TelcoBridges Tmedia TMG5800 User manual

?
?
Two AC power cords
19” equipment rack
Items not included in this box that you will need:
In the box, you will find:
2
A) Install rack-mounting hardware on TMG5800
and install on equipment rack.
3
4
Connect to VoIP network.
TMG5800 AC Quick Installation Guide
TelcoBridges, On a Blade, System-Blade, TB-1+1 Solution, TB-16-E1/T1/J1, TB640-DS3, TB640-E1/T1/J1, TB640-OC3/STM-1, TB-8-E1/T1/J1, TB-IVR Mezzanine, TB-Multi-Blade, TB-Multi-Blade Mezzanine, TB-N+1-15 Solution,
TB-N+1-3 Solution, TB-StreamServer, TBVideo,TB-VoIP Mezzanine, TM-1000 Network Probe, Tmedia, TMP6400, TMG5800, TMG3200, TMS1600, TMP800, TMG800 are trademarks of ridges Inc. All rights reserved 2011.
All other trademarks are property of their owners. Information subject to change without notice.
TelcoB
1
VoIP Ports 1& 2 (VoIP-1&2)
?
?
?
?
?
?
?
One TMG5800
One set of mounting brackets with screws
SCSI Cables and Patch Panels, if applicable
Three RJ45 Ethernet Straight Cables (male-male)
One warranty sheet
One packing slip
One TMG5800 Quick Installation Guide
Attach Bracket
to Tmedia Unit
Attach Tmedia
Unit to Equipment
Rack
Power LED
B) Use ETH0 or ETH1 ports to connect to Linux Host.
Management Interface
ETH VoIP TMS
12 1122
18 765432
916151413121110
Serial
232
RS
VGA
ETH0 ETH1
ETH VoIP TMS
12 1122
18 765432
916151413121110
Serial
232
RS
VGA
ETH0 ETH1

7
5
TMG5800 AC Quick Installation Guide
TelcoBridges, On a Blade, System-Blade, TB-1+1 Solution, TB-16-E1/T1/J1, TB640-DS3, TB640-E1/T1/J1, TB640-OC3/STM-1, TB-8-E1/T1/J1, TB-IVR Mezzanine, TB-Multi-Blade, TB-Multi-Blade Mezzanine, TB-N+1-15 Solution,
TB-N+1-3 Solution, TB-StreamServer, TBVideo,TB-VoIP Mezzanine, TM-1000 Network Probe, Tmedia, TMP6400, TMG5800, TMG3200, TMS1600, TMP800, TMG800 are trademarks of ridges Inc. All rights reserved 2011.
All other trademarks are property of their owners. Information subject to change without notice.
TelcoB
?
?
RJ-48 Interface (T1/E1/J1)
SCSI Interface (T1/E1/J1), a patch panel is provided
Connect to PSTN Network, using one of the following options:
?
?
Dual BNC (DS3)
Optical Interface (OC3/STM-1)
A.
49-64
33-48
17-32
1-16
SCSI
RJ-48
BIT1
BIT2
APS MAIN
STM 1
RxTx
BIT1
BIT2
RxTxRxTx
321
DS3
A) Connect to two independent
power sources (if only one power source is used,
press the green button at the rear
of the unit to disable the audible alarm).
B) Verify Power LED = Solid Green
(Refer to Panel 3)
6
Connect to the Linux host through management Ethernet. The IP address of the management
port is assigned through DHCP. If DHCP is not available, use the serial cable to connect to the
TMG Linux Host for the first time.
Default HOSTNAME is the Linux Host serial number, which can be found in the packing slip.
Refer to the "Read Me" sheet for the username and password to log onto the Linux OS.
Navigate to: HTTP://HOSTNAME:12358, to configure the TMG5800.
(username/password: root/root)
B.
C.
More information is available on the TelcoBridges TB Wiki at:
http://docs.telcobridges.com/mediawiki/index.php/TMG5800
Next Steps?
