Teledyne TED 191 User manual

i
TELEDYNEELECTRONICTECHNOLOGIES
AnalyticalInstruments
TED '
PORTABLE OXYGEN MONITOR
INSTRUCTION MANUAL
TYPE B EQUIPMENT: Equipment providing a particular degree of protec-
tion against electric shock, particularly regarding—
• allowable LEAKAGE CURRENT
• Reliability of the protective earth connection
(if present).
P/N TM0021
04/03/00
ECO # 00-0086

2
TELEDYNE ELECTRONIC TECHNOLOGIES
Analytical Instruments
COPYRIGHT © 1996
TELEDYNE ELECTRONIC TECHNOLOGIES – ANALYTICAL INSTRUMENTS
All Rights Reserved
No part of this manual may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any other language or computer language in
whole or in part, in any form or by any means, whether it be electronic,
mechanical, manual, or otherwise, without the prior written consent of Teledyne
Electronic Technologies Analytical Instruments, 16830 Chestnut Street, City of
Industry, CA 91749-1580
Phone [phone]
FAX [phone]
Technical Support: [phone]
TWX [phone] TDYANLY COID
or your local representative.
WARRANTY STATEMENT
The electronic control and display components of the TED 191 Portable Oxygen
Monitor are warranted against defective workmanship and materials for 24
months from date of shipment from Teledyne.
The class T-7 Micro-Fuel Cell is warranted for one year from the date of shipment
from Teledyne.
The liability of Teledyne, if any, shall be limited solely to the replacement and
repair of the goods, and shall not include shipping costs or other incidental
damages as defined in Section 2-715 of the U.S Uniform Commercial Code.
This warranty is null and void if any goods are subjected to misuse, negligence,
accident or repairs other than those performed by Teledyne or an authorized
service center.
Caution: Federal Law restricts this device to sale by or on the order of a
physician.

3
TELEDYNE ELECTRONIC TECHNOLOGIES
Analytical Instruments
TABLE OF CONTENTS
SECTION TOPIC PAGE NUMBER
INTRODUCTION 4
APPLICATIONS 5
DESCRIPTIONS OF FUNCTIONAL ZONES:
FRONT PANEL 6
REAR PANEL 7
1. OPERATIONS:
1.1 SET-UP 8
1.2 INSTALL THE BATTERIES
9
1.3 INSTALL THE SENSOR 10
1.4 CALIBRATE THE INSTRUMENT 11
1.5 NORMAL OPERATION 12
1.6 SET THE ALARMS 13
2. ANAESTHETIC AGENTS 14
3. CLEANING 15
4. DO’S AND DON’T’S 16
5. ROUTINE MAINTENANCE .17
6. TROUBLESHOOTING 18
7. TECHNICAL SPECIFICATIONS 20
8. EFFECT OF PRESSURE 22
9. EFFECT OF HUMIDITY 23
10. EFFECT OF TEMPERATURE 24
11. DISCREPANCY IN READING 25
12. REPAIR SERVICE 26
SENSOR CELL REPLACEMENT LOG 27
TECHNICAL SERVICE LOG 28
GENERAL NOTES 29
SPARE PARTS LIST 30

4
TELEDYNE ELECTRONIC TECHNOLOGIES
Analytical Instruments
INTRODUCTION
The TED 191 Portable Oxygen Monitor is an easy-to-use, portable instrument that provides fast
and accurate oxygen monitoring and audio-visual alarm capability. The TED 191 is designed to
monitor concentrations of up to 100% oxygen in medical gas mixtures.
The TED 191 Portable Oxygen Monitor is designed and manufactured in accordance with strict
performance and quality protocols and subject to ISO 9002 Quality System protocols. When used
correctly, this instrument will provide you with many years of trouble free service.
The TED 191 Portable Oxygen Monitor is a compact, self-contained unit, which is battery powered
by four (4) dry cell batteries (size AA/penlight).

5
TELEDYNE ELECTRONIC TECHNOLOGIES
Analytical Instruments
APPLICATIONS
The instrument is designed for the measurement of oxygen concentrations in a variety of medical
gas mixtures. It is recommended that the instrument be used only as a secondary measuring
device to verify the concentration of oxygen in gas mixtures prepared using a gas blender or
similar apparatus. The use of this monitor as a primary or only means of preparing gas mixtures is
not advised.
The monitor is capable of verifying oxygen concentrations in gas mixtures used in:
•Anesthesia
•Neonatal Intensive care
•Adult Intensive care
•Respiratory / Oxygen Therapy

6
TELEDYNE ELECTRONIC TECHNOLOGIES
Analytical Instruments
21
30
40
50 60
70
80
90
102
21
30
40
50 60
70
80
90
102
LO
HI
X21
TELEDYNE
% OXYGEN
OXYGEN MONITOR I O
DESCRIPTION OF FUNCTIONAL ZONES
FRONT PANEL
On / Off Switch Allows the operator to turn the instrument on and off.
Alarm Mute Switch Allows the operator to “mute” the sound of the audible alarm
signal for ± 60 seconds. During this time, a red signal lamp will
flash, indicating a “muted” alarm condition is in force.
Calibration Control Allows the operator to calibrate the instrument to one primary set
point (usually 100%) in accordance with the designated calibration
protocol. This protocol is defined further in this manual and also.
Instructions in abbreviated form can be found on the top of the
monitor casing.
High Alarm Setting Allows the operator to define a high alarm threshold limit. Range
18% to 102% - if the actual measured value as displayed on the
LCD exceeds this set threshold, an audible and visual alarm
condition will be invoked.
Low alarm setting Knob Allows the operator to define a low alarm threshold limit. Range
18% to 100% - if the actual measured value as displayed on the
LCD falls below this set threshold, an audible and visual alarm
condition will be invoked.
Liquid Crystal Display Displays measured oxygen concentration, low battery condition
and provides a visual indication of either a high (+) or low (-) alarm
threshold violation.
Alarm Mute ButtonHigh Alarm Setting Knob Calibration Control
Liquid Crystal Display (LCD) On / Off Switch
Low Alarm Setting Knob

7
TELEDYNE ELECTRONIC TECHNOLOGIES
Analytical Instruments
DESCRIPTION OF FUNCTIONAL ZONES
REAR PANEL
Battery Drawer The Battery Drawer contains 4 x AA (Penlight) batteries
required to power the instrument.
Sensor Cable Connector Plug The Oxygen Sensor Connector Cable is plugged into this
“one way” socket.
Battery Drawer Sensor Cable Connector Plug

8
TELEDYNE ELECTRONIC TECHNOLOGIES
Analytical Instruments
SECTION ONE
OPERATIONS
Note : Upon receipt, inspect the entire unit and accompanying accessories for damage or broken
or loose parts. If damaged, do not use. Notify the Shipper, and consult Teledyne
Electronic Technologies Analytical Instruments
1.1 SET-UP
To set-up your TED 191 Portable Oxygen Monitor :
1.1.1 Install the Batteries
See 1.2 below for procedure
1.1.2 Install the Sensor
See 1.3 below for procedure
1.1.3 Calibrate the Instrument
See 1.4 below for procedure
1.1.4 Normal Operation
See 1.5 below for procedure
1.1.5 Set the Alarms
See 1.6 below for procedure

9
TELEDYNE ELECTRONIC TECHNOLOGIES
Analytical Instruments
OPERATIONS
1.2 INSTALLING THE BATTERIES
Withdraw the battery drawer from the monitor casing, by grasping the side lugs located on
either side of the battery drawer, and, firmly pinching them inwards, simultaneously pull the
drawer outwards. When new, this action can be somewhat stiff and difficult to execute. Care
should be taken not to damage either the drawer or the casing of the monitor when
executing this procedure.
Fresh batteries must be inserted into the four battery recepticles located within the battery
drawer assembly. Care should be taken to ensure that the correct battery polarity is
maintained.
Caution : Improper installation of the batteries may result in heat damage to the
batteries.
Re-insert the battery drawer into the monitor casing, and close.

10
TELEDYNE ELECTRONIC TECHNOLOGIES
Analytical Instruments
OPERATIONS
1.3 INSTALLING THE OXYGEN SENSOR
The T-7 Oxygen Sensor must be installed before the instrument can be used.
Ensure that the monitor is switched off.
Remove the sensor from its protective bag. Inspect the sensor for damage or electrolyte
leakage. If the sensor is damaged obtain a replacement. Do not use the defective sensor as
it may be damaged.
Caution: the sensor electrolyte is caustic. Do not let it come into contact with skin. If it does,
immediately flush the affective area with water. Consult the Emergency First Aid procedures
as set out in the Material Safety Data Sheet for the sensor. Do not attempt to open or repair
the sensor. Leaking or exhausted sensors should be disposed of in accordance with local
regulations. Consult the Material safety Data Sheet supplied with the sensor.
Plug one end of the coiled cable into the telephone jack receptacle on the end of the
sensor. The jack will only fit one way, so if it does not fit, rotate it until it slides in easily.
Plug the other end of the coiled cable into the receptacle located on the right hand side of
the rear panel of the instrument. This jack will only fit one way, so do not force it.
Note : For sterilization procedures on the Oxygen Cell, see Section 3 on Page 15 below.
Caution : Do NOT autoclave the oxygen sensor
