Teledyne 200E User manual

A
dvanced Pollution Instrumentation, In
c
A
Teledyne Technologies Compan
y
TELEDYNE
INSTRUMENTS
INSTRUCTION MANUAL
Chemiluminescence
Nitrogen Oxides Analyzer
Model 200E
© TELEDYNE INSTRUMENTS
ADVANCED POLLUTION INSTRUMENTATION DIVISION
(T-API)
6565 NANCY RIDGE DRIVE
SAN DIEGO, CA 92121-2251, USA
Toll-free Phone: [phone]
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Website: http://www.teledyne-api.com/

INSTRUCTION MANUAL
MODEL 200E
NITROGEN OXIDES ANALYZER
© Teledyne Instruments
ADVANCED POLLUTION INSTRUMENTATION DIVISION
(T-API)
6565 NANCY RIDGE DRIVE
SAN DIEGO, CA 92121-2251
USA
Toll-free Phone: [phone]
Phone: [phone]
Fax: [phone]
Email: [email protected]
Website: http://www.teledyne-api.com/
044100102
Rev. A
Copyright 2001 T-API Inc. 19-March-2003

M200E Documentation Model 200E Instruction Manual
SAFETY MESSAGES
Your safety and the safety of others is very important. We have provided many important
safety messages in this manual. Please read these messages carefully.
A safety message alerts you to potential hazards that could hurt you or others. Each safety
message is associated with a safety alert symbol. These symbols are found in the manual
and inside the instrument. The definition of these symbols is described below:
GENERAL SAFETY HAZARD: Refer to the instructions for
details on the specific hazard.
CAUTION: Hot Surface Warning.
CAUTION: Electrical Shock Hazard.
TECHNICIAN SYMBOL: All operations marked with this symbol
are to be performed by qualified maintenance personnel only.
CAUTION
The analyzer should only be used for the purpose and in the manner described in
this manual. If you use the analyzer in a manner other than that for which it was
intended, unpredictable behavior could ensue with possible hazardous
consequences.
This analyzer is for indoor use only and for altitudes up to 2000 m (6500 ft).
ii 044100102 Rev A

Model 200E Instruction Manual M200E Documentation
TABLE OF CONTENTS
SAFETY MESSAGES ...............................................................................................................II
TABLE OF CONTENTS .......................................................................................................... III
LIST OF FIGURES.................................................................................................................IX
LIST OF TABLES................................................................................................................... XI
LIST OF APPENDICES ....................................................................................................... XIII
1. M200E DOCUMENTATION...................................................................................................1
1.1. Available Documentation ...............................................................................................1
1.2. Manual Structure..........................................................................................................1
1.3. How to use this Instruction Manual .................................................................................3
2. SPECIFICATIONS, APPROVALS AND WARRANTY ...............................................................5
2.1. M200E Operating Specifications ......................................................................................5
2.2. EPA Equivalency Designation..........................................................................................6
2.3. CE Mark Compliance .....................................................................................................7
2.4. Warranty.....................................................................................................................7
3. GETTING STARTED.............................................................................................................9
3.1. Unpacking and Initial Setup ...........................................................................................9
3.2. M200E Layout ............................................................................................................ 11
3.3. Pneumatic Connections ............................................................................................... 13
3.3.1. Span Gas Defined ................................................................................................ 14
3.3.2. Zero Gas Defined ................................................................................................. 15
3.4. Electrical Connections ................................................................................................. 17
3.4.1. Power Connection ................................................................................................ 17
3.4.2. Analog Output Connections ................................................................................... 17
3.4.3. Ethernet Connection and Configuration.................................................................... 20
3.5. Initial Operation ......................................................................................................... 20
3.5.1. Startup............................................................................................................... 20
3.5.2. Warm-Up............................................................................................................ 21
3.5.3. Warning Messages ............................................................................................... 21
3.5.4. Functional Check.................................................................................................. 23
3.6. First Calibration..........................................................................................................26
3.6.1. Basic Calibration Procedure ................................................................................... 26
3.6.2. Interferences for NOXMeasurements....................................................................... 27
4. FREQUENTLY ASKED QUESTIONS & GLOSSARY................................................................29
4.1. Frequently Asked Questions ......................................................................................... 29
4.2. Glossary ...................................................................................................................30
5. OPTIONAL HARDWARE AND SOFTWARE ..........................................................................33
5.1. External Pumps (Option 10) ......................................................................................... 33
5.2. Rack Mount Kits (Options 20-23) .................................................................................. 33
5.3. Current Loop Analog Outputs (Option 41) ...................................................................... 33
5.4. Particulate Filter Kit (Option 42A) ................................................................................. 34
5.5. Calibration Valve Options............................................................................................. 34
5.5.1. Zero/Span Valves (Option 50)................................................................................ 34
5.5.2. Internal Zero/Span (IZS) (Option 51) ..................................................................... 35
5.5.3. IZS Permeation Tubes (Options 53 & 55)................................................................. 36
5.6. Scrubbers and Expendables ......................................................................................... 37
5.6.1. Charcoal Scrubber (Option 64A)............................................................................. 37
5.6.2. Charcoal Refill Kit (Part# 00596)............................................................................ 37
5.6.3. Zero Air Scrubber (Option 64B).............................................................................. 37
5.6.4. Zero Air Scrubber Maintenance Kit (Option 43)......................................................... 37
5.6.5. M200E Expendables Kit (Option 42) ........................................................................ 38
5.6.6. M200E Spare Parts Kit (Option 43) ......................................................................... 38
5.7. Communication Options .............................................................................................. 38
5.7.1. RS232 Modem Cables (Options 60 and 60A) ............................................................ 38
5.7.2. RS-232 Multidrop (Option 62) ................................................................................ 38
5.7.3. Ethernet (Option 63) ............................................................................................ 38
5.8. Sample Gas Conditioners (Options 86 & 88) ................................................................... 39
5.9. Manual on CD (Part number 044100200) ....................................................................... 40
044100102 Rev A iii

M200E Documentation Model 200E Instruction Manual
5.10. Extended Warranty (Options 92 & 93)..........................................................................40
6. OPERATING INSTRUCTIONS ........................................................................................... 41
6.1. Overview of Operating Modes .......................................................................................41
6.2. Sample Mode .............................................................................................................42
6.2.1. Test Functions .....................................................................................................42
6.2.2. Warning Messages................................................................................................44
6.2.3. Calibration Functions ............................................................................................44
6.3. Calibration Mode.........................................................................................................45
6.4. Setup Mode ...............................................................................................................45
6.4.1. Password (PASS)..................................................................................................45
6.4.2. Configuration Information (CFG).............................................................................47
6.4.3. Clock (CLK) .........................................................................................................47
6.5. Setup - Range Configuration (RNGE) .............................................................................48
6.5.1. Physical and Analog Output Ranges.........................................................................49
6.5.2. Reporting Range Modes.........................................................................................49
6.5.3. Single Range mode (SNGL)....................................................................................50
6.5.4. Independent Range Mode (IND) .............................................................................50
6.5.5. Auto Range Mode (AUTO) ......................................................................................52
6.5.6. Range Units.........................................................................................................52
6.5.7. Dilution Ratio.......................................................................................................53
6.6. Setup - Internal Variables (VARS) .................................................................................55
6.7. Setup - Diagnostics (DIAG) ..........................................................................................57
6.7.1. Signal I/O ...........................................................................................................58
6.7.2. Analog Output Step Test........................................................................................59
6.7.3. Analog I/O Configuration .......................................................................................60
6.7.3.1. Analog Output Signal Type and Range Selection .................................................61
6.7.3.2. Analog Output Calibration Mode .......................................................................62
6.7.3.3. Manual Analog Output Calibration.....................................................................64
6.7.3.4. Analog Output Offset Adjustment .....................................................................65
6.7.3.5. Current Loop Output Adjustment ......................................................................66
6.7.3.6. AIN Calibration ..............................................................................................68
6.7.4. Test Channel Output .............................................................................................68
6.7.5. Optic Test ...........................................................................................................70
6.7.6. Electrical Test ......................................................................................................70
6.7.7. Ozone Generator Override .....................................................................................71
6.7.8. Flow Calibration ...................................................................................................72
6.8. Digital Inputs and Outputs ...........................................................................................72
6.8.1. Status Outputs.....................................................................................................72
6.8.2. Control Inputs......................................................................................................73
6.9. Setup - Communication Ports (COMM) ...........................................................................74
6.9.1. Analyzer ID .........................................................................................................75
6.9.2. COM Port Default Settings .....................................................................................75
6.9.3. COM Port Cable Connections ..................................................................................76
6.9.4. COM2 Configuration..............................................................................................76
6.9.5. DTE and DCE Communication.................................................................................77
6.9.6. COM Port Communication Modes ............................................................................77
6.9.7. COM Port Baud Rate .............................................................................................80
6.9.8. COM Port Testing .................................................................................................80
6.9.9. Ethernet Port Configuration....................................................................................81
6.9.10. Hessen Mode Configuration ..................................................................................84
6.10. Setup - Data Acquisition System (DAS) ........................................................................85
6.10.1. iDAS Structure ...................................................................................................86
6.10.1.1. iDAS Channels .............................................................................................86
6.10.1.2. iDAS Parameters ..........................................................................................87
6.10.1.3. iDAS Triggering Events..................................................................................88
6.10.2. Configuring the iDAS ...........................................................................................89
6.10.2.1. Default M200E iDAS Configuration ..................................................................89
6.10.2.2. Viewing iDAS Data and Settings .....................................................................91
6.10.2.3. Editing iDAS Data Channels ...........................................................................92
6.10.2.4. Trigger Events .............................................................................................93
iv 044100102 Rev A

Model 200E Instruction Manual M200E Documentation
6.10.2.5. Editing iDAS Parameters ............................................................................... 94
6.10.2.6. Sample Period and Report Period ................................................................... 95
6.10.2.7. Number of Records ...................................................................................... 97
6.10.2.8. RS-232 Report Function ................................................................................ 98
6.10.2.9. Compact Report........................................................................................... 99
6.10.2.10. Starting Date............................................................................................. 99
6.10.2.11. Disabling/Enabling Data Channels................................................................. 99
6.10.2.12. HOLDOFF Feature..................................................................................... 100
6.10.3. Remote iDAS Configuration................................................................................ 101
6.11. Remote Operation of the Analyzer............................................................................. 102
6.11.1. Basic Operation................................................................................................ 102
6.11.1.1. Terminal Operating Modes........................................................................... 102
6.11.1.2. Help Commands in Terminal Mode................................................................ 103
6.11.1.3. Command Syntax ...................................................................................... 103
6.11.1.4. Data Types ............................................................................................... 104
6.11.2. Status Reporting .............................................................................................. 105
6.11.3. Remote Access by Modem ................................................................................. 105
6.11.4. COM Port Password Security .............................................................................. 106
6.11.5. APICOM Remote Control Program ....................................................................... 107
6.11.6. Additional Communications Documentation .......................................................... 108
7. CALIBRATION PROCEDURES ..........................................................................................109
7.1. Calibration Preparations ............................................................................................ 109
7.1.1. Required Equipment, Supplies, and Expendables .................................................... 109
7.1.2. Zero Air ............................................................................................................ 109
7.1.3. Span Gas Standards ........................................................................................... 109
7.1.4. NO2Permeation Tubes ........................................................................................ 110
7.1.5. Calibration Gas Traceability ................................................................................. 110
7.1.6. Data Recording Devices ...................................................................................... 110
7.1.7. NO2Conversion Efficiency ................................................................................... 110
7.2. Manual Calibration.................................................................................................... 112
7.2.1. Connect Zero Air and Span Gases to the Analyzer................................................... 113
7.2.2. Set Expected NO and NOXSpan Gas Concentrations................................................ 113
7.2.3. Perform Zero/Span Calibration:............................................................................ 114
7.3. Calibration Checks.................................................................................................... 115
7.4. Calibration with Zero/Span Valves .............................................................................. 115
7.5. Calibration with IZS Option ........................................................................................ 117
7.6. Calibration Checks with IZS or Zero/Span Valves .......................................................... 119
7.7. Calibration With Independent or AUTO Ranges.............................................................. 120
7.7.1. Calibration in AUTO Range Mode .......................................................................... 120
7.7.2. Independent Range Mode.................................................................................... 121
7.7.3. Calibration With Remote Contact Closures ............................................................. 121
7.8. Automatic Calibration (AutoCal).................................................................................. 122
7.9. Calibration Quality Analysis........................................................................................ 124
8. EPA PROTOCOL CALIBRATION .......................................................................................127
8.1. Calibration of Equipment ........................................................................................... 127
8.2. Gas Phase Titration (GPT).......................................................................................... 129
8.2.1. GPT Principle of Operation ................................................................................... 129
8.2.2. GPT Calibrator Check Procedure ........................................................................... 129
8.2.3. Example GPT Calculation..................................................................................... 131
8.3. Multipoint Calibration Procedure ................................................................................. 132
8.3.1. Zero Calibration ................................................................................................. 133
8.3.2. Span Calibration ................................................................................................ 133
8.3.3. GPT NO2Calibration ........................................................................................... 134
8.4. Calibration Frequency ............................................................................................... 135
8.5. Other Quality Assurance Procedures............................................................................ 135
8.6. Summary of Quality Assurance Checks ........................................................................ 137
8.7. Short Calibration Checks ........................................................................................... 137
8.7.1. Zero/Span Check Procedures ............................................................................... 138
8.7.2. Precision Check ................................................................................................. 138
8.7.3. Precision Check Procedure................................................................................... 138
044100102 Rev A v

M200E Documentation Model 200E Instruction Manual
8.8. Certification of Working Standards .............................................................................. 138
8.8.1. Certification Procedures of Working Standards ........................................................ 139
8.8.1.1. Other Methods of Establishing Traceability ....................................................... 139
8.9. References............................................................................................................... 139
9. INSTRUMENT MAINTENANCE ........................................................................................ 141
9.1. Maintenance Schedule ............................................................................................... 141
9.2. Predictive Diagnostics................................................................................................ 143
9.3. Maintenance Procedures ............................................................................................ 143
9.3.1. Changing the Sample Particulate Filter .................................................................. 144
9.3.2. Changing the O3Dryer Particulate Filter................................................................. 145
9.3.3. Changing the Ozone Filter Chemical ...................................................................... 146
9.3.4. Rebuilding the External Sample Pump ................................................................... 147
9.3.5. Changing the Pump and IZS Dust Filters ................................................................ 148
9.3.6. Changing the IZS Permeation Tube ....................................................................... 148
9.3.7. Changing the External Zero Air Scrubber ............................................................... 149
9.3.8. Changing the NO2converter................................................................................. 150
9.3.9. Cleaning the Reaction Cell ................................................................................... 151
9.3.10. Cleaning or Changing Critical Flow Orifices ........................................................... 153
9.3.11. Checking for Light Leaks.................................................................................... 154
10. THEORY OF OPERATION .............................................................................................. 155
10.1. Measurement Principle............................................................................................. 155
10.1.1. Chemiluminescence .......................................................................................... 155
10.1.2. NOX and NO2Determination................................................................................ 156
10.1.3. Chemiluminescence Detection ............................................................................ 157
10.1.3.1. The Photo Multiplier Tube ............................................................................ 157
10.1.3.2. Optical Filter.............................................................................................. 158
10.1.4. Auto Zero ........................................................................................................ 158
10.1.5. Measurement Interferences................................................................................ 159
10.1.5.1. Direct Interference ..................................................................................... 159
10.1.5.2. Third Body Quenching................................................................................. 159
10.1.5.3. Light Leaks................................................................................................ 161
10.2. Pneumatic Operation ............................................................................................... 161
10.2.1. Pump and Exhaust Manifold ............................................................................... 161
10.2.2. Sample Gas Flow .............................................................................................. 162
10.2.3. Sample Particulate Filter .................................................................................... 163
10.2.4. Ozone Gas Air Flow........................................................................................... 164
10.2.5. O3Generator ................................................................................................... 164
10.2.6. Perma Pure®Dryer ........................................................................................... 165
10.2.7. Ozone Supply Air Filter ...................................................................................... 166
10.2.8. Ozone Scrubber................................................................................................ 167
10.2.9. Flow Rate Control - Critical Flow Orifices .............................................................. 167
10.2.10. Pneumatic Sensors.......................................................................................... 170
10.2.10.1. Sample Pressure Sensor ............................................................................ 170
10.2.10.2. Vacuum Pressure Sensor ........................................................................... 170
10.2.10.3. O3Supply Air Flow Sensor ......................................................................... 170
10.3. Electronic Operation ................................................................................................ 171
10.3.1. CPU ................................................................................................................ 172
10.3.1.1. Disk On Chip ............................................................................................. 173
10.3.1.2. Flash Chip ................................................................................................. 173
10.3.2. Sensor Module, Reaction Cell & PMT .................................................................... 173
10.3.2.1. Reaction Cell Heating Circuit ........................................................................ 173
10.3.2.2. Photo Multiplier Tube (PMT) ......................................................................... 174
10.3.2.3. PMT Cooling System ................................................................................... 174
10.3.2.4. TEC Control Board ...................................................................................... 175
10.3.2.5. PMT Preamplifier ........................................................................................ 175
10.3.3. Pneumatic Sensor Board .................................................................................... 176
10.3.4. Relay Board ..................................................................................................... 177
10.3.4.1. Heater Control ........................................................................................... 177
10.3.4.2. Valve Control............................................................................................. 177
10.3.4.3. Status LEDs............................................................................................... 177
vi 044100102 Rev A

Model 200E Instruction Manual M200E Documentation
10.3.5. Motherboard.................................................................................................... 178
10.3.5.1. A to D Conversion ...................................................................................... 178
10.3.5.2. Sensor Inputs............................................................................................ 178
10.3.5.3. Thermistor Interface................................................................................... 179
10.3.5.4. Analog Outputs.......................................................................................... 179
10.3.5.5. External Digital I/O .................................................................................... 180
10.3.5.6. I2C Data Bus ............................................................................................. 180
10.3.5.7. Power-up Circuit ........................................................................................ 180
10.3.6. Power Supply/ Circuit Breaker ............................................................................ 180
10.3.7. Communications Interface ................................................................................. 181
10.3.7.1. Front Panel ............................................................................................... 182
10.3.7.2. Display..................................................................................................... 182
10.3.7.3. Keypad..................................................................................................... 183
10.3.7.4. Front Panel States LED’s ............................................................................. 183
10.3.7.5. Display / Keyboard Interface Electronics........................................................ 183
10.4. Software Operation ................................................................................................. 184
10.4.1. Adaptive Filter ................................................................................................. 184
10.4.2. Calibration - Slope and Offset............................................................................. 185
10.4.3. Temperature/Pressure Compensation (TPC) ......................................................... 186
10.4.4. NO2Converter Efficiency Compensation ............................................................... 187
10.4.5. Internal Data Acquisition System (iDAS) .............................................................. 187
11. TROUBLESHOOTING & REPAIR ....................................................................................189
11.1. General Troubleshooting .......................................................................................... 189
11.1.1. Warning Messages............................................................................................ 190
11.1.2. Fault Diagnosis with Test Functions..................................................................... 190
11.1.3. Using the Diagnostic Signal I/O Function.............................................................. 191
11.1.4. Status LED’s .................................................................................................... 192
11.1.4.1. Motherboard Status Indicator (Watchdog) ..................................................... 192
11.1.4.2. CPU Status Indicator .................................................................................. 193
11.1.4.3. Relay Board and Status LEDs....................................................................... 193
11.2. Gas Flow Problems.................................................................................................. 195
11.2.1. Zero or Low Flow Problems ................................................................................ 196
11.2.1.1. Sample Flow is Zero or Low......................................................................... 196
11.2.1.2. Ozone Flow is Zero or Low .......................................................................... 197
11.2.2. High Flow........................................................................................................ 198
11.2.3. Sample Flow is Zero or Low But Analyzer Reports Correct Flow ............................... 198
11.3. Calibration Problems ............................................................................................... 198
11.3.1. Negative Concentrations.................................................................................... 198
11.3.2. No Response ................................................................................................... 199
11.3.3. Unstable Zero and Span .................................................................................... 200
11.3.4. Inability to Span - No SPAN Key ......................................................................... 200
11.3.5. Inability to Zero - No ZERO Key.......................................................................... 201
11.3.6. Non-Linear Response ........................................................................................ 201
11.3.7. Discrepancy Between Analog Output and Display .................................................. 202
11.3.8. Discrepancy between NO and NOXslopes ............................................................. 202
11.4. Other Performance Problems .................................................................................... 202
11.4.1. Excessive noise................................................................................................ 203
11.4.2. Slow Response................................................................................................. 203
11.4.3. Auto-zero Warnings .......................................................................................... 203
11.5. Subsystem Checkout............................................................................................... 204
11.5.1. Simple Vacuum Leak and Pump Check................................................................. 204
11.5.2. Detailed Pressure Leak Check............................................................................. 204
11.5.3. Performing a Sample Flow Check ........................................................................ 205
11.5.4. AC Power Configuration..................................................................................... 206
11.5.5. DC Power Supply.............................................................................................. 206
11.5.6. I2C Bus ........................................................................................................... 207
11.5.7. Keyboard / Display Interface.............................................................................. 207
11.5.8. Relay Board..................................................................................................... 208
11.5.9. Motherboard.................................................................................................... 208
11.5.9.1. A/D functions ............................................................................................ 208
044100102 Rev A vii

M200E Documentation Model 200E Instruction Manual
11.5.9.2. Analog Output Voltages............................................................................... 208
11.5.9.3. Status Outputs........................................................................................... 209
11.5.9.4. Control Inputs ........................................................................................... 209
11.5.10. CPU .............................................................................................................. 210
11.5.11. RS-232 Communication ................................................................................... 210
11.5.11.1. General RS-232 Troubleshooting................................................................. 210
11.5.11.2. Modem or Terminal Operation .................................................................... 211
11.5.12. PMT Sensor.................................................................................................... 211
11.5.13. PMT Preamplifier Board.................................................................................... 211
11.5.14. High Voltage Power Supply............................................................................... 212
11.5.15. Pneumatic Sensor Assembly ............................................................................. 212
11.5.15.1. Reaction Cell Pressure ............................................................................... 213
11.5.15.2. Sample Pressure ...................................................................................... 213
11.5.15.3. Ozone Flow.............................................................................................. 214
11.5.16. NO2Converter ................................................................................................ 214
11.5.17. O3Generator.................................................................................................. 216
11.5.18. IZS Option ..................................................................................................... 216
11.5.19. Box Temperature ............................................................................................ 216
11.5.20. PMT Temperature............................................................................................ 217
11.6. Repair Procedures ................................................................................................... 217
11.6.1. Disk-on-Chip Replacement ................................................................................. 217
11.6.2. Flash Chip Replacement or Upgrade .................................................................... 218
11.6.3. O3Generator Replacement................................................................................. 218
11.6.4. Sample and Ozone Dryer Replacement ................................................................ 219
11.6.5. PMT Sensor Hardware Calibration........................................................................ 219
11.6.6. Replacing the PMT, HVPS or TEC ......................................................................... 221
11.7. Technical Assistance................................................................................................ 223
viii 044100102 Rev A

Model 200E Instruction Manual M200E Documentation
LIST OF FIGURES
Figure 3-1: Location of Shipping Screws and Power Configuration Plug............................... 10
Figure 3-2: M200E Layout............................................................................................ 11
Figure 3-3: M200E Rear Panel Layout ............................................................................ 12
Figure 3-4: M200E Front Panel Layout ........................................................................... 12
Figure 3-5: Basic Pneumatic Connections for Units Without Valve Options........................... 14
Figure 3-6: Basic Pneumatic Connections for Units With Valve Options ............................... 16
Figure 3-7: Analog Output Connector ............................................................................ 17
Figure 3-8: Status Output Connector............................................................................. 18
Figure 3-9: Control Input Connector.............................................................................. 19
Figure 3-10: Front Panel Display During Startup Sequence................................................. 21
Figure 3-11: M200E Pneumatic Diagram In Standard Configuration ..................................... 24
Figure 3-12: M200E Pneumatic Diagram With Options Installed .......................................... 25
Figure 5-1: Current Loop Option Installed on the Motherboard .......................................... 34
Figure 5-2: M200E Ethernet Card and Rear Panel With Ethernet Installed ........................... 39
Figure 6-1: Analog Output Connector Key ...................................................................... 48
Figure 6-2: Setup for Calibrating Analog Outputs ............................................................ 64
Figure 6-3: Setup for Calibrating Current Outputs ........................................................... 67
Figure 6-4: Status Output Connector............................................................................. 73
Figure 6-5: Control Inputs with Local and External 5 V Power Supply ................................. 74
Figure 6-6: APICOM Graphical User Interface for Configuring the iDAS ..............................101
Figure 6-7: iDAS Configuration Through a Terminal Emulation Program.............................102
Figure 6-8: APICOM Remote Control Program Interface...................................................107
Figure 7-1: Gas Supply Setup for Determination of NO2Conversion Efficiency ....................111
Figure 7-2: Setup for Manual Calibration without Z/S valve or IZS Option..........................113
Figure 7-3: Pneumatic Connections for Manual Calibration Checks with IZS........................117
Figure 7-4: Setup for Manual Calibration Check with Z/S Valve or IZS Option.....................119
Figure 8-1: GPT Calibration System..............................................................................133
Figure 9-1: Sample Particulate Filter Assembly ..............................................................144
Figure 9-2: Particle Filter on O3Supply Air Dryer............................................................145
Figure 9-3: 04419 Ozone Filter Unit .............................................................................146
Figure 9-4: Zero Air Scrubber Assembly........................................................................150
Figure 9-5: NO2Converter Assembly ............................................................................151
Figure 9-6: Reaction Cell Assembly ..............................................................................152
Figure 9-7: Critical Flow Orifice Assembly......................................................................153
Figure 10-1: M200E Sensitivity Spectrum .......................................................................156
Figure 10-2: NO2Conversion Principle ............................................................................157
Figure 10-3: Reaction Cell with PMT Tube .......................................................................158
Figure 10-4: Reaction Cell During the AutoZero Cycle.......................................................159
Figure 10-5: External Pump Pack...................................................................................162
Figure 10-6: Ozone Generator Principle ..........................................................................164
Figure 10-7: Semi-Permeable Membrane Drying Process...................................................165
Figure 10-8: M200E Perma Pure®Dryer..........................................................................166
Figure 10-9: Location of Flow Control Assemblies.............................................................168
Figure 10-10: Flow Control Assembly & Critical Flow Orifice ................................................168
Figure 10-11: M200E Electronic Block Diagram..................................................................171
Figure 10-12: M200E CPU Board Annotated ......................................................................172
Figure 10-13: Schematic of Basic PMT Design and Functionality...........................................174
Figure 10-14: PMT Preamp Block Diagram ........................................................................176
Figure 10-15: Power Distribution Block Diagram ................................................................181
Figure 10-16: M200E Electronic Interface Block Diagram ....................................................182
Figure 10-17: Keyboard and Display Interface Block Diagram..............................................184
044100102 Rev A ix

M200E Documentation Model 200E Instruction Manual
Figure 10-18: Schematic of Basic Software Operation ........................................................185
Figure 11-1: Viewing and Clearing Warning Messages ......................................................190
Figure 11-2: Switching Signal I/O Functions....................................................................192
Figure 11-3: Motherboard Watchdog Status Indicator .......................................................193
Figure 11-4: Relay Board PCA .......................................................................................194
Figure 11-5: Pressure / Flow Sensor Assembly ................................................................214
Figure 11-6: Pre-Amplifier Board Layout.........................................................................220
Figure 11-7: M200E Sensor Assembly ............................................................................222
Figure A-1: Basic Sample Display Menu ........................................................................226
Figure A-2: Sample Display Menu - Units with Z/S Valve or IZS Option installed .................227
Figure A-3: Primary Setup Menu (Except iDAS)..............................................................228
Figure A-4: Secondary Setup Menu (COMM & VARS).......................................................229
Figure A-5: Secondary Setup Menu (DIAG) ...................................................................230
Figure A-6: Internal Data Acquisition (iDAS) Menu .........................................................231
x 044100102 Rev A

Model 200E Instruction Manual M200E Documentation
LIST OF TABLES
Table 2-1: Model 200E Basic Unit Specifications............................................................... 5
Table 3-1: Inlet / Outlet Connector Nomenclature .......................................................... 13
Table 3-2: Analog Output Pin-Outs............................................................................... 18
Table 3-3: Status Output Signals ................................................................................. 18
Table 3-4: Control Input Signals .................................................................................. 19
Table 3-5: Front Panel Display During System Warm-Up ................................................. 21
Table 3-6: Possible Warning Messages at Start-Up ......................................................... 22
Table 5-1: IZS or Z/S Valve States .............................................................................. 35
Table 5-2: Available Permeation Source Options ............................................................ 36
Table 5-3: Contents of Zero Air Scrubber Maintenance Kit ............................................... 37
Table 5-4: Dryer and NH3Removal Options................................................................... 39
Table 6-1: Analyzer Operating modes........................................................................... 41
Table 6-2: Test Functions Defined................................................................................ 43
Table 6-3: List of Warning Messages Revision C.4 .......................................................... 44
Table 6-4: Password Levels......................................................................................... 45
Table 6-5: Variable Names (VARS) Revision C.4............................................................. 55
Table 6-6: M200E Diagnostic (DIAG) Functions.............................................................. 57
Table 6-7: DIAG - Analog I/O Functions........................................................................ 60
Table 6-8: Analog Output Voltage Ranges ..................................................................... 60
Table 6-9: Analog Output Current Loop Range............................................................... 61
Table 6-10: Analog Output Pin Assignments.................................................................... 61
Table 6-11: Voltage Tolerances for Analog Output Calibration............................................ 64
Table 6-12: Current Loop Output Calibration with Resistor ................................................ 68
Table 6-13: Test Parameters Available for Analog Output A4 ............................................. 69
Table 6-14: Status Output Pin Assignments .................................................................... 73
Table 6-15: Control Input Pin Assignments ..................................................................... 74
Table 6-16: COM1 and COM2 DB-9 Pin Assignments ........................................................ 77
Table 6-17: COM Port Communication Modes .................................................................. 78
Table 6-18: Ethernet Status Indicators........................................................................... 81
Table 6-19: Front Panel LED Status Indicators for iDAS .................................................... 85
Table 6-20: iDAS Data Channel Properties ...................................................................... 87
Table 6-21: iDAS Data Parameter Functions.................................................................... 88
Table 6-22: M200E Default iDAS Configuration, Revision C.7. ............................................ 90
Table 6-23: Terminal Mode Software Commands ............................................................103
Table 6-24: Command Types .......................................................................................104
Table 6-25: Serial Interface Documents ........................................................................108
Table 7-1: IZS Option Valve States with CAL_ON_NO2Turned ON ...................................117
Table 7-2: AutoCal Modes..........................................................................................122
Table 7-3: AutoCal Attribute Setup Parameters.............................................................122
Table 7-4: Example Auto-Cal Sequence .......................................................................123
Table 7-5: Calibration Data Quality Evaluation..............................................................125
Table 8-1: Activity Matrix for EPA Calibration Equipment and Supplies .............................128
Table 8-2: Activity Matrix for Calibration Procedure .......................................................128
Table 8-3: Definition of Level 1 and Level 2 Zero and Span Checks..................................136
Table 8-4: Activity Matrix for Data Quality ...................................................................137
Table 9-1: M200E Preventive Maintenance Schedule......................................................141
Table 9-2: Predictive Uses for Test Functions................................................................143
Table 10-1: List of Interferents ....................................................................................160
Table 10-2: M200E Valve Cycle Phases..........................................................................163
Table 10-3: M200E Gas Flow Rates...............................................................................169
Table 10-4: Front Panel Status LED’s ............................................................................183
044100102 Rev A xi

M200E Documentation Model 200E Instruction Manual
Table 11-1: Test Functions - Possible Causes for Out-Of-Range Values ..............................191
Table 11-2: Relay Board Status LEDs ............................................................................195
Table 11-3: DC Power Test Point and Wiring Color Code ..................................................206
Table 11-4: DC Power Supply Acceptable Levels .............................................................207
Table 11-5: Relay Board Control Devices .......................................................................208
Table 11-6: Analog Output Test Function - Nominal Values ..............................................209
Table 11-7: Status Outputs Check ................................................................................209
xii 044100102 Rev A

Model 200E Instruction Manual M200E Documentation
LIST OF APPENDICES
APPENDIX A: SOFTWARE DOCUMENTATION............................................................225
APPENDIX A-1: M200E Software Menu Trees and Index, Revision C.8 ............................... 226
APPENDIX A-2: Setup Variables For Serial I/O, Revision C.8 ............................................ 232
APPENDIX A-3: Warnings and Test Measurements, Revision C.8 ...................................... 241
APPENDIX A-4: M200E Signal I/O Definitions, Revision C.8 ............................................. 243
APPENDIX A-5: M200E Trigger Events and iDAS Functions, Revision C.8 ........................... 246
APPENDIX A-6: Terminal Command Designators, Revision C.8 ......................................... 248
APPENDIX B: SPARE PARTS AND EXPENDABLES .....................................................251
APPENDIX C: REPAIR QUESTIONNAIRE - M200E.....................................................257
APPENDIX D: DIAGRAMS AND SCHEMATICS............................................................259
044100102 Rev A xiii

M200E Documentation Model 200E Instruction Manual
USER NOTES:
xiv 044100102 Rev A

Model 200E Instruction Manual M200E Documentation
1. M200E DOCUMENTATION
1.1. Available Documentation
Thank you for purchasing the Model 200E Nitrogen Oxides Analyzer! The documentation for
this instrument is available in different formats:
• Printed format, part number 044100100
• Electronic format on a CD-ROM, part number 044100200
The electronic manual is in Adobe®Systems Inc. “Portable Document Format” (PDF). The
Adobe®Acrobat Reader®software, which is necessary to view these files, can be
downloaded for free from the internet at http://www.adobe.com/.
The electronic version of the manual has many advantages:
• Keyword and phrase search feature
• Figures, tables and internet addresses are linked so that clicking on the item will
display the associated feature or open the website.
• A list of chapters and sections as well as thumbnails of each page are displayed to
the left of the text.
• Entries in the table of contents are linked to the corresponding locations in the
manual.
• Ability to print sections (or all) of the manual
Additional documentation for the Model 200E Nitrogen Oxides Analyzer is available from T-
API’s website at http://www.teledyne-api.com/manuals/
• APICOM software manual, part number 03945
• Multi-drop manual, part number 02179
• DAS manual, part number 02837.
• Ethernet configuration document, part number 04324.
Other documentation may be added to the website in the future.
1.2. Manual Structure
1.0 Table of Contents:
Outlines the contents of the manual in the order the information is presented. This is a good
overview of the topics covered in the manual. There is also a list of appendices, figures and
tables. In the electronic version of the manual, clicking on a any of these table entries
automatically views that section.
044100102 Rev A 1

M200E Documentation Model 200E Instruction Manual
2.0 Specifications and Warranty
A list of the analyzer’s performance specifications, a description of the conditions and
configuration under which EPA equivalency was approved and T-API’s warranty statement.
3.0 Getting Started
Concise instructions for setting up, installing and running your analyzer for the first time.
4.0 FAQ & Glossary:
Answers to the most frequently asked questions about operating the analyzer and a
glossary of acronyms and technical terms.
5.0 Optional Hardware & Software
A description of optional equipment to add functionality to your analyzer.
6.0 Operation Instructions
Step by step instructions for operating the analyzer.
7.0 Calibration Procedures
General information and step by step instructions for calibrating your analyzer.
8.0 EPA Protocol Calibration
Specific information regarding calibration requirements for analyzers used in EPA-regulated
monitoring applications.
9.0 Instrument Maintenance
Description of preventative maintenance procedures that should be regularly performed on
you instrument to assure good operating condition. This includes information on using the
iDAS to predict possible component failures before they happen.
10.0 Theory of Operation
An in-depth look at the various principals by which your analyzer operates as well as a
description of how the various electronic, mechanical and pneumatic components of the
instrument work and interact with each other. A close reading of this section is invaluable
for understanding the instrument’s operation.
11.0 Troubleshooting & Repair
This section includes pointers and instructions for diagnosing problems with the instrument,
such as excessive noise or drift, as well as instructions on performing repairs of the
instrument’s major subsystems.
Appendices
For easier access and better updating, some information has been separated out of the
manual and placed in a series of appendices at the end of this manual. These include
2 044100102 Rev A

Model 200E Instruction Manual M200E Documentation
version-specific software menu trees, warning messages, definitions of iDAS & serial I/O
variables as well as spare part listings, repair questionnaire, interconnect drawing, detailed
pneumatic and electronic schematics.
1.3. How to use this Instruction Manual
Throughout this manual, words printed in capital, bold letters, such as SETUP or ENTR
represent messages as they appear on the analyzer’s front panel display.
The flowcharts in this manual contain typical representations of the analyzer’s display
during the described operations. These representations are not necessarily exact and may
differ slightly from the actual display of your instrument.
NOTE:
Warnings and special notes are called out in bold,
centered frames such as this one.
Cautionary notes with special symbols such as this one may appear
throughout the manual indicating hazardous operations requiring
either trained, technical personnel or particular attention.
044100102 Rev A 3

M200E Documentation Model 200E Instruction Manual
USER NOTES:
4 044100102 Rev A

Model 200E Instruction Manual Specifications, Approvals and Warranty
2. SPECIFICATIONS, APPROVALS AND
WARRANTY
2.1. M200E Operating Specifications
Table 2-1: Model 200E Basic Unit Specifications
Min/Max Range
(Physical Analog Output)
Min: 0-50 ppb
Max: 0-20 ppm
Measurement Units ppb, ppm, µg/m3, mg/m3(user selectable)
Zero Noise10.2 ppb (RMS)
Span Noise1<0.5% of reading above 50 ppb or 0.2 ppm, whichever is greater
Lower Detectable Limit20.4 ppb
Zero Drift (24 hours) <0.5 ppb (at constant temperature and voltage.)
Zero Drift (7 days) 1 ppb (at constant temperature and voltage.)
Span Drift (7 Days) <0.5% of full Scale (at constant temperature and voltage.)
Linearity 1% of full scale
Precision 0.5% of reading
Temperature Coefficient < 0.1% per °C
Voltage Coefficient < 0.1% per V
Lag Time1 20 s
Rise/Fall Time195% in <60 s
Sample Flow Rate 500 cm3/min. ± 10%
Temperature Range 5 - 40 °C operating and EPA equivalency
Humidity Range 0-95% RH non-condensing
Dimensions H x W x D 18 cm x 43 cm x 61 cm (7" x 17" x 23.6")
Weight, Analyzer 18 kg (40 lbs)
Weight, Ext Pump Pack 7 kg (16 lbs)
AC Power Rating 100 V, 50/60 Hz (3.25A);
115 V, 60 Hz (3.0 A);
220 - 240 V, 50/60 Hz (2.5 A)
Power, Ext Pump 100 V, 50/60 Hz (3.25A); 115 V, 60 Hz (3.0 A);
220 - 240 V, 50/60 Hz (2.5 A)
Environmental Installation category (over-voltage category) II; Pollution degree 2
Analog Outputs 4 outputs
Analog Output Ranges All Outputs: 0.1 V, 1 V, 5 V or 10 V (user selectable)
Three outputs convertible to 4-20 mA isolated current loop.
All Ranges with 5% under/over range
Analog Output Resolution 1 part in 4096 of selected full-scale voltage (12 bit)
Status Outputs 8 Status outputs from opto-isolators, 7 defined, 1 spare
Control Inputs 6 Control inputs, 4 defined, 2 spare
Serial I/O 1 RS-232; 1 RS-485 or RS-232 (configurable)
Communication speed: 300 - 115200 baud (user selectable)
Certifications USEPA: Reference Method Number RFNA 1194-099
CE: EN61326 (1997 w/A1: 98) Class A, FCC Part 15 Subpart B Section
15.107 Class A, ICES-003 Class A (ANSI C63.4 1992) & AS/NZS 3548
(w/A1 & A2; 97) Class A.
1As defined by the USEPA.
2Defined as twice the zero noise level by the USEPA.
044100102 Rev A 5
