Tenda F1200 User manual

Copyright Statement
is the registered trademark of Shenzhen Tenda Technology Co.,
Ltd. All the products and product names mentioned herein are the trademarks or
registered trademarks of their respective holders. Copyright of the whole product
as integration, including its accessories and software, belongs to Shenzhen Tenda
Technology Co., Ltd. No part of this publication can be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any
form or by any means without the prior written permission of Shenzhen Tenda
Technology Co., Ltd. If you would like to know more about our product
information, please visit our website at http://www.tendacn.com.
!
Disclaimer
Pictures, images and product specifications herein are for references only. To
improve internal design, operational function, and/or reliability, Tenda reserves
the right to make changes to the products described in this document without
obligation to notify any person or organization of such revisions or changes. Tenda
does not assume any liability that may occur due to the use or application of, the
product or circuit layout(s) described herein. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements,
information and recommendations in this document do not constitute the warranty
of any kind, express or implied.

Preface
Thank you choosing Tenda! Please read this user guide before you start! This user
guide instructs you to install and configure the router.
This user guide uses the following formats to highlight
special messages:
Note: This format is used to highlight information of importance or special
interest. Ignoring this type of note may result in ineffective configurations, loss of
data or damage to device.
Tip: This format is used to highlight a procedure that will save time or
resources.
Knowledge Center: Description of fields on the device GUI.
Technical Support
Website: http://www.tendacn.com
Telephone: [phone]
Email: [e-mail]

Table of Contents
I Product Overview .............................................................................................4
1 Package Contents ............................................................................................4
2 Getting to know your router .............................................................................4
LEDs on Front Panel ....................................................................................... 4
Buttons & Interfaces on Back Panel..................................................................6
Label..............................................................................................................6
3 Position Your Router .......................................................................................7
II Quick Internet Setup .......................................................................................8
1 Getting Prepared .............................................................................................8
Hardware Install ................................................................................................9
3. Internet Setup .............................................................................................. 10
1) Configure PC ............................................................................................ 10
2) Configure Router ...................................................................................... 10
4 Verify Internet Connectivity........................................................................... 14
5 Join Your Wireless Network ........................................................................... 16
Windows 7.................................................................................................... 16
Windows XP ................................................................................................. 19
III Features & Configurations ........................................................................... 22
1 Status ........................................................................................................... 22
1.1 System Status .......................................................................................... 22
1.2 WAN Status ............................................................................................. 23
1.3 LAN Status ............................................................................................. 24
1.4 Wireless Status ........................................................................................ 24
1.5 Connection Status .................................................................................... 25
2 Network ....................................................................................................... 25
2.1. LAN Settings.......................................................................................... 25
2.2. WAN Settings ......................................................................................... 26
2.3 Port Mode ............................................................................................... 31
2.4 MAC Clone ............................................................................................. 32
2.5. DHCP .................................................................................................... 33
2.6 DHCP Client List..................................................................................... 34
2.7 Static Assignment .................................................................................... 34
2.8 DHCP Server - Guest Network .................................................................. 36
3 Wireless Settings........................................................................................... 38
3.1 Wireless-Basic......................................................................................... 38
3.2 Guest Network......................................................................................... 39
3.3 Security .................................................................................................. 41
3.4 Advanced ................................................................................................ 42
3.6 Wireless Extender .................................................................................... 44

3.5 Access Control ........................................................................................ 74
3.7 WPS Setup .............................................................................................. 78
3.8 Connection Status .................................................................................... 81
4 Advanced Applications .................................................................................. 81
4.1 Bandwidth Control................................................................................... 81
4.3 DDNS ..................................................................................................... 84
4.1 Virtual Server.......................................................................................... 87
4.2 DMZ Host ............................................................................................... 89
4.4 UPnP ...................................................................................................... 90
4.6 Route Table ............................................................................................. 91
4.5 Static Route ............................................................................................ 91
5 Security........................................................................................................ 96
5.1 MAC Filter.............................................................................................. 96
5.2 Client Filter ............................................................................................ 98
5.3 URL Filter .............................................................................................. 99
5.4 Remote Web Management....................................................................... 101
6 Tools .......................................................................................................... 102
6.1 Logs ..................................................................................................... 102
6.2 Traffic Statistics .................................................................................... 103
6.3 Time ..................................................................................................... 105
6.4 Change Password ................................................................................... 106
6.5 Backup.................................................................................................. 108
6.6 Restore ................................................................................................. 109
6.7 Firmware Update ................................................................................... 110
6.9 Reboot .................................................................................................. 113
Appendix 1 Configure PC TCP/IP Settings ...................................................... 116
Windows 7..................................................................................................... 116
Windows XP .................................................................................................. 122
Appendix 2 Join Your Wireless Network .......................................................... 126
Join Your Wireless Network - Windows 7......................................................... 126
Appendix 3 Factory Default Settings ............................................................... 131
Appendix 4 FAQs ............................................................................................ 133
Appendix 5 Remove Wireless Network from Your PC....................................... 135
Windows 7..................................................................................................... 135
Windows XP .................................................................................................. 136
Appendix 6 Safety and Emission Statement...................................................... 139

I Product Overview
1 Package Contents
Unpack the package. Your box should contain the following items:
If any of the parts are incorrect, missing, or damaged, contact your Tenda dealer.
Keep the carton, including the original packing materials, in case you need to
return the product for repair.
2 Getting to know your router
LEDs on Front Panel

LED Status Description
5GHz
Solid 5G wireless radio is on
Blinking Data being transferred over 5G wireless network
Off 5G wireless radio is off
2.4GHz
Solid 2.4G wireless radio is on
Blinking Data being transferred over 2.4G wireless network
Off 2.4G wireless radio is off
LAN
（1/2/3）
Solid LAN port connected correctly
Blinking LAN port is transferring data
Off No link is detected on this port.
WAN
Solid WAN port connected correctly
Blinking WAN port is transferring data
Off No link is detected on this port.
WPS
Solid WPS is enabled
Blinking Device is performing WPS authentication on a client
device.
Off WPS function is disabled or WPS authentication
negotiation is completed
SYS
Blinking System is functioning correctly.
Solid/Off The unit is malfunctioning.
POWER
Solid Indicates a proper connection to the power supply
Off Power is not supplied to the router. Please check the
power connection between the power outlet and router.

Buttons & Interfaces on Back Panel
1→WiFi: Wireless radio ON/OFF button. Pressing the WiFi On/Off button turns
the wireless radios on and off.
2→WPS/RST: Pressing it for over 7 seconds restores the device to factory default
settings. For factory default parameters, see Appendix 3 Factory Default Settings.
Pressing it for about 1 second enables WPS-PBC and the WPS LED blinks. You can
use this button to quickly add a wireless device or computer to your wireless
network.
3→LAN (1/2/3): The local (LAN) Ethernet ports are for cabling the device to local
computers, switches, etc.
4→WAN: The Internet (WAN) Ethernet port is for cabling the router to a cable or
DSL modem.
5→PWR: The power port for connecting the router to power outlet.
Label

1→Default Login IP address. This IP address is to be used to access the router’s
settings through a web browser. If you change it, you have to open a new
connection to the new IP address and log in again.
2→MAC address.
3→WPS pin code.
3 Position Your Router
The operating distance or range of your wireless connection can vary significantly
depending on the physical placement of your router. For best performance, place
your router:
Near the center of the area where your computers, smart phones and other
devices operate, and preferably within line of sight to your wireless devices.
In an elevated location such as a high shelf, keeping the number of walls
and ceilings between the router and your other devices such as computers and
smart phones to a minimum.
Away from electrical devices that are potential sources of interference,
such as ceiling fans, home security systems, microwaves or PCs.
Away from any large metal surfaces, such as a solid metal door or
aluminum studs.
Away from other materials such as glass, insulated walls, fish tanks,
mirrors, brick, and concrete that can also affect your wireless signal.

8
II Quick Internet Setup
1 Getting Prepared
Before you start the installation process, you need to prepare the following:
Item Description
Router Comes in the package
Power Adapter
Please use the power adapter that comes in the package.
Using a power adapter with a different voltage rating than
the one included with the router will cause damage to the
router.
PC Should have installed IE8 or higher browser
Ethernet Cable You will need it to connect your PC to the router
Internet service This is provided by your ISP
Gather ISP
Information
Your Internet service provider (ISP) should have provided
you with all of the information needed to connect to the
Internet. If you cannot locate this information, ask your
ISP to provide it.
If your ISP uses a PPPoE Internet connection, you will
need ISP login name and password.
If you use a DHCP Internet connection, no information
is needed.
If your ISP gives you a fixed or static IP address for
Internet connection, you will need to gather the
following information:
1) IP Address
2) Subnet Mask
3) Gateway
4) DNS Server
5) Alternate DNS Server (Optional)
