Specifications
This chapter contains specifications for the MSO4000B and the DPO4000B series
oscilloscopes. All specifications are guaranteed unless noted as "typical."
Typical specifications are provided for your convenience but are not guaranteed.
Specifications that are marked with the symbol are checked in Performance
Verification.
All specifications apply to all MSO4000B and DPO4000B models unless noted
otherwise. To meet specifications, two conditions must first be met:
The oscilloscope must have been operating continuously for twenty minutes
within the specified operating temperature range. (See Table 11 on page 24.)
You must perform the Signal Path Compensation (SPC) operation described
instep2oftheSelf Test before evaluating specifications. (See page 55, Self
Test.) If the operating temperature changes by more than 10 °C (18 °F), you
must perform the SPC operation again.
Model Bandwidth
Analog
Channels
Sample
Rate
(1 ch)
Sample
Rate
(2 ch)
Sample
Rate
(4 ch)
Record
Length
(1 ch)
Record
Length
(2 ch)
Record
Length
(4 ch)
MSO4000B models:
MSO4104B 1GHz 45GS/
s5GS/ s5GS/ s20M 20M 20M
MSO4104B-L 1GHz 45GS/
s5GS/ s2.5 GS/s 5M 5M 5M
MSO4102B 1GH
z25GS
/s 5GS /s –20M 20M –
MSO4102B-L 1GH
z25GS
/s 2.5 GS/s –5M 5M –
DPO4000B models:
DPO4104B 1G
Hz 45G
S/s 5G S/s 5G S/s 20M 20M 20M
DPO4104B-L 1GHz 45GS/s 5GS/s 2.5 GS/s 5M 5M 5M
DPO4102B 1 GHz 25GS/s 5GS/s –20M 20M –
DPO4102B-L 1 GHz 25 GS/s 2.5 GS/s –5M 5M –
DPO4054B 500 MHz 4 2.5 GS/s 2.5 GS/s 2.5 GS/s 20M 20M 20M
DPO4034B 350 MHz 4 2.5 GS/s 2.5 GS/s 2.5 GS/s 20M 20M 20M
DPO4014B 100 MHz 4 2.5 GS/s 2.5 GS/s 2.5 GS/s 20M 20M 20M
MSO4000B and DPO4000B Series Specifications and Performance Verification 1

Specifications
Analog Channel Input and Vertical Specifications
The following table shows the analog channel input and vertical specifications for
the MSO4000B Series and the DPO4000B Series oscilloscopes.
Table 1: Analog channel input and vertical specifications
Characteristic Description
Number of input
channels
MSO/DPO4XX4B, MSO/DPO4XX4B-L: Four analog channels, digitized simultaneously
MSO/DPO4102B, MSO/DPO4102B-L Two analog channels, digitized simultaneously
Input coupling DC or AC
Input resistance
selection
1Mor 50 
1M1M±1%
50 ±1%
MSO4104B,
DPO4104B,
MSO4104B-L
DPO4104B-L
MSO4102B-L
DPO4102B-L
MSO4102B
DPO4102B
VSWR 1.5:1 from DC to 1 GHz, typical
DPO4054B VSWR 1.5:1 from DC to 500 MHz, typical
DPO4034B VSWR 1.5:1 from DC to 350 MHz, typical
Input impedance,
DC coupled 50 
DPO4014B VSWR1.5:1 from DC to 100 MHz, typical
Input Capacitance,
1MDC coupled
13 pF ± 2 pF
1M300 VRMS at the BNC with peaks ±425 V
Installation Category II
For <100 mV/div, derate at 20 dB/decade above 100 kHz to 30 VRMS at 1 MHz,
10 dB/decade above 1 MHz
For 100 mV/div, derate at 20 dB/decade above 3 MHz to 30 VRMS at 30 MHz,
10 dB/decade above 30 MHz
Maximum peak input voltage at the BNC, ±425 V
Maximum input
voltage
50 5V
RMS with peaks ±20 V (Duty Factor 6.25%)
Overvoltage trip is intended to protect against overloads that might damage
termination resistors. A sufficiently large impulse might cause damage
regardless of the overvoltage protection circuitry because of the finite time
required to detect and respond.
DC Balance 0.1 div with the input DC 50 coupled and 50 terminated
0.2 div at 1 mV/div with the input DC 50 coupled and 50 terminated
0.2 div with the input DC 1 Mcoupled and 50 terminated
2 MSO4000B and DPO4000B Series Specifications and Performance Verification

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
Number of digitized
bits
8bits
Displayed vertically with 25 digitization levels (DL) per division, 10.24 divisions dynamic range.
"DL" is the abbreviation for "digitization level." A DL is the smallest voltage level change that can be
resolved by an 8-bit A-D Converter. This value is also known as the least significant bit (LSB).
1MΩ1 mV/div to 10 V/div in a 1-2-5 sequenceSensitivity range
(coarse) 50 Ω1 mV/div to 1 V/div in a 1-2-5 sequence
1 mV/div to 5 V/div <–50% to >+50% of selected setting
10 V/div <–50% to 0%
1MΩ
Allows continuous adjustment from 1 mV/div to 10 V/div
1 mV/div to 500 mV/div <–50% to >+50% of selected setting
1 V/div <–50% to 0%
Sensitivity range (fine)
50 Ω
Allows continuous adjustment from 1 mV/div to 1 V/div
Sensitivity resolution
(fine), typical
1% of current setting
DC gain accuracy For 50 Ω,1MΩ, TPP0500, and TPP1000 path:
±1.5%, derated at 0.100%/°C above 30 °C
±2.0%, derated at 0.100%/°C above 30 °C, 1 mV/Div setting
±3.0% variable gain, derated at 0.100%/°C above 30 °C
Offset range
Volts/div setting
1Minput 50 input
1 mV/div to 50 mV/div ±1 V ±1 V
50.5 mV/div to 99.5 mV/div ±0.5 V ±0.5 V
100 mV/div to 500 mV/div ±10 V ±10 V
505 mV/div to 995 mV/div ±5 V ±5 V
1 V/div to 5 V/div ±100 V ±5 V
5.05 V/div to 10 V/div ±50 V Not applicable
Offset ranges,
minimum
For 50 path, 1 V/div is the maximum vertical setting.
The input signal cannot exceed Max Input Voltage for the 50 input path. Refer to the Max Input Voltage
specification for more information.
Position range ±5 divisions
Offset accuracy ±[0.005 × | offset – position | + DC Balance]
Both the position and constant offset term must be converted to volts by multiplying by the appropriate
volts/div term.
MSO4000B and DPO4000B Series Specifications and Performance Verification 3

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
Number of Waveforms
for Average
Acquisition Mode
2to512waveforms
Default of 16 waveforms
Measurement type DC Accuracy (in Volts)
Average of 16 waveforms ±[DC Gain Accuracy × | reading – (offset -
position) | + offset accuracy + 0.1 division ]
Refer to DC Gain Accuracy for temperature
derating information.
Delta Volts between any two averages of 16
waveforms acquired with the same oscilloscope
setup and ambient conditions
±[DC gain accuracy × | reading | + 0.05 div]
Refer to DC Gain Accuracy for temperature
derating information.
DC voltage
measurement
accuracy
Average acquisition
mode
Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate
volts/div term.
The basic accuracy specification applies directly to any sample and to the following measurements: High,
Low, Max, Min, Mean, Cycle Mean, RMS, and Cycle RMS. The delta volt accuracy specification applies to
subtractive calculations involving two of these measurements.
The delta volts (difference voltage) accuracy specification applies directly to the following measurements:
Positive Overshoot, Negative Overshoot, Pk-Pk, and Amplitude.
Measurement type DC Accuracy (in volts)
Any sample ±[DC gain accuracy × | reading – (offset –
position) | + Offset Accuracy + 0.15 div + 0.6 mV]
Refer to DC Gain Accuracy for temperature
derating information.
Delta volts between any two samples acquired
with the same oscilloscope setup and ambient
conditions
±[DC gain accuracy × | reading | + 0.15 div +
1.2 mV]
Refer to DC Gain Accuracy for temperature
derating information.
DC voltage
measurement
accuracy
Sample acquisition
mode, typical
Offset, position, and the constant offset term must be converted to volts by multiplying by the appropriate
volts/div term.
Analog bandwidth
selections
DPO4104X, DPO4054B, DPO4034B: 20 MHz, 250 MHz, and Full
DPO4014B: 20 MHz and Full
4 MSO4000B and DPO4000B Series Specifications and Performance Verification

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
These limits are for ambient temperature of 30°C and the bandwidth selection set to FULL. Reduce the
upper bandwidth frequency by 1% for each °C above 30°C
Instrument Volts/Div setting Bandwidth
5 mV/div — 1 V/div DC to 1.00 GHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
1 mV/div — 1.99 mV/div DC to 175 MHz
5 mV/div — 1 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
DPO4054B
1 mV/div — 1.99 mV/div DC to 175 MHz
2 mV/div — 1 V/div DC to 350 MHzDPO4034B
1 mV/div — 1.99 mV/div DC to 175 MHz
Analog bandwidth,
50 , DC coupled
DPO4010B 1 mV/div — 1 V/div DC to 100 MHz
These limits are for ambient temperature of 30°C and the bandwidth selection set to FULL. Reduce the
upper bandwidth frequency by 1% for each °C above 30°C
Instrument Volts/Div setting Bandwidth
5 mV/div — 10 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
1 mV/div — 1.99 mV/div DC to 175 MHz
5 mV/div — 10 V/div DC to 500 MHz
2 mV/div — 4.98 mV/div DC to 350 MHz
MSO4054B,
DPO4054B
1 mV/div — 1.99 mV/div DC to 175 MHz
DPO4034B 5 mV/div — 10 V/div DC to 350 MHz
2 mV/div — 4.98 mV/div DC to 175 MHz
1 mV/div — 1.99 mV/div DC to 175 MHz
DPO4014B 1 mV/div — 1.99 mV/div DC to 100 MHz
Analog bandwidth,
1M, DC coupled,
typical
The DPO4104B, MSO4104B-L, DPO4104B-L, MSO4102B-L, DPO4102B-L, MSO4102B, and DPO4102B
models have separate 50 and 1 Manalog paths, so the 1 Mpath is not checked when the 50 path
is checked in the performance test procedure. All other models have only one analog path, so they are
fully tested with the 50 termination.
MSO4000B and DPO4000B Series Specifications and Performance Verification 5

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
These limits are for ambient temperature of 30°C and the bandwidth selection set to FULL. Reduce the
upper bandwidth frequency by 1% for each °C above 30°C
Instrument Volts/Div setting Bandwidth
50 mV/div — 100 V/div DC to 1 GHz (TPP1000
probe)
DC to 500 MHz
(TPP0500 probe)
20 mV/div — 49.8 mV/div DC to 350 MHz
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
10 mV/div — 19.9 mV/div DC to 175 MHz
50 mV/div — 100 V/div DC to 500 MHz
20 mV/div — 49.8 mV/div DC to 350 MHz
DPO4054B
10 mV/div — 19.9 mV/div DC to 175 MHz
50 mV/div — 100 V/div DC to 350 MHz
20 mV/div — 49.8 mV/div DC to 350 MHz
DPO4034B
10 mV/div — 19.9 mV/div DC to 175 MHz
Analog bandwidth with
TPP0500 or TPP1000
probe, typical
DPO4014B 10 mV/div — 100 V/div DC to 100 MHz
Lower frequency limit,
AC coupled, typical
< 10 Hz when AC, 1 Mcoupled
The AC coupled lower frequency limits are reduced by a factor of 10 when 10X passive probes are used.
Upper frequency limit,
250 MHz bandwidth
limited, typical
250 MHz, ±20%
Not available on the DPO4014B
Upper frequency limit,
20 MHz bandwidth
limited, typical
20 MHz, ±20%
6 MSO4000B and DPO4000B Series Specifications and Performance Verification

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
The formula is calculated by measuring -3 dB bandwidth of the oscilloscope. The formula accounts for the
rise time contribution of the oscilloscope independent of the rise time of the signal source.
Instrument 50 
1 mV/div to
1.99 mV/div
50 
2 mV/div to
4.99 mV/div
50 
5 mV/div to 1 V/div
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
2 ns 1 ns 350 ps
DPO4054B 2 ns 1 ns 700 ps
DPO4034B 2ns 1ns 1ns
DPO4014B 3.5 ns 3.5 ns 3.5 ns
Instrument TPP1000 probe
10 mV/div to
19.9 mV/div
TPP1000 probe
20 mV/div to
49.8 mV/div
TPP1000 probe
50 mV/div to 10 V/div
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
2 ns 1 ns 350 ps
DPO4054B 2 ns 1 ns 700 ps
DPO4034B 2ns 1ns 1ns
Calculated rise time at
0.350/BW = tr,typical
DPO4014B 3.5 ns 3.5 ns 3.5 ns
Instrument TPP0500 probe
10 mV/div to
19.9 mV/div
TPP0500 probe
20 mV/div to
49.8 mV/div
TPP0500 probe
50 mV/div to 10 V/div
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
2 ns 1 ns 700 ps
DPO4054B 2 ns 1 ns 700 ps
DPO4034B 2ns 1ns 1ns
Calculated rise time at
0.350/BW = tr,typical
DPO4014B 3.5 ns 3.5 ns 3.5 ns
MSO4000B and DPO4000B Series Specifications and Performance Verification 7

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
Peak Detect or
Envelope mode pulse
response, typical
Instrument (Sample rate maximum) Minimum pulse width
MSO4104B, DPO4104B, , MSO4102B, DPO4102B
MSO4104B-L DPO4104B-L, (2 channels
enabled)
MSO4102B-L, DPO4102B-L, (1 channel enabled)
>800 ps (5 GS/s)
DPO4054B, DPO4034B, DPO4014B
DPO4104B-L , (3 channels enabled)
MSO/DPO4102B-L, (2 channels enabled)
>1.6 ns (2.5 GS/s)
RMS noise (mV)
Instrument Bandwidth limit
1M50 
Full bandwidth (300 V + 8.0% of
Volts/div setting)
(75 V + 6.0% of
Volts/div setting)
250 MHz bandwidth (100 V + 5.0% of
Volts/div setting)
(50 V + 4.0% of
Volts/div setting)
MSO4104B,
DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L,
MSO4102B,
DPO4102B
20 MHz bandwidth (100 V + 5.0% of
Volts/div setting)
(50 V + 4.0% of
Volts/div setting)
Full bandwidth (130 V + 8.0% of
Volts/div setting)
(130 V + 8.0% of
Volts/div setting)
250 MHz bandwidth (100 V + 6.0% of
Volts/div setting)
(100 V + 6.0% of
Volts/div setting)
DPO4054B
20 MHz bandwidth (100 V + 4.0% of
Volts/div setting)
(100 V + 4.0% of
Volts/div setting)
Full bandwidth (130 V + 8.0% of
Volts/div setting)
(130 V + 8.0% of
Volts/div setting)
250 MHz bandwidth (100 V + 6.0% of
Volts/div setting)
(100 V + 6.0% of
Volts/div setting)
DPO4034B
20 MHz bandwidth (100 V + 4.0% of
Volts/div setting)
(100 V + 4.0% of
Volts/div setting)
DPO4014B Full bandwidth (130 V + 8.0% of
Volts/div setting)
(130 V + 8.0% of
Volts/div setting)
Random Noise,
Sample Acquisition
Mode
20 MHz bandwidth (100 V + 4.0% of
Volts/div setting)
(100 V + 4.0% of
Volts/div setting)
Delay between
channels, full
bandwidth, typical
100 ps between any two channels with input impedance set to 50 , DC coupling, with equal volts/division
setting or above 10 mV/div
All settings in the instrument can be manually time aligned using the Probe Deskew function from –125 ns
to +125 ns with a resolution of 20 ps
Deskew range –125 ns to +125 ns with a resolution of 20 ps
8 MSO4000B and DPO4000B Series Specifications and Performance Verification

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
Crosstalk (channel
isolation), typical
100:1 at 100 MHz and 30:1 at >100 MHz up to the rated bandwidth for any two channels having
equal Volts/Div settings
TekVPI Interface The probe interface allows installing, powering, compensating, and controlling a wide range of probes
offering a variety of features.
The interface is available on all front panel inputs including Aux In. Aux In only provides 1 Minput
impedance and does not offer 50 as the other input channels do.
Total probe power Five Tek VPI-compliant probe interfaces (one per channel)
50 W maximum internal probe power
Voltage Max Amperage Voltage Tolerance
5V 50 mA (250 mW) ±5%
Probe power per
channel
12 V 2 A (24 W) ±10%
Horizontal and Acquisition System Specifications
The following table shows the horizontal and acquisitions system specifications
for the MSO4000B Series and the DPO4000B Series oscilloscopes.
Table 2: Horizontal and acquisition system specifications
Characteristic Description
MSO4104B, DPO4104B,
MSO4104B-L, DPO4104B-L,
MSO4102B-L, DPO4102B-L,
MSO4102B, DPO4102B
5 GS/s — 2.5 S/sSample-rate range
DPO4054B,
DPO4034B
DPO4014B
2.5 GS/s —2.5 S/s
Record Length Range Non-L models: 20 M, 10 M, 5 M, 1 M, 100 k, 10 k, 1 k
L models: 5 M, 1 M, 100 k, 10 k, 1 k
Instrument 1 k 10 k 100 k – 20 M
MSO4104B, DPO4104B,
MSO4102B-L, DPO4102B-L,
MSO4102B, DPO4102B
MSO4104B-L, DPO4104B-L (2
channels enabled)
400 ps – 40 s 400 ps –
400 s
400 ps – 1,000 s
Seconds/Division range
DPO4054B,
DPO4034B
DPO4014B
MSO4104B-L, DPO4104B-L (4
channels enabled)
1 ns – 40 s 1 ns – 400 s 1 ns – 1,000 s
Maximum triggered acquisition rate > 50,000 wfm/s
MSO4000B and DPO4000B Series Specifications and Performance Verification 9

Specifications
Table 2: Horizontal and acquisition system specifications (cont.)
Characteristic Description
Aperture Uncertainty (3 ps + 0.1 ppm × record duration)RMS, for records having 1 minute duration
Long-term sample rate and
delay time accuracy
±5 ppm over any 1mstimeinterval
10 MSO4000B and DPO4000B Series Specifications and Performance Verification

Specifications
Table 2: Horizontal and acquisition system specifications (cont.)
Characteristic Description
The formula to calculate the delta-time measurement accuracy (DTA) for a given instrument
setting and input signal is given in the following table. (See Table 3.) The formula assumes
insignificant signal content above Nyquist and insignificant error due to aliasing. The
abbreviations used in the formula are as follows:
SR1= slew rate around 1st point in measurement (1st edge)
SR2= slew rate around 2nd point in measurement (2nd edge)
N =input-referred noise (VRMS)(RefertoRandom Noise and Sample Acquisition Mode
specifications.)
TBA = time base accuracy (5 ppm) (Refer to Long-term Sample Rate and Delay Time
Accuracy specifications.)
tp= delta-time measurement duration (sec)
RD = (record length)/(sample rate)
tsr = 1/(sample rate)
assume edge shape that results from Gaussian filter response
Delta-time measurement
accuracy
The term under the square-root sign is the stability and is due to TIE (Time Interval Error). The
errors due to this term occur throughout a single-shot measurement. The second term is due
to both the absolute center-frequency accuracy and the center-frequency stability of the time
base and varies between multiple single-shot measurements over the observation interval (the
amount of time from the first single-shot measurement to the final single-shot measurement).
Table 3: Delta-Time measurement accuracy formula
The terms used in these formulas are defined under Delta-time measurement accuracy, in the preceding table. (See Table 2.)
MSO4000B and DPO4000B Series Specifications and Performance Verification 11

Specifications
Trigger Specifications
The following table shows the trigger specifications for the MSO4000B Series
and the DPO4000B Series oscilloscopes.
Table 4: Trigger specifications
Characteristic Description
Aux In (External) trigger input
impedance, typical
1M±1%inparallelwith13pF±2pF
Aux In (External) trigger maximum
input voltage
The maximum input voltage at the BNC 300 VRMS
Installation Category II
Derate at 20 dB/decade above 3 MHz to 30 VRMS at 30 MHz, 10 dB/decade above 30 MHz.
Aux In (External) trigger bandwidth,
typical
250 MHz ±20%
MSO4104B, DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L, MSO4102B,
DPO4102B
1GHz
DPO4054B 500 MHz
DPO4034B 350 MHz
Trigger bandwidth, Edge, typical
DPO4014B 100 MHz
MSO4104B, DPO4104B,
MSO4104B-L,
DPO4104B-L,
MSO4102B-L,
DPO4102B-L, MSO4102B,
DPO4102B
1GHz
DPO4054B 500 MHz
DPO4034B 350 MHz
Trigger bandwidth, Pulse and Logic,
typical
DPO4014B 100 MHz
12 MSO4000B and DPO4000B Series Specifications and Performance Verification
