Tenda W307R User manual

BRIEF INTRODUCTION
Up to 300Mbps Uploading and Downloading Speed
Integrates AP, Wireless Router, Switch and Firewall
Bandwidth Control (QoS) over Specific Computer's
Downloading Speed
Easy Setup with Tenda Setup wizard or Simple Web
configuration
PRODUCT FEATURES
Wireless N
W307R Wireless Broadband Router, based on MIMO technology
while backward compatible with wireless b/g, delivers a
maximum speed of up to 300Mbps and extends your wireless
coverage. Integrating wireless router, switch and firewall into one,
it is a total network solution for small offices and families. W307R
upgrades your current network from 54Mbps to 300Mbps,
enabling you to enjoy streaming HD movies, online gaming and
share big files from multiple PCs simultaneously.
Wireless N Technology up to 300Mbps
Wireless-N Broadband Router
6X Speed of Speed of
54Mbps Wireless Router 54Mbps Wireless Router
Model No.:W307R
4
A
F
T
.
R
0
D
All For Better NetworkAll For Better Network
All For Better NetworkAll For Better Network
Greater Coverage around
Your Home or Office WPS for Simply Network Security

WHAT THIS PRODUCT DOES
BENEFITS
TECHNICAL SPECIFICATIONS
Create a high speed network for family entertainment
purposes like streaming video and online gaming,
or for small offices conducting essential business
activities.
Latest MIMO technology delivers 6 times faster
than 54Mbps
Maximum speed of up to 300Mbps guarantees
streaming video and online gaming
Simple advanced network security by WPS, WPA
and WPA2
WISP to amplify wireless coverage
IEEE 802.3, IEEE 802.3u, IEEE802.11b, IEEE802.11g, IEEE802.11n
Up to 300Mbps
Reset, WPS
2.4-2.5GHz
AC 9V,1.2A
0 to 40ºC
10% ~ 90% RH non-condensing
-40 to 70ºC
160mmX102mmX30mm (6.3"X4.0"X1.2")
0.99Kg
All For Better NetworkAll For Better Network
All For Better NetworkAll For Better Network
Shenzhen Tenda Technology Co., Ltd.
Contact us
Address:Tenda Industrial Park, No. 34-1, Shilong Rd.,Shiyan Town,
Bao’an District, Shenzhen, P.R. China 518108
Tel: [phone] Fax: [phone]
E-mail: [email protected] Http: www.tenda.cn
Copyright statement
Obligation-free statement
Dynamic IP, Static IP, PPPoE, PPTP, L2TP
64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK
2 External Non-detachable antennas (3dBi)
1 Power Port,1 WAN port, 4 LAN Ports
PACKAGE CONTENTS
W307R Wireless-N Broadband Router
Power Adapter
Quick Installation Guide
CD-ROM (User Guide included)
MINIMUM REQUIREMENTS
Internet Explorer 5.5 or Firefox 1.0 Higher
Network Adapter
CD-ROM Drive
Standards Standards
Max.Wireless SpeedMax.Wireless Speed
InterfaceInterface
ButtonsButtons
FrequencyFrequency
Power RatingPower Rating
Operating TemperatureOperating Temperature
Operating HumidityOperating Humidity
Storage TemperatureStorage Temperature
Storage HumidityStorage Humidity
Dimension (WXDXH)Dimension (WXDXH)
Gross WeightGross Weight
Connection typeConnection type
Encryption modeEncryption mode
AntennaAntenna
CertificateCertificate CE, RoHS
Wireless NTenda is the registered trademark of Shenzhen Tenda
Technology Co. LTD in CHINA and certain other countries.
Copyright © 2007 Shenzhen Tenda Technology Co. LTD
All rights reserved. Other brands and product name
are trademarks or registered trademarks of their
respective holders.
The maximum performance for wireless is derived from IEEE Standard 802.11 specifications. Actual
performance can vary, including lowe r wireless netwo rk capacity, data throughput rate, range and
cove rage. Performance depends on many factors, c onditions and va riables, including distance f rom
the access point, volume of netwo rk traffic, building materials and construction, operating system
used, mix of wireless products used, interference and other adverse conditions.
Check the product package and contents for specific features supported. S pecifications are subjec t to
change without notice.
Model No.:W307R
5% ~ 90% RH non-condensing
11N Wireless
USB Adapter
11N Wireless
PCI Adapter
11N Wireless
Notebook Adapter
Ethernet Switch
Computer
W322PV2.0W322PV2.0
W322U
