Tema Telecomunicazioni AD630 User manual

AD630
VoIP SIP 25W PoE Horn Speaker
IP65 grade of protection
Audio Over IP Network Series
PRODUCT MANUAL
Version HW 1.0 - Version SW 1.10
Revision
Date
Revision reason
Prepared
Checked/Approved
2 21/02/2018 Update MM, DP DP, FL
TEMA TELECOMUNICAZIONI
“IP COMMUNICATION AND SECURITY COMPANY”
WWW.TEMATLC.IT
Products for VoIP SIP LAN networking Communications, Paging Amplifiers Systems and
Audio Applications. Zone Announcements, Night Ringer, Multicast general call,
Background music, Standard SIP call or Emergency call, SD memory with pre-recorded
messages, Relays for LAN drives.

TEMA TELECOMUNICAZIONI AD630VoIP SIP 25W / PoE Horn
MAS-AD630-REV02EN Page 2 of 48
We, TEMA TELECOMUNICAZIONI SRL Via C. Girardengo, 1/4 - 20161 MILANO
declare under our sole responsibility that the product:
Product name Diffusore a Tromba VoIP SIP 25W PoE IP65
Trade name TEMA TELECOMUNICAZIONI Srl
Type or model AD630
and accessories --
to which this declaration relates is in conformity with the essential requirements and other
relevant requirements of the R&TTE Directive ( 1999/5/EC, 2006/95/EC, 2004/108/EC ).
The product is in conformity with the followings standards and/or other normative documents:
HEALT & SAFETY EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011
EMC EN 55022:2010, EN 55024:2010, EN 61000-3-2:2006
EN 61000-3-3 :2008
MILANO, 20 February 2017 TEMA TELECOMUNICAZIONI SRL
D. Pontillo
I. IMPORTANT INFORMATIONS REGARDING THE RECOVERY AND RECYCLING OF THIS
ELECTRONIC DEVICE
DICHIARAZIONE DI CONFORMITÀ CE
DECLARATION OF CONFORMITY CE
The crossed
-
out wheeled bin symbol below indicates that this
electronic equipment is
intended to be disposed in a separate collection and not in an unsorted municipal
waste, in order to provide for the treatment of WEEE (Waste Electrical and Electronic
Equipment) using best available recovery and recycling techniques. Specific treatment
for WEEE is indispensable in order to avoid the dispersion of pollutants and other
hazardous substances into the waste stream, while recycling leads to reduction of
disposal of waste and the negative impacts on environment and human health. That is,
priority is given to reuse of WEEE in its components, subassemblies and
consumables. As the final holder, the user has an important role in contributing to
reuse, recycling and other forms of recovery of WEEE and is responsible to return this
waste in the collection facilities set up by EC Member States and to fulfill other duties
in compliance with Directive 2002/96/EC and local laws.
UNI EN ISO 9001:2008
TEMA TELECOMUNICAZIONI is a certified company
The crossed
-
out wheeled bin symbol below indicates that this electronic equipment is
intended to be disposed in a separate collection and not in an unsorted municipal
waste, in order to provide for the treatment of WEEE (Waste Electrical and Electronic
Equipment) using best available recovery and recycling techniques. Specific treatment
for WEEE is indispensable in order to avoid the dispersion of pollutants and other
hazardous substances into the waste stream, while recycling leads to reduction of
disposal of waste and the negative impacts on environment and human health. That is,
priority is given to reuse of WEEE in its components, subassemblies and
consumables. As the final holder, the user has an important role in contributing to
reuse, recycling and other forms of recovery of WEEE and is responsible to return this
waste in the collection facilities set up by EC Member States and to fulfill other duties
in compliance with Directive 2002/96/EC and local laws.
UNI EN ISO 9001:20
15
TEMA TELECOMUNICAZIONI i
s a certified company

TEMA TELECOMUNICAZIONI AD630VoIP SIP 25W / PoE Horn
MAS-AD630-REV02EN Page 3 of 48
RECOMMENDATIONS
1. It is recommended to read this entire manual before proceeding to the installation of the device.
2. The installation and commissioning of the device can only be performed by specialized technicians.
3. The device is accurately manufactured and tested. In any case, the product is not recommended for use
where an error of operations can cause property damage and/or injury to persons.
4. It is expressly not recommended maintenance inside the device which must be carried out by Tema
Telecomunicazioni, the removal of the closures will invalidate the warranty and makes accessible internal
parts with risk of electric shock.
5. Tema Telecomunicazioni accepts no responsibility for damage to property and/or persons resulting from
incorrect use of the equipment or by procedures that do not comply with the instructions in this manual.
Tema Telecomunicazioni reserves the right to make modification to the technical and functional
specifications at any time and without any notice.
6. Products powered via PoE (Power over Ethernet) may only be connected with cables coming from the
internal network company (inside the building), are not allowed connections LAN cables coming from outside
the building.
7. Use for this device only and exclusively original spare parts and consumables supplied by Tema
Telecomunicazioni. The company is not responsible for damage caused by the use of materials not supplied
by the same.
8. Do not expose the unit to direct sunlight, protect from heat, dust, humidity and chemicals.
9. Tema Telecomunicazioni reserves the right to vary the product characteristics for improvement without prior
notice. Check the WWW.TEMATLC.IT website for any updates to the latest firmware, manuals, and
technical documentation.
10. This document is property of Tema Telecomunicazioni, It is forbidden any duplication and reproduction, even
partial, as well as storage on any medium without written permission of Tema Telecomunicazioni.
This
symbol in the descriptions indicates a general warning or a damage danger
to equipment or people.
This symbol in the descriptions indicates useful information or a suggestion for
the optimization of the device functionality.

TEMA TELECOMUNICAZIONI AD630VoIP SIP 25W / PoE Horn
MAS-AD630-REV02EN Page 4 of 48
1. PRESENTATION ........................................................................................................................................ 5
2. FEATURES.................................................................................................................................................. 7
3. PACKING LIST ........................................................................................................................................... 7
4. TECHNICAL SPECIFICATIONS ............................................................................................................... 8
5. OPERATION................................................................................................................................................ 9
5.1. D EVICE CONNECTION DIAGRAMS ..........................................................................................................................9
6. OPERATING MODES............................................................................................................................... 10
6.1. C ALLS TO DEVICES ...........................................................................................................................................10
6.2. RELAY FUNCTION ...........................................................................................................................................10
6.3. C ALLS GENERATED FOR ACQUISITION OF EXTERNAL CONTACTS FOR SPECIAL SIGNALINGS ........................................10
6.4. M ULTICAST A UDIO S TREAMING .........................................................................................................................11
7. COMMANDS AND CODES...................................................................................................................... 11
8. INSTALLATION OF THE DEVICE .......................................................................................................... 12
8.1. M OUNTING AND POSITIONING OF THE AD630 HORN .............................................................................................12
8.2. O PENING OF THE COVER AND ACCESS TO INTERNAL PARTS - PASSAGE OF CABLES ..................................................12
8.3. C ONNECTING THE INTERNAL MODULE OF AD630.................................................................................................13
8.4. C ORRECT CONNECTION OF AN ADDITIONAL PASSIVE SPEAKER ..............................................................................15
8.5. 100V AUDIO LINE FOR ADDITIONAL SPEAKERS AWAY FROM AD630 IP H ORN ..........................................................16
9. PROGRAMMING ...................................................................................................................................... 17
9.1. P REPARATION FOR THE SYSTEM PARAMETERS PROGRAMMING ..............................................................................17
9.2. A CCESS TO PROGRAMMING ...............................................................................................................................19
9.3. N ETWORK PARAMETERS ...................................................................................................................................20
9.4. SIP P ARAMETERS ...........................................................................................................................................21
9.5. G ENERAL PARAMETERS ....................................................................................................................................22
9.6. S ET OF THE OPERATING MODE ..........................................................................................................................23
9.7. R ELAY AND ALARM INPUT SETTINGS ...................................................................................................................24
9.8. C AMERA .........................................................................................................................................................25
9.9. C ALL BUTTONS ................................................................................................................................................26
9.10. M ESSAGES MANAGEMENT ...........................................................................................................................27
9.11. A UTOMATIC A NNOUNCEMENTS .....................................................................................................................29
9.12. C ALLS R EPORT ..........................................................................................................................................31
10. MAINTENANCE........................................................................................................................................ 32
10.1. S YSTEM ....................................................................................................................................................32
10.2. L OGIN CREDENTIALS ...................................................................................................................................33
10.3. D IAGNOSTIC LOGS ......................................................................................................................................33
11. PRESENTATION AND USE OF THE "AA Video Console" SOFTWARE ........................................ 34
11.1. P RESENTATION ..........................................................................................................................................34
11.2. S OFTWARE CONFIGURATION FOR SIP S ERVER MODE .....................................................................................35
11.3. S OFTWARE CONFIGURATION FOR P EER -T O -P EER MODE .................................................................................36
12. Introduction to AA-Video Console APP version for operating systems iOS............................... 37
12.1. D OWNLOADING AND INSTALLING THE APP ......................................................................................................37
12.2. U SING THE APPLICATION .............................................................................................................................39
13. Introduction to AA-Video Console APP version for ANDROID systems ...................................... 39
13.1. D OWNLOADING AND INSTALLING THE APP ......................................................................................................39
13.2. U SING THE APPLICATION .............................................................................................................................41
14. APPENDIXES............................................................................................................................................ 43
14.1. A PPENDIX 1: O THER EXAMPLES OF M ULTICAST A UDIO S TREAMING APPLICATIONS .............................................43
14.2. A PPENDIX 2: U SE OF THE VLC M EDIA P LAYER SOFTWARE AS A M ULTICAST E NCODER FOR AUDIO FILES ..............45
14.3. A PPENDIX 3: U SE OF THE AUDACITY SOFTWARE FOR AUDIO FILES RECORDING ...............................................46
14.4. A PPENDIX 4: C ABLING OF A UTP RJ45 NETWORK CABLE ACCORDING TO THE STANDARD EIA568B.....................47
INDE
X
PAGE

TEMA TELECOMUNICAZIONI AD630VoIP SIP 25W / PoE Horn
MAS-AD630-REV02EN Page 5 of 48
1. PRESENTATION
AD630 allows to realize Paging Amplification Audio Sound Systems in a standard LAN network completely
integrating with IP-PBX SIP in order to be able to play announcements from any telephone in the internal network
and any technologies: analog, SIP, Smartphones and Softphones.
Access can be authorized by Password with code to be typed before starting the announcement. Two internal
relays can be programmed to be automatically activated when it is called or to be controlled from the phone via
LAN that originated the call to the AD630 horn, eg. to report the event to any auxiliary devices connected
downstream.
The system programming is done remotely via LAN thanks to the integrated Web server. AD630 incorporates an
efficient 40W (2x20W) Class-D amplifier.
2nd SIP Account – Night Ringer. AD630 can be registered on the PBX with a second telephone number, different
from the one used for ads and inserted in the night ring group. To the arrival of an incoming call, the system plays a
sound (user selectable) to all the network speakers. The volume can be adjusted independently of the others
managed audio channels.
Inputs from external contact with a variety of functions, for example: provide to make a SIP call to a
preprogrammed number and inform the operator of the event with an appropriate voice message. The signaling
can be repeated a number of programmable times, the operator can interrupt the sequence with a keyboard code.
Other examples of use will follow in this manual.
Multicast Audio Streaming for music and announcements diffusion. AD630 handles up to 5 multicast channels in
LAN with priority levels to allow the background music broadcasting on loudspeakers network. The generation of
musical programs in streaming audio can be managed from a PC of the LAN/WAN network with special software or
special TEMA Encoder.
Service "SIP Security Info Call" - Emergency SIP Call. By connecting a button or an external contact, AD630 can
call a phone number programmed to alert the event with a specific warning message. It is a security service for
emergencies or simple request for help and information, and allows a one-way phone call.
Total remote management via LAN, integrated Web Server. Programming, configuration, loading and listening to
audio files, firmware release update, audio volume adjustment, backup and restore the configuration, device
reboot.
Possibility to connect one or more external passive loudspeakers on the 2nd amplifier to expand audio coverage
of the served area. High power output of 20W when powered with an external power supply, automatic lowering of
the power with 10W limitation when powered only from LAN cable via PoE.
Tested with most popular P X brands:
SIEMENS - AVAYA - ALCATEL – PANASONIC – SAMSUNG - NEC -
LG
WILDIX - AASTRA - ASCOM - VT NITSUKO - SELTA – PHILIPS
