tempmate M2T User manual

empower your supply chain.
V1.0-12/2021-DE · Technical Changes and Errors excepted 3
1. Introduction ............................................................................................................................................................................................ 3
2. Intended Use ...........................................................................................................................................................................................3
3. tempmate.®-M2 Model ..................................................................................................................................................................... 4
4. Device Description ................................................................................................................................................................................6
5. Display ...................................................................................................................................................................................................... 7
6. Operation and Usage............................................................................................................................................................................8
 Conguration................................................................................................................................................................................8
Start Logger ..................................................................................................................................................................................8
Set Mark .........................................................................................................................................................................................9
Stop Logger ..................................................................................................................................................................................9
Manual Data Readout ...............................................................................................................................................................9
Readout with tempbase Software .....................................................................................................................................10
7. External Sensors .................................................................................................................................................................................11
8. Replace Battery ...................................................................................................................................................................................12
9. Important Notes .................................................................................................................................................................................13
10 Technical Data tempmate.®-M2 T..............................................................................................................................................14
11. Technical Data tempmate.®-M2 TH........................................................................................................................................15
12. Technical Data tempmate.®-M2 Accessory...........................................................................................................................16
13. Contact ................................................................................................................................................................................................18
Table of content
The tempmate.®-M2 is designed to be mounted on
a shipment or stationary and measure relevant para-
meters such as temperature and optionally relative
humidity. The device records data and stores it on an
internal memory.
1. Introduction 2. Intended Use
The tempmate.®-M2 is designed to be mounted on
shipments or stationary and to record relevant parame-
ters as mentioned in the data sheet. Any use or opera-
tionrequiringspecicrequirementsandstandardsnot
explicitly mentioned in the data sheet must be validated
and tested at the customer‘s own responsibility.

empower your supply chain.
V1.0-12/2021-DE · Technical Changes and Errors excepted 5
tempmate.®-M2 Model
Multi-Use
Temperature
Rel. Humidity
LCD

empower your supply chain.
V1.0-12/2021-DE · Technical Changes and Errors excepted 7
4. Device Description 5. Display
LCD
LCD
LED
LED
Start Button
Start Button
Stop Button
Stop Button
Sensor rel.
Humidity
Not Started
Started*
Stopped
Number Measured
Values
Highest
Measured Value
Lowest
Measured Value
Average Value
MKT Value
Time & Date
*ifthestartdelayisset,thissymbolashesafterasuc-
cessful start until the time limit has elapsed

empower your supply chain.
V1.0-12/2021-DE · Technical Changes and Errors excepted 9
6. Operation and Usage
STEP 1 Conguration*optional
Thisstepisonlynecessaryifyouwanttoadaptthepre-installedcongurationtoyourapplication.
- Download the free tempbase 2 software – https://www.tempmate.com/de/download/
- Install the tempbase 2 software on your PC.
- Remove the cap and connect the not started logger to your PC.
- Open the tempbase 2 software and select the „Logger Setup“ button“ (1).
- Make the desired settings and save them via the „Save Parameter“ button (2).
- Remove the logger from your PC and replace the cap securely.
STEP 2 Start Logger
- Press and hold the green start button for 5 seconds.
- AsuccessfulstartisindicatedbythegreenLEDonyourdeviceashing10times.
- Note:Ifanotherornoashingsignalappears,donotusetheloggerandcontactsupport.
STEP 3 Set Mark
- Brieypressthegreenstartbuttontwiceinsuccessiontosetamark.
- A successfully set mark is indicated by the word „MARK“ and the number of marks set so
far in your display.
- Note: Up to 10 marks can be set per operation.
STEP 4 Stop Logger
- Press and hold the red stop button for 5 seconds.
- AsuccessfulstopisindicatedbytheredLEDonyourdeviceashing10times.
Alternative stop modes
Automatic Stop (default setting)
o The device will stop automatically when the maximum number of measured values in the
data memory is reached and no manual stop is performed beforehand.
o This stop mode works in addition to the manual stop.
Software Stop (optional)
o This setting can be made in the tempbase 2 software. (see STEP 1)
o The stop is triggered automatically by connecting the logger to the PC and opening
the software.
 o Amanualstopisnotpossibleinthisconguration.
STEP 5 Manual Readout of Data
- Remove the cap and connect the logger to your PC.
- AsuccessfulconnectionisindicatedbybothLEDsashing.TheabbreviationsCSVandPDFappear
one after the other in the display.
- The logger automatically opens as an external drive on your PC. This process may take a few minutes
depending on the amount of data.

empower your supply chain.
V1.0-12/2021-DE · Technical Changes and Errors excepted 11
- OpenthedriveandcopythePDFandCSVreportstoredonitforyourling.
- Note:AreportisautomaticallygeneratedasPDFand/orCSVwhenthedeviceisstopped.Thedevice
can still be read out during a running measurement and an intermediate report can be downloaded.
- Note: Already generated reports are automatically overwritten and deleted when the device
is restarted.
Readout with the tempbase 2 software (optional)
- Remove the cap and connect the logger to your PC.
- Open the tempbase 2 software and select the „Export/Import“ button (3).
- Selectthedesiredleformat(PDF/XLS/IME)forexportandthelelocationandconrmthedownload.
7. External Sensors
- Remove the cap and connect the not started logger to your PC.
- Open the tempbase 2 software and select the „Logger Setup“ button.
- In the „Sensor Type“ area, select the sensor type you want to work with.
- Conrmyourcongurationbyclickingon„SaveParameter“andremovethedevicefromyourPC.
- To record with an external sensor, use a screwdriver to loosen the screw on the bottom of the device
and remove the standard cap.
- Replace it with the external sensor of your choice and screw it again.
8. Replace Battery
- Open the cover on the back of the device by turning it counterclockwise.
- Remove the old battery and dispose of it according to national regulations.

empower your supply chain.
V1.0-12/2021-DE · Technical Changes and Errors excepted 13
- Insert the new battery and replace the cover, closing it clockwise.
- Remove the cap and connect the logger to your PC.
- Open the tempbase 2 software to synchronize date & time again. This process is automatically trigge
red when the logger is connected to PC and software.
- Caution: Back up your data and download your last report before removing the battery
from the instrument.
9. Important Notes
- Congurationcannotbechangedduringrecording.
- We recommend recalibration after 1 year.
- Always dispose of batteries according to your country‘s regulations.
- Do not place the device in corrosive liquids and do not expose it to direct heat.

empower your supply chain.
V1.0-12/2021-DE · Technical Changes and Errors excepted 15
MainTechnicalSpecicationstempmate.®-M2
Temperature Sensor HQ Digital Temperature sensor (internal and external optional)
Temperature Range -30°C to +70°C (–40°C to +90°C with ext. T Sensor)
(-80°C to +200°C with ext. PT100 Sensor)
Temperature Accuracy ±0.3°C (at –20°C to + 40°C, other 0.5°C)
Temperature Resolution 0.1°C
Humidity Sensor n/a
Humidity Range n/a
Humidity Accuracy n/a
Humidity Resolution n/a
Data Storage 60,000 values
Display Big Multifunction LCD
Start Setting Manually by pressing button, by software or timed
Recording Time Up to 6 months
Interval 10sec. up to 11h 59min. (default 10 min.)
Alarm Settings Up to 6 points customizable
Alarm Type Single alarm or cumulative
Battery CR2450 / replaceable by customer
Dimensions 100 x 53 x 12 mm
Weight 54g
Protection Class IP65
Connection Interface USB 2.0, A-Type
Conformity EN 12830, CE, RoHS
Software PDForCSVreaderortempbase2software/freedownload
Interface to PC Integrated USB port
Reprogrammable Yes, with internal HTML tool* or optional tempbase 2 Software
Automatic Reporting PDF&CSV
MainTechnicalSpecicationstempmate.®-M2
Temperature Sensor HQ Digital Temperature sensor (internal and external optional)
Temperature Range -30°C to +70°C (–40°C to +90°C with ext. T Sensor)
(-80°C to +200°C with ext. PT100 Sensor)
Temperature Accuracy ±0.3°C (at –20°C to + 40°C, other 0.5°C)
Temperature Resolution 0.1°C
Humidity Sensor HQ Digital Temperature/rel. Humidity sensor (internal and external optional)
Humidity Range 0%rH to 100%rH
Humidity Accuracy ±3%rH (20 to 80%rH), 5% others (at 25°C)
Humidity Resolution 0.1%rH
Data Storage 60,000 values
Display Big Multifunction LCD
Start Setting Manually by pressing button, by software or timed
Recording Time Up to 6 months
Interval 10sec. up to 11h 59min. (default 10 min.)
Alarm Settings up to 6 points temperature and 2 points humidity customizable
Alarm Type Single alarm or cumulative
Battery CR2450 / replaceable by customer
Dimensions 100 x 53 x 12 mm
Weight 54g
Protection Class IP65
Connection Interface USB 2.0, A-Type
Conformity EN 12830, CE, RoHS
Software PDForCSVreaderortempbase2software/freedownload
Interface to PC integrated USB port
Reprogrammable Yes, with internal HTML tool* or optional tempbase 2 Software
Automatic Reporting PDF&CSV

empower your supply chain.
V1.0-12/2021-DE · Technical Changes and Errors excepted 17
tempmate.®-M2 External T-Sensor
Sensor HQ Digital Temperature Sensor
Temperature Range –40°C to +90°C
Temperature Accuracy 0.3°C (at –20 ° C to + 40 ° C, other 0.5°C)
Temperature Resolution 0.1°C
Sensor Tip Stainless Steel (30 x 5 mm)
Sensor Connetion M2-USB Connection
Cable length 1.2 m
Cable Diameter 3 mm
Cable Material PVC
MainTechnicalSpecicationstempmate.®-M2 Accessory
tempmate.®-M2 External High/Low T-Sensor
Temperature Sensor PT100 Sensor
Temperature Range -80°C to +200°C
Temperature Accuracy ±1°C
Temperature Resolution 0,1°C
Sensor Tip Stainless Steel (30 x 5 mm)
Sensor Connetion M2-USB Connection
Cable Diameter 3 mm
Cable length 1.2 m
Cable Material PTFE
tempmate.®-M2 External T/rH-Sensor
Sensor HQ Digital Temperature/rel. Humidity Sensor
Temperature Range –40°C to +90°C
Temperature Accuracy 0.3°C (at –20 ° C to + 40 ° C, other 0.5°C)
Temperature Resolution 0,1°C
Humidity Range 0 - 100 %rH
Humidity Accuracy ±3%rH (10% to 70%), 5% others (at +25°C)
Humidity Resolution 0.1 %rH
Sensor Tip Stainless Steel (30 x 5 mm)
Sensor Connetion M2-USB Connection
Cable length 1.2 m
Cable Diameter 3 mm
Cable Material PVC

empower your supply chain.
V1.0-12/2021-DE · Technical Changes and Errors excepted 19
Do you have any questions? Please contact us - our
experienced team will be happy to support you.
[email protected]
[phone]
Contact

tempmate GmbH
Wannenäckerstr. 41
74078 Heilbronn, Germany
Tel. [phone]
[email protected]
