Tecnoware ERA LED 0.85 User manual

Uninterruptible Power Supply
ERA LED 0.65
ERA LED 0.85
ERA LED 1.1
User’s manual

UPS ERA LED 0.65 – 0.85 – 1.1 1 User’s manual
ndex
Safety Warnings ................................................................................ 2
1 ntroduction ................................................................................. 3
2 General Characteristics ................................................................... 4
3 Receipt and site selection ................................................................ 4
4 EXTERNAL DESCR PT ON .................................................................. 5
4.1 Front Panel ............................................................................. 5
4.2 Rear Si e ................................................................................ 6
5 Electrical nstallation and First Start Up ............................................... 7
6 Functioning ................................................................................. 8
6.1 Normal Mo e ........................................................................... 8
6.2 Battery Mo e ........................................................................... 8
6.3 Low Battery an Automatic Restart ................................................. 8
6.4 Loa Control ............................................................................ 9
6.5 Fault Con ition ........................................................................ 9
7 Communication nterface ................................................................. 9
8 Technical Characteristics ................................................................ 10
9 Maintenance ............................................................................... 11
9.1 UPS Cleaning ......................................................................... 11
9.2 Battery ................................................................................ 11
9.3 Battery Replacement ............................................................... 11
9.4 Operator Safety ...................................................................... 12
10 Troubleshooting ........................................................................... 12
Conformity to the European Directives ................................................... 14
Product Disposal ............................................................................... 14
Lead Batteries ................................................................................. 14
© Copyright 2012 TECNOWARE s.r.l. All rights reserve .
All tra emarks are property of their respective owners.
TECNOWARE s.r.l.
Via Montetrini, 2E – Loc. Molino el Piano – 50065- Pontassieve (FI) – Italy
www.tecnoware.com
E ition: May 2012 – version: 1.0
No part of this manual may be repro uce , even partially, without the
authorisation of TECNOWARE s.r.l.
TECNOWARE s.r.l. reserves the right to change specifications at any time
an without notice.

User’s manual 2 UPS ERA LED 0.65 – 0.85 – 1.1
Safety Warnings
Read this manual carefully and completely before installing and using the TECNOWARE ERA LED
Uninterruptible Power Supply, which, from here after, will also be referred to as UPS.
This manual should be kept close to the UPS and read before the UPS is installed and used.
The UPS must be used only by properly trained personnel. To ensure correct and safe
operations, it is necessary that operators and maintenance personnel observe the general
safety Standards as well as the specific instructions included in this manual.
Risk of electric shock: do not remove the cover. The UPS contains internal parts, which are at a
high Voltage and are potentially dangerous, capable of causing injury or death by electric
shock.
There are no internal parts in the UPS, which are user serviceable. Any repair or maintenance
work must be performed exclusively by qualified technical personnel authorized by
TECNOWARE. TECNOWARE declines any responsibility if this warning is disregarded.
Warning to the technical personnel authorized for Service: since internal components are
connected to the batteries, they will remain powered, and therefore dangerous, even after the
UPS has been disconnected from AC power mains. Before any repair or maintenance work,
disconnect the batteries, by removing the positive cable (red colour) from the positive pole of
the battery.
t is compulsory to ground the UPS according to Safety Standards. The AC mains power supply
socket used to power the UPS must have an earth connection.
n the event of AC main power supply failure (when the UPS works in Battery mode), do not
unplug the power supply cable to the UPS to ensure earth continuity to the connected loads.
Since the AC mains power supply cable acts as a separation device, the AC mains power socket
used to supply the UPS and/or the rear side of the UPS must be accessible to easily disconnect
the cable in case of dangerous conditions.
Risk of electric shock at the Output lines when the UPS is ON.
Risk of electric shock at the Output lines while the unit is connected to the AC utility line.
Do not obstruct ventilation slots or holes and do not rest any object on top of the UPS.
Do not insert objects or pour liquids in the ventilation holes.
nstall the UPS indoors, in a protected, clean and moisture-free environment.
Do not expose to the direct sun light.
Do not keep liquids, flammable gases or corrosive substances near the UPS.

UPS ERA LED 0.65 – 0.85 – 1.1 3 User’s manual
1ntroduction
ERA LED is a Line Interactive UPS (Uninterruptible Power Supply) specifically esigne to protect your computer
from any type of irregularities in the AC line (such as black-outs, un er or over voltages, micro-interruptions),
which often cause amage to your Har ware an Software.
Un er normal AC line con ition, ERA LED performs output voltage regulation an filters frequently occurring
electrical isturbances (such as transients, spikes, interferences, etc.), thus protecting all evices connecte to
the outlets, an recharging the batteries in an i eal way. In case of anomaly to the AC line, the UPS continues
fee ing the protecte equipment.
ERA LED is equippe with an USB interface which can be use to notify a power failure or a low battery con ition
irectly to a computer: this makes it possible to automatically save your ata uring an exten e black-out with
the most wi esprea operating systems (Win ows, Mac OS X, Linux, etc.).
Read this manual carefully before using the ERA LED; it includes important safety
warnings and useful advices for correct use and installation.
This manual is a guide that enables you to correctly install and use your ERA LED. This
manual includes important SAFETY instructions for the operator, for the UPS correct
installation, and gives useful advice on the product and battery maintenance. For any
type of problem, please refer to this manual before calling the customer service.
ERA LED is constantly being evelope an improve : consequently, your unit may iffer somewhat from the
escription containe in this manual.
This manual inclu es the following mo els:
•ERA LED 0.65 (650 VA)
•ERA LED 0.85 (850 VA)
•ERA LED 1.1 (1100 VA)
In this manual ERA LED will simply be referre to as UPS.

User’s manual 4 UPS ERA LED 0.65 – 0.85 – 1.1
2General Characteristics
ERA LED has all the a vance features, which guarantee maximum reliability an safety:
•All functions are controlle by a microprocessor, giving full guarantee of high reliability.
•Output Voltage regulation through AVR (Automatic Voltage Regulation).
•Overloa protection both in normal mo e an in battery mo e.
•High performance battery charger, which exten s the battery me ium life ensuring an optimal recharge.
•Start up even if the electrical network is not available.
•Automatic restart after an automatic shut own ue to a low battery con ition once the AC utility power
returns.
•A apts automatically to 50 or 60 Hz input frequency.
•Acoustic signals of various kin s in icating functioning mo es an alarm/fault con ition.
•Communication with the computer through USB interface.
•High efficiency
•Maximum reliability
•Smart esign an easy to use
3Receipt and site selection
Carefully remove the UPS from its packaging, an carry out a meticulous inspection. We recommen keeping the
original packaging in a secure place, in case you nee to sen the UPS for maintenance purposes. In case of
transport amage, notify the carrier an ealer imme iately.
We recommen paying attention to the below points in or er to choose a correct placement for your UPS:
•The UPS is esigne to operate in a protecte environment (e.g. offices). We therefore recommen
installing it in a place with very little or no humi ity, ust or smoke.
•In all circumstances, see the “Technical Characteristics” chapter for environmental specifications an
check that the selecte area meets these specifications.
•During normal operation the UPS ischarges a minimal amount of heat. So it is necessary to leave at least
20 cm of unobstructe space all aroun the UPS in or er to keep it properly ventilate .
•Do not obstruct ventilation holes.
•Do not insert objects or pour liqui s in the ventilation holes.
•Do not rest any object on top of the UPS.
•Do not keep liqui s, flammable gases or corrosive substances near the unit.
•Install the UPS on a properly tile floor. Avoi the installation on a floor that is not tile flat.

UPS ERA LED 0.65 – 0.85 – 1.1 5 User’s manual
4EXTERNAL DESCR PT ON
4.1 Front Panel
The front panel informs the user about operating status, alarm con itions an measurements. Front panel shown
below consists of two parts:
1. The ON/OFF button: enables the user to turn ON/OFF the UPS.
2. The L NE/BATTERY le : this le (blue color) is always on uring the functioning in Normal Mo e, it flashes
one time every 4 secon s in Battery mo e an it flashes one time every secon in Low Battery con ition.
Figure 1 – Front panel
2
1

User’s manual 6 UPS ERA LED 0.65 – 0.85 – 1.1
4.2 Rear Side
5
Figure 2 – Rear Side
1. Grounded AC nput power socket: IEC C14 type; to connect the UPS to the AC utility line.
2. nput fuse: electrical specification: max current 5 A, voltage 250 V.
3. Grounded UPS Output receptacles: IEC C13 type, black colour, to supply critical loa s.
4. Computer nterface (USB connector): it is the communication USB port.
n case of anomaly to the AC line (black-out), the UPS Output receptacles (black colour,
#3) continue supplying the correct power to all connected equipment.
1
3
2
4

UPS ERA LED 0.65 – 0.85 – 1.1 7 User’s manual
5Electrical nstallation and First Start Up
We a vise you to follow the steps below explaine for greater safety:
1. Switch off all the evices (Personal Computer or other electronic evices) that nee to be supplie by the
UPS.
2. Connect the UPS Input socket to the AC line outlet through the Personal Computer supplying cable. t is
mandatory to ground the AC line outlet according to the Safety Standards. Carefully check the groun ing,
make sure that the utility power is available, an that its range falls within the UPS specifications (refer to
the “Specifications” chapter).
3. Press the ON/OFF button on the front panel: the UPS emits a brief acoustic signal, turns the le isplay on,
an performs a functioning SELF-TEST. After some secon s the UPS starts to work in Normal mode. Leave
the UPS in Normal mo e for at least 4 hours in or er to completely recharge the batteries.
4. Switch the UPS off (by pressing again the ON/OFF button).
5. Connect the evices to be supplie to the UPS outputs, by using only the inclu e cables. Be sure all the
evices have the main switch in ON position.
6. Turn on the UPS again. Check that it starts working correctly an it oesn’t signal any sort of anomaly.
Moreover be sure that all the evices connecte to the UPS outputs are working correctly.
7. Simulate a black-out by removing the AC Input line. The UPS starts working in Battery mode: the UPS emits a
brief acoustic signal every 10 secon s.
8. Be sure that all the evices connecte to the UPS outputs are working correctly an the UPS oesn’t signal
any sort of anomaly.
9. Restore the AC Input line: after few secon s the UPS turns back in Normal mo e.
Before using ERA LED normally, leave it in Normal mo e in or er to charge the batteries completely as specifie at
point 3. The batteries reach the 90% of their capacity after about 4 hours of recharge.
t is compulsory to ground/earth the UPS according to the Safety Standards.
Risk of electric shock at the Output lines if the UPS is ON, even when the UPS is not
connected to AC utility line.
Risk of electric shock at the Output lines while the unit is connected to the AC utility
line.
Risk of electric shock: do not remove the cover. The UPS contains internal parts, which
are at a high Voltage and are potentially dangerous, capable of causing injury or death
by electric shock.
There are no internal parts in the UPS that are user serviceable. Any repair or
maintenance work must be performed exclusively by qualified technical personnel
authorized by TECNOWARE. TECNOWARE declines any responsibility if this warning is
disregarded.
Disregard for these warnings may lead to a risk of electric shock to operators.

User’s manual 8 UPS ERA LED 0.65 – 0.85 – 1.1
6Functioning
6.1 Normal Mode
The UPS typically works in Normal mode: Input mains power is available an its amplitu e is within specifications.
In Normal mo e the L NE/BATTERY le is always on.
During Normal mo e, the UPS recharges the batteries an keeps them in an optimal charging voltage.
6.2 Battery Mode
The UPS automatically runs in Battery mode if the AC Input Line voltage amplitu e gets out of security limits (in
case of a black-out or over-voltage/low-voltage): in this case, the UPS supplies the require output power by its
internal battery an by the Inverter block.
The UPS automatically returns in Normal mo e a few secon s after the AC Input Line is recovere .
In Battery mo e the UPS emits an acoustic alarm signal every 10 secon s an simultaneously the L NE/BATTERY
le flashes.
6.3 Low Battery and Automatic Restart
In Battery mo e, ERA LED in icates the Low Battery con ition whenever the battery reaches a charge level
allowing connecte evices to operate for approximately one more minute.
During Low Battery con ition the UPS emits an acoustic alarm signal every secon an simultaneously the
L NE/BATTERY le flashes.
If AC Input oes not come back on within few minutes, the UPS shuts-down automatically thus preventing the
batteries from ischarging excessively; the UPS stops supplying Output power, eactivates control panel in ication
an goes to a waiting state. Once AC Input comes back on, the UPS restarts automatically an after some secon s
it goes back to work in Normal mo e.
After a complete ischarge, the UPS nee s 4 hours to recharge completely the batteries. The UPS recharges
batteries automatically if it works in Normal mo e or if it is off an connecte to the AC Input Line.

UPS ERA LED 0.65 – 0.85 – 1.1 9 User’s manual
6.4 Load Control
When the Output loa is higher than nominal value the UPS warns of Overload condition by emitting a continuous
acoustic alarm.
The UPS warns of an Overloa less than 110% by acoustic alarm.
An Overloa between 110% an 130% is accepte for about 30 secon s an after UPS switches automatically off.
The UPS switches imme iately off if the Overloa is higher than than 130%.
Once the requeste power is back within range, the UPS switches automatically to the Normal mo e.
Make sure that the UPS never indicates Overload condition.
Do not connect a load greater than rated value to the UPS (see POWER specifications in
the chapter “Technical Characteristics”), as this may damage the unit. n this case the
warranty is void.
6.5 Fault Condition
The UPS in icates the Fault condition by emitting a continuous acoustic alarm.
During Fault con ition, the UPS oesn’t supply Output power an so all the supplie evices are switche off.
7Communication nterface
The UPS is factory-equippe with USB Communication nterface. On the UPS rear si e there is the connector of
the USB Interface.
The USB signals are all isolated through photo-couplers from the dangerous voltages that are present inside
the UPS.
Connecting to the Web site www.tecnoware.com, it is possible to ownloa , free of charge, the up ate UPS
management Software ViewPower, compatible with the most popular Operative Systems.

User’s manual 10 UPS ERA LED 0.65 – 0.85 – 1.1
8Technical Characteristics
UPS ERA LED Model 0.65 0.85 1.1
Power 650 VA (455 W) 850 VA (595 W) 1100 VA (770 W)
Recommen e for:
Personal Computer with 450W
PSU (350W real power)
+ LCD Monitor (60W)
Personal Computer with 550W
PSU (450W real power)
+ LCD Monitor (60W)
Personal Computer with 600W
PSU (500W real power)
+ LCD Monitor (60W)
Technology Line Interactive with Stabilizer
Nominal Input Voltage Single-phase 230 Vac
Input Voltage Range +20% / -25%
Input/Output Frequency 50/60 Hz (automatic selection)
Input Frequency Range +/- 5%
Nominal Output Voltage Single-phase 230 Vac
Output Voltage Regulation
(Normal mo e) Through AVR (Automatic Voltage Regulation)
Output Voltage Regulation
(Battery mo e) +/- 5%
Output Inverter Waveform Mo ifie Sinewave
Accepte Overloa < 130%
Certifications
CE
Stan ar s: CEI EN 62040-1: 2009 (Low Voltage Directive) –
CEI EN 62040-2: 2006 (EMC Directive)
Efficiency 92%
Battery Type Lea aci , seale , free maintenance
Number of batteries 1
Nominal Battery Voltage 12 V c
Battery Specifications 12 V c – 4,5 Ah – 6 cells 12 V c – 7,2 Ah – 6 cells 12 V c – 9 Ah – 6 cells
Backup Time (typical) 10 min
Battery Charge Time (typical) 4 hours
Au ible Noise (at 1 meter) < 40 BA
Cooling Natural
Environmental Operative Specification Temperature: 0-40 °C - Humi ity 0-95% (without con ensation)
Altitu e: max 3.000 mt
Computer Interface 1 USB port
UPS Management Software Software ViewPower,
ownloa able free of charge from www.tecnoware.com
Output sockets 4 UPS Output sockets (IEC type)
Dimension (W x H x D) 10,1 x 14,2 x 27,9 cm
Net Weight 3.7 Kg 3.7 Kg 3.7 Kg
Technical ata may change without prior notice

UPS ERA LED 0.65 – 0.85 – 1.1 11 User’s manual
9Maintenance
9.1 UPS Cleaning
Before starting any cleaning operation, be sure that:
1. The AC nput Voltage for the UPS has been removed.
2. The UPS is OFF.
Use only a cloth ampene with water to clean the unit.
If UPS works in an environmental unusually usty or irty, remove the irty from the ventilation holes.
Before restarting the UPS be sure it is completely ry. If any liqui gets insi e the UPS, o not start the unit an
contact Technical Service imme iately.
9.2 Battery
If the UPS is NOT going to be use for a long perio of time, ensure that the batteries are left fully charge .
If the UPS has not been use for more than three months, go through the “First Start Up” proce ure escribe in
the chapter 5 before using it again.
Please keep in min that the batteries must be recharge at least once a month. Take in min that batteries are
recharge automatically if the UPS works in Normal mo e or if the UPS is off an connecte to the AC Input Line.
Battery life strongly epen s on the ambient temperature. There are also other factors like the number of charge-
ischarge cycles, the ischarge epth, humi ity an altitu e.
The recommen e environmental specifications for a correct use of batteries are liste in the “Technical
Specifications” section.
9.3 Battery Replacement
Battery replacement must be performe exclusively by qualifie an authorize technical personnel. We a vise
you to follow the steps below explaine for greater safety:
1. Turn the UPS off an isconnect the AC Input Line for the UPS.
2. Unscrew the 4 screws on the UPS bottom si e. Remove the case cover an so you can access to the battery
location.
3. Disconnect the battery wires an gently extract the battery from the case.
4. The new battery must be exactly the same type as the original one.
5. Put insi e the new battery an connect it as the original one.
6. Reassemble the case cover.

User’s manual 12 UPS ERA LED 0.65 – 0.85 – 1.1
Battery replacement must be performed exclusively by qualified technical personnel
authorized by TECNOWARE. TECNOWARE declines any responsibility if this warning is
disregarded.
When replacing batteries, replace with the same type and number.
CAUT ON: A battery can present a risk of electrical shock and high short circuit current.
The following precautions should be observed when working on batteries:
a) Remove watches, rings or other metal objects;
b) Use tools with insulated handles;
c) Wear rubber gloves and boots;
d) Do not lay tools or metal parts on top of batteries;
e) Disconnect the charging source prior to connecting or disconnecting battery
terminals;
f) Determine if battery is inadvertently grounded. f inadvertently grounded, remove
source from ground.
CAUT ON: Do not dispose of batteries in a fire. The batteries may explode.
CAUT ON: Do not open or mutilate batteries. Released electrolyte is harmful to the skin
and eyes. t may be toxic.
9.4 Operator Safety
Whenever the UPS is not respon ing anymore to original characteristics, the UPS must be ma e non-operative an
every usage not authorise must be avoi e . After it will be necessary to refer to qualifie technical personnel.
Original safety characteristics might not be if, for example, the UPS has visible amage or irregular operation.
10 Troubleshooting
Alarms an problems you may encounter uring operating the UPS are given in the table below. Apply
the suggestions correspon ing to each anomaly as escribe into the table.
If your anomaly is exclu e or the suggeste actions o not solve your problem, consult the Technical Service.
Please give the following information to the Technical Service:
Mo el an serial number of the UPS, which can be foun on the nameplate on the rear of the UPS.
Description of anomaly.

UPS ERA LED 0.65 – 0.85 – 1.1 13 User’s manual
Risk of electric shock: do not remove the cover. The UPS contains internal parts that are
at a high Voltage and are potentially dangerous, capable of causing injury or death by
electric shock.
There are no internal parts in the UPS that are user serviceable. Any repair or
maintenance work must be performed exclusively by qualified technical personnel
authorized by TECNOWARE.
TECNOWARE declines any responsibility if this warning is disregarded.
Warning to the technical personnel authorized for service: since internal components
are connected to the batteries, they will remain powered, and therefore dangerous,
even after the UPS has been disconnected from AC power mains. Before any repair or
maintenance work, disconnect the batteries, by removing the positive cable (red colour)
from the positive pole of the battery.
ANOMALY POSS BLE CAUSE ACT ON TO SOLVE
The UPS oes not
turn on
ON/OFF button Press the ON/OFF button an check that is pushe .
Batteries are flat Recharge the batteries for at least 4 hours.
Electronic boar failure Refer to Technical Service.
The UPS always
function on
Battery mo e
Input mains power cable
is isconnecte .
Check the input mains power cable.
Check the presence of the electrical mains.
Input mains fuse is burnt
Replace the fuse with another of the same type.
Black-out con itions /
surge/ Over-Voltage or
Low-Voltage
Wait until the AC Input Line returns to normal con itions.
Electronic boar failure Refer to Technical Service.
Battery Autonomy
is too short
Battery is not fully
charge . Recharge the battery for at least 6 hours.
Electronic boar failure Refer to Technical Service.
“OVERLOAD” alarm
“OVERLOAD” con ition Disconnect all evices that cause the overloa con ition.
“FAULT” alarm “FAULT” con ition
Check if UPS is in OVERLOAD con ition.
Refer to Technical Service.
The UPS oes not
communicate with
the Computer
The UPS Management
Software sen s a
communication error
Check that the USB (or RS232) cable is correctly connecte
between the UPS an the Computer.
The Software is not
correctly installe
Install correctly the specific Software for your Computer’s
Operative System.
f the described anomalies should continue despite the advised troubleshooting, or should they
manifest in any other form, please contact:
TECNOWARE SERV CE
www.tecnoware.com

User’s manual 14 UPS ERA LED 0.65 – 0.85 – 1.1
Conformity to the European Directives
TECNOWARE S.r.l. confirms that ERA LED models comply with the req irements set o t in: the Low Voltage Directive (Safety)
2006/95/EC and following amendments, the EMC (Electro-Magnetic Compatibility) Directive 2004/108/EC and following
amendments.
The following standards were applied:
Low Voltage Directive (Safety): CEI EN 62040-1: 2009
EMC Directive (Electro-Magnetic Compatibility): CEI EN 62040-2: 2006
Product Disposal
UPS ERA LED cannot be disposed as an rban waste, b t m st be treated as a separate waste. Any
violation is indictable with financial sanctions as per in force reg lations.
An incorrect waste disposal or an improper se of the same or of any parts can be damaging for the
environment and for h man health.
A correct waste disposal of prod cts having the d stbin symbol marked by a cross help to avoid
negative conseq ences to the environment and to h man health.
Lead Batteries
ERA LED models contain lead acid, sealed, maintenance free batteries.
The batteries cannot be disposed as an rban waste, b t m st be treated in conformity with
2006/66/CE E ropean Directive; any violation is indictable with financial sanctions as established into
2006/66/CE E ropean Directive.

TECNOWARE s.r.l.
www.tecnoware.com
