TelcoBridges TSBC Series Operating and maintenance instructions

TSBC Series Installation Guide
TSBC-HW
August 1, 2017

The information in this document as well as product specifications referred to throughout, are subject to change without notice.
No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any
purpose, without the express written permission of TelcoBridges. TelcoBridges may have patents or pending patent
applications, trademarks, copyrights, or other intellectual property rights covering subject matter in this document. The
furnishing of this document does not give you license to these patents, trademarks, copyrights, or other intellectual property
except as expressly provided in any written license agreement from TelcoBridges Inc.
The information provided in this document is intended as a guide only. For the latest detailed engineering specifications, please
contact TelcoBridges TB Support or visit the TBWiki: http://docs.telcobridges.com. TelcoBridges is committed to continually
improving product designs; as a result, product specifications may be subject to change without notification.
© 2003-2017 TelcoBridges. All rights reserved.
TelcoBridges, Tmedia, TMG800, TMG3200, TMG3200-TE, TMG3200-DS3, TMG3200-STM1, TMG7800, TMG7800-TE,
TMG7800-DS3, TMG7800-STM1, TMG7800-CTRL, Tctrl, TMG7800-TMS, Tsig, TSG800, TSG3200, TSG3200-TE,
TSG3200-DS3, TSG3200-STM1, Ttrans, TMGIP800, TMGIP3200, TMGIP7800,
Tmedia 1+1, Tmedia N+1, TMG800+1, TMG3200-TE+1, TMG3200-DS3+1, TMG3200-STM1+1, TMG7800-TE+1,
TMG7800-DS3+1, TMG7800-STM1+1, Tsbc, TSBC-SW, TSBC-HW, TSBC-HW-SRV, TSBC-HW-SRV-HIGH, TSBC-HW-
SRV-MID, TSBC-HW-TRANS, TSBC-HW-TRANS-1372, TSBC-HW-TRANS-2744, Tdev, TMP800, TMP6400, TMP6400-
CTRL, TMP6400-TMS, Tmonitor, TM1000, TM3000, Toolpack, Toolpack API, TB640, TB-8, TB-16, and TB-Video, are
trademarks of TelcoBridges Inc. All other trademarks are the property of their owners. This information is subject to
change without notice.
HEAD OFFICE
TelcoBridges Inc.
91 rue de la Barre, Suite 01
Boucherville, QC, J4B 2X6
CANADA
www.telcobridges.com
T [phone]
F [phone]
[email protected]
TB Support - Technical Support
Tel: [phone]
[email protected]
www.telcobridges.com/en/tbsupport.aspx
ii
Issue 1.0f

iii
About this Guide
This guide provides installation, and setup procedures for the TSBC-HW.
Conventions
Terminology Description
TSBC-HW This term is used when a description applies to both a TSBC-HW-SRV and TSBC-
HW-TRANS.
TSBC-HW-SRV This term is used when a description applies to a TSBC-HW-SRV-HIGH and TSBC-
HW-SRV-MID.
TSBC-HW-SRV-HIGH This term is used when a description applies only to the TSBC-HW-SRV-HIGH.
TSBC-HW-SRV-MID This term is used when a description applies only to the TSBC-HW-SRV-MID.
TSBC-HW-TRANS This term is used when a description applies to a TSBC-HW-TRANS-1372 and
TSBC-HW-TRANS-2744.
TSBC-HW-TRANS-1372 This term is used when a description applies only to the TSBC-HW-TRANS-1372.
TSBC-HW-TRANS-2744 This term is used when a description applies only to the TSBC-HW-TRANS-2744.
Preface

TSBC Series System Installation Guide
iv
Contact Us
If you have comments about this guide or any other TelcoBridges technical
documentation, please send an email to [email protected].

v
Section 1 Introduction....................................................................................................................... 1
1.1 Identifying the TSBC-HW Equipment..................................................................................2
1.1.1 TSBC-HW-SRV...................................................................................................................2
1.1.2 TSBC-HW-TRANS..............................................................................................................4
1.2 Installation Prerequisites.....................................................................................................5
1.2.1 TSBC-HW-SRV...................................................................................................................5
1.2.2 TSBC-HW-TRANS..............................................................................................................6
1.3 Preventing Electrostatic Discharge Damage.......................................................................8
1.4 Recommended Reading......................................................................................................8
Section 2 Installation Preparation..................................................................................................... 9
2.1 Package Contents.............................................................................................................10
2.1.1 TSBC-HW-SRV-HIGH.......................................................................................................10
2.1.2 TSBC-HW-SRV-MID.........................................................................................................10
2.1.3 TSBC-HW-TRANS1372/TBSC-HW-TRANS-2744............................................................11
2.2 Rack Mounting the TSBC-HW Equipment ........................................................................12
2.2.1 Prerequisites .....................................................................................................................12
2.2.2 Vertical Placement of the Equipment................................................................................12
2.2.3 Installing the TSBC-HW-SRV on an Equipment Rack ......................................................13
2.2.3.1 TSBC-HW-SRV.................................................................................................................13
2.2.3.2 TSBC-HW-TRANS............................................................................................................13
Section 3 Installing the TSBC-HW-SRV......................................................................................... 15
3.1 Connecting to the TSBC-HW-SRV Management Interface...............................................16
3.2 Connecting to the Control Network ...................................................................................17
3.3 Connecting to the Data Network .......................................................................................18
3.3.1 TSBC-HW-SRV-HIGH: 1Gb..............................................................................................18
3.3.2 TSBC-HW-SRV-HIGH: 10G..............................................................................................19
3.3.3 TSBC-HW-SRV-MID: 1G ..................................................................................................20
3.3.4 TSBC-HW-SRV-MID: 10G ................................................................................................20
3.4 Powering Up......................................................................................................................22
3.4.1 Connecting to AC Power...................................................................................................22
3.5 Connecting to DC Power...................................................................................................22
Section 4 Installing the TSBC-HW-TRANS.................................................................................... 25
4.1 Connecting to the Control Network ...................................................................................26
4.2 Connecting to the Transcoding Network...........................................................................27
4.3 Grounding the Equipment Chassis....................................................................................28
4.4 Powering Up......................................................................................................................29
4.4.1 Connecting to AC Power...................................................................................................29
4.4.2 Connecting to DC Power...................................................................................................30
Section 5 Start Up and Verification ................................................................................................ 31
5.1 Start Up.............................................................................................................................31
5.2 Verifying the LED Status Indications.................................................................................32
5.2.1 TSBC-HW-SRV.................................................................................................................32

TSBC Series System Installation Guide
vi
5.2.2 TSBC-HW-TRANS............................................................................................................33
Section 6 Powering Down the Equipment...................................................................................... 35
6.1 TSBC-HW-SRV.................................................................................................................35
6.1.1 Local Method.....................................................................................................................35
6.1.2 Remote Method.................................................................................................................35
6.2 TSBC-HW-TRANS............................................................................................................35
Section 7 Initial System Configuration............................................................................................ 37
7.1 TSBC-HW-SRV SSH Connection .....................................................................................38
7.2 TSBC-HW-SRV Serial Connection....................................................................................38
7.2.1 Connecting to the TSBC-HW-SRV Console......................................................................38
7.2.2 Configuring the Terminal Emulator Application.................................................................41
7.3 Changing the TSBC-HW-SRV Management Port IP Address ..........................................43
7.4 Retrieving TSBC-HW-SRV Information.............................................................................43
7.5 Changing TSBC-HW-SRV Management Port Passwords ................................................43
7.6 Configuring the TSBC-HW-SRV Using the Web Portal.....................................................43
Section 8 System Backups............................................................................................................. 45
8.1 Creating a Database Backup ............................................................................................46
8.2 Downloading a Database Backup.....................................................................................46
8.3 Uploading a Database Backup..........................................................................................46
8.4 Restoring a Database Backup...........................................................................................46

1
Section 1 Introduction
This section provides an introduction to the installation and setup of a TSBC-HW:
The following topics are covered:
•Section 1.1 “Identifying the TSBC-HW Equipment”
• Section 1.2 “Installation Prerequisites”
• Section 1.3 “Preventing Electrostatic Discharge Damage”
• Section 1.4 “Recommended Reading”

TSBC Series System Installation Guide
2
1.1 Identifying the TSBC-HW Equipment
The TSBC-HW is comprised of the following equipment:
• TSBC-HW-SRV
• TSBC-HW-TRANS
1.1.1 TSBC-HW-SRV
The TSBC-HW-SRV is available in two models:
• TSBC-HW-SRV-HIGH, (figure 1.1 on page 3)
• TSBC-HW-SRV-MID, (figure 1.2 on page 4)
TSBC-HW-SRV-HIGH
Characteristics Dual Xeon E5-2643, 6C/12T, 3.4 GHz
24GB RAM RDIMM, 2400MHz
2x 200GB SSD
NUMA optimized for PCIe faster access
Dell iDRAC6 out-of-band interface
Interfaces Configuration for 10GE interfaces Management: 2x GigE copper
Control: 2x GigE copper
VoIP: 4x 10GE SFP+ SR optics
(850nm)
Configuration for GigE interfaces Management: 2x GigE copper
Control: 2x GigE copper
VoIP: 6x GigE copper

3
Introduction
Figure 1.1 TSBC-HW-SRV-HIGH
For information about the TSBC-HW-SRV-HIGH, refer to Dell’s documentation:
http://www.dell.com/support/home/us/en/19/product-support/product/poweredge-r630/manuals
TSBC-HW-SRV-MID
TSBC-HW-SRV-HIGH (front view)
TSBC-HW-SRV-HIGH 1Gb (rear view) AC Power Supply
TSBC-HW-SRV-HIGH 1Gb (rear view) DC Power Supply
TSBC-HW-SRV-HIGH 10 Gb (rear view) AC Power Supply
TSBC-HW-SRV-HIGH 10 Gb (rear view) DC Power Supply
Characteristics Single Xeon E3-1240, 4C/8T, 3.5GHz
16GB RAM RDIMM, 2400MHz
2x 200GB SSD
NUMA optimized for PCIe faster access
Dell iDRAC8 out-of-band interface
Interfaces Configuration for 10GE interfaces Management: 2x GigE copper
Control: 2x GigE copper
VoIP: 2x 10GBASE-T
Configuration for GigE interfaces Management: 2x GigE copper
Control: 2x GigE copper
VoIP: 6x GigE copper

TSBC Series System Installation Guide
4
Figure 1.2 TSBC-HW-SRV-MID
For information about the TSBC-HW-SRV-MID, refer to Dell’s documentation:
http://www.dell.com/support/home/us/en/04/product-support/product/poweredge-r330/manuals
1.1.2 TSBC-HW-TRANS
The TSBC-HW-TRANS, shown in figure 1.3 on page 4, is available in two models:
• TSBC-HW-TRANS-1372
• TSBC-HW-TRANS-2744
Figure 1.3 TSBC-HW-TRANS
TSBC-HW-SRV-MID (front view)
TSBC-HW-SRV MID 1Gb (rear view) AC Power SupplyTSBC-HW-SRV-
TSBC-HW-SRV-MID 10 Gb (rear view) AC Power Supply
TSBC-HW-TRANS-1372/2744 (front view)
TSBC-HW-TRANS-1372/2744 (rear view)
MGMT0
ETH VOIP
01 01
TMS
01

5
Introduction
1.2 Installation Prerequisites
For the installation to proceed without interruption, it is important that you verify that you have all
necessary materials on hand.
A TSBC-HW system can range in size from 1 to 18U is vertical rack space at full capacity
Figure 1.4 Example of an equipment rack-space allocation
1.2.1 TSBC-HW-SRV
Adequate space for the installation of the TSBC-HW-SRV
You must mount the TSBC-HW-SRV on a 19" equipment rack (customer provided). Your TSBC-HW-
SRV is a 1U unit.
Note The depth of the TSBC-HW-SRV is greater than the 16” (406mm) depth of the TSBC-
HW-TRANS1372/2744 units. It is important to plan for an equipment rack of adequate
size.
The dimension of the TSBC-HW-SRV-HIGH are:
• Height x Width x Depth (mm) 42.8 x 482.3 x 755.1
TSBC-HW-TRANS
TSBC-HW-SRV
1U
1U
For this type of
installation 2Us
of rack space are
required
TSBC-HW-TRANS
TSBC-HW-SRV
1U
1U
For this type of
larger installation
18Us of
rack space are
required
TSBC-HW-SRV
1U
TSBC-HW-TRANS
1U
From 1 - 16 TSBC-HW-TRANS

TSBC Series System Installation Guide
6
• Height x Width x Depth (inch) 1.68 x 18.98" x 29.72"
The dimension of the TSBC-HW-SRV-MID (without bezel and redundant power supply)
• Height x Width x Depth (mm) 42.8 x 434.0 x 625.0
• Height x Width x Depth (inch) 1.68 x 17.08" x 24.60"
Adequate power supply and power connections
Each TSBC-HW-SRV requires two power connections to provide for its redundant power supply. To
guarantee an uninterrupted supply of electricity, each power connection must be fed by a dedicated
power source.
An IP address for the management port
Each TSBC-HW-SRV requires a IP address for the management port.To avoid delays, you should have
the IP address, netmask and gateway addresses on hand. Take note that the management port
supports DHCP, see Section 3.1 “Connecting to the TSBC-HW-SRV Management Interface” on
page 16 for further information.
Cabling
Ensure that you have the correct quantity of cables for your system:
TSBC-HW-SRV-HIGH
• Fiber cable pairs (for 10G configurations)
• Ethernet CAT5 cables
TSBC-HW-SRV-MID
• Ethernet CAT5 cables
• Ethernet CAT7 cables (for 10G configurations)
1.2.2 TSBC-HW-TRANS
Adequate space for the installation of the TSBC-HW-TRANS
You will need to mount the TSBC-HW-TRANS on a 19" equipment rack (customer provided). The
TSBC-HW-TRANS is housed in a 1U chassis.
The dimension of the TSBC-HW-TRANS are:
• Height x Width x Depth (mm) 44.5 x 429.0 x 406.0
• Height x Width x Depth (inch) 1.75 x 16.9" x 16"
Adequate power supply and power connections
Each TSBC-HW-TRANS requires two power connections to provide for its redundant power supply.

7
Introduction
To guarantee an uninterrupted supply of electricity, each power connection must be fed by a dedicated
power source.

TSBC Series System Installation Guide
8
1.3 Preventing Electrostatic Discharge Damage
Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. It may occur if
electronic printed circuit cards are improperly handled and may cause complete or intermittent failure.
Always follow ESD prevention procedures when removing and replacing modules:
• Ensure that the equipment is grounded.
• Wear an ESD-preventive wrist strap and ensure that it makes good contact with your
skin. Connect the wrist strap clip to an unpainted surface of the equipment or the
grounded equipment rack in order to channel away all ESD voltage safely to ground.
To guard against ESD damage and shocks, the wrist strap and cord must be in proper
working condition.
• If no wrist strap is available, and you must work with the equipment, ground yourself
by touching a metal part of the chassis.
1.4 Recommended Reading
This document assumes that you have a clear understanding of the installation of the equipment
described in this document and have been trained to work with the equipment.If you have any technical
questions, TelcoBridges TB Support (technical support team) can be reached at the following numbers
or an email can be sent to: [email protected].
• Americas & Europe Technical Support Centre (GMT-05:00, Montreal):
Telephone: [phone] x131 or x102
• Asia Technical Support Centre (GMT +08:00, Hong Kong)
Telephone: [phone]
• 24/7 International Support
Telephone: [phone]
• Documents exploring various aspects of the product are available on the TB Wiki:
http://docs.telcobridges.com
!
Warning

9
Installation Preparation
Section 2 Installation Preparation
This section provides information about the following topics:
•Section 2.1 “Package Contents”
• Section 2.2 “Rack Mounting the TSBC-HW Equipment”

TSBC Series System Installation Guide
10
2.1 Package Contents
Depending on your system requirements, you may receive one or more of the following items:
•Section 2.1.1 “TSBC-HW-SRV-HIGH” on page 10.
• Section 2.1.2 “TSBC-HW-SRV-MID” on page 10.
• Section 2.1.3 “TSBC-HW-TRANS1372/TBSC-HW-TRANS-2744” on page 11.
The contents of these devices are described in the following sections.
2.1.1 TSBC-HW-SRV-HIGH
In the box, you will find the following items:
• One Dell PowerEdge R630, (http://www.dell.com/support/home/us/en/19/product-
support/product/poweredge-r630/manuals)
• One TelcoBridges Important Notice (pertinent product serial numbers and other important
information).
• One set of static rails and associated installation hardware.
• One packing slip.
• Two AC power cables (optional), or two DC power cables.
2.1.2 TSBC-HW-SRV-MID
In the box, you will find the following items:
• One Dell PowerEdge R330, (http://www.dell.com/support/home/us/en/04/product-
support/product/poweredge-r330/manuals)
• One TelcoBridges Important Notice (pertinent product serial numbers and other important
information).
• One set of static rails and associated installation hardware.
• One packing slip.
• Two AC power cables (optional).

11
Installation Preparation
2.1.3 TSBC-HW-TRANS1372/TBSC-HW-TRANS-2744
In the box, you will find the following items:
• One TSBC-HW-TRANS unit (TSBC-HW-TRANS-1372 or TSBC-HW-TRANS-2744). See figure 1.3
on page 4
.
• One set of mounting brackets and screws, used to mount the TSBC-HW-TRANS unit to a 19" rack.
• One serial adapter to interface the serial port of your computer with the RJ-45 port of the TSBC-
HW-TRANS unit.
• Three CAT5 Ethernet (blue) straight cables (male-male), 3 meters in length.
• One Important Notice (two-sided document containing pertinent product serial numbers, and other
important information).
• One Product Warranty.
• One packing slip.
• Two AC power cables (optional), or two DC power cables.
Not included
• A 19” equipment rack. The TSBC-HW-TRANS unit must be installed on a 19” wide equipment rack.
• USB-Type B cable. This can be used as an alternative way to connect to the serial port of the
transcoding unit.

TSBC Series System Installation Guide
12
2.2 Rack Mounting the TSBC-HW Equipment
The TSBC-HW equipment is mounted on a customer provided equipment rack using the mounting
hardware packaged in each box.
2.2.1 Prerequisites
To rack mount the equipment, you will need:
• One customer-provided equipment rack, measuring 19” in width and 29.7” in depth. The rack must
be solidly anchored to the floor with appropriate support at the top of the racks.
• Climate controlled room: 0 to +50 Celsius, 0 to 95% non-condensing humidity.
2.2.2 Vertical Placement of the Equipment
The TSBC-HW-SRV and TSBC-HW-TRANS are each housed in 1U chassis, as tabulated in table 2.1
on page 12. It is important that you provide for enough room on the equipment rack to allow for the
installation of the equipment.
Consider the available space on your equipment rack and the height of each piece of equipment.
Due to the rear-exhaust heat vents and the efficient heat dissipation design, there is no need to leave
any physical vertical space above or below the TSBC-HW-SRV or TSBC-HW-TRANS.
Table 2.1 TSBC-HW Physical Height
TSBC-HW Model Number Vertical Height
TSBC-HW-SRV-HIGH 1U (1.68 inches or 42.80 mm)
TSBC-HW-SRV-MID 1U (1.68 inches or 42.80 mm)
TSBC-HW-TRANS 1U (1.75 inches or 44.45 mm)

13
Installation Preparation
2.2.3 Installing the TSBC-HW-SRV on an Equipment Rack
The TSBC-HW-SRV and TSBC-HW-TRANS are mounted on a 19" equipment rack using the angle
brackets and screws provided in the box.
2.2.3.1 TSBC-HW-SRV
To install the TSBC-HW-SRV-HIGH or TSBC-HW-SRV-MID on the equipment rack, refer to either the
static or sliding rails installation Instructions in the following Dell documents:
• TSBC-HW-SRV-HIGH: Dell PowerEdge R630,
(http://www.dell.com/support/home/us/en/19/product-support/product/poweredge-r630/manuals)
• TSBC-HW-SRV-MID: Dell PowerEdge R330, (http://www.dell.com/support/home/us/en/04/product-
support/product/poweredge-r330/manuals)
2.2.3.2 TSBC-HW-TRANS
Mounting the TSBC-HW-TRANS
1. Using four metal screws, attach one angle bracket to the front, left-hand side of the TSBC-HW-
TRANS, when viewed from the front. Do the same for the angle bracket on the right-hand side.
2. Start mounting equipment beneath the TSBC-HW-SRV, keeping in mind the space required on the
equipment rack as described in Section 2.2.2 “Vertical Placement of the Equipment” on page 12

TSBC Series System Installation Guide
14
