Teltonika FMM80A Installation guide

FMM80A
Simple OBDII tracker
Quick Manual v1.4

Quick Manual v1.4// FMM80A 2
CONTENT
Know your device................................................................................................................................................................................................3
Pinout ...................................................................................................................................................................................................................4
Set up your device ..............................................................................................................................................................................................5
PC Connection (Windows)..................................................................................................................................................................................6
How to install USB drivers (Windows) ..............................................................................................................................................................6
Conguration.......................................................................................................................................................................................................7
Quick SMS conguration....................................................................................................................................................................................9
Mounting recommendations.......................................................................................................................................................................... 11
Basic characteristics ........................................................................................................................................................................................ 12
LED indications................................................................................................................................................................................................. 12
Safety information .......................................................................................................................................................................................... 16
Certication and Approvals ............................................................................................................................................................................ 17
Warranty ........................................................................................................................................................................................................... 19
Warranty disclaimer ........................................................................................................................................................................................ 19

Quick Manual v1.4// FMM80A 3
KNOW YOUR DEVICE
OBDII
CONNECTOR
STATUS
LED
NAVIGATE
LED
MICRO-SIM
SLOT
BATTERY
SOCKET
MICRO-USB
TOP VIEW TOP VIEW (WITHOUT COVER)

Quick Manual v1.4// FMM80A 4
PIN NUMBER PIN NAME DESCRIPTION
4 GND (-) Ground
5 GND (-) Ground
16 VCC (10 - 30)V
DC(+)
Power supply (+10-30
V DC)
PINOUT
FMM80A OBDII socket pinout
PIN4 PIN5
PIN16

Quick Manual v1.4// FMM80A 5
SET UP YOUR DEVICE
HOW TO INSERT MICRO-SIM CARD AND CONNECT THE BATTERY
Device is ready to be
connected.
4
1COVER REMOVAL 3BATTERY CONNECTION 2MICRO-SIM CARD INSERT ATTACHING COVER BACK
Gently remove FMM80A
cover using plastic pry tool
from both sides.
Insert Micro-SIM card as
shown with PIN request
disabled or read our Wiki1
how to enter it later in
Teltonika Congurator2.
Make sure that Micro-
SIM card cut-o corner is
pointing forward to slot.
1 wiki.teltonika-gps.com/view/
FMM80A_Security_info
2 wiki.teltonika.lt/view/Teltonika_
Congurator
Connect battery as shown to
device. Position the battery
in place where it does not
obstruct other components.
Attach device cover back.

Quick Manual v1.4// FMM80A 6
PC CONNECTION (WINDOWS)
HOW TO INSTALL USB DRIVERS (WINDOWS)
1. Please download COM port drivers from here1.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the conrmation window will appear. Click Finish to complete the
setup.
1 wiki.teltonika-gps.com/images/d/d0/TeltonikaCOMDriver.zip
1. Power-up FMM80A with DC voltage (10 – 30 V) power supply using supplied power cable. LED’s should start blinking, see
“LED indications1”.
2. Connect device to computer using Micro-USB cable or Bluetooth connection:
• Using Micro-USB cable
• You will need to install USB drivers, see “How to install USB drivers (Windows)2”
• Using Bluetooth
• FMM80A Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add Bluetooth or other device
> Bluetooth. Choose your device named – “FMM80A_last_7_imei_digits”, without LE in the end. Enter default password
5555, press Connect and then select Done.
3. You are now ready to use the device on your computer.
1 wiki.teltonika-gps.com/view/FMM80A_LED_status
2 Page 6, "How to install USB drivers"

Quick Manual v1.4// FMM80A 7
MS .NET REQUIREMENTS
Operating system MS .NET Framework version Version Links
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET Framework 4.6.2 32 and 64 bit www.microsoft.com1
1 dotnet.microsoft.com/en-us/download/dotnet-framework/net462
At rst FMM80A device will have default factory settings set. These settings should be changed according to the users needs. Main
conguration can be performed via Teltonika Congurator1software. Get the latest Congurator version from here2. Congurator
operates on Microsoft Windows OS and uses prerequisite MS .NET Framework. Make sure you have the correct version installed.
1 wiki.teltonika-gps.com/view/Teltonika_Congurator
2 wiki.teltonika-gps.com/view/Teltonika_Congurator_versions
CONFIGURATION

Quick Manual v1.4// FMM80A 8
Downloaded Congurator will be in compressed archive.
Extract it and launch Congurator.exe. After launch software
language can be changed by clicking 🌐 in the right bottom
corner.
Conguration process begins by pressing on connected device.
FMM80A
Various Status window1 tabs display information about GNSS2,
GSM3, I/O4, Maintenance5 and etc. FMM80A has one user
editable prole, which can be loaded and saved to the device.
After any modication of conguration the changes need to
be saved to device using Save to device button. Main buttons
oer following functionality:
 Load from device – loads conguration from device.
 Save to device – saves conguration to device.
 Load from le – loads conguration from le.
 Save to le – saves conguration to le.
 Update rmware – updates rmware on device.
 Read records – reads records from the device.
 Reboot device – restarts device.
 Reset conguration – sets device conguration to
default.
Most important congurator section is GPRS – where all
your server and GPRS settings6 can be congured and Data
Acquisition7 – where data acquiring parameters can be
congured. More details about FMM80A conguration using
Congurator can be found in our Wiki8.
After connection to Congurator Status window will be
displayed.
FMM80A
1 wiki.teltonika-gps.com/view/FMM80A_Status_info
2 wiki.teltonika-gps.com/view/FMM80A_Status_info#GNSS_Info
3 wiki.teltonika-gps.com/view/FMM80A_Status_info#GSM_Info
4 wiki.teltonika-gps.com/view/FMM80A_Status_info#I.2FO_Info
5 wiki.teltonika-gps.com/view/FMM80A_Status_info#Maintenance
6 wiki.teltonika-gps.com/view/FMM80A_GPRS_settings
7 wiki.teltonika-gps.com/view/FMM80A_Data_acquisition_settings
8 wiki.teltonika-gps.com/view/FMM80A_Conguration

Quick Manual v1.4// FMM80A 9
QUICK SMS CONFIGURATION
Default conguration has optimal parameters present to ensure best performance of track quality and data usage.
Quickly set up your device by sending this SMS command to it:
Note: Before SMS text, two space symbols should be inserted.
GPRS SETTINGS:
 2001 – APN
 2002 – APN username (if there are no APN username,
empty eld should be left)
 2003 – APN password (if there are no APN password,
empty eld should be left)
SERVER SETTINGS:
 2004 – Domain
 2005 – Port
 2006 – Data sending protocol (0 – TCP, 1 – UDP)
« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»
1 2 3 4 5 6
1
2
3
4
5
6

Quick Manual v1.4// FMM80A 10
DEFAULT CONFIGURATION SETTINGS
MOVEMENT AND IGNITION DETECTION: DEVICE MAKES A RECORD ON MOVING
IF ONE OF THESE EVENTS HAPPEN:
SPEED DIFFERENCE
between last coordinate
and current position is
greater than 10 km/h
VEHICLE DRIVES
100 meters
VEHICLE TURNS
10 degrees
PASSES
300 seconds
After successful SMS conguration, FMM80A device will synchronize time and update records to congured server. Time intervals
and default I/O elements can be changed by using Teltonika Congurator1or SMS parameters2.
1 wiki.teltonika-gps.com/view/Teltonika_Congurator
2 wiki.teltonika-gps.com/view/Template:FMB_Device_Family_Parameter_list
VEHICLE MOVEMENT
will be detected by
accelerometer
DEVICE MAKES A
RECORD ON STOP IF:
1 HOUR PASSES
while vehicle is
stationary and
ignition is o
IGNITION
will be detected by
vehicle power voltage
between 13,2 – 30 V
RECORDS SENDING TO
SERVER:
EVERY 120 SECOND
it is sent to the server
If device has made a
record

Quick Manual v1.4// FMM80A 11
MOUNTING RECOMMENDATIONS
CONNECTING THE DEVICE TO THE VEHICLE:
Find OBDII connector in your vehicle.
Most common OBDII connector locations.

Quick Manual v1.4// FMM80A 12
BEHAVIOUR MEANING
Permanently
switched on GNSS signal is not received
Blinking every
second Normal mode, GNSS is working
O
GNSS is turned o because:
Device is not working or Device is in
sleep mode
Blinking fast
constantly Device rmware is being ashed
BEHAVIOUR MEANING
Blinking every
second Normal mode
Blinking every two
seconds Sleep mode
Blinking fast for a
short time Modem activity
O Device is not working or Device is in
boot mode
LED INDICATIONS
NAVIGATION LED INDICATIONS
STATUS LED INDICATIONS
BASIC CHARACTERISTICS
MODULE
Name Quectel BG95-M1
Technology LTE CAT M1/GNSS/BLUETOOTH
GNSS
GNSS
L1: GPS, GLONASS, GALILEO,
BEIDOU, SBAS*, QZSS*, DGPS*,
AGPS
Receiver 33 channel
Tracking sensitivity -165 dBM
Position Accuracy < 2.5 m CEP
Velocity Accuracy < 0.1 m/s (within +/- 15% error)
Hot start < 1 s
Warm start < 25 s
*Optional modes available with custom rmware applications, for more
information contact your sales manager.

Quick Manual v1.4// FMM80A 13
Cold start < 35 s
CELLUAR
Technology LTE CAT M1
4G bands
LTE-FDD (CAT M1):
B1/B2/B3/B4/B5/B8/B12/B13/B18/
B19/B20/B25/B26/B27/B28/B66/B85
Data transfer LTE: Max. 588Kbps (DL)/
Max.1119Kbps (UL)
Transmit power
Class 5 for LTE-FDD 21±2.7dBM
Bluetooth: 4.57±2dBM
Bluetooth LE: -4.83±2dBM
Data support
SMS (TEXT, PDU), Network
protocols (TCP,UDP,TLS, EGTS,
MQTT)
POWER
Input voltage range 10 - 30 V DC with overvoltage
protection
Back-up battery 115 mAh Li-Po battery 3.7 V (0.43
Wh)
Internal fuse 3A, 125V
Power Consumption
At 12V < 6.5 mA (Ultra Deep Sleep)
At 12V < 8 mA (Deep Sleep)
At 12V < 13 mA (Online Deep Sleep)
At 12V < 16.3 mA (GPS Sleep)
At 12V < 31 mA (nominal with no
load)
At 12V < 0.25A Max. (with full Load
/ Peak
BLUETOOTH
Specication 4.0 + LE
Supported
peripherals
Temperature and Humidity
sensor1, Inateck Barcode Scanner,
Universal BLE sensors support
INTERFACE
Connection OBDII socket
GNSS antenna Internal High Gain
GSM antenna Internal High Gain
USB 2.0 USB Micro B
LED indication 2 status LED lights
SIM Micro-SIM
Memory 128MB internal ash memory
1 https://teltonika.lt/product/bluetooth-sensor/

Quick Manual v1.4// FMM80A 14
PHYSICAL SPECIFICATION
Dimensions 67,2 x 49,6 x 25 mm (L x W x H)
Weight 63 g
OPERATING ENVIRONMENT
Operating
temperature
(without battery)
-40 °C to +85 °C
Storage temperature
(without battery) -40 °C to +85 °C
Operating
temperature
(with battery)
0 °C to +45 °C
Storage temperature
(with battery) -20 °C to +60 °C
Operating humidity 5% to 95% non-condensing
Ingress Protection
Rating IP41
Battery charge
temperature 0 °C to +45 °C
Battery discharge
temperature -20 °C to +60 °C
Battery storage
temperature
-20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
FEATURES
Sensors Accelerometer
Scenarios
Green Driving2, Over Speeding
detection3, Jamming detection4,
GNSS Fuel Counter5, Excessive
Idling detection6, Unplug
detection7, Towing detection8,
Crash detection9, Auto Geofence10,
Manual Geofence11, Trip 12
2 wiki.teltonika-gps.com/view/FMM80A_Features_settings#Eco.2FGreen_
Driving
3 wiki.teltonika-gps.com/view/FMM80A_Features_settings#Over_
Speeding
4 wiki.teltonika-gps.com/view/FMM80A_Features_settings#Jamming
5 wiki.teltonika-gps.com/view/FMM80A_Features_settings#GPS_Fuel_
Counter
6 wiki.teltonika-gps.com/view/FMM80A_Accelerometer_Features_
settings#Excessive_ Idling
7 wiki.teltonika-gps.com/view/FMM80A_Accelerometer_Features_
settings#Unplug_ Detection
8 wiki.teltonika-gps.com/view/FMM80A_Accelerometer_Features_
settings#Towing_ Detection
9 wiki.teltonika-gps.com/view/FMM80A_Accelerometer_Features_
settings#Crash_ Detection
10 wiki.teltonika-gps.com/view/FMM80A_Auto_Geofence_settings
11 wiki.teltonika-gps.com/view/FMM80A_Manual_Geofence_settings
12 wiki.teltonika-gps.com/view/FMM80A_Features_settings

Quick Manual v1.4// FMM80A 15
Sleep modes GPS Sleep13, Online Deep Sleep14,
Deep Sleep15, Ultra Deep Sleep16
Conguration and
rmware update
FOTA Web17, Teltonika
Congurator18 (USB, Bluetooth)
SMS Conguration, Events, DOUT
control, Debug
GPRS commands Conguration, DOUT control, Debug
Time
Synchronization GPS, NITZ, NTP
Ignition detection Accelerometer, External Power
Voltage
13 wiki.teltonika-gps.com/view/FMM80A_Sleep_modes#GPS_Sleep_mode
14 wiki.teltonika-gps.com/view/FMM80A_Sleep_modes#GPS_Sleep_mode
15 wiki.teltonika-gps.com/view/FMM80A_Sleep_modes#Deep_Sleep_mode
16 wiki.teltonika-gps.com/view/FMM80A_Sleep_modes#Ultra_Deep_Sleep_
mode
17 wiki.teltonika-gps.com/view/FOTA_WEB
18 wiki.teltonika-gps.com/view/Teltonika_Congurator

Quick Manual v1.4// FMM80A 16
This message contains information on how to operate
FMM80A safely. By following these requirements and
recommendations, you will avoid dangerous situations. You
must read these instructions carefully and follow them strictly
before operating the device!
• The device uses SELV limited power source. The nominal
voltage is +12 V DC. The allowed voltage range is +10…+30
V DC.
• To avoid mechanical damage, it is advised to transport
the device in an impact-proof package. Before usage,
the device should be placed so that its LED indicators are
visible. They show the status of device operation.
• Before unmounting the device from vehicle, ignition
MUST be OFF.
SAFETY INFORMATION Do not disassemble the device. If the device is
damaged, the power supply cables are not isolated
or the isolation is damaged, DO NOT touch the
device before unplugging the power supply.
All wireless data transferring devices produce
interference that may aect other devices which are
placed nearby.
The programming must be performed using a PC
with autonomic power supply.
Please consult representatives of your vehicle
model regarding OBDII location on your vehicle.
In case you are not sure about proper connection,
please consult qualied personnel.
Installation and/or handling during a lightning storm
is prohibited.
The device is susceptible to water and humidity.
Teltonika is not responsible for any harm caused by
wrong cables used for connection between PC and
FMM80A
WARNING! Do not use FMM80A device if it distracts
driver or causes inconvenience due to OBDII
placement. Device must not interfere with driver.
Battery should not be disposed of with general
household waste. Bring damaged or worn-out
batteries to your local recycling center or dispose
them to battery recycle bin found in stores.

Quick Manual v1.4// FMM80A 17
CERTIFICATION AND APPROVALS
This sign on the package means that it is necessary
to read the User‘s Manual before your start using the
device. Full User‘s Manual version can be found in
our Wiki1.
1wiki.teltonika-gps.com/index.php?title=FMM80A
This sign on the package means that all used
electronic and electric equipment should not be
mixed with general household waste.
The RoHS2 is a directive regulating the manufacture,
import and distribution of Electronics and Electrical
Equipment (EEE) within the EU, which bans from use
10 dierent hazardous materials (to date).
2 wiki.teltonika-gps.com/view/FMM80A_RoHS
FCC ID: 2A3HUFMM80A.
• This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference
that may cause undesired operation.
• This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
• Changes or modications not expressly approved by the
manufacturer could void the user’s authority to operate
the equipment.
• This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. To comply
with FCC RF Exposure compliance requirements, this grant
is applicable to only Mobile Congurations. The antennas
used for the transmitter must be installed to provide a
separation distance of at least 20cm from all persons and
must not be co-located or operating in conjunction with
any other antenna or transmitter.

Quick Manual v1.4// FMM80A 18
CHECK ALL CERTIFICATES
All newest certicates may be found in our Wiki3.
3 wiki.teltonika-gps.com/view/FMM80A_Certication_%26_Approvals
IC NOTICE
This device complies with Industry Canada license-
exempt RSS standard(s). Operation is subject to the
following two conditions:
1. this device may not cause interference, and
2. this device must accept any interference,
including interference that may cause undesired
operation of the device.
This Class B digital apparatus complies with
Canadian ICES-003.
IC: 28804-FMM80A.
This equipment complies with ISED radiation
exposure limits set forth for an uncontrolled
environment. To comply with RSS-102 RF Exposure
compliance requirements, this grant is applicable
to only Mobile Congurations. The antennas used
for the transmitter must be installed to provide
a separation distance of at least 20cm from all
persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
REMARQUE IC
Cet appareil est conforme aux Normes RSS
d'Industy Canada. Son utilisation est soumise à deux
conditions:
3. Ce dispositif ne peut pas provoquer
d'interférences, et
4. Ce dispositif doit accepter toutes les
interférences reçues, y compris les interférences
susceptibles de provoquer un fonctionnement
non souhaité.
Cet appareil de classe B est conforme à la norme
canadienne ICES-003.
IC: 28804-FMM80A.
Cet équipement est conforme aux limites d'exposition aux
rayonnements ISED établies pour un environnement non
contrôlé. Pour se conformer aux exigences de conformité
d'exposition aux radiofréquences RSS-102, cette subvention
s'applique uniquement aux congurations mobiles. Les
antennes utilisées pour l'émetteur doivent être installées
pour fournir une distance de séparation d'au moins 20cm
de toutes les personnes et ne doivent pas être co-localisées
ou fonctionner en conjonction avec une autre antenne ou
émetteur.

Quick Manual v1.4// FMM80A 19
WARRANTY
We guarantee our products 24-month warranty1period.
All batteries carry a 6-month warranty period.
Post-warranty repair service for products is not provided.
If a product stops operating within this specic warranty time, the product can be:
• Repaired
• Replaced with a new product
• Replaced with an equivalent repaired product fullling the same functionality
• Replaced with a dierent product fullling the same functionality in case of EOL for the original product
1 Additional agreement for an extended warranty period can be agreed upon separately.
WARRANTY DISCLAIMER
• Customers are only allowed to return products as a result of the product being defective, due to order assembly or
manufacturing fault.
• Products are intended to be used by personnel with training and experience.
• Warranty does not cover defects or malfunctions caused by accidents, misuse, abuse, catastrophes, improper maintenance
or inadequate installation – not following operating instructions (including failure to heed warnings) or use with equipment
with which it is not intended to be used.
• Warranty does not apply to any consequential damages.
• Warranty is not applicable for supplementary product equipment (i. e. PSU, power cables, antennas) unless the accessory is
defective on arrival.
• More information on what is RMA1
1 wiki.teltonika-gps.com/view/RMA_guidelines
