Data Sheet
Cisco TelePresence SpeakerTrack 60 Camera
Product Overview
Optimize your videoconferencing experience so you can see your customers, partners, and colleagues up close
and personal, even when they are on the other side of the globe. The Cisco TelePresence®SpeakerTrack 60
Camera (SpeakerTrack 60) is an unparalleled dual-camera system that lets participants in a video meeting see
the active speaker on the other end of a conference - in full view. It enables rich, spontaneous collaboration to
help you manage costs, make decisions faster, improve customer intimacy, scale scarce resources, and speed
products to market.
In most videoconferences, the camera simply captures the whole meeting room, making all participants appear
small, especially if the conference is held in a large meeting room. Having the active speaker always appear in full
view provides an intimate, like-life experience that can be better than being there. Using two cameras that act
independently, SpeakerTrack 60 quickly tracks and displays active speakers, switching between them in an
instant. So meetings can progress fluidly, and speaker expressions and reactions are captured in real time.
The Cisco TelePresence portfolio is designed to create a delightful in-person experience over the network -
empowering you to collaborate with others like never before. Through a powerful combination of technologies and
design that lets you and remote participants feel as if you are all in the same room, the Cisco TelePresence
portfolio can transform your business. Many organizations are already using it to promote productivity and
innovation.
Figure 1. Cisco TelePresence SpeakerTrack 60
Product Features
SpeakerTrack 60 employs a unique dual-camera approach for fast, direct switching. One camera quickly locates a
close-up of the active speaker while the other gets ready to seek and display the next active speaker. Table 1
summarizes features of the camera.

© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 2 of 3
Table 1. Key Features of SpeakerTrack 60 Camera
Feature Summary
Sleek, sophisticated
design and features
●Fast, direct switching between active speakers delivers a continuous meeting experience.
●Multispeaker view prevents unnecessary switching when the next active speaker is already in the current shot.
●Automatic framing of all participants provides an ideal, dynamic overview of the full room.
●Sleek industrial design and wall-mount option enables discreet room set-up.
●Simple user interaction provides a consistent experience with the rest of the Cisco TelePresence products.
●True 1080p60 HD resolution delivers rich, vivid image quality002E.
Product Capabilities
Table 2 lists the product capability specifications for the SpeakerTrack 60 Camera.
Table 2. Product Specifications
Specification Description
Resolution 1920 x 1080 at 60 frames per second (fps)
Zoom ●10x optical zoom
●2x digital zoom
●20x zoom combined
Pan and tilt ●Pan range: +/-100 degrees
●Tilt range: +/-20 degrees
Field of view (FoV) ●Horizontal FoV: 80 degrees
●Vertical FoV: 48.8 degrees
●Tracking horizontal FoV: 80 degrees
Focus distance ●1.0m to infinity (wide)
F-value ●1.5
Camera control Ethernet
Focus, white balance, and
brightness
●Manual or automatic
IP network features ●Domain Name System (DNS) lookup for service configuration
●Date and time support through Network Time Protocol (NTP)
●TCP/IP
●Dynamic Host Configuration Protocol (DHCP)
Network interfaces ●One LAN or Ethernet (RJ-45) 10-/100-Mb
Video interfaces ●HDMI 1.4
Power ●12V/3A
●100-120 or 200-240 VAC; 50 or 60 Hz
Operating temperature and
humidity
●32 to 104°F (0 to 40°C) ambient temperature
●10 to 90% relative humidity (RH)
Storage and transport
temperature
●-4 to 140°F (-20 to 60°C) at RH 10-90% (noncondensing )
Dimensions and weight ●Length: 31.5 in. (80.0 cm)
●Height: 11.5 in. (29.2 cm)
●Depth: 8.3 in. (21.0 cm)
●Weight: 25.4 lb (11.5 kg)

© 2013 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 3 of 3
Ordering Information
To place an order, please contact your local Cisco representative and refer to Table 3.
Table 3. Ordering Information
Product Name Part Number Compliance Model Number
Cisco TelePresence SpeakerTrack 60 kit
(comes with Cameras, mounting bracket, microphone array and PSU) CTS-SPKER-TRACK60 TTC8-09
Cisco TelePresence Mounting Bracket spare CTS-ST-ARRAY60=
Cisco Service and Support
Cisco and our partners provide a broad portfolio of smart, personalized services and support that can help you
realize the full business value of your Cisco TelePresence investment by increasing business agility and network
availability. This portfolio of services accelerates business innovation by harnessing the network as a powerful
business platform. For more information about these services, please visit:
http://www.cisco.com/go/telepresenceservices.
