10 and 12
respectively using screw(K) as shown.
Fix handle(H) to plate 14 using
screw(E) as shown.

18
19
17
1
2
P
Q
3 x 16 mm
P x 4
Q x 4 (WHITE)
15/16
P
Q
Q
Q
Q
P
P
P
9
Insert part(Q) and reinforce back
plate using screw(P) as shown.
Place the pad.

20
D x 2 N x 2
4 x 35 mm 6 x 30 mm
16/16
D
D
N
N
N
D
WALL
O x 2 (WHITE)
O
O
O
Drill holes on your wall, knock into part(N).
Fix the component(assembled in step 3) to
wall using screw(D) as shown.
Use sticker(O) to cover screw(D).
