Tenda TEH1026G User manual

24+2G Gigabit Ethernet Switch
BRIEF INTRODUCTION PRODUCT FEATURES
Wired
Model No.:TEH1026G
All For Better NetworkAll For Better Network
All For Better Network
The TEH1026G is a hybrid switch offering 24 10/100M ports and
two 10/100/1,000M ports. It supports auto MDI/MDIX and store-
and-forward switching, and has an 8.8Gbps backplane bandwidth.
The TEH1026G is a specially designed solution for keeping traffic
moving in medium-sized network groups that will be accessing
one or two servers heavily via the Gigabit ports, like in some school
or enterprise deployments. Administrators might also consider
deploying TEH1026Gs that are connected via Gigabit ports to two
separate groups within 300 feet of each other as a practical and
cost-effective alternative to fiber for their cooperation.
Complies with IEEE 802.3x full-duplex and flow control
Provides 24 10/100Mbps LAN ports,2 10/100/1000Mbps
LAN ports
Supports UPnP,NMA auto-negotiation
Integrated 4,000 MAC address table
Non-blocking,Store-and-forward switching
24+2G Gigabit Ethernet Switch
Expand your networking Easy to use
Store-and-forward

WHAT THIS PRODUCT DOES
BENEFITS
TECHNICAL SPECIFICATIONS
All For Better NetworkAll For Better Network
All For Better Network
Shenzhen Tenda Technology Co., Ltd.
Contact us
Address:Tenda Industrial Park, No. 34-1, Shilong Rd.,Shiyan Town,
Bao’an District, Shenzhen, P.R. China 518108
Tel: [phone] Fax: [phone]
E-mail: [email protected] Http: www.tenda.cn
Copyright statement
Obligation-free statement
PACKAGE CONTENTS
MINIMUM REQUIREMENTS
Internet Explorer 5.5 or Firefox 1.0
Network Adapter
Wired
Tenda is the registered trademark of Shenzhen Tenda
Technology Co. LTD in CHINA and certain other countries.
Copyright © 2007 Shenzhen Tenda Technology Co. LTD
All rights reserved. Other brands and product name
are trademarks or registered trademarks of their
respective holders.
The maximum performance for wireless is derived from IEEE Standard 802.11 specifications. Actual
performance can vary, including lower wireless network capacity, data throughput rate, range and
coverage. Performance depends on many factors, conditions and variables, including distance from
the access point, volume of network traffic, building materials and construction, operating system
used, mix of wireless products used, inter ference and other adverse conditions.
Check the product package and contents for specific features supported. Specifications are subject to
change without notice.
Model No.:TEH1026G
To have dedicated bandwidth on point to point
connections with every computer and to therefore run
in Full duplex with no collisions.
Plug and Play;
Provides two gigabit ports for unlink
Easy to use
TEH1026G 24+2G Gigabit Ethernet Switch
Power Cord
User Guide
2 Mounting Ears
8 Screws
4 Rubber Feet
32 to 104 F (0 to 40 ) º ºC
10 to 90% Noncondensing
-40 to 158 (-40 to 70ºC) ºF
5 to 90% Noncondensing
437mmX177mmX43mm (17.2"X7.0"X1.7")
2.29Kg
Protocols and Standards
Power Supply
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Dimension (WXDXH)
Gross Weight
Certificate CE, RoHS
IEEE802.3, IEEE802.3u and IEEE802.3ab,IEEE 802.3x
AC160-264V,47-63Hz
MAC Address Table Size 4K
Transmission Method Store-and-Forward
10Base-T:Cat.3 or 3e UTP; 100Base-TX:Cat.5 UTP;1000Base-T: Cat.5e UTP
Switching Fabric Non-blocking
Transmission Media
Interface
24 10/100Mbps RJ45 Ports,2 10/100/1000Mbps RJ45 Ports
Housing Material Metal
Packet Buffer 1.5M
