DPO2000 and MSO2000 Series
Oscilloscopes
Specifications and Performance Verification
ZZZ
Technical Reference
*P077009600*
077-0096-00

DPO2000 and MSO2000 Series
Oscilloscopes
Specifications and Performance Verification
ZZZ
Technical Reference
xx
Revision B
This document supports firmware version 1.03 and above
for both MSO2000 Series instruments and DPO2000 Series
instruments.
Warning
The servicing instructions are for use by qualified personnel
only. To avoid personal injury, do not perform any servicing
unless you are qualified to do so. Refer to all safety summaries
prior to performing service.
www.tektronix.com
077-0096-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Tektronix is an authorized licensee of the CompactFlash trademark.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Table of Contents
General safety summary .......................................................................................... iii
Specifications ....................................................................................................... 1
Performance Verification ......................................................................................... 11
Upgrade the Firmware ....................................................................................... 12
Test Record.................................................................................................... 13
Performance Verification Procedures....................................................................... 16
DPO2000 and MSO2000 Series Specifications and Performance Verification i

Table of Contents
List of Tables
Table 1: Analog channel input and vertical specifications..................................................... 1
Table 2: Digital channel input specifications, MSO2000 only ................................................ 3
Table 3: Horizontal and acquisition system specifications..................................................... 4
Table 4: Trigger specifications.................................................................................... 5
Table 5: Display specifications.................................................................................... 7
Table 6: Input/Output port specifications........................................................................ 7
Table 7: Power source specifications............................................................................. 8
Table 8: Data storage specifications.............................................................................. 8
Table 9: Environmental specifications ........................................................................... 8
Table 10: Mechanical specifications.............................................................................. 9
Table 11: DC Gain Accuracy Worksheet ....................................................................... 21
ii DPO2000 and MSO2000 Series Specifications and Performance Verification

General safety summary
General safety summary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it.
To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
To avoid fire or personal
injury
Use proper power cord. Use only the power cord specified for this product and
certified for the country of use.
Connect and disconnect properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Ground the product. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Connect the probe reference lead to earth ground only.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Power disconnect. The power cord disconnects the product from the power source.
Do not block the power cord; it must remain accessible to the user at all times.
Do not operate without covers. Do not operate this product with covers or panels
removed.
Do not operate with suspected failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
Avoid exposed circuitry. Do not touch exposed connections and components when
power is present.
Use proper AC adapter. Use only the AC adapter specified for this product.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry.
Provide proper ventilation. Refer to the manual's installation instructions for details
on installing the product so it has proper ventilation.
DPO2000 and MSO2000 Series Specifications and Performance Verification iii

General safety summary
Termsinthismanual These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and terms on the
product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARN ING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
iv DPO2000 and MSO2000 Series Specifications and Performance Verification

Specifications
This chapter contains specifications for the DPO2000 and the MSO2000 series
oscilloscopes. All specifications are guaranteed unless noted as "typical."
Typical specifications are provided for your convenience but are not guaranteed.
Specifications that are marked with the symbol are checked in Performance
Verification.
All specifications apply to all DPO2000 and MSO2000 models unless noted
otherwise. To meet specifications, two conditions must first be met:
The oscilloscope must have been operating continuously for twenty minutes
within the operating temperature range specified.
You must perform the Signal Path Compensation (SPC) operation prior to
evaluating specifications. (See page 18, Signal Path Compensation (SPC).)
If the operating temperature changes by more than 10 °C (18 °F), you must
perform the SPC operation again.
Table 1: Analog channel input and vertical specifications
Characteristic Description
DPO2012, MSO2012 DPO20x4, MSO20x4Number of input
channels 2 analog, digitized simultaneously 4 analog, digitized simultaneously
Input coupling DC, AC, or GND
AC coupling connects a capacitor in series with the input circuitry.
GND coupling provides a reference waveform derived from the values identified during SPC. This reference
waveform shows visually where ground is expected to be.
Input resistance, DC
coupled
1MΩ±2%
Input capacitance, DC
coupled
11.5 pF ±2 pF
Maximum input
voltage
The maximum input voltage at the BNC, between the center conductor and shield is 450 Vpeak (<100 ms
duration), 300 VRMS to 4 MHz, derated to 6 VRMS at 200 MHz.
DC Balance ±(1mV+0.1div)
Deskew range ±100 ns, analog channels only
DPO2024, MSO2024 ≥100:1 with 200 MHz sinewave and equal V/div settings on each channel.Crosstalk (channel
isolation), typical DPO201x, MSO201x ≥100:1 with 100 MHz sinewave and equal V/div settings on each channel.
TekVPI Interface The probe interface allows installing, powering, compensating, and controlling a wide range of probes
offering a variety of features
If a probe requires 12 V bulk power, it must be supplied by the Optional External Power Adapter
The interface is available on all front panel inputs including Aux In
Total probe power 50 W from optional 12 V VPI External Power Adapter
Zero 12 V bulk power without optional External Power Adapter
DPO2000 and MSO2000 Series Specifications and Performance Verification 1

Specifications
Table 1: Analog channel input and vertical specifications (cont.)
Characteristic Description
Number of digitized
bits
8bits
Displayed vertically with 25 digitization levels (DL) per division, 10 divisions dynamic range. Only 8 vertical
divisions are displayed
"DL" is the abbreviation for "digitization level." A DL is the smallest voltage level change that can be
resolved by the 8-bit A-D Converter. This value is also known as the LSB (least significant bit).
Sensitivity range 2 mV/div to 5 V/div in a 1-2-5 sequence with probe attenuation set to 1X
Position range ±4 divisions
Instrument
5 mV/div to 5 V/div
with an ambient
temperature of
0°Cto40°C
(0 °F to 104 °F)
5 mV/div to5V/div
with an ambient
temperature of
0°Cto50°C
(0 °F to 122 °F) <5 mV/div
DPO2024, MSO2024 DC to ≥200 MHz DC to ≥160 MHz 20 MHz
Analog bandwidth,
DC coupled
DPO2014, MSO2014,
DPO2012, MSO2012
DC to ≥100 MHz 20 MHz
The rise time is calculated from the bandwidth of the oscilloscope. The formula accounts for the rise time
contribution of the oscilloscope independent of the rise time of the signal source.
Instrument Risetime
DPO2024, MSO2024 2.1 ns
Calculated rise time
DPO2014, MSO2014,
DPO2012, MSO2012
3.5 ns
Common mode
rejection ratio (CMRR),
typical
100:1 at 60 Hz, reducing to 10:1 with 50 MHz sinewave with equal Volts/div and Coupling settings
on each channel.
Lower frequency limit,
AC coupled, typical
≤10 Hz
Upper frequency limit,
20 MHz bandwidth
limited, typical
20 MHz, +50%, –0%
DC gain accuracy ±3%, 5 V/div through 10 mV/div
±4%, 5 mV/div and 2 mV/div
More than shown above when using variable gain
