Technibel CAF94MR5IAA User manual

CAF94MR5IAA
CAF124MR5IAA
CAF184MR5IAA
37.4163.247.0 02/2006
Split air conditioner system • Climatiseurs split
Split-klimagerät • Condizionatore d’aria split system
Acondicionador de aire de consola partida sistema split
OPERATING INSTRUCTIONS • NOTICE D’UTILISATION
BEDIENUNGSANLEITUNG • ISTRUZIONI D’USO
INSTRUCCIONES DE USO

2
Features
This air conditioner is equipped with cooling, heating, and drying functions. Details on these functions are
provided below; refer to these descriptions when using the air conditioner.
•Microprocessor Controlled Operation
The interior compartment of the remote control
unit contains several features to facilitate
automatic operation, easy logically displayed
for easy use.
•Simple One-touchWireless Remote Control
The remote control unit has several features to
facilitate automatic operation.
•24-Hour ON or OFFTimer
This timer can be set to automatically turn the
unit on or off at 10 minutes intervals within a
24 hour period.
•1-Hour OFFTimer
This timer can be set to automatically turn off
the unit at any time after one hour.
•ECONOMY Mode
Pressing this button changes the setting of the
room temperature thermostat, allowing you to
set the temperature at whatever level that you
find comfortable.
•Automatic and 3-step Fan Speed
Auto/High/Medium/Low
•Air Sweep Control
This function moves a flap up and down in the
air outlet, directing air in a sweeping motion
around the room and providing comfort in
every corner.
•High Power Cooling
When a cooling or drying operation is to be
performed, the air conditioner operates for
15 minutes in the high power mode.
•Odor Reduction Mode
When a cooling or drying operation is to
commence, the indoor fan motor is shut down
for 40 seconds to minimize the odors which are
produced when operation starts up.
•Mold Inhibiting Mode
Upon completion of a cooling or drying
operation, the indoor fan motor operates in the
fan mode for 30 seconds to prevent
condensation inside the indoor unit and inhibit
the growth of mold.
•Air Clean Filter
An air filter that uses antibacterial filter to
eliminate unpleasant odors and clean the air.

3
Contents
Page
Features ........................................................................................................... 2
Product Information ........................................................................................ 3
Alert Symbols .................................................................................................. 3
Installation Location ........................................................................................ 4
Electrical Requirements .................................................................................. 4
Safety Instructions .......................................................................................... 4
Names of Parts and operation selector ........................................................ 5
Using the Remote Control Unit.................................................................... 10
Operation with the Remote Control Unit .................................................... 11
1.Automatic Operation ....................................................................... 11
2. Manual Operation ............................................................................ 12
3. Adjusting the Fan Speed .................................................................14
4. ECONOMY Mode ............................................................................. 14
Special Remarks ............................................................................................ 16
Setting theTimer ........................................................................................... 17
Setting the 1-Hour OFFTimer ....................................................................... 20
Setting the HIGH POWER Operation............................................................ 20
Tips for Energy Saving ................................................................................. 21
Adjusting the Airflow Direction.................................................................... 22
Operation without the Remote Control Unit............................................... 23
Care and Cleaning ......................................................................................... 23
Troubleshooting ............................................................................................ 25
Operating Range ...........................................................................................25
Product Information
If you have problems or questions concerning your Air Conditioner, you
will need the following information. Model and serial numbers are on the
nameplate on the bottom of the cabinet.
Model No. ______________________ Serial No. _________________________
Date of purchase ____________________________________________________
Dealer’s address ____________________________________________________
Phone number_____________________
DECLARATION OF CONFORMITY
This product is marked « » as it satisfies EEC Directive No. 89/336/
EEC, 73/23/EEC and 93/68/EEC.
This declaration will become void in case of mis-usage and/or from non
observance though partial of Manufacturer’s installation and/or
operating instructions.
Alert Symbols
The following symbols used in this manual, alert you to potentially
dangerous conditions to users, service personnel or the appliance:
This symbol refers to a hazard or unsafe
practice which can result in severe
personal injury or death.
This symbol refers to a hazard or unsafe
practice which can result in personal
injury or product or property damage.
CAUTION

4
Installation Location
•We recommend that this air conditioner be installed properly by
qualified installation technicians in accordance with the Installation
Instructions provided with the unit.
•Before installation, check that the voltage of the electric supply in your
home or office is the same as the voltage shown on the nameplate.
•Do not install this air conditioner where there are fumes or
flammable gases, or in an extremely humid space such as a
greenhouse.
•Do not install the air conditioner where excessively high heat-
generating objects are placed.
Avoid: To protect the air conditioner from heavy corrosion, avoid installing the
outdoor unit where salty sea water can splash directly onto it or in
sulphurous air near a spa.
Electrical Requirements
1. All wiring must conform to the local electrical codes. Consult your
dealer or a qualified electrician for details.
2. Each unit must be properly grounded with a ground (or earth) wire or
through the supply wiring.
3. Wiring must be done by a qualified electrician.
Safety Instructions
•Read this Instruction Manual carefully before using this air
conditioner. If you still have any difficulties or problems, consult your
dealer for help.
•This air conditioner is designed to give you comfortable room
conditions. Use this only for its intended purpose as described in this
Instruction Manual.
•Never use or store gasoline or other flammable vapor or liquid near
the air conditioner – it is very dangerous.
•This air conditioner has no ventilator for intaking fresh air from
outdoors.You must open doors or windows frequently when you
use gas or oil heating appliances in the same room, which consume
a lot of oxygen from the air. Otherwise there is a risk of suffocation
in an extreme case.
•Do not turn the air conditioner on and off from the power mains
switch. Use the ON/OFF operation button.
•Do not stick anything into the air outlet of the outdoor unit.This is
dangerous because the fan is rotating at high speed.
•Do not let children play with the air conditioner.
•Do not cool or heat the room too much if babies or invalids are
present.
CAUTION

5
Names of parts and operation selector
INDOOR UNIT
1. Remote control unit.
2. Sensor: Detects the room temperature around the remote
control unit, the air conditioner is controlled accordingly.
3. Receiver: This section picks up infrared signals from the
remote control unit (Transmitter).
4. Air outlet: Conditioned air is blown out of the air conditioner
through the air outlet (four flaps).
5. Air intake latch, on two sides.
6.
Air intake grille:Air from the room is drawn into this section and
passes through air filter which removes dust.
7. Air filter.
8. Suspension brackets.
9. Refrigerant couplings.
10.Condensate drain connection.
11. Electric junction box.
12. Sensor: Detects the room temperature around the unit; when
the remote control unit is not active the air conditioner will be
set by the detected temperature.
13.Operation selector.
ON Position: In this position the air conditioner is operating
and controlled by the remote control unit.
Set the selector normally in this position.
OFF Position: Switch the selector to the off position if you
are not going to use the air conditioner for
a few days or longer.
TEST Position: This position is used only for servicing the
air conditioner, so don’t leave the selector in
this position for normal operation.
14.Operation lamp (OPER): This lamp lights when the air
conditioner is running.
15. SERVICE lamp: When a fault occurs in the air conditioner, this
lamp turns on or flashes in combination with the other two
lamps to indicate the type of fault.
16.TIMER lamp: This lamp lights when the system is being
controlled by the timer.
2
1
The OFF position does not disconnect the power. Use the
main power switch to turn off power completely.
WARNING
CAUTION
4
810
3
11
3
5
6
7
12
13 14 16 15
9

(5) ECONOMY ..............................
(6) High power operation ...........
(7) Flap indication
Auto. flap indication ..............
Flap angle indication .............
Sweep indication....................
(8) Fan speed
Automatic operation .............
HIGH .......................................
MEDIUM .................................
LOW ........................................
(1) Operation mode
AUTO ......................................
HEAT.......................................
DOUBLE SENSOR DRY .........
COOL ......................................
(2) Confirmation of
transmission ..........................
(3) Set temperature
16–30 °C
When set to 28 °C .........
Current temperature
indication ......................
(4) Timer
ON Timer ...............................
OFF Timer ..............................
1-hour OFF Timer ...................
Remote Control Unit (Display)
Displayed when indoor
unit sensor is in use
Displayed when setting
timer
Displayed when
transmitting data
Displayed when setting
temperature
Symbols
Displayed when setting temperature in
automatic operation
6

NOTE The illustration above pictures the remote control unit after the cover has
been lowered and removed.
Transmitter When you press the buttons on the remote control unit, the mark
appears in the display to transmit the setting changes to the receiver in the
air conditioner.
Sensor A temperature sensor inside the remote control unit senses the room
temperature.
Display Information on the operating conditions is displayed while the remote
control unit is switched on. If the unit is turned off, only the mode that was
set previously is still displayed.
HIGH POWER button : When you press this button, the current operation mode is set to the
HIGH POWER mode, and the unit is operated in this mode for
15 minutes.
ON/OFF operation button This button is for turning the air conditioner on and off.
: When you press this button, regardless of whether the unit is
operating or stopping, the unit operates for one hour and then
shuts down.
Press the button to increase the set temperature.
Press the button to reduce the set temperature.
For details, see Automatic operation and Manual operation.
Remote Control Unit
Temperature setting
buttons (TEMP.)
1 HR.TIMER button
(1-HOUR OFFTIMER)
Sensor Transmitter
Display
1 HR.TIMER button
HIGH POWER button
OFFTIME setting button
ONTIME setting button
Return button
Advance button
SET button
CANCEL button
ACL button
Battery compartment (Pull off the
cover to expose the batteries.)
CLOCK button
ECONOMY button
MODE selector button
FLAP button
ADDRESS switch
(Cover closed)
ON/OFF operation button
Temperature setting buttons (TEMP.)
FAN SPEED selector button
A/C SENSOR button
Model No.: RCS-3MVHPN4E
7

(1) (2) (3) (4) (5) (6) (7) (8)
Remote Control Unit (continued)
No display : The timer does not operate.
: The air conditioner stops at the set time.
: The air conditioner starts at the set time.
: The air conditioner stops and starts, or starts and stops, at
the set times every day. For details, see “Setting theTimer”.
ECONOMY button For details, see “ECONOMY Mode”. When you press this button in the
HEAT, DRY or COOL mode, the mark appears in the display, and the
remote control unit will automatically adjust the set temperature to
save energy.
MODE selector button Use this button to select AUTO, HEAT, DRY or COOL mode.
(AUTO) : When this setting is selected, the air conditioner calculates the
difference between the outdoor temperature and the room
temperature and automatically switches to the “COOL”, “DRY”
or “HEAT”mode as appropriate.
(HEAT) : The air conditioner makes the room warmer.
(DRY) : The air conditioner reduces the humidity in the room.
(COOL) : The air conditioner makes the room cooler.
FLAP button Press this button either to select the setting of the airflow direction to
the auto. flap in each mode or one of the six possible positions
manually or to select the sweep function which moves the flap up and
down automatically.
: Auto flap setting: If selected in a heating operation, the flap is set
to position (3) in the following chart. If selected in a cooling or dry
operation, the flap is set at position (7) in the following chart.
: The airflow direction can be set manually. (six positions)
: The flap moves up and down automatically.
NOTE When you press the FLAP button, the air flow direction will be changed
one by one as follows.
FAN SPEED selector button : The air conditioner automatically decides the fan speeds.
: High fan speed
: Medium fan speed
: Low fan speed
ACL button (ALL CLEAR) Puts the remote control unit into pre-operation status. Always press this
button after replacing the batteries.
ONTIME/OFFTIME
setting buttons
Swing
8

ADDRESS switch •Change the address switch to prevent mixing of signals from remote
control units when two Sanyo air conditioners are installed next to each
other. Normally, the address switch is set to A. When switching the
adress, take the steps listed below. Contact your dealer where you made
the purchase if 3 or more Sanyo air conditioners are to be operated.
1Break off the address switching tabs on the remote control unit, and
set the address switch to B.
2Insert batteries into the remote control unit, press the ACL button,
and attach the cover.
3Open the intake grille of the indoor unit, and set the operation knob
to the DEMO position.
4Press the ON/OFF operation button on the remote control unit, and
check that a receiving tone (beep) is heard from the indoor unit.
5Set the operation selector to the ON position, and close the intake
grille.
6Operate the remote control unit, and check that a receiving tone
(beep) is heard from the indoor unit.
•Normally, the tabs on the remote control unit should not be bent.
A/C SENSOR button When you press this button (use a small-tipped object such as a
ballpoint pen), the
mark will appear at the display. And the room
temperature is detected by the sensor which is built into the indoor unit
and the air conditioner is controlled accordingly.
NOTE If the remote control is located near a heat source, such as a space heater
or in direct sunlight, press the A/C SENSOR button to switch to the sensor
on the indoor unit.
NOTE The remote control unit sends the temperature signal to the air conditioner regularly at five minute
intervals. If the signal from the remote control unit stops for more than ten minutes due to the loss of
the remote control unit or other trouble, the air conditioner will switch to the temperature sensor which
is built into the indoor unit and control the room temperature. In these cases, the temperature around
the remote control unit may differ from the temperature detected at the air conditioner’s position.
Remote Control Unit (continued)
9

ACL button
Using the Remote Control Unit
How to Install Batteries
1. Slide the cover in the direction indicated by the arrow
and remove it.
2. Install two AAA alkaline batteries. Make sure the
batteries point in the direction marked in the battery
compartment.
3. Use a thin object such as the tip of a pen to press the
ACL button.
NOTE •The batteries last about six months, depending on how much you
use the remote control unit. Replace the batteries when the remote
control unit’s display fails to indicate, or when the remote control
cannot be used to change the air conditioner’s settings.
•Use two fresh leak-proof type-AAA alkaline batteries.
•In replacing batteries, follow the instructions as mentioned in the
sub-section “How to Install Batteries”.
•If you do not use the remote control unit more than 1 month, take
out the batteries.
How to Use the Remote
Control Unit When using the remote control unit, always point the unit’s transmitter
head directly at the air conditioner’s receiver.
Remote control
unit
(Transmitter head)
Cover
10
Receiver
Air conditioner
(Indoor unit)

STEP 1 Press the MODE selector button and select (AUTO).
STEP 2 Press the ON/OFF button and switch the air conditioner ON.
STEP 3 Press the temperature setting buttons (TEMP.).
The air conditioner starts operating after automatically selecting the type of operation
—whether heating, drying (dehumidifying) or cooling—that suits the conditions in the
room, and automatically adjusting the temperature, fan speed and airflow direction.
Each time one of the temperature setting buttons (TEMP.) is pressed, the temperature is
changed by 1 °C.
The temperature can be changed from +4 °C (higher) to
–4 °C (lower) from the standard temperature setting.
(The upper limit during cooling is 30 °C.)
Operation with the Remote Control
Unit
1. Automatic Operation
Standard temperature settings during automatic operation
Type of operation Standard temperature setting
Heating 24 °C
Drying 20 °C to 26 °C range
(The exact temperature depends on the prevailing temperature
when the unit starts operating.)
Cooling 27 °C
STEP 2
STEP 3
STEP 1
11

As shown in the figure below, the automatic selection of the operating modes
is determined by the indoor temperature and outside air temperature.
•When multiple indoor units are used and units in other rooms are already operating,
they will be set to the same type of operation as the operating indoor units.
•The temperature, airflow direction and fan speed are set automatically but the airflow
direction and fan speed can be changed to suit your individual preference. It will take
a few seconds for the fan speed to be switched.
2. Manual Operation
NOTE Check that the circuit breaker on the power panel is turned on and that
the operation selector of the indoor unit is in the ON position.
STEP 1
STEP 5
STEP 2
STEP 3
STEP 4
Indoor temperature
Outside air
temperature
Cooling
operation
Drying operation
Temperature setting
(standard)
Approx.
15°C
Heating operation
Approx.
22°C
Approx.
27°C
Approx.
22°C
Approx.
20°C
Approx.
18°C
27°C
20°C to 26°C
24°C
Operation with the Remote Control Unit (continued)
12

Operation with the Remote Control Unit (continued)
•After the cooling or drying operation has stopped, the indoor fan runs
for about 30 seconds to dry out the inside of the air conditioner. (The
operating lamps remain off.) The flap closes after the fan has
stopped.
•If the room temperature rises above the temperature setting during a
drying operation, the unit performs similar operation to cooling, and
when the room temperature approaches the temperature setting, it
performs the humidity-priority drying operation.
•The drying operation does not serve to raise the room temperature.
(When the outside air temperature is low or when the heat quantity
inside the room is low, the room temperature will not rise.)
•A change made to the temperature setting remains stored in the
memory even after operation has stopped.
•If the temperature setting is lowered during a drying operation so that
the unit has switched to a cooling operation, the outdoor unit shuts
down for 3 minutes. (This happens only when one indoor unit is
used.)
•When the unit is running in the drying operation mode while the
temperature setting is higher than the room temperature, the
humidity may not be reduced. In a case like this, select a temperature
setting which is lower than the current room temperature, and
perform the drying operation.
NOTE This appliance has a built-in 3-minute time delay circuit to ensure reliable
operation. When the operation button is pressed, the compressor will
start running within three minutes. In the event of power failure, the unit
will stop.
STEP 1 Press the MODE selector button and select the desired
mode.
For heating operation →
For dehumidifying operation →
For cooling operation →
STEP 2 To start the air conditioner, press the ON/OFF operation
button.
STEP 3 Press the temperature setting buttons to change the
temperature setting to the desired temperature.
Adjustable temperature range:
30 °C max.
16 °C min.
NOTE •Room temperature control works to ensure that the
temperature stabilizes within a range of ±2 °C of the
temperature setting. For this reason, the value displayed
on the remote control unit may differ from the actual
temperature setting. Before the temperature stabilizes,
this difference may exceed the ±2 °C range.
•The operating lamp of the indoor unit lights in one of the
colors shown below.
STEP 4 Set the FAN SPEED selector button to the setting you want.
(Refer to “Adjusting the Airflow Direction”on page 23.)
STEP 5 Press the FLAP button and set the airflow direction as
desired.
(Refer to “Adjusting the Airflow Direction”on page 22.)
To stop the air conditioner, press the ON/OFF operation button again.
Heating Red
Operating lamp Drying Orange
Cooling Green
13

3.Adjusting the Fan Speed
A.Automatic Simply set the FAN SPEED selector button to the position.
B. Manual If you want to adjust fan speed manually during operation, just set the
FAN SPEED selector button as desired. [ , , or ]
4. ECONOMY Mode
The ECONOMY Mode is used for saving energy.
Press the ECONOMY button while the air conditioner is operating.
The mark appears in the display.
To cancel the ECONOMY function, press the ECONOMY button again.
Operation with the Remote Control Unit (continued)
14

When the ECONOMY mode is selected, the air conditioner
automatically raises the temperature setting 1 °C when 60 minutes
have passed after the selection was made. This enables you to save
energy without sacrificing comfort. This function is convenient when
gentle cooling is needed.
When the ECONOMY mode is selected, the air conditioner
automatically lowers the temperature setting 3 °C when 60 minutes
have passed after the selection was made, and then another 4 °C after
another 2 hours have passed, regardless of the indoor temperature
when ECONOMY was selected. This enables you to save energy
without sacrificing comfort. This function is convenient when gentle
heating is needed.
NOTE The temperature does not shift in theAuto mode during ECONOMY
mode.
B. In Heating Mode:
( )
Operation with the Remote Control Unit (continued)
A. In Cooling and DRY
Mode: ( and )
Setting temperature Room temperature
Time
1 °C
Setting temperature Room temperature
Time
3 °C
4 °C
15

Special Remarks
Power failure
during operation • In the event of power failure, the unit will stop.Though the power is
resumed, the unit will not restart automatically.
Press the ON/OFF operation button and restart the unit again.
Clicking Sound
Clicking sound is heard
from the air conditioner • In heating or cooling operation, any plastic parts may expand or
shrink due to a sudden temperature change. In this event, a clicking
sound may occur. This is normal, and the sound will soon disappear.
Remote Control Unit • The remote control unit sends the setting condition to the air
conditioner regularly at five minute intervals.
16

1. How to set the present
time
Setting theTimer
(Example)To set to 10:30 pm.
Operation
1. Press the CLOCK button three
times.
2. Press the Advance, Return ( , )
button until PM 10:30 is
displayed.
3. Press the CLOCK button again.
Indication
The time indication alone blinks.
The time can be set in 1-minute
increments. Holding down the
button advances the time rapidly
in 10-minute increments.
This completes the setting of the
current time.
2. How to set the OFF time (Example)To stop the air conditioner at 11:00 am.
1. Press the OFF TIME setting
button once.
2. Press the Advance, Return ( , )
button until AM 11:00 is
displayed.
3. Press the SET button.
The timer indication blinks
and present OFF time is shown.
The time can be set in 10-minute
increments. Holding down the
button advances the time rapidly
in 10-minute increments.
The timer indication stops
blinking and the present time is
displayed.
17

3. How to set the ON time (Example)To start operation at 7:10 am.
Setting theTimer (continued)
NOTE •The timer can be programmed while the unit is operating or while it is
stopped.
•A timer program is canceled after the timer has operated. So the
timer should be set every time programming operation is to be
performed.
•The airflow direction, fan speed and temperature setting can be
changed after a timer program has been set even when the unit is
stopped. Even when operation is stopped during an ON timer
program, the unit will start operating when the set time is reached
provided that the program is not canceled.
•As a safeguard to prevent you forgetting to turn off the air
conditioner, the unit’s operation will be stopped if the remote control
unit has not been operated for at least 25 hours after the ON timer
starts.
•When the ON timer is used, the temperature setting may not be
reached by the set time depending on the size and conditions in the
room.
To cancel a timer program •Press the CANCEL button.
•When either an ON or OFF timer is to be canceled, press the button
corresponding to the timer whose program is to be canceled, and
then press the CANCEL button.
Operation
1. Press the ONTIME setting
button once.
2. Press the Advance, Return ( , )
button until AM 7:10 is
displayed.
3. Press the SET button.
Indication
The timer indication blinks
and present ON time is shown.
The time can be set in 10-minute
increments. Holding down the
button advances the time rapidly
in 10-minute increments.
The timer indication stops
blinking and the present time is
displayed.
NOTE ON timer (comfort programming)
The unit starts operating automatically to attempt to change the
temperature to the desired level by the set time. (The unit operates at the
low fan speed from up to 60 minutes prior to the set time.)
OFF timer
The unit stops operating at the set time.
18

(Example)To start operation at 7:10 am. and stop the air conditioner at
11:00 am.
Setting theTimer (continued)
4. How to set DAILY ON/
OFF REPEAT timer
7:10 am. 11:00 am.
ON OFF
Operation
1. Set the timer ON/OFF times as
shown in 2-1, 2, 3 and 3-1, 2, 3.
Indication
The present time 10:30 pm. and
are displayed.
OFF
time
Present
time
ON
time
Daily
ON/OFF
NOTE •The ON/OFF combination timer uses the current time as the
reference, and it is activated starting from whichever set time
comes first.
•With the ON/OFF combination timer, the settings are repeated
every day.
•You can check the timer ON/OFF times after you have set them
by pressing the ONTIME and OFF TIME setting buttons.
19

Setting the 1-Hour OFFTimer
1. 1-Hour OFFTimer This function causes the unit to operate for one hour and then stop,
regardless of whether the unit is on or off when this button is pressed.
The indicator in the display indicates that this function is operating.
Setting the 1-Hour OFFTimer:
Regardless of whether the unit is operating or stopped, press the 1 HR.
TIMER button.
appears in the display.
Cancelling the 1-Hour OFFTimer:
Press the ON/OFF operation button to turn the unit off, wait for the unit to
stop operating, and then press the ON/OFF operation button again.The 1-
HourTimer function is now cancelled and the unit operates normally.
NOTE If, while the 1-HourTimer function is operating, the 1 HR.TIMER button is
pressed once to cancel the function and then again, the unit continues to
operate for one hour from that point in time and then stops.
•The 1 Hour OFFTimer setting is given priority over the DAILY ON/OFF
REPEAT setting.
•It is not possible to use the OFFTimer and 1-Hour OFFTimer together.
Whichever function is set last takes precedence. If the 1 HR.TIMER
button is pressed while theTIMER OFF function operates, the OFF
Timer is cancelled and the unit will stop operating one hour later.
2. Operation together
with the DAILY ON/
OFF REPEAT Timer
Setting the HIGH POWER Operation
1. HIGH POWER Operation This function causes the unit to operate at HIGH POWER in the present
mode of operation for 15 minutes when this button is pressed while the
unit is on.The indicator on the display indicates that this function is
operating.
Canceling the HIGH POWER operation
HIGH POWER operation is canceled by pressing the ON/OFF operation
button, HIGH POWER button (when it is pressed again) or MODE selector
button, when the OFF time or HIGH POWER time setting is reached or
when the ECONOMY mode operation is performed. The 15-minute timer
is also cleared.
It is not possible to use the HIGH POWER operation and ECONOMY mode
operation together. Whichever function is set last takes precedence.
If the HIGH POWER button is pressed while the ECONOMY mode is
operating, the ECONOMY mode operation is cancelled and the unit will
change to the HIGH POWER operation.
2. Operation together with
the ECONOMY mode
20
