Tenda R502 User manual

R502 Multifunctional Broadband Router User Guide
0

R502 Multifunctional Broadband Router User Guide
Copyright Statement
is the registered trademark of Shenzhen Tenda
Technology Co., Ltd. Other trademark or trade name
mentioned herein are the trademark or registered trademark
of above company. Copyright of the whole product as
integration, including its accessories and software, belongs to
Shenzhen Tenda Technology Co., Ltd. Without the permission
of Shenzhen Tenda Technology Co., Ltd, individual or party is
not allowed to copy, plagiarize, imitate or translate it into other
languages.
All the photos and product specifications mentioned in this
manual are for references only, as the upgrading of software
and hardware, there will be changes. And if there are changes,
Tenda is not responsible for informing in advance. If you want
to know more about our products information, please access
our website at www.tenda.cn
1

R502 Multifunctional Broadband Router User Guide
2
Contents
Contents................................................................................2
Chapter One Hardware Installation………………………….3
1.1 Hardware Installation ...............................................................3
1.2 LED Indicators on Rear Panel .................................................4
1.3 Topology .................................................................................. 4
Chapter Two Configuration Guide ......................................5
2.1 To configure the network on your PC correctly ........................5
2.2 To check the connection ..........................................................8
2.3 Log in the Router .....................................................................9
2.4Get to Know the Management Interface................................. 10
2.5 Quick Installation Guide......................................................... 11
2.6 Running Status ...................................................................... 15
2.7 Wizard .................................................................................. 16
2.8 Advanced Config .................................................................. 17
2.9 DHCP Server........................................................................ 24
2.10 Virtual Server ...................................................................... 27
2.11 Security Setting.................................................................... 32
2.12 Routing Setting .................................................................... 41
2.13 System Tool ......................................................................... 42
Package Contents ..............................................................49
Physical Environment........................................................50

R502 Multifunctional Broadband Router User Guide
3
Chapter One Hardware Installation
Rear Panel Port Details
4 10/100M LAN
Ports
Connect to 10/100Base-T Ethernet LAN Cards
or Uplink to Switch/Hub
RESET
Warning! When you press “RESET” up to 7
seconds, your configuration will be lost and the
router restores to factory default settings.
WAN Connect to XDSL/Cable Modem/Ethernet
AC9V AC 9V power Interface
1.1 Hardware Installation
1、Pleases use cable to connect LAN port of router with LAN adapter
of your PC or you can also connect the LAN port with switches or
Hubs in LAN
2、Please connect WAN port of router to internet with Cat. 5 cable
3、Please power on the router with specified adapter

R502 Multifunctional Broadband Router User Guide
1.2 LED Indicators on Rear Panel
LED Indicators Details
POWER Indicates the status of the Power
SYS Blinking Indicates the device’s system goes well.
WAN Blinking Indicates the WAN port is transmitting or
receiving data.
Always
ON
Indicates corresponding LAN port is
connected correctly.
LAN
(1/2/3/4) Blinking Indicates the corresponding LAN port is
transmitting or receiving data.
1.3 Topology：
4

R502 Multifunctional Broadband Router User Guide
Chapter Two Configuration Guide
2.1 To configure the network on your PC correctly
1、Please click “My Network
Places” on your desktop and
select “Properties”.
2、Please right-click “Local
Area Connection” and select
“Properties”.
5

R502 Multifunctional Broadband Router User Guide
6
3、Please select “ Internet
Protocol(TCP/IP)” and click
“Properties”.
4、On this page, there are two
options for IP settings : “Obtain
an IP address
automatically(O)” and “Use the
following IP address(S)”
a: If you select “Obtain an IP
address automatically(O)”,
please refer to the figure on the
right.

R502 Multifunctional Broadband Router User Guide
7
b、If you select “Use the
following IP address(S)”, you
have to input below
parameters respectively:
IP address:192.168.0.XXX
(XXX is among 2~254)
Subnet Mask: 255.255.255.0
Default gateway: 192.168.0.1
Also there are two ways for
DNS settings, Please select
“Use the following DNS server
addresses”.
Preferred DNS Server: Please
input the DNS server address
provided by ISP. Please
contact your ISP for this
information if you are not clear.
Alternate DNS Server: If you
have a secondary DNS Server
address, please fill in this
blank.
After finishing above settings,
please click “OK” to submit
configuration, and click “OK” in
“Local Area connection” to

R502 Multifunctional Broadband Router User Guide
save configuration.
2.2 To check the
connection
1.Click”Start------Program-----
Accessories----Command
Prompt”, you will see below
dialogue box.
2、Please input command
“Ping 192.168.0.1” and then
press “Enter”, If the screen
displays as the right
Figure, it shows your PC
and router have been
connected normally.
Otherwise, please check
whether your router is
powered on or whether the
cable between your PC
and router is normally
connected.
8

R502 Multifunctional Broadband Router User Guide
2.3 Log in the Router
1.please open IE and enter
“http://192.168.0.1” in the
address bar, then press
“Enter”
2、Then right Figure will
appear to require User name
and Password, please enter
as per below factory default:
User Name: admin
Password: admin
Then click “OK”.
In order to have a faster
access to your router’s
management interface, please
select “Remember my
password”
3、If the User name and
Password are correct, IE will
enter into administrator’s
interface as right Figure.
9

R502 Multifunctional Broadband Router User Guide
2.4 Get to Know the
Management Interface
1、After entering into the
configuration Interface, you will
see 9 function menus on the
left ,including: Running Status,
Wizard, Advanced Config,
DHCP Server, Virtual Server,
Security Setting, Route
Setting, System Tool, Logout.
Press the separate button, you
can configure the function
settings respectively.
2、When selecting each Menu,
there will be a detailed setting
Figure appearing on the right
where you can configure in
details for each Menu.
10

R502 Multifunctional Broadband Router User Guide
2.5 Quick Installation Guide
1、Click “Next” when you enter in
the “Welcome” interface.
2、Please select your Access
mode when you enter into
Wizard interface.
This Router supports 4 kinds of
Access modes:
Factory default Access mode is
“Dynamic IP”
A. If you select “ADSL Virtual
Dial-up(PPPoE)”, just enter the
User Name and Password,
provided by the ISP, into the
“Wizard ADSL” dialogue box.
For example, your ISP provided
you below User name and
password:
User [email protected]
11

R502 Multifunctional Broadband Router User Guide
name
Password 123456
Then you have to fill in above
parameters as the figure on the
right.
B. If you select “Ethernet
Broadband, automatically obtain
an IP from ISP (dynamic IP)”.
Please click “Next” first and then
click “Save”.
C. If you select “Ethernet
Broadband, fixed IP provided by
ISP (fixed IP)”，figure on the right
will appear, you have to enter IP
address, Subnet-mask,
Gateway, DNS Server address
and Secondary DNS if available.
For example, your ISP provided
you below information:
IP
Address: 192.168.5.88
Subnet
-mask: 255.255.255.0
Gateway: 192.168.5.1
12

R502 Multifunctional Broadband Router User Guide
DNS
Server: 202.96.134.133
Secondary
DNS: 202.96.128.68
Then you have to fill in above
parameters as right Figure.
D. If you select “PPP Tunneling
Protocol (Can support
multi-protocol Virtual Private
Networks)(VPN)(PPTP).
PPTP Account: fill in with your
Account provided by your ISP.
PPTP Password: fill in with your
password provided by your ISP.
PPTP Gateway: Including
Domain name and IP Address.
You only need to fill in one of
them.
MTU: default value is 1492, you
may change it according to your
need.
MPPE: If you want the
connection between your Router
and Server encrypted, then
enable it, otherwise disable it.
13

R502 Multifunctional Broadband Router User Guide
For example: your ISP provided
you below information:
User name: tenda
Password: tenda
Server IP Address:192.168.2.1
Then you have to fill in
parameters as right Figure
shown.
There are 2 Access modes for
PPTP:
a:If you select “Ethernet
Broadband, automatically obtain
an IP address from ISP(dynamic
IP)”, please click “Save” to finish
setting.
b: If you select “Ethernet
Broadband, fixed IP address
provided by ISP(Static IP)”,
you have to fill in the information
provided by your ISP as right
Figure shown and click “Save” to
save configuration.
14

R502 Multifunctional Broadband Router User Guide
15
3、After you select one of above
4 access modes and finish the
settings accordingly, please click
“Next” and then click “Save” to
save your configuration
4、Running Status
After finishing above settings,
you can click “Running Status”
menu on the left to check the
connection status between your
router and ISP end.
2.6 Running Status
This section will show you the
Router’s running status.
The right Figure will show the
router’s running status.

R502 Multifunctional Broadband Router User Guide
This page shows the router’s
LAN port status (the router is
under default setting)
1.WAN Status
This page shows you WAN
status: Link Status, WAN IP,
Subnet mask, Gateway, DNS
Server, Secondary DNS, WAN
Link Type, Linked Time.
2.LAN Status
This page shows you LAN
status: IP Address, Subnet
mask, DHCP Server, NAT, and
Firewall.
3.Information
This page shows your router’s
Running Time, Client count,
Firmware Version, LAN MAC
Address, WAN MAC Address.
16
2.7 Wizard
Please refer to 2.5 for Quick

R502 Multifunctional Broadband Router User Guide
Installation Guide 2.5.
2.8 Advanced Config
LAN Settings
This page shows you
the detailed settings for
LAN ports.
1.MAC Address
This is router’s MAC
address that you can not
change.
2.IP Address: 192.168.0.1 is
the Router’s current IP
Address and Factory default IP
Address. You may change it
if necessary.
For example, you can change
the router’s IP address to
192.168.3.1.
Warning: If you change
this IP address, you are
17

R502 Multifunctional Broadband Router User Guide
required to use the new IP
address to log into the WEB
Management Interface so that
you can successfully access to
the Internet. Moreover, the
default gateway of all the
computers under this router is
required to set as this IP
address.
Subnet mask: default value
is 255.255.255.0.
WAN Settings
18
This page shows you the
detailed Settings for WAN.

R502 Multifunctional Broadband Router User Guide
19
You can change the
parameters respectively for
different Access Modes. Taking
ADSL Access mode as
example, we may change
parameters as follows:
MTU
(Maximum
Transmission
Unit）
Service
Some ISPs
need this to
validate
customers’
information.
Connect
Automatically,
Connect after
Start and
Break off.
Connection
mode
Manual
connect,
connect by
user.
